1. Overview
Bed Watcher is a standalone security device which is dedicated for remote presence and motion detection
and vital sign monitoring. Bed Watcher is designed for floor, shelf, wall or ceiling mounting with the help
of the rack with rotating bracket and is capable detecting vital signs at up to 4 meters (13.1 feet) distance.
The device by itself is a radar operating depending on the model either at license free 5.8 GHz ISM or at
license free 6.0 - 8.5 GHz UWB frequency band. The device is faced on Figure 1.
Figure 1. Bed Watcher
2. Features and Functions
Operational range –0.3 … 4.0 m (1.0 … 13.1 ft)
Central frequency –5,800 MHz or 7,200 MHz
Frequency range –150 MHz (5,725 … 5,875 MHz) or 500 MHz (7,000 ... 7,500 MHz)
Antenna pattern –60 degrees
Emission power –0.1 mW
Power –according to IEEE 802.3af PoE standard
Power consumption –less than 400 mA
READY LED (green)
ALARM LED (red)
ETHERNET RJ45 socket for data transmission and power
USB 2.0 type-B socket for firmware update
Dimensions (with no rack) - 155 x 150 x 40 mm
Weight –300 g

NanoPulse, Inc.
Bed Watcher User’s Guide
4
30.06.2016
3. Installation
Bed Watcher device is designed for secure floor, shelf, wall or ceiling mounted using the rack with
rotating bracket shown on Figure 2 which is optionally supplied with the device. The rack can be fastened
with 4 screws to the ceiling or wall. Then, the Bed Watcher may be inserted into or extracted from the
bracket using the frame on its bottom.
Figure 2. Rack with rotating bracket
4. Interfaces and Connectors
The Bed Watcher has limited number of electrical connectors which makes it simple placing the device in
the network. All electrical connectors are located on the top and bottom sides of the device. Thus,
USB 2.0 type-B socket is located on the top side of the device as shown on Figure 3.
USB
Firmware
Update
Port
NANOPULSE INC, .
7.0 - 7.5 zUWB SENSOR GH
Model: -02.00NP BW
S/N: -00027-160101BW
Figure 3. Top side of the Bed Watcher
Pin assignment of the USB 2.0 type-B socket is compliant with USB protocol:
1 - Power +5V
2 - Data-
3 - Data+
4 - Ground
USB 2.0 type-B socket is used for firmware update only. Please read section 7 of this User's Guide for
details about updating the firmware.

NanoPulse, Inc.
Bed Watcher User’s Guide
5
30.06.2016
ETHERNET connector is a RJ45 socket located on the bottom side of the device as shown on Figure 4.
1 8
ETHERNET
Data & PoE 48 V 400 mA Port
Default : 192.168.0.101IP
: 40:D8:55:09:E0: 2MAC 4
READY ALARM
Figure 4. Bottom side of the Bed Watcher
Pin assignment of the RJ45 socket depends on the device network mode. Please see Table 1 below for the
pin assignment description:
Table 1. RJ45 socket pin assignment
Pin
number
at the
socket
10/100 Mbps
mode B,
DC on spares
10/100 Mbps
mode A,
mixed DC & data
1000 Mbps
mode B,
DC & bi-data
1000 Mbps
mode A,
DC & bi-data
Terminal
mode
Data
Power
Data
Power
Data
Power
Data
Power
Data
Power
Pin 1
Rx +
Rx +
DC +
TxRx A +
TxRx A +
DC +
NO 1
Pin 2
Rx −
Rx −
DC +
TxRx A −
TxRx A −
DC +
NO 1
Pin 3
Tx +
Tx +
DC −
TxRx B +
TxRx B +
DC −
NO 2
Pin 4
DC +
TxRx C +
DC +
TxRx C +
DC +
Pin 5
DC +
TxRx C −
DC +
TxRx C −
DC +
Pin 6
Tx −
Tx −
DC −
TxRx B −
TxRx B −
DC −
NO 2
Pin 7
DC −
TxRx D +
DC −
TxRx D +
DC −
Pin 8
DC −
TxRx D −
DC −
TxRx D −
DC −
Tx - data line for transmitting data from the device to the network
Rx - data line for receiving data by the device from the network
TxRx - bidirectional data line
DC+ - positive power line
DC- - common (ground) level line
NO1 - normally opened contact 1
NO2 - normally opened contact 2
5. Operation
5.1. Power Up
Before running the device it is necessary to connect it to the network compliant with IEEE 802.3af
PoE standard. As soon as the device gets power it attempts to get IP address from DHCP server.
READY LED blinks at that time. If DHCP server is not found the device assigns static IP address to
itself. Default static IP address is 192.168.0.101. This address can be changed by the user with
supplied Bed Watcher Test Utility. After the device has its own IP address READY LED becomes
green and the device starts monitoring continuously.
5.2. Turning the Device On and Off
In order to turn the device on and off it is necessary to plug in or plug off UTP cable to the network
compliant with IEEE 802.3af PoE standard. There is no power switch located on the unit.

