NAPCO XP-400 Installation manual

Hexadecimal Data Entry
To Enter a hexadecimal digit
enter the following:
A= A1 D= A4
B= A2 E= A5
C= A3 F= A6
Set Key
Press this key before
entering a Program-
ming Block Number.
XP-400 Programming Instructions
®
DEALER PROGRAM MODE -KEYPAD KEY DEFINITION
Note: These Programming Instruction are intended to be used in conjunction with WI854C,
please refer to WI854C for additional information, instructions and definitions.
Exiting Dealer Program Mode
(4) (5) (6) (7)
Dealer Code
Enter B A 8
Enter A 8 +
Default Dealer Code shown in parentheses
(4) (5) (6) (7)
Dealer Code
Blank Key
Press this key to disable all fea-
tures within a LED type Program-
ming Block or to blank out digits in
a Direct Entry type Programming
Block.
1. Remove power from the panel.
2. Remove all wiring from terminal
15 (PGM) and terminal 3.
3. Connect terminal 15 (PGM) to
terminal 3.
4. Apply power to the XP-400 con-
trol panel.
5. After a few seconds the ARMED,
READY and jSYSTEM TROU-
BLE LEDs will flash.
6. The keypad will beep 3 times
indicating the panel default val-
ues have been loaded.
7. Remove wiring between terminal
15 (PGM) and terminal 3.
8. Re-install original wiring for ter-
minal 15 (PGM) and terminal 3.
Note: Any programming in
Dealer Options 1 [96] and Dealer
Options 2 [97] will not be de-
faulted. If Dealer Code Lockout
has been programmed the panel
will not default the Dealer Code.
DEFAULTING THE PANEL
ARMED
READY
SYSTEMjj
FIRE
AC
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
NAPCO
1 2 3
4 5 6
7 8 9
A 0 B
CD
K F G
K F G
Scroll Key
Use this key to scroll
through data that has been
entered in Programming
Blocks.
Entering Dealer Program Mode READY
ARMED ON
OFF
FLASHING
Indicates the panel is in Dealer
Program Mode. The panel is
ready for a programming block
number to be entered.
SYSTEM
ü
READY
ARMED FLASHING
FLASHING
FLASHING
Indicates the panel is
Ready to exit Dealer
Program Mode. Enter
the Dealer Code to exit.
SYSTEM
ü
Entering Dealer Program Mode is not permitted while the panel
is Armed, Reporting, or the Bell Output is on. To Enter Dealer
Mode while the Bell is ON or the panel is Reporting or Armed;
power up the panel and enter Dealer Mode within the first 3
minutes. Pressing the bkey clears the 3 minute timer.
NOTE:
After 15 minutes of keypad inactivity the keypad
will emit a steady tone indicating the panel has been
left in Dealer Program Mode. Enter Dealer Code to
exit or press the Bkey to return to Dealer
NOTE:
WI854C 8/97
Wi854c.pub
page 1 Thursday, December 18, 1997 18:43

2
Types of Programming Blocks
LED Programming Block
Enable features by pressing the key that corresponds to the associated feature; the LED will turn ON. To disable a feature press the key again;
the LED will turn OFF. To disable all features within a LED Type Programming Block press the Dkey; all LEDs will turn OFF.
LED Programming Block Example
Program zones 2 and 3 as Follower Zones.
1. Enter Programming Block 02, by pressing
B(Beep), then 02 (Beep).
2. Press the 2key to select zone 2.
3. Press the 3key to select zone 3.
Zone 2 and Zone 3
LEDs are ON indi-
cating that zones 2
and 3 have been
programmed as fol-
lower zones.
1LED Type
Programming
Block
Direct Entry Programming Example 2
(Hexadecimal data entry)
Program Telephone Prefix Number with a 9E.
1. Press B(Beep) 44 (Beep).
2. Press 9
3. Press A
4. Press 5
2
Direct Entry Programming Block
Enter data directly. For hexadecimal entries of A-F, use the Akey + 1through 6keys, respectively. Use the D
key to blank out digits in Direct Entry type programming blocks. Default values are shown in parentheses.
Direct Entry Programming Example 1
Program the panel for a 60 second Exit Delay.
1. Press B(Beep) 10 (Beep)
2. Press 060.
1
060Exit Delay, seconds
(0) (4) (5) Maximum Entry 255
10 Exit Delay
9E
44 Dialing Prefix
Direct Entry
Type
Programming
Blocks
02 Exit/Entry Follower
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF Ð
Ð
ZONE 1
ZONE 2
ZONE 3
ZONE 4
READY
ARMED OFF
FLASHING
FLASHINGSYSTEM
ü
Indicates the panel is in
Dealer Program Mode and
the next digit entered will be
interpreted as a Hexadeci-
mal digit. Valid entries are
1-6 (A-F).
Wi854c.pub
page 2 Thursday, December 18, 1997 18:43

