MuxLab 500453 User manual

© MuxLab Inc. 94-000729-A SE-000729-A
8495 Dalton Road, Mount Royal, Quebec, Canada. H4T 1V5
Tel: [phone] Fax: [phone]
Toll Free (North America): [phone]
E-mail: [email protected] URL: www.muxlab.com
Specifications
Environment HDMI 1.3a (Supports the 3D feature of HDMI 1.4)
Devices DVD, plasma, projectors, monitors, TV, PC, laptops, servers supporting
HDMI.
Transmission Transparent to the user
Bandwidth 340 MHz
Signals HDMI 1.3a protocol
Connectors One (1) HDMI receptacle.
One (1) RJ45S for Cat 5e/6 unshielded or shielded twisted pair.
Two (2) RJ45S for LAN (10/100BaseT) connection.
Two (2) 3.5mm jacks for IR emitter and sensor.
Note: HDMI cables not included.
Maximum Distance
Based on a maximum
length of 6.6 ft (2 m) of
HDMI cable per end.
480i/p: Cat 5e/6: 330 ft (100 m)
720p, 1080i: Cat 5e/6: 330 ft (100 m)
1080p: Cat 5e/6: 330 ft (100 m)
1080p Deep Color: Cat 5e/6: 330 ft (100 m)
Note: When installed in an electrically noisy environment, an STP cable
must be used. Also, cross-connection reduces the effective distance
depending on the grade of twisted cable used.
RJ45 Pin Configuration
Reverse Polarity
Sensitive. Use EIA/TIA
568A or 586B straight-
through wiring.
RJ45 Link
Pin 1 (R) Pin 2 (T)
Pin 3 (R) Pin 6 (T)
Pin 4 (R) Pin 5 (T)
Pin 7 (R) Pin 8 (T)
Cable One (1) Cat 5e/6 or better twisted pair cables required
Power Supply Two (2) 110-240V/5VDC power supplies with interchangeable blades
Power Consumption Transmitter: 2.75 Watt Receiver: 5.15 Watt
Temperature Operating: 0° to 40°C Storage: -20° to 85°C
Humidity: Up to 95% non-condensing
Enclosure Metal
Dimensions 4.40” x 3.00” x 1.00” (11.2 x 7.6 x 2.5 cm)
Weight 1.4 lb (.6 kg)
Compliance Regulatory: FCC, CE, RoHS Flammability: 94V0
Warranty 2 years
Order Information 500453 HDMI / LAN Mono Extender Kit
HDMI / LAN Mono Extender Kit
500453
Quick Installation Guide
Overview
The HDMI / LAN Mono Extender Kit (500453) allows HDMI equipment to be
connected up to 330 ft (100 m) @ 1080p Deep Color via one (1) Cat 5e/6 unshielded
twisted pair cables in a point-to-point configuration. The product also features two
LAN ports for interconnecting Ethernet equipment via the same Cat5e/6 cable. The kit
comes with one (1) Transmitter and one (1) Receiver as well as an IR Emitter (500998)
and IR Sensor (500999) for remote control applications.
Applications
Applications include commercial and residential AV systems, classroom projector
systems, digital signage, boardroom systems, collaborative PC systems, and medical
information systems.
Installation
1. Identify the connectors on the Transmitter and Receiver as indicated on the product labels.

© MuxLab Inc. 2012
2. Verify that the distance between the HDMI Transmitter and Receiver is within MuxLab
specifications (see Specifications table).
3. To install the Transmitter:
3a. Connect the Transmitter to the HDMI video source with an HDMI compliant cable.
3b. Connect one (1) lengths of Cat 5e/6 (or higher) grade UTP cables to
RJ45 LINK connectors on the Transmitter.
4. To install the Receiver:
4a. Connect the Receiver to the HDMI display equipment with an HDMI compliant cable.
4b. Connect the one (1) Cat 5e/6 cables to RJ45 LINK connectors on the Receiver.
5. Connect the 12 VDC power supply to the Receiver first, and then plug the power supply into
an AC power outlet. Connect the 12 VDC power supply to the Transmitter first, and then plug
the power supply into an AC power outlet. If power is present, the green power LED of the
Transmitter and the Receiver will be ON.
Note: Power the HDMI/LAN Mono Extender only after all connections are made.
6. Power the HDMI equipment and verify the image quality.
7. This product support bidirectional IR control. If infrared remote control is needed
to control the Source equipment from the Display, connect the IR Sensor to the 3.5mm Stereo
Jack of the receiver and the IR Emitter to the 3.5mm Mono Jack of the Transmitter.
Note: You can differentiate the IR Sensor and the IR Emitter by looking at the 3.5 mm
plug. The IR Sensor is using a Stereo Plug (3 Contacts) and the IR Emitter a
mono plug (2 Contacts).
8. Position the IR Sensor so that it is directed to the hand-held remote control. For a clear IR
signal reception, aim the hand-held remote control to the top of the IR Sensor enclosure.
9. Position the IR Emitter as close as possible to the source’s IR Sensor (i.e. DVD player). For a
clear IR signal reception, the IR Emitter can be glued on the source’s IR Sensor. The IR
Emitter’s signal is transmitted from the side of the enclosure.
10. If infrared remote control is needed to control the Display equipment from the Source,
connect the IR Emitter to the 3.5mm Stereo Jack of the receiver and the IR Sensor to the
3.5mm Mono Jack of the Transmitter.
11. If an Ethernet 10/100 LAN connection is required, connect Cat5e/6 jumper cables between the
LAN equipment and the RJ45 LAN connectors on the Transmitter and Receiver.
12. The following diagram shows the final configuration.
Troubleshooting
The following table describes some of the symptoms, probable causes and possible solutions
in respect to the installation of the HDMI/LAN Mono Extender Kit:
Tx LEDs Rx LEDs
Symptom Power HDMI RJ45 Power HDMI RJ45
Probable
Cause
Possible
Solutions
No Image OFF OFF OFF OFF OFF OFF No power • Check power
connections
No Image ON OFF OFF ON OFF OFF UTP Cable • Check the UTP
cables.
No Image ON OFF ON ON OFF ON HDMI Cable • Check the HDMI
Cable.
NoImage ONONONONONONSynchronization • Check cable length.
Flickering
ON ON ON ON ON ON Synchronization • Check cable length
• Check the HDMI
Cable Quality.
Choppy sound ON ON ON ON ON ON Synchronization • Check cable length
• Check the HDMI
Cable Quality.
Green or pink
hue
ON ON ON ON ON ON DDC
communication
• Cycle power of the
HDMI Extender.
• Check UTP cables
and replace.
Image flickers
when powering
up nearby
equipment
ON ON ON ON ON ON Interference • Use STP cables
IR not
functioning
ON ON ON ON ON ON Remote control
not directed to
the IR Sensor or
IR Emitter not
directed to the
source.
• Make sure the IR
Sensor is directed
towards the remote
and the IR Emitter
to the equipment
IR not
functioning
ON ON ON ON ON ON Interference
from sunlight,
Fluorescent,
Neon or
Halogen lights
• Place the IR
equipment away for
the interfering light
IR not
functioning
ON OFF OFF ON OFF OFF Interference
from RF
radiation from
the TV
• Place the IR
equipment away for
the RF radiation
If you still cannot diagnose the problem, please call MuxLab Customer Technical Support at
877-689-5228 (toll-free in North America) or ([phone] (International).
