MyWam Mouse User manual

Mouse –a modern stroller for the
youngest
Operation and maintenance
manual

2
Contents: page:
1. The Purpose of the Stroller Mouse 3
2. Important safety rules and instruction 3
3. Intention of the manual 7
4. Construction of the stroller 7
5. Accessories 9
6. Anti-Corrosion Protection 10
7. Reuse of the Stroller 11
8. The manual 11
9. The Usage of the Stroller 24
10. Cleaning and Maintenance 25
11. Periodical maintenance checks 26
12. The Stroller’s Technical Data __________________ 28
13. Table of parameters__________________________ 29
14. Utilization and recycling __________________ 29
15. Notes 29
16. The Manufacturer 30
17. Declaration of CE Manufacturer’s Conformity 31
18. Warranty Card 32
CAUTION! Before the stroller is used, the user is obliged to read
the instructions carefully and follow them closely

3
1. The Purpose of the Stroller Mouse
The specialistic Stroller Mouse was designed for children who suffer from
neurological and orthopedic problems, which make it hard or impossible for
them to move independently. The stroller is equipped with adjustments
which make it possible to safely and comfortably adapt it to the child’s
individual needs.
The stroller Mouse is for users who are 70-110 cm hight and weigh up to 35
kg.
Statistically, children from the age of 2 to 6 fit these specifications.
While choosing the stroller it is most important, however, to consider the
individual physical features of the child as well as his/her disability.
Follow the instructions of the specialist while using the stroller.
The risk associated with the use of the stroller was described in detail in
point 2: “Important Safety Rules.”
1.1. The Range of the Stroller’s Use
The stroller is suitable for use both inside (house, apartments and health
centres) and outside on hard and smooth surfaces.
2. Important Safety Rules
2.1. CAUTION! Before you use the stroller, make sure that it has been assembled
properly, and all the mechanisms, fixing elements and fastenings have been
carefully assembled, locked and prepared for use. Pay particular attention
to the frame folding mechanism as well as backrest assembly and proper
installation of all four wheels.
2.2. CAUTION! Never leave your child unattended in the stroller
2.3. CAUTION! Failure to follow the instructions, particularly those concerning
the movable parts of the stroller may be dangerous for the user. Always
read the manual before using the stroller.
2.4. CAUTION! To avoid injuries, keep your child in a safe distance from the
stroller while folding or unfolding the product.
2.5. CAUTION! Always use restraint systems for the carried children. These
include: five-point belts, wedge, groin straps, chest and loin pads, head
supports, footrest, footrest straps, safety barrier or tray.
2.6. CAUTION! The stroller must be completely assembled before use. In case of
any problems at this point, please contact the Seller and Manufacturer.
2.7. CAUTION! The product is not suitable for running or skating.
2.8. The stroller should be cleaned and maintained regularly. No abrasive
materials should be used for cleaning.
2.9. The product contains small parts, which may be dangerous if swallowed by
children.

4
2.10. DO NOT use the stroller if it was damaged or if you suspect it was damaged
or if it does not work properly. Contact the Seller and Manufacturer
promptly to get advice.
2.11. Make sure you use only the original stroller accessories.
2.12. The brake must be locked while taking the child in and out of the stroller.
2.13. All additional bags or parcels may influence the stroller’s stability.
2.14. All adjustments should be performed under the supervision and care of a
doctor or a physical therapist.
2.15. Only the spare parts provided or approved by the Manufacturer can be used
in the stroller.
2.16. Any repairs which are not performed by the authorised Manufacturer's
service team, result in the loss of warranty. The Manufacturer is not
responsible for any bodily injuries or product damages resulting from the
repairs performed by persons other than the authorised Manufacturer's
service team.
2.17. The manufacturer is responsible for the proper functioning of the stroller
only if the stroller was bought in a specialist medical store
2.18. CAUTION! Before the stroller is used, the user is obliged to read
the instructions carefully and follow them closely.
2.19. Before each use:
2.19.1. Check the stroller for any visible signs of damage or other defects that
may put your child in danger.
2.19.2. Check for the appropriate wheel pressure.
2.19.3. Check if the break works properly.
2.19.4. Check for the condition of tire treads.
2.19.5. Check if the wheels have been assembled properly.
2.19.6. Check if the stroller’s frame has been folded properly. The frame
should be locked securely.
2.19.7. Check if the seat has been assembled properly and attached to the
stroller’s frame.
2.19.8. Adjust the stroller’s accessories and equipment to the size and needs
of the child, e.g., adjust the angle of the seat, the backrest and the
footrest, as well as the length of the 5-point belt.
2.19.9. After placing your child in the stroller, mount the safety barrier .
2.19.10. Secure your child using all the available restraint systems such as: 5-
point belts, wedge, chest pads, head supports, footrest, safety barrier.
Their aim is to prevent your child from falling or sliding out of the

