Napco Commercial Platform:
The most powerful, feature-rich platform for 24V commercial
fire, burglary or combination burglary/fire, supporting up to 255
zones using all-new fire and burglary devices in hardwire, wireless,
conventional & addressable technologies
Firewolf 24V Commercial Intelligent
Addressable Fire Panel,NFPA72-compliant,
up to 96 outputs, 4 onboard NACs (6.5A
total), expandable to 24, built in Sync/
Strobe/Horn Module (System Sensor &
Wheelock) and dual line DACT plus optional
TCP/IP reporting. Features remote Smoke
Obscuration Reporting. Nearly a mile., max.
wire run – any wire type –ideal for retrofits.
Also supports legacy and conventional (12V)
devices, too and more of them per loop!
Powerful battery capacity up to 32Ah total.
Gemini-C Commercial Addressable/
Conventional 255-Zone Burglary System;
Supports full line of new GEMC Commercial-
rated conventional, addressable or wireless
devices simultaneously on from 8 to 255
zones, with partitioning. UL Merchantile.
GEM-C Combination Burglary/Access/
Fire System; UL 864, 9th Edition Isolated
commercial Burg./Access and Fire buses
and option for separate burg/access
battery backups-- easy calcs., ideal for
AHJs. No costly extra Bus Isolator or Loop
Isolator modules required! Integrates with
GeminiAccess ACM Module. Uses familiar
Quickloader Up/downloading and Gemini
style keypads in burglary or fire models.
✔ More zones – 255, 128 or 32 points
✔ More power – 7 amps
✔ More NAC’s – Up to 4 on board
✔ Built in strobe/horn synch
✔ More standby power
✔ 32 Amp hour battery capacity
✔ Regulated 24V output
NAC Extender provides nearly 7A and
4 onboard NACs with up to 2A ea; up to
16Ah total battery capacity. Easily distributes
synched bell and strobe outputs with built
in module. Monitors AC, battery trouble,
tamper and ground fault on Napco bus or
provides universal FACP support.
Regulated Auxiliary Power Supplies
Commercial burglary or fire, 12V regulated
2A models (fire shown); or 1.75A version
with plug-in transformer. Backward
compatible with all Gemini Panels. Alarm
panel supervised power option. Ideal for
simultaneous powering of CCTV cameras.
Firewolf Advanced Analog Addressable
Commercial Fire Devices support auto-drift
compensation and maintenance alert function
Gemini-C Addressable Commercial
Burglary Devices permit longest loop length,
upto 10,000 feet; no repeaters necessary!
Gemini-C New UL Commercial Wireless
Line with supervised tamper & automatic,
continuously supervised signal strength
(requires no manual test activation).
Gemini-C Burglary & Firewolf Menu-Driven
Custom Alpha Keypads Familiar Napco
ez-programming. Keypads mount anywhere
on the bus. Burg model with integral
4-zone EZM.
Compliances - NFPA 72, UL Commercial
Fire, UL864 9th Ed., SIA CP01, UL985. UL
household & commercial burg.: UL1610,
UL609, UL365, UL1023 (CSFM, FM, MEA
listings pending.)
24V Addressable &
Conventional Fire
Addressable /
Conventional 255-Zone
Merchantile Burglary Combination
Burglary/Access & Fire
32, 128 & 255 Points
Universal NAC
Extender
Regulated
Auxiliary Power
Supplies
Introducing the all new

SYSTEM
•Main Control board supports up to (2) Addressable SLCs (Signaling
Line Circuit controllers).
•Fire Addressable SLC Loop Controller
•Burg Addressable SLC Loop Controller
•Fire 4-wire bus for keypads and conventional devices
•Burglary Control Module
•Provides Isolated Burg 4-wire bus for keypads and conventional
devices
•Provides independent Burg battery connection and charger
•Provides 12V power
•Independent Burg Bell output
•Power Supply includes either 4A or 7A @ 24V
•Integrates with NAPCO ACM – Access Control Modules
•RS-232 Printer Module for optional onsite parallel printer
•Supports a maximum of 15 Keypads, mounted anywhere on the bus,
fi r e GEMC-FK1 or burg. GEMC-BK1. ( 7 fire keypads, max. Or, as few as 1
fire keypad required on fire system or equipment savings.)