3
Viewing Data in Programming Blocks
To view data within a programming Block, enter the Program Block Number, then press the Ckey, continue pressing the Ckey until all digits within the Pro-
gramming Block have been viewed. Data will be displayed in the binary format shown in the table below:
ZONE LED ON ZONE LED OFF
0/Blank 1 2 3 4 5 6 7 8 9 *A/0 BC D EF
ZONE 1
ZONE 2
ZONE 3
ZONE 4
For Technical As-
sistance, Contact
the Napco Toll
Free Helpline (
[phone]
*In the following Program-
ming Blocks, data that has
been entered as a ‘0’ will
be displayed as an ‘A’:
Subscriber ID Numbers,
Phone Numbers, Pager
Leading and Trailing digits
and Report Codes.
NOTE:
Example: Viewing the Dialing Prefix
A Dialing Prefix of 9E has been programmed at Programming Block Number
44 (outside access number). Follow the steps below to view the data.:
Press B44 to enter Programming Block 44. The 1st
digit of Programming Block 44 is displayed.
1
Press the Bkey to view the 2nd digit.
2
9E
44 Dialing Prefix The Following Program-
ming Options are not
permitted for UL installa-
tions: [05], [06], [23-2],
[26-4] and [26-4].
The symbol by a
programming Block indi-
cates the programming
option is not permitted
for UL installations.
NOTE:
UL
For information about
programming blocks re-
fer to XP-600 Installation
Manual WI854C.
NOTE:
ZONE 3
ZONE 1
ZONE 2
ZONE 4
Data = 9
ZONE 3
ZONE 1
ZONE 2
ZONE 4
Data = E
Wi854c.pub
page 3 Thursday, December 18, 1997 18:43

4
Zone Features
UL
Default
OFF
OFF
ON
OFF
00 Exit/Entry Zones
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
01 Home/Away with Delay Zones
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
02 Exit/Entry Follower Zones
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
03 Auto Bypass Reentry Zones
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
04 24 Hour Protection Zones
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
05 40 ms Loop Response Zones
Zone 1
Zone 2
Zone 3
Zone 4
Default
ON
ON
ON
ON
07 Burg (Steady) Output
Zone 1
Zone 2
Zone 3
Zone 4
Default
ON
ON
ON
ON
08 Programmable Output (PGM)
Zone 1
Zone 2
Zone 3
Zone 4
UL
Default
OFF
OFF
OFF
OFF
06 Open Circuit Zones
Zone 1
Zone 2
Zone 3
Zone 4
See wiring
diagram for
Open Circuit
wiring.
Wi854c.pub
page 4 Thursday, December 18, 1997 18:43