5
stroller. They are also to prevent your child’s feet from sliding off the
footrest.
2.20. The stroller CANNOT be used for a purpose other than intended.
2.21. Never leave your child unattended in the stroller, especially on a hilly
surface.
2.22. Never use the stroller while ascending or descending stairs, no matter if the
child is in or out of the stroller.
2.23. Neither the child or any other person is allowed to stand on the footrest
while getting in or out of the stroller.
2.24. It is not allowed to carry a child in the stroller while using any form of
transportation such as a car, a bus or a train.
2.25. Do not use the stroller’s seat as a car seat.
2.26. 2.27. The stroller’s brake must be locked while taking the child in and out of
the stroller.
2.27. The maximum weight for the bag placed on the handle bar is 2 kg.
2.28. Make sure your child’s limbs do not get in the wheel spokes or other parts of
the stroller while using it.
2.29. Be especially careful while using the stroller on an uneven or hilly surface, as
its center of gravity is likely to shift.
2.30. While transporting the stroller e.g., by car, by bus or train, the child MUST be
removed from the stroller. The stroller needs to be adequately protected
from damage during transportation. The Manufacturer CANNOT be held
responsible for any damage resulting from improper protection of the
stroller during transport.
2.31. Never leave your child in the stroller while lifting it or carrying it.
2.32. While lifting and carrying the stroller, you need to hold it by the frame or
other fixed elements. When folded, the stroller has a special handle that
enables easy lifting and carrying. Hold the seat exclusively by the fixed
elements of the stroller.
2.33. The child’s maximum allowed weight is 30 kg. The maximum weight of the
storage bag is 2 kg. The maximum load for the anti-slip therapeutic tray is 3
kg. The maximum load for the shopping basket is 3 kg.
2.34. CAUTION! Both prior to and during use of the stroller, read the
manual instructions and safety rules carefully and follow them
closely.
2.35. CAUTION! You need to exert CAUTION when using, maintaining or
folding the stroller due to the fact that the dimensions of the fixed and
moveable slots and holes may pose some danger.
2.36. CAUTION! The upholstery must be dry while using the stroller

6
2.37. CAUTION! The Manufacturer is ONLY responsible for the defects
and technical damage resulting from the use of the stroller that is in strict
compliance with the instructions and safety rules specified in this
manual.
2.38. CAUTION! When reclining the seat, you need to adjust the length of
the 5-point belt each time.
2.39. CAUTION! Never leave your child in the stroller while making any
alterations, modifications or adjustments. Failing to follow this
instruction may result in serious danger to the child or others.
2.40. CAUTION! When reclining the seat, the stroller’s center of gravity
shifts, which may result in instability
There is a risk of confining and/or squeezing the user of the stroller or the
accompanying person while using or adjusting the stroller.You need to
adjust the stroller with utmost care. After adjusting the stroller, you need
to stabilize the stroller by carefully tightening the knobs/screws.When
adjusting the stroller, the child must be removed from the stroller!

7
3. Intention of the manual
The manual contains basic information about the proper use of the Mouse stroller, its
assembly, maintenance and cleaning and warranty conditions.
Please keep the manual in an easily accessible place. The manual is intended for the
caregivers of special needs children, as well as the doctors and physical therapists
who will use the stroller.
IMPORTANT! Keep the manual for future reference.
4. Construction of the stroller
4.1. General Parts List
Fig.. 4.1.