•Addressable SLC Loop Isolator (optional use - for some fire
applications requiring increased circuit integrity)
•Dual Phone Line built in
•2 Onboard Serial Ports - One for internet reporting; One for high-
speed local downloading
•TCP/IP Internet reporting module
•Regulated Auxiliary Power Supplies - Commercial Burglary or fire, 12V
regulated 2A or 1.75A version with plug in transfomer
•Choice of two panel enclosures - Between the studs enclosure, recess
or surface mount. Larger version, with reversible door, supports up
to 32Ah at 24V. Dimensions: 24” x 14.25” x 5.2” (H x W x D) without
cover. Removable battery shelves, accomodate pairs of 7Ah, 7.5Ah
and 8Ah batts. etc. Smaller Enclosure – supports 16Ah at 24V.
Dimensions: 16” x 14.25” x 5.2” (H x W x D) without cover. (16Ah
battery backup capacity).
INPUTS
Up to 255 Zones. Points/Zones can come from any of the following
initiating devices (in up to 8 partitionable areas):
•Addressable SLC Loop (Burg or Fire) – supports up to (2) 126 point
loops
•Commercial RF Receiver –
•Supports Commercial Wireless Fire devices
•Wireless Smoke Detector
•Wireless Heat Detector
•Supports Commercial Wireless Burglary devices
•Wireless PIR Sensor
•Wireless Dual Technology Sensor
•Wireless Glass break Sensor
•Wireless 2-Point Window/Door Transmitter
•Conventional 1- to 4-zone EZM Expansion modules on the 4-wire burg
or fire bus or SLC loops
•Conventional 2-wire or 4-wire smoke detector input module
•Addressable SLC Fire Devices Supported:
•Analog Smoke Detector
•Heat Detector
•Duct Detector
•Pull Station
•Conventional Zone Module
•Short Circuit Isolator
•Addressable SLC Burg Devices Supported:
•1 Zone Burg Input Module
•4 Zone Burg Input modules
•PIR Motion Sensor
•Dual Tech Microwave/PIR Sensor
OUTPUTS
Up to 96 outputs
•Four on board Class B or 2 Class A NAC circuits, 2 amps each, total 6.5
amps at 24V
•Built in Wheelock and System Sensor NAC sync/strobe/horn protocol
allows initial silence of audible appliances while maintaining visual
notification, without the use of additional modules.
•Addressable SLC Fire Devices: Supervised relay, unsupervised relay
•Addressable SLC Burg Devices: unsupervised relay
•Burg/Fire 4-wire bus devices: 8 zone form C relay (GEMC-RM3008), 8
open collector output (GEMC-OUT8)
Napco Commercial Platform Advantages
•Easy Wire Compatibility -SLC controller supports shielded, unshielded,
twisted and untwisted wire - ideal for retrofits
•Longer SLC loop lengths, support more device load each, too
(see below for distance at maximum device load in alarm/standby
each)
•10,000ft. #14AWG • 6,200ft #16AWG •4,000 ft. #18AWG
•Support for Legacy and Existing Notification Appliances - One NAC
output configurable for 12V for easy retrofit compatibility
•UL Regulated NAC outputs
•Automatic drift compensation for system’s analog smoke detectors
•Separate 7A NAC Extender – (4) NAC’s, may be installed anywhere on
the 4-wire bus. Provides universal FACP support.
•Keypads mount anywhere on the bus and have flash-able firmware –
for updates via Quickloader
•Smoke Obsuration Report -Quickloader device sensitivity report
allows the printout of a report for the AHJ listing the current status of
all analog smoke detectors in the system including the programmed
obscuration level for each device and the actual sensitivity reading for
each device. Report is generated in 3 ways- either remotely (uploaded)
or locally through notebook PC or use optional onsite printer.
•Isolated backup battery circuits for Burglary and Fire for EZ backup
calculation and AHJ compliance; allows dealer to accommodate
separate backup times for burg and fire. This allows burg system to
drop out after burg battery depletion, while fire system is maintained
and extremely stable for extended period.
•Full line of UL Commercial Devices for more flexibility & labor-savings
Example, Use Gemini Commercial Wireless 2-input module (GEMC-
WL-WD2) to convert any UL listed device into a UL wireless device,
ideal for sprinkler supervisories or for use with pull stations (mounts
on top of wall/conduit or in deep sngle-gang box (plastic).