5
Zn 1 LED ON = Momentary Keyswitch Arming
System Times
Entry Delay, seconds
(0) (3) (0) Maximum Entry 255
11 Entry Delay
Exit Delay, seconds
(0) (4) (5) Maximum Entry 255
10 Exit Delay
Bell Time-out, minutes
(0) (0) (5) Maximum Entry 255
12 Burg (Steady) Output Time-out
13 Reserved
Test Timer, days
(0) (0) (1) Maximum Entry 255
14 Test Timer Interval
Line Cut Time-to-Fail, seconds
(0) (0) (0) Enable Feature-Valid Entries 10-255
15 Line Cut Time-to-Fail (Disabled = 000)
Supervisory Timer, hours
(1) (2) Maximum Entry 26
16 Wireless Supervisory Timer
System Features
UL
Default
OFF
OFF
OFF
OFF
23 Programmable Output (PGM) Features 1
Zn 1 LED ON = Audio Verification
Zn 2 LED ON = *Access Output (A 3)
Zn 3 LED ON = *Follow Keypad Sounder
Zn 4 LED ON = *Keyfob/Keyswitch Chirp
*See Note 2
Default
OFF
OFF
OFF
OFF
24 Programmable Output (PGM) Features 2
Zn 1 LED ON = Reserved
Zn 2 LED ON = AUX
Zn 3 LED ON = Panic
Zn 4 LED ON = Test Timer
Default
OFF
OFF
OFF
OFF
26 Miscellaneous Features 2
Zn 2 LED ON = Reserved
Zn 3 LED ON = Inhibit Fail to Communicate
Zn 4 LED ON = Inhibit Low Battery Display
UL
Default
OFF
OFF
OFF
OFF
25 Programmable Output (PGM) Features 3
Zn 1 LED ON = AC Fail
Zn 2 LED ON = Low Battery
Zn 3 LED ON = *Trouble
Zn 4 LED ON = Armed
*See Note 3
Default
OFF
OFF
OFF
ON
20 Keypad Features 1
Zn 1 LED ON = *Keypad Panic 2 (KK )
Zn 2 LED ON = *Keypad AUX (FF )
Zn 3 LED ON = *Keypad Panic (GG )
*See Note 1
Default
OFF
OFF
ON
ON
21 Keypad Features 2
Zn 1 LED ON = Audible panic
Zn 2 LED ON = Exit/Entry with Urgency
Zn 3 LED ON = Display Bypass (ARMED)
Zn 4 LED ON = Disable Code Entry Beeps
Default
ON
OFF
OFF
ON
22 Miscellaneous Features 1
Zn 1 LED ON = Abort Delay
Zn 2 LED ON = Easy Arm/Easy Exit
Zn 3 LED ON = Swinger Shutdown
Zn 4 LED ON = Bell on Line Cut (Armed)
Zn 4 LED ON = *Ambush (4th User Code)
Includes Bell Cut, Receiver Fail-to-Respond, Receiver Tamper, Receiver
JAM, Transmitter Low Battery and Transmitter Supervisory Faliure.
NOTE 3:
Cannot be programmed with any other Programmable Output (PGM) Feature.
NOTE 2:
Additional programming required for reporting, see Blocks [36]&[56].
NOTE 1:
UL
Wi854c.pub
page 5 Thursday, December 18, 1997 18:43

6
Telephone Number 1 Programming
30 Subscriber ID Number
[0] Disabled
[1] Ademco Slow
[2] Radionics Slow
[3] Silent Knight Fast
[4] Universal High Speed
[5] Reserved
[6] Point ID
[7] Pager
32 Receiver Format
(4)
31 Telephone Number 1
NOTE:
Requires features to be enabled, see block [20].
NOTE 1:
A fixed Dial Tone Detection (E) is included prior to the Dialing Prefix (Block
Number 44). Programming an E is not required for Telco 1, Telco 2 and
Telco 3. If dial tone detection is not desired select No Dial Tone Detection
in Communicator Features (Block Number 46). Program a D if a 4 second
delay is required.
Includes Bell Cut, Receiver Fail-to-Respond, Receiver Tamper, Receiver
JAM, Transmitter Low Battery and Transmitter Supervisory Faliure.
ZONE 3 TX LOW BATTERY “RF TRAN LOW BAT, ZN03”
NOTE 2:
Default
OFF
OFF
OFF
OFF
39 Opening Closing Report, Telco 1
Zn 1 LED ON = User 1 Reporting
Zn 2 LED ON = User 2 Reporting
Zn 3 LED ON = User 3 Reporting
Zn 4 LED ON = User 4 Reporting
Default
ON
ON
ON
ON
34 Zone Report, Telco 1
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
35 Zone Restore Report, Telco 1
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
ON
36 System Reporting, Telco 1
Zn 1 LED ON = *KP Panic 2 (KK )
Zn 2 LED ON = *KP AUX (ff )/Ambush
Zn 3 LED ON = *KP Panic (gG )
Zn 4 LED ON = Test Timer
*See Note 1
Default
ON
OFF
OFF
OFF
37 System Reporting, Telco 1
Zn 1 LED ON = AC Fail Report (15 min. report delay)
Zn 2 LED ON = Low Battery Report
Zn 3 LED ON = *Trouble Report
Zn 4 LED ON = Reserved
*See Note 2
Default
OFF
OFF
OFF
OFF
38 System Restore Report, Telco 1
Zn 1 LED ON = AC Restore Report
Zn 2 LED ON = Battery Restore Report
Zn 3 LED ON = Trbl Restore Report
Zn 4 LED ON = Reserved
Default
OFF
OFF
ON
OFF
33 Receiver Options
Zn 1 LED ON = 2300 Hz Handshake/Kissoff
Zn 2 LED ON = Sumcheck
Zn 3 LED ON = Single Digit
Zn 4 LED ON = No Handshake/Pager Extend
Wi854c.pub
page 6 Thursday, December 18, 1997 18:43