8
4.2. The steal frame (Fig.4.1. ) with aluminium elements
includes:
4.2.1. Adjustable, ergonomic handlebar (Fig.4.1.-nr 2)
4.2.2. Front swivel wheels (Fig.4.1.-nr12)
4.2.3. Front wheel direction lock (Fig.4.1.-nr15)
4.2.4. Front wheel fork shock absorption system (Fig.4.1.-nr14)
4.2.5. Front wheel folding system (Fig.4.1.-nr13)
4.2.6. Rear wheels (Fig.4.1.-nr 8)
4.2.7. 2-step rear wheel shock absorption system (Fig.4.1.-nr24)
4.2.8. Rear wheel folding (Fig.4.1.-nr23)
4.2.9. Central breake (Fig.4.1.-nr 9)
4.2.10. Shopping basket (Fig.4.1.-nr11)
4.2.11. hooks fixing seat to frame (Fig.4.1.-nr 6)
4.2.12. Transport lock (Fig.4.1.-nr 3)
4.2.13. Frame folding mechanism (upper and lower) (Fig.4.1.-nr 4)
4.3. rtyfrtuyrt
4.3.1. Reclining seat includes:
4.3.2. The seat is made of synthetic material
4.3.3. Side pad / reducer (Fig.4.1.-nr18)
4.3.4. Adjustable backrest (Fig.4.1.-nr5)
4.3.5. Safety barrier fixing (Fig.4.1.-nr7)
4.3.6. Safety barrier (Fig.4.1.-nr19)
4.3.7. 5-point safty belts (Fig.4.1.-nr20)
4.3.8. Wedge (Fig.4.1.-nr17)
4.3.9. Adjustable head pads (Fig.4.1.-nr21)
4.3.10. Adjustable canopy with window (Fig.4.1.-nr1)
4.3.11. Adjustable and folding footrest (Fig.4.1.-nr16)
4.3.12. footrest extension (Fig.4.1.–nr22)
4.3.13. Optional inclination bar (Fig.4.1.-nr10)

9
5. Accessories
Mouse stroller offers a wide range of accessories.
5.1. The standard accessories on the stroller’s frame include:
Figure 5.1.1. Figure 5.1.2
The central brake Shopping basket
(Fastened under the seat)
5.2. The standard seat accessories include
Figure 5.2.1. Figure 5.2.2
Safety barrier 5-points safty belt
Figure 5.2.3. Figure 5.2.4.
Wedge Head pads with adjustment

10
Figure 5.2.5. Figure 5.2.6.
Adjustable canopy with window Adjustable and folding footrest
Figure 5.2.7
Side pads- reducer
6. Anti-corrosion Protection
In order to avoid damage resulting from corrosion, the stroller shouldn’t be
used or kept in wet or damp spaces. If the stroller has been soaked in water,
it needs to be dried with a soft cloth and treated by a preservative that has
light oil basis. The stroller is made with high quality shell.
If the enamel has been damaged, you need to protect it with the lacquer
recommended by our firm. Regular cleaning and maintenance using light oil
ensures long and hassle-free use of the stroller.

11
7. The Reuse of the stroller
The product is suitable for reuse. All products that are reused may change
their usability due to change in their specifications and performance
characteristics and, therefore, need to be checked for efficacy. The safety of
the persons using the stroller as well as the accompanying people may be
endangered in such circumstances. When maintained properly, the product
keeps its quality for about three years. To reuse the stroller you need to
dismantle all upholstered parts and exchange them for the new ones.
The stroller’s frame, the wheels and the handles need to be cleaned and
disinfected with available cleaning agents. The stroller needs to be
subsequently examined by an authorized specialist as to wear and tear as
well as damage.
All parts that are mismatched or unsuitable for use need to be replaced.
Only then the stroller can be reused.
The maintenance plan and information about the parts and tools are
contained in part 11: “ The periodical maintenance.”
8. The manual
8.1. Stroller assembly
8.1.1. Unfolding the stroller’s frame
To unfold the stroller, release the transport lock and pull up the handle bar
until you hear a “click”. It may be necessary to push down the ‘expanding’
points behind the backrest and the footrest until they are blocked.
Figure 8.1.1.a. Figure 8.1.1.b.
8.1.2. Front wheel assembly.
To attach the wheels, insert the wheel axle into the folding system slot until
you hear a ‘click’. The audible clicking sound is the indication that the
assembly has been done properly.

12
8.1.3. Rear wheel assembly
To attach the rear wheels, press the button in the middle of the wheels.
Attach both wheels, by inserting the wheel axles into the folding system
slot. You need to hear the
‘click’.
Figure 8.1.2. Figure 8.1.3.
8.1.4. Seat assembly
The seat can face the front or the back. For assembly the seat, put 4 male
hooks of the seat into 4 female hooks of the frame (Fig. 8.1.4) . Press until
you hear a ’click’ twice, from left and right side.
Figure 8.1.4.

13
8.2. Dismantling the stroller
8.2.1. Dismantling the seat
To dismantle the seat, press two colorful buttons situated on the lower part
of the stroller’s frame hooks. Next, eject the seat from the all 4 frame hooks
(Fig. 8.1.4 ).
Figure 8.2.1.
8.2.2. Dismantling the rear wheels
To dismantle the rear wheel, press the button in the middle of the wheel
and eject it from the rear wheel folding system slots. Repeat action for
second wheel.
8.2.3. Dismantling the front wheels
Press the button on the front wheel folding system and eject the wheel axle
from the front wheel folding system slot. Repeat action for second wheel.
.
Figure 8.2.2. Figure 8.2.3.