Firewolf Fire-Only 24V Intelligent Addressable Fire Configuration,
NFPA72
•Main Control board - supports (1) Addressable Fire SLC controller
•Fire 4-wire bus for keypads and conventional devices
•Power Supply 7A and 4A
•RS-232 Printer Module
•Fire Keypad with Gemini-style Menu-functionality
•Dual Phone Line built in; Synch module built in (System Sensor &
Wheelock protocols)
NAC Extender - Powerful flexibility
•Nearly 7Amps power
•4 onboard NACs with up to 2A ea., expandable for up to 24 per
system
•Up to 16Ah total battery capacity
•Regulated 24V Aux. power
•Distributes synched bell and strobe outputs with built-in module
•Monitors AC, battery trouble, tamper and ground fault on Napco bus
-or- provides universal FACP support.
Gemini-C Intrusion-Only Configuration, Commercial Conventional/
Addressable 255-Zone Burglary System
•Supports full line of new GEMC Commercial-rated addressable
conventional, or wireless devices simultaneously
•8 to 255 fully-configurable zones, with up to 8 partitions
•Familiar Napco Quickloader up/downloading and keypad operation
•32Ah, max. battery capacity
Agencies
NFPA 72, UL Commercial Fire, UL864 9th Ed., SIA CP01, UL985. UL
household & commercial burg.: UL1610, UL609, UL365, UL1023 (CSFM,
FM, MEA listings pending.)
Napco Commercial™Platform GEMC System Components:
24V Fire, Burglary or Combination Burg./Fire Systems
Napco Commercial Platform Systems
Simultaneously support all-new UL
commercial Firewolf fire and Gemini
burglary devices in hardwire, wireless
and addressable technologies

2-WIRE
FIRE SLC
ADDRESSABLE
LOOP
4 OR 7 AMP MAIN POWER SUPPLY (GEMC-PS24V7A-R or
GEMC-PS24V4A-R)
2-WIRE
BURG SLC
ADDRESSABLE
LOOP
GEMINI C-SERIES COMMERCIAL
COMBINATION CONTROL PANEL
UP TO 126
DEVICES
DUAL TECH PIR
GEMC-BSLC-DT
SINGLE RELAY
MODULE
GEMC-BSLC-RLY
ADDRESSABLE
SMOKE
DETECTOR
FWC-FSLC-SMK
FWC-FSLC-HEAT
ADDRESSABLE
HEAT
DETECTOR
GEMC-BM or
GEMC-BM/PS
BURGLARY
MODULE
PIR
GEMC-WL-PIR
DUAL TECH PIR
GEMC-WL-DT
GLASS BREAK
GEMC-WL-GB
GEMC-WL-WD2*
WINDOW / DOOR
TRANSMITTER
WITH TAMPER
KEYFOB
GEM-KEYF
FWC-FSLC-PULL
ADDRESSABLE
PULL STATION
PULL
BURGLARY BUS DEVICES
GEMC-RECV
WIRELESS
RECEIVER
SINGLE POINT
CONVENTIONAL
ZONE
EXPANDER
GEMC-BSLC-1PT
GEMC-BSLC-4PT
4 POINT
CONVENTIONAL
ZONE
EXPANDER
FWC-FSLC-EZM2
DUAL INPUT
MONITOR MODULE
F
I
R
EW
O
L
F
(4, MAX.)
BURGLARY
KEYPAD
(15, MAX.)
GEMC-BK1
PIR
GEMC-BSLC-PIR
GEM-ACM1D
ACCESS
CONTROL
MODULE
(4, MAX.)
GEM-2D
SECOND DOOR
ACCESS CONTROL
ACCESSORY
FWC-FSLC-DUCT
DUCT DETECTOR
F
I
R
EW
O
L
F
ACCESS
CONTROL
DEVICES
(ONE FOR EACH
GEM-ACM1D)
GEMC-WL-WD
LOW PROFILE
WINDOW / DOOR
TRANSMITTER
GEMC-EZM8
8 ZONE
CONVENTIONAL
ZONE EXPANSION
MODULE
(31, MAX.)
GEMC-OUT8
8 ZONE OUTPUT
REMOTE RELAY
MODULE
(11, MAX.)
GEMC-RM3008
OUTPUT
MODULE
(11, MAX.)
†Residential Burglary when both loops are used
Single Commercial Burglary Supervised Loop and Integral Magnetic Contact
2 SLC MODULES, max.
•Two Fire or •Two Burglary or
•One Fire and one Burglary
Note: The four GEMC-RECV max. is reduced by 1 for each SLC module.
GEMC-RS232
SERIAL OUTPUT
CONVERTER
GEMC-12V2APS-R
12V AUX POWER
SUPPLY
UP TO 126
DEVICES
SMOKE DETECTOR
GEMC-WL-SMK
GEMC-WL-HEAT
HEAT DETECTOR
SINGLE ZONE
TRANSMITTER
WITH TAMPER
GEMC-WL-WD2
Single Fire
initiating
N/O device
GEMC-NAC7
NAC EXTENDER
(5, MAX.)