NanoPulse, Inc.
Bed Watcher User’s Guide
6
30.06.2016
5.3. Status LEDs
There are 2 LEDs showing the device status: READY LED (green) and ALARM LED (red). LEDs
are described in Table 2 below.
Table 2. Status LEDs Description
LED
COLOR
STATUS
READY
Green
Device is powered and IP address is not assigned yet –LED blinks
Device is powered and IP address is assigned –LED is always On
Device is not getting power –LED is always Off
ALARM
Red
Live object is not detected for the last 10+ seconds –LED is always On
Live object is detected for the last 10+ seconds –LED is always Off
5.4. Reading Device Status
Bed Watcher device status can be read via ETHERNET RJ45 socket located on the bottom side of the
device. When STA or AP network mode is enabled the device operates as a TCP/IP server and
responds on requests from client applications according to the data exchange protocol described in a
separate document. When TERMINAL network mode in enabled, the alarm status is signaled by
closing NO1 and NO2 contacts, which remain open at no alarm conditions.
6. Configuration Options
The Bed Watcher has minimum number of parameters that can be configured. Bed Watcher Test utility
for Windows must be used in order to read device settings or program new device settings. Its main
window is shown on Figure 5.
Figure 5. Bed Watcher Test Utility - Main Window

NanoPulse, Inc.
Bed Watcher User’s Guide
7
30.06.2016
Prior using the utility you must connect it to a Bed Watcher device using Connect menu item from Device
menu or corresponding toolbar button. Use Network port and specify IP address of the device. The device
must either have received the IP address from DHCP server in your network or have assigned static IP
address to itself. The default IP address is 192.168.0.101.
If the connection is successful, you will be able to read current device settings by pressing on the screen
buttons. Pressing on the “Get…” buttons does not change settings in the device. Pressing on the “Set…”
buttons makes changes in the device configuration; therefore it must be done with caution.
Below you can read description of the utility buttons:
Get Device ID, Get Device Name, Get Device Class, Get HW Version, Get FW Version - these buttons
let you get information about the device.
It is strongly recommended start communication with the device by pressing on Get Device ID button for
making sure the device responds on the utility requests.
Get Data - this button reads current device status, including collected information about the monitored
object. The following data fields are being read:
Input Voltage, mV - shows the device power status. Input voltage shall not go down below 5400
mV. If it happens there may be an issue in the power circuit and the device must be inspected and
probably repaired. Correct device operation is not guaranteed at the input voltage lower than 5400
mV.
Current Load, mA - shows the device power consumption. It shall not exceed 500 mA. If it
happens there may be an issue in the power circuit and the device must be inspected and probably
repaired. Correct device operation is not guaranteed at the current load greater than 500 mA.
RF Voltage, mV - engineering parameter. Shall be ignored by the user.
MCU Temperature, ºC - shows the processor temperature. MCU temperature shall not exceed
85 ºC. If it happens there may be an issue in the power circuit and the device must be inspected
and probably repaired. Correct device operation is not guaranteed at the MCU temperatures higher
than 85 ºC.
VCO, MHz - engineering parameter. Shall be ignored by the user.
Energy, units - displays level of activity in the monitored premises.
Respiration, bpm - displays calculated breathing rate in breathes per minute. This value is not
accurate though and shall not be considered for decision making.
Pulse, bpm - displays calculated pulse rate in beats per minute. This value is not accurate though
and shall not be considered for decision making.
Alarm Flag - when set indicates no activity in the monitored premises.
Alarm Duration, s. - displays number of seconds passed since the Alarm Flag was set
Presence Flag - when set indicates activity in the monitored premises. Opposite to the Alarm Flag.
Presence Duration, s. - displays number of seconds passed since the Presence Flag was set
Motion Flag - when set indicates strong movement in the monitored premises. Can be set together
with Presence Flag only.
Motion Duration, s. - displays number of seconds passed since the Motion Flag was set
Run Cycle - this button enables the utility reading the data periodically from the Bed Watcher device. The
value on the right side from the button sets the poll period in seconds. The shortest poll period value is
1 second. Each poll is equivalent to the Get Data button tap.
Set UltraScope mode - engineering button. Switches off the device operation until it is rebooted or
controlled by the UltraScope engineering software.

