NANLITE FS-60B User manual

Guangdong NanGuang Photo&Video Systems Co., Ltd
USER MANUAL
FS-60B

1
1
Product Diagram
Technical Data
FS-60B LED Bi-color Spot Light
Rated Power: 70W
Input voltage/current: AC100-240V
50/60Hz
Color Temperature: 2700K-6500K
CRI: Average 96
TLCI: Average 97

2
Product Details
8. LCD display 9. Umbrella hole 10. Lock catch
11. Reflector
12. Angle fixing
knob
13. Yoke
14. Bracket fixing
knob
2. Right knob
3. Left knob
4. MODE button
5. Power socket
6. Power switch
7. USB port
1. Lamp body
handle

3
Detailed Description
1. Lamp body handle: Be convenient for users to lift the lamps and adjust the direction of the light.
2. Right knob: For selecting options and adjusting the color temperature under CCT mode.
3. Left knob: For adjusting the DIM and scrolling through different selections.
4. MODE button: For switching between CCT mode, EFFECT mode and MENU.
5. Power socket: AC power input socket.
6. Power switch: For switching on/off the fixture.
7. USB port: For updating the firmware.
8. LCD display : For displaying the data.
9. Umbrella hole: For installing/removing an umbrella.
10. Lock catch: For installing and disassembling reflector and other accessories.
11. Reflector: For gathering light to improve the central illumination.
12. Angle fixing knob: Allows for adjusting and fixing the direction of light in tilt.
13. Yoke: Designed for connecting the lamp to the light stand and adjusting the direction of light.
14. Bracket fixing knob: For locking the light fixture and stand, and adjusting the horizontal direction of light.

4
Usage
1. Installation of the Reflector
①When installing the reflector, ensure its mounting points align with the slots on the light fixture. When the
mounting points and slots are aligned, push the reflector in place and rotate it in the direction shown on the
light until it clicks into place.
Note: This light is with FM mount, so please use accessories with FM mount. If the accessories with Bowens
mount are needed, please mount after installing the Bowens mount adapter.
②When removing the reflector, push and hold the lock catch and rotate until the reflector is free to be removed
from the fixture.
Lock catch

5
2. Installation of Bowens Mount Adapter
①Adjust the yoke to the top position before
installation.
②When installing the adapter, ensure its mounting
points align with the slots on the light fixture, rotate
it according to the direction shown on the light until
the adapter is put into place.
③Mount the adapter on the light stand. ④Ensure the Bowens mount accessories align with
the slots of the Bowens mount adapter, rotate it
according to the direction shown on the adapter
until the accessories are put into place.

6
3. Installation of an Umbrella
Loosen the angle fixing knob. Put the umbrella into the
umbrella hole.
Tighten the angle fixing knob to
lock the umbrella in place.
⑤When removing the accessory, push and hold the
release button and rotate according to the direction
shown on the adapter until the accessory is free to
be removed from the adapter.
⑥When removing the adapter, push and hold the
release button and rotate according to the direction
shown on the light until the adapter is free to be
removed from the light.

7
4. 2.4G and Bluetooth Remote Control
The FS-60B is able to be remotely controlled by 2.4G remote controller or by NANLINK APP via the WS-TB-1
transmitter box, and has built-in Buletooth.
Note: ①2.4G remote controller and transmitter box are sold separately.
②The fixture supports the 2.4G wireless protocol V1.0 and V2.0. Please set fixture to V2.0 while using
WS-RC-C1 or WS-RC-C2 remote controller. Please set fixture to V1.0 while using other remote controllers.
MENU
BT: RESET
WIRELESS PR : V1.0
MENU
BT: RESET
WIRELESS PR : V2.0
MENU
BT: RESET
WIRELESS PR : V1.0
MODE
Rotate ''Right knob'' to WIRELESS PROTOCOL.
Press MODE button to the interface of MENU.
Rotate ''Left knob'' to select V1.0 or V2.0.
MENU
OUTPUT MODE: MAX
CH: 512
MENU
OUTPUT MODE: MAX
CH: 512

8
2. CCT Mode setting
Press MODE button to CCT mode, rotate "Right knob" to adjust the CCT (CCT range: 2700K…6500K),
rotate "Left knob" to adjust the DIM (DIM range: 000%…100%).
Operating Instructions
1. First ensure that the power switch of the fixture is "off ". Then connect the fixture with power supply and turn on the
Iight, the screen will display all the relevant information for the fixture.
CCT CH: 512
000% 5600K
Press MODE button to CCT mode.
MODE
CCT CH: 512
000% 5600K
CCT CH: 512
000% 5600K
CCT CH: 512
100% 5600K
Rotate "Left knob" to adjust the DIM.
0%
.
.
.
100%