GEMC-F8ZCPIM
8 Fire Zone Expander
}
8 ZONES OF
CONVENTIONAL 2-WIRE SMOKES
PULL STATIONS AND/OR HEAT DETECTORS
HORN
STROBE
MUST BE
ALL
WHEELOCK
OR ALL
SYSTEM
SENSOR
EOLR
2.2K
STROBE
HORN
HORN
STROBE
EOLR
2.2K
STROBE
HORN
STROBE
HORN
STROBE
HORN
STROBE
HORN
}
•4 ON-BOARD NAC
CIRCUITS (CLASS B) (NOT SHOWN)
-- or --
•2 ON-BOARD NAC
CIRCUITS (CLASS A)
EOLR
2.2K
S
+
+
–
–
SMOKE
2-WIRE
S
+
+
–
–
SMOKE
2-WIRE
EOLR
2.2K
S
+
+
–
–
SMOKE
2-WIRE
S
+
+
–
–
SMOKE
2-WIRE
EOLR
2.2K
S
+
+
–
–
SMOKE
2-WIRE
S
+
+
–
–
SMOKE
2-WIRE
EOLR
2.2K
S
+
+
– –
SMOKE
2-WIRE
S
+
+
–
–
SMOKE
2-WIRE
EOLR
2.2K
S
+
+
–
–
SMOKE
2-WIRE
S
+
+
–
–
SMOKE
2-WIRE
EOLR
2.2K
S
+
+
– –
SMOKE
2-WIRE
S
+
+
– –
SMOKE
2-WIRE
EOLR
2.2K
S
+
+
–
–
SMOKE
2-WIRE
S
+
+
–
–
SMOKE
2-WIRE
EOLR
2.2K
S
+
+
–
–
SMOKE
2-WIRE
S
+
+
–
–
SMOKE
2-WIRE
GEMC-RECV
WIRELESS
RECEIVER
FIRE BUS DEVICES
GEMC-EZM8
8 ZONE
CONVENTIONAL
ZONE EXPANSION
MODULE
GEMC-OUT8
8 ZONE OUTPUT
REMOTE RELAY
MODULE
GEMC-RM3008
OUTPUT
MODULE
GEMC-FPRINT
PRINTER
MODULE
GEMC-12V2APS-CF
12V AUX POWER
SUPPLY
HORN
STROBE
MUST BE
ALL
WHEELOCK
OR ALL
SYSTEM
SENSOR
EOLR
2.2K
STROBE
HORN
HORN
STROBE
EOLR
2.2K
STROBE
HORN
STROBE
HORN
STROBE
HORN
STROBE
HORN
FWC-FSLC-EZM1
FAST RESPONSE
MONITOR MODULE
FWC-FSLC-RM2
DUAL RELAY
MODULE
F
I
R
EW
O
L
F
FWC-FSLC-SOM1
SUPERVISED
OUTPUT MODULE
F
I
R
EW
O
L
F
FWC-FSLC-CZM
CONVENTIONAL
ZONE MODULE
F
I
R
EW
O
L
F
FWC-FSLC-ISO
SHORT CIRCUIT
ISOLATOR
F
I
R
EW
O
L
F
FWC-FSLC-SMK6B
(6" BASE ONLY)
FIRE KEYPAD
GEMC-FK1
(4, MAX.)
EOLR
2.2K
HORN
EOLR
2.2K
STROBE
HORN
STROBE
HORN
STROBE
HORN
STROBE
HORN
STROBE
HORN
HORN
STROBE
EOLR
2.2K
HORN
EOLR
2.2K
STROBE
HORN
STROBE
HORN
STROBE
HORN
STROBE
HORN
STROBE
HORN
HORN
STROBE
}
•4 ON-BOARD NAC
CIRCUITS (CLASS B) (SHOWN)
-- or --
•2 ON-BOARD NAC
CIRCUITS (CLASS A)
MUST BE ALL
WHEELOCK OR ALL
SYSTEM SENSOR
GEMC & FIREWOLF SYSTEM COMPONENTS
FI
R
E
K
E
Y
P
A
D
GE
M
C
-
FK1
B
U
R
G
L
A
R
Y
R
R
Platform supports commercial analog, addressable, wireless or conventional fire or burglary devices.