7
Backup Telephone Programming
Dialing Prefix for Telco 1, Telco 2
& Telco 3.
40 Subscriber ID Number (Telco 2)
41 Telephone Number 2
[1] Ademco Slow
[2] Radionics Slow
[3] Silent Knight Fast
[4] Universal High Speed
[5] Reserved
[6] Point ID
[7] Pager
42 Receiver Format
(4)
44 Dialing Prefix
Default
OFF
OFF
ON
OFF
43 Receiver Options
Zn 1 LED ON = 2300 Hz Handshake/Kissoff
Zn 2 LED ON = Sumcheck
Zn 3 LED ON = Single Digit
Zn 4 LED ON = No Handshake
Default
ON
OFF
ON
OFF
45 Communicator Features 1
Zn 1 LED ON = Communicator Enabled
Zn 2 LED ON = DTMF w/ Rotary Back up
Zn 3 LED ON = DTMF only
Zn 4 LED ON = Backup to Telco 2
Default
OFF
OFF
OFF
OFF
46 Communicator Features 2
Zn 1 LED ON = No Dial Tone Detection
Zn 2 LED ON = 2:1 Rotary Dialing
Zn 3 LED ON = Backup if < 4 attempts
Zn 4 LED ON = Reserved
NOTE:
A fixed Dial Tone Detection (E) is included prior to the Dialing Prefix (Block
Number 44). Programming an E is not required for Telco 1, Telco 2 and
Telco 3. If dial tone detection is not desired select No Dial Tone Detection
in Communicator Features (Block Number 46). Program a D if a 4 second
delay is required.
Wi854c.pub
page 7 Thursday, December 18, 1997 18:43

8
Telephone Number 3 Programming
50 Subscriber ID Number
[0] Disabled
[1] Ademco Slow
[2] Radionics Slow
[3] Silent Knight Fast
[4] Universal High Speed
[5] Reserved
[6] Point ID
[7] Pager
52 Receiver Format
(4)
51 Telephone Number 3
NOTE:
Requires features to be enabled, see block [20].
NOTE 1:
A fixed Dial Tone Detection (E) is included prior to the Dialing Prefix (Block
Number 44). Programming an E is not required for Telco 1, Telco 2 and
Telco 3. If dial tone detection is not desired select No Dial Tone Detection
in Communicator Features (Block Number 46). Program a D if a 4 second
delay is required.
Includes Bell Cut, Receiver Fail-to-Respond, Receiver Tamper, Receiver
JAM, Transmitter Low Battery and Transmitter Supervisory Faliure.
ZONE 3 TX LOW BATTERY “RF TRAN LOW BAT, ZN03”
NOTE 2:
Default
OFF
OFF
OFF
OFF
59 Opening Closing Report, Telco 3
Zn 1 LED ON = User 1 Reporting
Zn 2 LED ON = User 2 Reporting
Zn 3 LED ON = User 3 Reporting
Zn 4 LED ON = User 4 Reporting
Default
OFF
OFF
OFF
OFF
54 Zone Report, Telco 3
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
55 Zone Restore Report, Telco 3
Zone 1
Zone 2
Zone 3
Zone 4
Default
OFF
OFF
OFF
OFF
56 System Reporting, Telco 3
Zn 1 LED ON = *KP Panic 2 (KK )
Zn 2 LED ON = *KP AUX (ff )/Ambush
Zn 3 LED ON = *KP Panic (gG )
Zn 4 LED ON = Test Timer
*See Note 1
Default
OFF
OFF
OFF
OFF
57 System Reporting, Telco 3
Zn 1 LED ON = AC Fail Report (15 min. report delay)
Zn 2 LED ON = Low Battery Report
Zn 3 LED ON = *Trouble Report
Zn 4 LED ON = Reserved
*See Note 2
Default
OFF
OFF
OFF
OFF
58 System Restore Report, Telco 3
Zn 1 LED ON = AC Restore Report
Zn 2 LED ON = Battery Restore Report
Zn 3 LED ON = Trbl Restore Report
Zn 4 LED ON = Reserved
Default
OFF
OFF
ON
OFF
53 Receiver Options
Zn 1 LED ON = 2300 Hz Handshake/Kissoff
Zn 2 LED ON = Sumcheck
Zn 3 LED ON = Single Digit
Zn 4 LED ON = No Handshake/Pager Extend
Wi854c.pub
page 8 Thursday, December 18, 1997 18:43