14
8.2.4. jlk
8.2.4.1. Folding the bottom part of the frame
To fold the stroller’s frame, pull up both handles of the bottom frame
folding mechanism. Next, fold the stroller’s frame and lock the transport
block
Figure 8.2.4.1
8.2.4.2. The folding of the upper part of the frame
To fold the stroller’s frame, press the red button on the frame folding
mechanism and simultaneously pull up both handles situated on the upper
part of the frame folding mechanism. Fold the stroller’s frame and lock the
transport lock.
Figure 8.2.4.2

15
8.3. Adjustable, ergonomic handlebar
To change the handle bar’s angle, simultaneously press the two buttons
situated on each side of the handle bar. After the angle has been adjusted,
release the buttons, and the handle bar will stay in this position.
Figure 8.3.
8.4. Front wheel direction lock
To block the front wheels, turn the lock knob left. Turn the lock knob right,
to unlock.
Figure 8.4.

16
8.5. Front wheel forks shock absorption system
The stroller is equipped with the front wheel absorption system that works
automatically. It should not be adjusted.
Figure 8.5.
8.6. Two-step rear wheel shock absorption system
The stroller is equipped with two types of shock absorption system: spring
and strut. In order to change the type of shock absorber, rotate the rear
wheel shock absorption lever at 180 degrees forward or backward.
The lever on both wheels should be adjusted the same way.
Figure 8.6.

17
8.7. The central brake and optional inclination bar
To switch the brake on, press the brake pedal down.
To switch the brake off, pull the brake pedal up. Fig. 8.7.1.
To lift the front wheels, simultaneously press the inclination bar and pull the
handlebar towards you in the same time. Fig. 8.7.2.
Figure 8.7.1 Figure 8.7.2
8.8. Shopping basket (fastened under the seat)
The stroller is equipped with a shopping basket that is fastened to the lower
part of the frame. The basket can hold small, every-day items that are
resistant to shaking, hitting, breaking, wetting, flooding and dirt. The
maximum load that the basket can hold is 5 kg.
Figure 8.8.
8.9. The frame hooks
The four frame hooks, two left and two right, that are attached to the seat
are very important parts of the stroller. They serve the purpose of attaching
the seat to the stroller’s frame. The proper use of the hooks is essential for
the safety of the child as well as that of other people.

18
The detailed description of the proper use of the hooks are found in point
8.1 and 8.2 Make sure there aren’t any cracks and damage in the stroller’s
frame. Also, check if it works properly. Do not use the stroller in case of
any suspicion as to the proper operation of the stroller. Keep the safety of
your child in mind at all times.
During adjustment, make sure that all 4 hooks are properly
mounted !
Figure 8.9.
8.10. The transport lock.
The stroller is equipped with the transport lock that prevents the frame
from unfolding on its own during travel. You need to put the transport lock
on after folding the frame and take it off before unfolding it. Do not unfold
the stroller’s frame when the lock is on as you can break it.
8.11. The transport handle
The transport handle is located under the shopping basket.
Figure 8.10. Figure 8.11.

19
8.12. The frame folding mechanism
The four frame folding mechanisms are very important elements of the
stroller. They consist of two bottom mechanisms (big handles) and two top
mechanisms (smaller handles and the red button). Points 8.1. and 8.2.
contain the exact description. Make sure there aren’t any cracks and
damage in the stroller’s frame. Also, check if it works properly.
Do not use the stroller in case of any suspicion as to the proper operation of
the stroller. Keep the safety of your child in mind at all times.
Figure 8.12
8.13. Adjustable seat
The stroller has a seat that can be adjusted to four different positions
including a bassinet position. To change the position, pull back the steel
handle at the back of the seat and slowly change the position of the seat.
After securing the desired position, let go of the handle.
Caution! Each change of the seat position alters the general center of
gravity, which impacts the stability of the stroller.
Caution! Never leave your child in the stroller while making adjustments! It
can put your child in danger.
Figure 8.13

20
8.14. Adjustable backrest
The stroller’s backrest can be adjusted to various positions varying from a
seating position to a lying position. To change the position, move the
backrest towards a seating position first. Then, pull the handle located at the
back of the backrest and change the position slowly. After reaching the
desired position, pull the handle down.
Caution! Each change of the backrest position requires an adjustment of the
5-point belts.
Caution! Never leave your child in the stroller while making adjustments! It
can put your child in danger.
Figure 8.14
8.15. Attaching safety barrier
The attachment tubes are situated at the sides of the seat. They serve the
purpose of attaching the tray or the safety barrier to the seat.
Figure 8.15