NanoPulse, Inc.
Bed Watcher User’s Guide
8
30.06.2016
Reset Device - forces the device to be rebooted. This button does not help when the device is in
UltraScope mode.
Set Bootloader - forces the device to stop normal operation and enter in bootloader mode for updating the
firmware. Please read section 7 of this User's Guide for details about updating the firmware.
Check FW Update - forces the device to stop normal operation and poll specified IP address for firmware
updates. The utility will offer the user to perform the update when a new firmware file is found.
Get Range - reads maximum device operating range in cm. The device is not capable to detect an object
beyond this range.
Set Range - programs the device maximum operating range in cm. The device is not capable to detect an
object beyond this range. The value is taken from the edit box below the Set Range button.
Operating Range Criteria - selects the criterion which defines operating range. Sensitivity defines the
range for breathing detection. Visibility defines the range for motion detection. Sensitivity range is
always shorter than visibility range.
Get DSP Params - reads the device settings that affect on Alarm, Presence and Motion Flags appearance.
Set DSP Params - programs the device settings that affect on Alarm, Presence and Motion Flags
appearance.
The following DSP Params can be read or programmed:
Sampling Rate, Hz - read-only value - specifies
Noise Threshold, units –specifies sensitivity of the device. The smaller value of the threshold –
the higher sensitivity has the device in terms of live object detection. On the other hand, setting
the threshold too low will make the device over sensitive and the device will be detecting live
objects even in empty premises. Default value is 100 000 energy units.
Motion Threshold, units –specifies device reaction on strong movements. The smaller value of
the threshold –the higher probability that the device sets Motion Flag when the object is detected.
Default value is 10 000 000 000 energy units.
Alarm On Delay, s. –determines degree of confidence for the alarm event. The bigger “Alarm On
Delay” is – the higher confidence of the alarm event. On the other hand, setting “Alarm On
Delay” too big will delay reporting moment about empty premises from the real event further in
time. Default value is 10 seconds.
Alarm Off Delay, s. –reduces probability of false live object detection. The bigger “Alarm Off
Delay” is – the lower probability of the false live object detection. On the other hand, setting
“Alarm Off Delay” too big will delay reporting moment about live object detection from the real
event further in time. Default value is 10 seconds.
Get MAC address - displays MAC address of the device.
Get Country Code - displays country code for Wi-Fi operation. Applicable only to the devices with Wi-Fi
option enabled.
Get Network Mode - displays selected network mode, either AP for Wi-Fi access point or STA for
network station (wired or wireless) or TERMINAL for NO/NC relay contacts.