GEMINI C-SERIES
MOTHERBOARD
GEMC-BSLC Burg SLC Mod. and
GEMC-FW-SLC Fire SCL Mod
Mount beneath motherboard
INTERNET REPORTING MODULE

Napco Commercial Combo. Burglary/Fire Kits
GEMC-COMBO255KT 255 Point GEM-C Commercial Combo. Fire/Burg System Kit
•24V Panel, 255 Points via commercial addressable, wireless or conventional fire or burg. devices, 4 on board NACs, 8 partitions (No Loop
Isolator/Extender required)
•7 Amp, 24V Power Supply
•Burg. Module, with power supply with built in bus isolator for complete separation of fire and burg power and battery standby operation
•Built in horn/strobe synch. module on each NAC
•Built in dual line communicator; dual onboard serial ports
•Quickloader up/downloading including remote smoke obscuration reporting
•Locking, Large Red Enclosure, 16 x 25” reversible door, with 14.25” x 25” base. Houses up to 32Ah battery backup.
•Menu-driven LCD Fire Keypad mounts anywhere on bus (Also, full keyswitch support)
GEMC-COMBO128KT 128 Point GEM-C Commercial Combo. Fire/Burg System Kit
As above, but with
•24V Panel, 128 Points via commercial addressable, wireless or conventional fire or burg. devices, 4 on board NACs, 8 partitions (No Loop
Isolator/Extender required)
GEMC-COMBO32KT 32 Point GEM-C Commercial Combo. Fire/Burg System Kit
Similar to above, but with
•24V Panel, 32 Points via commercial addressable, wireless or conventional fire or burg. devices, 2 on board NACs, 8 partitions (No Loop
Isolator/Extender required)
•Locking, Medium Red Enclosure, 16 x 17” door, with 14.25” x 16” base. Houses up to 16Ah battery backup.
Napco Commercial Fire Kits
GEMC-FW-255KT 255 Point GEM-C Firewolf™ 24V Commercial Fire System Kit
•24V Panel, 255 Points via commercial addressable, wireless or conventional fire devices, 4 on board NACs providing up to 6.5A notification
power
•7 Amp, 24V Power Supply
•Built in horn/strobe synch. module on each NAC
•Built in dual line communicator; dual onboard serial ports
•Quickloader up/downloading including remote smoke obscuration reporting
•Locking, Large Red Enclosure, 16 x 25” reversible door, with 14.25” x 25” base. Houses up to 32Ah battery backup.
•Menu-driven LCD Fire Keypad mounts anywhere on bus. (Also, full keyswitch support)
GEMC-FW-128KT 128 Point GEM-C Firewolf™ 24V Commercial Fire System Kit
As above, but with
•24V Panel, 128 Points via commercial addressable, wireless or conventional fire devices, 4 on board NACs providing up to 6.5A notification
power
GEMC-FW-32KT 32 Point GEM-C Firewolf™ 24V Commercial Fire System Kit
Similar to above, but with
•24V Panel, 32 Points via commercial addressable, wireless or conventional fire devices, 2 on board NACs providing up to 4A notification
power
•Locking, Medium Red Enclosure, 16 x 17” door, with 14.25” x 16” base. Houses up to 16Ah battery backup.
Commercial Fire & Burglary Accessories and Options
GEMC-BM/PS Burg Module with 12V power supply provides isolated 4-wire burg bus for burg keypads and devices, plus 12V power output for aux. devices. In-
dependent Burg. Bell output. Complete separation of fire and burg power, plus indep. burg. battery connection and charger for indep. burg. standby
operation in power failure.
GEMC-BM Burg Module, isolated 4-wire burg bus for burg keypads and devices, plus 12V power output for aux devices. Indep. Burg bell output.
GEMC-FW-SLC Addressable SLC Fire Module, supports up to 128 addressable SLC fire devices. Up to 2 connect to GEM-C panel.
GEMC-BSLC Addressable SLC Burg Module, supports up to 128 addressable SLC burg devices. Up to 2 connect to GEM-C panel.
GEMC-F8ZCPIM Conventional 8-zone 2-wire fire input module. Plugs into GEM-C panel, for conventional 2-wire smokes or any conventional fire detection device.
Burglary Peripherals
GEMC-BK1 LCD Burglary Keypad for Combo. System, with 4-zone EZM built in (Requires GEMC-BM or BM/PS Module.)