9
Report Codes
60 Zone Report Codes
Zone 1 Alarm Code
(3) Zone 2 Alarm Code
(3) Zone 3 Alarm Code
(3) Zone 4 Alarm Code
(3)
The second digit of the Re-
port Code is the number of
the zone that is reporting.
For example zone 5 report
code (default of 3) would be
35.
61 Point ID Report Codes
Zone 1 Alarm Code
(3) Zone 2 Alarm Code
(3) Zone 3 Alarm Code
(3) Zone 4 Alarm Code
(3)
1FIRE
2PANIC
3BURGLARY
4HOLDUP
5GENERAL ALARM
6RESERVED
7GAS ALARM
8HEAT ALARM
9RESERVED
AAUXILIARY
B24 HOUR ALARM
62 Zone Codes
Zone 1, 2, 3 & 4 Restore Code
(E) Zone 1, 2, 3 & 4 Trouble Code
(F)
63 System Report Codes
Keypad Panic 2 (KK)
(1) (1) Keypad AUX (FF)
(2) (3) Keypad Panic (GG)
(2) (1) Test Timer
(F) (F) AC Fail
(F) (9) Low Battery
(F) (8) *Trouble
(F) (1)
64 System Restore Code
(E)
65 Opening and Closing Code
(C) Closing Code
(B) Opening Code
66 Ambush Report Code
(2) (2)
Enhanced Communicator Features
Includes Bell Cut, Fire Trouble, Receiver Fail-to-Respond, Receiver Tamper,
Receiver JAM, Transmitter Low Battery and Transmitter Supervisory Faliure.
NOTE 1:
NOTE:
*See Note 1
Default
OFF
OFF
OFF
OFF
67 Telephone Number 1
Zn 1 LED ON = Opening after Alarm (Cancel Code)
Zn 2 LED ON = Conditional Closing
Zn 3 LED ON = Reserved
Zn 4 LED ON = Reserved
Default
OFF
OFF
OFF
OFF
68 Telephone Number 3
Zn 1 LED ON = Opening after Alarm (Cancel Code)
Zn 2 LED ON = Conditional Closing
Zn 3 LED ON = Reserved
Zn 4 LED ON = Reserved
Wi854c.pub
page 9 Thursday, December 18, 1997 18:43

10
Wireless
Transmitters
:
71 Zone 1
RF ID # Point
:
72 Zone 2
:
73 Zone 3
:
74 Zone 4
Enter the RF ID# located on
the Transmitter and Key Fob
labels.
RF ID # XXXXXX:X
Enter the point number to be
associated with the zone. If only
one point of GEM-TRANS2 is
used, enter a 1in this location.
For GEM-GB, GEM-DT, GEM-
PIR enter a 1in this location.
:
81 Keyfob 1
Keyfobs AUX 1 AUX 2RF ID #
:
82 Keyfob 2
:
83 Keyfob 3
:
84 Keyfob 4
AUX 1 & 2
Programming
1 Panic
2 AUX
3 Bell ON
4 PGM
5 Instant
6 Access on PGM
7 Full Set System
8 Interior
Hexadecimal Data Entry
To Enter a hexadecimal digit enter the following: A=A1 B=A2 C=A3 D=A4 E=A5 F=A6
Programming Example
Map point 1 of a window door transmitter, with RF ID# 0012B0:0
to Zone 3.
1. Enter Dealer Mode.
2. Enter B(beeps)73 (beeps)
3. Enter 0012A200
4. Enter 1(beeps)
Note: If the RF ID# in step 3 is not entered correctly the
keypad will emit a 1 second tone indicating incorrect entry.
Repeat steps 2 - 4 above.
Hexadecimal B Entry
0 0 1 2 B0:0 1
73 Zone 3
Wi854c.pub
page 10 Thursday, December 18, 1997 18:43