NanoPulse, Inc.
Bed Watcher User’s Guide
9
30.06.2016
Get SSID - displays selected Wi-Fi network SSID. Applicable only to the devices with Wi-Fi option
enabled.
Get Security Type - displays selected Wi-Fi encryption mode, which is one of OPEN for no encryption,
WEP, WPA or WPA2. Applicable only to the devices with Wi-Fi option enabled.
Get Password - displays current Wi-Fi encryption keyword. Applicable only to the devices with Wi-Fi
option enabled.
Get Default IP Address - displays default IP address which is assigned to the device when DHCP server is
not found in the network.
Get Default IP Mask - displays default IP address mask which is assigned to the device when DHCP
server is not found in the network.
Get Default IP Gate - displays default IP gateway which is assigned to the device when DHCP server is
not found in the network.
Get Default IP Port - displays default IP port which is used by the device for data communication
purpose.
Get Assigned IP Address - displays IP address assigned to the device either by DHCP server or by the
device on its own (the default one).
Get Assigned IP Mask - displays IP address mask assigned to the device either by DHCP server or by the
device on its own (the default one).
Get Assigned IP Gate - displays IP gateway assigned to the device either by DHCP server or by the
device on its own (the default one).
Set Country Code - programs in the device country code for Wi-Fi operation from the dropdown list.
Applicable only to the devices with Wi-Fi option enabled.
Set Network Mode - programs in the device network mode, either AP for Wi-Fi access point or STA for
network station (wired or wireless) or TERMINAL for NO/NC relay contacts, selected from the
dropdown list.
Set SSID - programs in the device Wi-Fi network SSID specified in the edit box. Applicable only to the
devices with Wi-Fi option enabled.
Set Security Type - programs in the device Wi-Fi encryption mode selected from the dropdown list.
Applicable only to the devices with Wi-Fi option enabled.
Set Password - programs in the device Wi-Fi encryption keyword specified in the edit box. Applicable
only to the devices with Wi-Fi option enabled.
Set Default IP Address - programs in the device default IP address which is assigned to the device when
DHCP server is not found in the network.
Set Default IP Mask - programs in the device default IP address mask which is assigned to the device
when DHCP server is not found in the network.

NanoPulse, Inc.
Bed Watcher User’s Guide
10
30.06.2016
Set Default IP Gate - programs in the device default IP gateway which is assigned to the device when
DHCP server is not found in the network.
Set Default IP Port - programs in the device default IP port which is used by the device for data
communication purpose.
7. Firmware Update
Firmware update may be required if an error has been found it the device operation at certain conditions.
For making the firmware update in the device the following sequence must be performed:
1) The device must be switched in the bootloader mode by pressing on the Set Bootloader button in
the Bed Watcher Test Utility.
2) USB cable must be attached to the computer. READY (green) LED shall start blinking fast.
3) Firmware Update Utility for Windows must be run on the computer.
Figure 6. Firmware Uploader - Main Window
4) Search Devices button shall be pressed. When the device is found its name is displayed on the right
side from the Search Devices button. Otherwise no further steps are possible.
5) Firmware File... button shall be pressed for choosing the new firmware file on the local computer. The
file shall be obtained from the device manufacturer or re-seller. Selecting invalid file will make the
firmware update process impossible.
6) Update button shall be pressed. After that the utility will program the content of the selected firmware
file into the device. In case of no errors a message saying about successful operation will be shown.
Otherwise an error message will be displayed describing a possible reason of failure.
7) USB cable must be disconnected from the device
8) The device must be reboot by turning power off and on again.
If there is a failure during the firmware update process and / or no activity performed while the device is
in bootloader mode - the device will return to the normal mode after a 30 seconds timeout. The device
firmware will remain unchanged in this case.
8. Rules of Storage and Operation
The following rules of storage and operation must be strictly followed in order to guarantee proper
operation of the device. Violating these rules may be a reason for device faults and rejection of warranty
services.
The device must be used indoors, within +10C … +40C temperature range, humidity no greater
than 60%.
Power up the device no earlier than in 2 hours after it has been brought from cold or hot
environment conditions outside of the range specified in previous bullet.
Do not plug any cables in USB 2.0 type-B socket. It is designed for firmware updates only.

NanoPulse, Inc.
Bed Watcher User’s Guide
11
30.06.2016
Make sure that your network is compliant with IEEE 802.3af PoE standard prior plugging-in the
device.
9. Contact Information
If you have questions about Bed Watcher operation, problem reports or suggestions for the device or
documentation improvements please contact NanoPulse, Inc. representatives.
NanoPulse, Inc.
1 Krasnoselskiy per., 3 pom. I, of. 75
107140, Moscow,
Russia
Tel.: [phone]
http://www.nanopulse.ru
E-mail: [email protected]