9
3. EFFECT Mode setting
Press MODE button to EFFECT MODE. The FS-60B has built-in effects including CCT LOOP, INT LOOP, FLASH,
PULSE, STORM, TV, PAPARAZZI, CANDLE/FIRE, BAD BULB, FIREWORK, EXPLOSION and WELDING.
Note: ①In effect mode, DIM range is the same as the CCT MODE.
②In effect mode, the color temperature is not synchronized with the color temperature in CCT mode, and the
CCT adjustment range is the same as that in the CCT mode.
③When the fixture function is unlocked, in any modes, press "Left knob" to turn off the light, the brightness
percentage on the screen is 000% in this case. Press again to restore the light to its previous state, and
press continuously to switch between on and off.
Rotate "Right knob" to adjust the CCT.
CCT CH: 512
000% 2700K
CCT CH: 512
100% 6500K
2700K
.
.
.
6500K
Press MODE button to EFFECT mode.
Rotate "Right knob" to FX.
MODE
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP

10
①CCT LOOP
CCT LOOP setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 02S…30S), then
rotate "Left knob" to adjust the value of DIM, CCT and SPD.
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP
Rotate "Left knob" to select the desired effect.
CCT LOOP
.
.
.
WELDING
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP
Rotate "Right knob" to select from DIM, CCT and SPD.
Rotate "Left knob" to adjust the value of DIM, CCT and SPD.
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP
EFFECT CH: 512
DIM: 100%
FX: CCT LOOP
EFFECT CH: 512
DIM: 099%
FX: CCT LOOP

11
③FLASH
FLASH setting: rotate "Right knob" to select from DIM, CCT and INTERVALS (Range: 0.1S…10S),
then rotate "Left knob" to adjust the value of DIM, CCT and INTERVALS.
Rotate "Right knob" to select from DIM, CCT and INTERVALS.
②INT LOOP
INT LOOP setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 02S…30S),
then rotate "Left knob" to adjust the value of DIM, CCT and SPD.
Rotate "Right knob" to select from DIM, CCT and SPD.
EFFECT CH: 512
FX: INT LOOP
DIM: 000% - 100%
EFFECT CH: 512
FX: INT LOOP
DIM: 099% - 100%
Rotate "Left knob" to adjust the value of DIM, CCT and SPD.
EFFECT CH: 512
DIM: 000% - 100%
FX: INT LOOP
EFFECT CH: 512
FX: INT LOOP
DIM: 000% - 100%
EFFECT CH: 512
DIM: 100%
FX: FLASH
EFFECT CH: 512
DIM: 100%
FX: FLASH

12
Rotate "Left knob" to adjust the value of DIM, CCT and INTERVALS.
④PULSE
PULSE setting: rotate "Right knob" to select from DIM, CCT and PULSES/MIN (Range: 001…240),
then rotate "Left knob" to adjust the value of DIM, CCT and PULSES/MIN.
Rotate "Right knob" to select from DIM, CCT and PULSES/MIN.
Rotate "Left knob" to adjust the value of DIM, CCT and PULSES/MIN.
EFFECT CH: 512
DIM: 100%
FX: FLASH
EFFECT CH: 512
DIM: 099%
FX: FLASH
EFFECT CH: 512
DIM: 100%
FX: PULSE
EFFECT CH: 512
DIM: 100%
FX: PULSE
EFFECT CH: 512
DIM: 100%
FX: PULSE
EFFECT CH: 512
DIM: 099%
FX: PULSE

13
⑤STORM
STORM setting: rotate "Right knob" to select from DIM, CCT and INTVL (range: 1s ... 60s) ,
then rotate "Left knob" to adjust the value of DIM, CCT and INTVL.
Rotate "Right knob" to select from DIM, CCT and INTVL.
⑥TV
TV setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100),
then rotate "Left knob" to adjust the value of DIM, CCT and SPD.
Rotate "Right knob" to select from DIM, CCT and SPD.
Rotate "Left knob" to adjust the value of DIM, CCT and INTVL.
EFFECT CH: 512
DIM: 100%
FX: STORM
EFFECT CH: 512
DIM: 100%
FX: STORM
EFFECT CH: 512
DIM: 100%
FX: STORM
EFFECT CH: 512
DIM: 099%
FX: STORM
EFFECT CH: 512
DIM: 000% - 100%
FX: TV
EFFECT CH: 512
FX: TV
DIM: 000% - 100%

14
EFFECT CH: 512
FX: TV
DIM: 000% - 100%
EFFECT CH: 512
FX: TV
DIM: 099% - 100%
Rotate "Left knob" to adjust the value of DIM, CCT and SPD.
⑦PAPARAZZI
PAPARAZZI setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100),
then rotate "Left knob" to adjust the value of DIM, CCT and SPD.
Rotate "Right knob" to select from DIM, CCT and SPD.
Rotate "Left knob" to adjust the value of DIM, CCT and SPD.
EFFECT CH: 512
DIM: 100%
FX: PAPARAZZI
EFFECT CH: 512
DIM: 100%
FX: PAPARAZZI
EFFECT CH: 512
DIM: 100%
FX: PAPARAZZI
EFFECT CH: 512
DIM: 099%
FX: PAPARAZZI