GEMC-BSLC-4PT Addressable SLC 4 point input expansion module
GEMC-BSLC-1PT Addressable SLC 1 point input expansion module
GEMC-BSLC-DT Addressable SLC Commercial Dual Tech Microwave/PIR, 40 x 40’
GEMC-BSLC-PIR Addressable SLC Commercial PIR, 50 x 50’
GEMC-BSLC-RLY Addressable SLC Commercial 1 point output module
GEMC-WL-PIR Gemini Commercial Wireless PIR, 50 x 50’
GEMC-WL-GB Gemini Commercial Wireless Glassbreak, Acoustic 25’
GEMC-WL-DT Gemini Commercial Wireless Dual Tech Microwave/PIR, 40 x 40’
Fire Peripherals
GEMC-FK1 LCD Fire Red Keypad
GEMC-WL-SMK Gemini Commercial Wireless Smoke, Photoelectric
GEMC-WL-HEAT Gemini Commercial Wireless Heat, 135º F
Common Peripherals – For Commercial Fire and/or Burglary Systems
GEMC-WL-WD2 Gemini Comml Wireless 2-input module converts any UL listed device into a UL wireless device (ex., pull stations or sprinkler supervisories.)
GEMC-REVC Gemini Commercial Wireless 255 point RF Receiver (up to 4 per system, max.)
GEMC-EZM8 8-point expansion module
GEMC- FPRINT Parallel printer module
GEMC-RM3008 8 Form C Relay Output Module
GEMC-NL-MOD Internet Reporting Module
GEMC-RS232 RS232 Adapter for serial output from GEMC Panel
GEMC-OUT8 PGM Output Module, 8 open collector PGM outputs
GEMC-KOTAMPERKT Merchantile Tamper Kit, for large panel enclosures, supervised. (Not necessary if housing is recess-mounted.)
Firewolf Peripherals
FWC-FSLC-SMK Addressable Analog SLC Smoke, photoelectric, head**
FWC-FSLC-HEAT Addressable Analog SLC Heat, 135ºF, head**
FWC-FSLC-DUCT Addressable SLC Duct smoke detector, photoelectric
FWC-FSLC-EZM2 Addressable SLC 2-zone conventional expansion module. Uses one address on SLC loop, but yields 2 indepent contact monitoring circuits, for pull
stations, water flow and other dry contact alarm initiating devices.
FWC-FSLC-EZM1 Addressable SLC 1-input conventional module, similar to usage above.
FWC-FSLC-CZM Addressable SLC single module, for montoring of dry contacts, ie., pull stations and conv. smokes
FWC-FSLC-RM2 Addressable SLC 2-output module (requires 1 SLC address)
FWC-FSLC-ISO Addressable SLC Short Circuit Module. (Optional use, for certain apps. only; meets Class A, Style 7 loop reqts.)
FWC-FSLC-SOM1 Addressable SLC Fire supervised output module. Application examples: elevator recall, HVAC shutdown, add’l NAC output with power supply
FWC-FSLC-PULL Addressable SLC Fire Pull Station
FWC-FSLC-PROG2 Tool for address-programming SLC devices
FWC-FSLC-SMK6B ** Smoke/Heat 6"Base, required for FWC-FSLC- SMK and –HEAT devices
Options
GEMC-12V2APS-CF 12VDC Power Supply for Fire Bus, remote supervised. Direct 120VAC connection, supports 2ea. 12V, 7Ah standby batteries.
GEMC-12V2APS-R 12VDC Power Supply for Burg. Bus, remote supervised. Powered by supplied 16.5V, 50VA plug-in transformer, supports 2ea. 12V, 7AH standby
batteries.
GEMC-NAC6 Remote 4-output NAC Extender, for 6.5A ttl, or 2A, max. on any 1 output. Red 14 x 16” can, connects to 120VAC, supports 32Ah standby batts.
Supervised, fire bus connection. System Sensor and Wheelock NAC synch. (5 per system, for 20 add’l NAC circuits total.)
GEM-ACM1D Access Control Module (with power supply, provision for back up battery, in enclosure, plug-in transformer), 1 door kit
GEM-2D Access Add-on 2 door plug–in PCB for expansion of door capacity in above.
NAPCO COMMERCIAL GEMINI-C & FIREWOLF SERIES SYSTEM ORDERING INFORMATION
1-800-645-9445 www.napcosecurity.com/newproducts.html ©Napco August 2010. Specifications subject to change A593A
Napco Commercial, Gemini and Firewolf are trademarks of Napco Security Technologies. Wheelock, System Sensor, UL, etc. are trademarks of theiir respective cos.
