NAIM UNITIQUTE - User manual

All-in-one audio player
NAIM AUDIO LIMITED
Southampton Road • Salisbury • England • SP1 2LN
Tel: [phone] • Fax: [phone]
www.naimaudio.com

It’s a cliché we know, but good things come in small packages. The UnitiQute
all-in-one audio player however isn’t just good: it’s a brilliant-sounding, uniquely
versatile, seductively compact and, of course, irresistibly cute example of what
contemporary music in the home is all about. Music downloads, high-resolution music
files, internet radio, network music, UPnP™ servers, iPod/MP3 players, Wi-Fi streaming
– everything that the new era of music delivery can throw at it, UnitiQute can play.

Just like NaimUniti, its multi-award-winning sibling, UnitiQute is right at the forefront
of modern music delivery technology, and its significance for music enthusiasts of all
aspirations is far greater than the simple sum of its component parts. For the committed
enthusiast with an existing Naim setup, UnitiQute can not only deliver exceptional Naim
music-making as a second system, but also play the role of gateway to all the new
digital music delivery formats - from USB memory sticks, UPnP™ streaming to internet
radio. For the more casual listener, UnitiQute can take the place of both the old hi-fi
system and the iPod dock, sound far better than either, and at the same time introduce
new worlds of audio ripe for exploration.
Music for
everyone
For starters, UnitiQute includes a preamplifier with two analogue inputs, five
24bit/192kHz-capable digital inputs and all the traditional Naim musical clarity and
transparency. Next, UnitiQute includes a muscular power amplifier that provides all the
rhythmic punch and definition you would expect from Naim. You want conventional
radio? Well, UnitiQute includes FM and DAB tuners that get the best possible
performance from either format. UnitiQute is happy also to play music from an iPod
or MP3 player via its front panel-mounted USB socket. The USB audio connection is
digital so iPod sound quality is optimised, and Apple authenticated too so compatibility
is seamless. And the same USB socket can be used to play music files in almost any
format at up to 24bit/96kHz resolution straight from a memory stick. And it doesn’t end
there. A network Ethernet socket and integrated Wi-Fi means that, along with everything
else, UnitiQute can easily tap into Internet radio or UPnP™ servers, a Naim HDX for
example, to drop almost unlimited music choices right into your lap. Talk about cute.
Small box
Big on features
Bringing everything audio, digital and analogue together is one thing, but making it
all work seamlessly together is something else entirely. UnitiQute is controlled by a
dedicated remote handset in combination with a large, clear display. The UnitiQute
user interface borrows the principles of intuition and accessibility, and much of the
substance, from the already proven NaimUniti interface. The interface is clear, intuitive,
uncluttered and makes light work of access to UnitiQute’s remarkable versatility and
performance. And an iPhone/iPod Touch Uniti control App, expected early in 2010 will
enhance the UnitiQute experience still further and raise its brilliance yet another notch.
Then there are the multi-room audio opportunities that UnitiQute opens up. With
a UPnP™ server, a wireless network router and a UnitiQute you have a very high
performance hi-fi system with access to almost limitless music. Add a second,
or even a third UnitiQute and you have a multi-room hi-fi system that installs
effortlessly, is easily modified and sounds outstanding.
Easy access to
your music
connect with your music like never before

Enter the world
of digital music
Streaming
UnitiQute can play audio files at resolutions up to 24bit/96kHz streamed from UPnP™
music servers like the Naim HDX hard disk music player, or from PC or Apple Mac
music libraries. And if you don’t like the idea of running network cables around the
house, don’t worry. UnitiQute can do all this wirelessly.
Multi-format Radio
The UnitiQute multi-format tuner can switch seamlessly between DAB, FM and Internet
radio stations. Favourite stations are listed in a common interface menu for browsing
and selection. An entire world of radio is a few button presses away.
iPod and MP3
Connect an iPod or MP3 player via the UnitiQute USB interface and its audio files and
playlists are listed on the UnitiQute display for simple browsing, selection and playback.
USB-stored Audio
Connect a USB memory stick to the front panel USB socket and the audio files it
contains will be identified by the UnitiQute interface and be immediately available for
browsing, selection and playback. UnitiQute can play USB-stored music files
of up to 24bit/96kHz resolution.
connect with your music like never before

UnitiQute may be compact but it packs some serious audio technology within its elegant
extruded and die-cast enclosure. On the analogue side, the UnitiQute preamplifier module
is a distilled version of that found in its NaimUniti sibling. Similarly, and again, as with the
NaimUniti, the UnitiQute power amplifier borrows its design from the NAIT 5
i , and given
a pair of Naim n-SAT speakers to work with, the music it makes is dynamic, tuneful and
addictive.
UnitiQute digital audio performance profits immeasurably from nearly two decades of
high-end digital audio knowhow and experience at Naim. From the first CD player, the
CDS in 1991, to the stunning DAC digital to analogue converter of 2009, every Naim
digital product has advanced the art of digital audio engineering to the benefit of music
reproduction. UnitiQute is no different. UnitiQute is capable of handling an enormous range
of digital audio formats, and Naim digital audio engineering ensures that each one sounds
as musical and engaging as its inherent potential allows. UnitiQute digital connectivity also
means that as well as offering all-in-one functionality operating as a digital hub for external
digital sources, games consoles or digital TV audio for example, it can also output its
internal sources or external digital signals to an external DAC for even higher audio quality.
Analogue audio connectivity is not forgotten either. Two analogue inputs can accommodate
CD players or portable music players via rear panel phono sockets and a front-panel
mini-jack. And a preamplifier output means that with the addition of an external power
amplifier, or even a subwoofer, UnitiQute can become the heart of a very wide bandwidth
audio system. And when you want to listen privately, a front panel headphone socket
makes such selfishness all too easy.
Your complete
audio system

Specification
AUDIO OUTPUTS
Audio Outputs Speaker output, preamp output (RCA)
Signal-to-Noise Ratio (SN ratio) 80dB
Power Output 45W per channel into 4Ω,
30W per channel in 8Ω
Digital Output BNC 75Ω(plus RCA adapter)
Other Outputs Headphone
INPUTS
Antenna Inputs Wi-Fi, F type, (plus PAL adapter)
Analogue Inputs 3.5mm front-panel socket, 1 RCA
Overload Margin 20dB
Input Sensitivity 270mV at 47KΩ
Digital Inputs 5 S/PDIF (2 optical, 2 coaxial,
1 digital/analogue 3.5mm jack)
USB Inputs 1 front-panel socket
Other Inputs Ethernet and iPod (digital via
USB socket)
CONTROL
IR Input Front panel only
RS232 Yes
Other Front panel logo touch-sensitive
mute function
FORMATS
Audio Files Supported Internet radio (Windows Media-formatted
content, MP3 Streams, MMS)
Playlists (M3U, PLS)
MP3, AAC (up to 320kBit/s, CBR/VBR)
Windows Media-formatted content-9
(up to 320kBit/s)
FLAC and WAV (up to 24bit/96kHz via UPnP™
and USB only)
OGG Vorbis
POWER
Supply Voltage 100V, 115V, 230V; 50/60Hz
Power Consumption 200VA (maximum)
OTHER
Tuning Range FM 87.5 - 108Mhz
DAB Band III and L Band
iRadio Service Provider vTuner 5* full service
Languages English, German, Italian, French,
Spanish, Chinese, Dutch
PHYSICAL
Dimensions 87 x 207 x 314mm (H x W x D)
Weight 5.6Kg
Colour Black