15
EFFECT CH: 512
FX: CANDLE/FIRE
DIM: 000% - 100%
EFFECT CH: 512
FX: CANDLE/FIRE
DIM: 099% - 100%
Rotate "Left knob" to adjust the value of DIM, CCT and SPD.
⑧CANDLE/FIRE
CANDLE/FIRE setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100),
then rotate "Left knob" to adjust the value of DIM, CCT and SPD.
Rotate "Right knob" to select from DIM, CCT and SPD.
⑨BAD BULB
BAD BULB setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100),
then rotate "Left knob" to adjust the value of DIM, CCT and SPD.
Rotate "Right knob" to select from DIM, CCT and SPD.
EFFECT CH: 512
DIM: 000% - 100%
FX: CANDLE/FIRE
EFFECT CH: 512
FX: CANDLE/FIRE
DIM: 000% - 100%
EFFECT CH: 512
DIM: 100%
FX: BAD BULB
EFFECT CH: 512
DIM: 100%
FX: BAD BULB

16
⑩FIREWORK
RIREWORK setting: rotate "Right knob" to select from DIM ,CCT, SPD (Range: 001…100) and
DECAY (Range: 001…100), then rotate "Left knob" to select from DIM ,CCT, SPD and DECAY.
Rotate "Right knob" to select from DIM, CCT, SPD and DECAY.
Rotate "Left knob" to select from DIM, CCT, SPD and DECAY.
Rotate "Left knob" to adjust the value of DIM, CCT and SPD.
EFFECT CH: 512
DIM: 100%
FX: BAD BULB
EFFECT CH: 512
DIM: 099%
FX: BAD BULB
EFFECT CH: 512
DIM: 100%
FX: FIREWORK
EFFECT CH: 512
DIM: 100%
FX: FIREWORK
EFFECT CH: 512
DIM: 100%
FX: FIREWORK
EFFECT CH: 512
DIM: 099%
FX: FIREWORK

17
⑫WELDING
WELDING setting: rotate "Right knob" to select from DIM, CCT, SPD (Range: 001…100) and PAUSE (ON/OFF),
then rotate "Left knob" to adjust the value of DIM, CCT, SPD and PAUSE.
Rotate "Right knob" to select from DIM, CCT, SPD and PAUSE.
⑪EXPLOSION
EXPLOSION setting: rotate "Right knob" to select from DIM, CCT, SPD (Range: 001…100) and
DECAY (Range: 001…100), then rotate "Left knob" to select from DIM ,CCT, SPD and DECAY.
Rotate "Right knob" to select from DIM, CCT, SPD and DECAY.
Rotate "Left knob" to select from DIM ,CCT, SPD and DECAY.
EFFECT CH: 512
DIM: 100%
FX: EXPLOSION
EFFECT CH: 512
DIM: 100%
FX: EXPLOSION
EFFECT CH: 512
DIM: 100%
FX: EXPLOSION
EFFECT CH: 512
DIM: 099%
FX: EXPLOSION
EFFECT CH: 512
DIM: 000% - 100%
FX: WELDING
EFFECT CH: 512
FX: WELDING
DIM: 000% - 100%

18
EFFECT CH: 512
FX: WELDING
DIM: 000% - 100%
EFFECT CH: 512
FX: WELDING
DIM: 099% - 100%
Rotate "Left knob" to adjust the value of DIM, CCT, SPD and PAUSE.
·Special effects may be upgraded based on the firmware update. Please refer to the latest firmware function
description for reference.
MENU
OUTPUT MODE: MAX
CH: 512
MENU
OUTPUT MODE: MAX
CH: 512
MENU
OUTPUT MODE: MAX
CH: 512
MENU
OUTPUT MODE: MAX
CH: 512
4. MENU setting
MODE
Rotate "Right knob" to select from CH, OUTPUT MODE, BLUETOOTH, WIRELESS PROTOCOL, FAN,
FIRMWARE UPDATE, LANGUAGE and VERSION.
Press MODE button to MENU.
①CH
MODE
Press "Right knob" to MENU.

19
MENU
OUTPUT MODE: MAX
CH: 512
MENU
OUTPUT MODE: MAX
CH: 512
MENU
CH: 512
OUTPUT MODE: MAX
MENU
CH: 512
OUTPUT MODE: MAX
MENU
CH: 512
OUTPUT MODE: CONST
MENU
OUTPUT MODE: MAX
CH: 512
MENU
OUTPUT MODE: MAX
CH: 511
Rotate "Left knob" to set the channel.
②OUTPUT MODE
MODE
Rotate "Right knob" to OUTPUT MODE.
Press MODE button to MENU.
Rotate "Left knob" to select MAX or CONSTANT.