11
Downloading
(0) (9) Maximum Entry 15
91 Ring Count
93 Auto Download ID Number
(4) (5) (6) (7)
94 Dealer Code
Dealer Programming
(1) (2) (3) (4)
95 User 1 Code
90 Callback Telephone Number
(9)
98 Number of Re-Dials
Default
OFF
OFF
ON
OFF
92 Downloading Features
Zn 1 LED ON = Ring Method
Zn 2 LED ON = Answering Machine override
Zn 3 LED ON = Command 6(A6) Download
Zn 4 LED ON = Reserved
Default
ON
OFF
OFF
OFF
96 Dealer Options 1
Zn 1 LED ON = Dealer Code Lockout
Zn 2 LED ON = User 1 Code Lockout
Zn 3 LED ON = Reserved
Zn 4 LED ON = Reserved
Default
OFF
OFF
OFF
OFF
97 Dealer Options 2
Zn 1 LED ON = *International Dialing Protocol
Zn 2 LED ON = *Invert Bell Output
Zn 3 LED ON = System Trouble Auto Reset
Zn 4 LED ON = User 1 Code-Program only
*See Note 1
International Features
NOTE 1:
Wi854c.pub
page 11 Thursday, December 18, 1997 18:43

12
16 VAC 20 VA
TRANSFORMER
NAPCO TRF12
(OR EQUIVALENT
SEE WI879A).
Class 2
Transformer.
DO NOT
connect to
switched
outlet.
-4 +5 +61 2 +3
GEM-RECV-XP8
+RED
(+)
BLACK
E1
E2
RECHARGEABLE
BATTERY
12 VDC 4AH OR 7AH
ALL OUTPUTS ARE CURRENT LIMITED
WARNING
TO PREVENT RISK
OF ELECTRIC SHOCK
DISCONNECT TELEPHONE
LINES PRIOR TO SERVICING
EARTH
GROUND
BELL
Programmable
Output
PGM
(-)
12
+PWR
+10 -11 [phone] 19 -7 +8 -9 GND +PWR GND GREEN TIP RING TIP RING
PHONE
(Supervised)
To RJ31X
2.2K EOLR
(SUPERVISED)
+
+
GOLD
RED RED
RED
COLD WATER GROUND
CONNECTION
USE ONLY COLD-WATER
PIPE OR BURIED GROUND
ROD. USE AT LEAST #16
AWG WIRE.
TELCO
RED
GRN
GRAY
BRN
LOAD
50 mA MAX.
REMOTE BUS
(E)
2.2K
ZONE 4
(Z)
ZONE 1
(E)
2.2K
ZONE 3
2.2K
(E)
RED
BLK
GRN
(E)
(Z)
GOLD
WHITE RED
3.9K
ORANGE 2.2K
EZ
Zone
DoublingTM
Resistors
AUX POWER OUTPUT 10-12.5 VDC
(1) ALL ZONE RESISTORS MUST BE INSTALLED,
EVEN IF ZONE IS NOT USED.
(2) COMBINED STANDBY = KEYPAD CURRENT +
AUX POWER CURRENT + PGM CURRENT.
XP-400 WIRING DIAGRAM
(REFER TO INSTALLATION INSTRUCTIONS WI853C)
RESIDENTIAL BURG (4 HOUR STANDBY) (2)
COMBINED STANDBY = 350 mA BELL = 2.0 AMP
(1)
(Z)
NOT USED
Normally Open Zone Wiring
Wire the normally
open contact
as shown (Zone 4).
Program the
zone for
Open Circuit [06]
operation.
(Z)
ZONE 1
(E)
2.2K
ZONE 4
3.9K
3.9K
3.9K
RPX-4
ZONE 2
Wi854c.pub
page 12 Thursday, December 18, 1997 18:43
