©1994–2003 National Instruments Corp. All rights reserved.
National Instruments™, NI™, ni.com™, and SCXI™ are trademarks of National Instruments Corporation. Product and
company names mentioned herein are trademarks or trade names of their respective companies. For patents covering
National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file
on your CD, or ni.com/patents.
April 2003
371189A-01
SCXI -1382 BATTERY PACK INSTALLATION GUIDE
This guide describes how to install and use the SCXI-1382 battery pack
with the SCXI-1000DC chassis.
The SCXI-1382 is a battery pack containing a 12 V sealed lead-acid battery
with a capacity of 26 Ah at a 20 hr rate. This battery pack can power the
SCXI-1000DC chassis when other power sources are unavailable. You can
combine the SCXI-1383 with the SCXI-1382 to charge the SCXI-1382 or
to operate in float mode for uninterruptable power to an SCXI-1000DC
chassis. The SCXI-1383 is a constant voltage, current-limited charger.
There are two versions of the SCXI-1382 battery pack kit. One kit requires
an SCXI-1383 and one does not. If the kit contains an SCXI-1383 power
supply/float charger refer to the SCXI-1383 Power Supply/Float Charger
Installation Guide when setting up the system.
Conventions
The following conventions are used in this guide
»The »symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash. When this symbol is marked on
the product, refer to the Read Me First: Safety and Radio-Frequency
Interference document, shipped with the product, for precautions to take.
bold Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
™
ni.com
SCXI-1382 Battery Pack Installation Guide 2 ni.com
italic Italic text denotes variables, emphasis, a cross reference, or an introduction
to a key concept. This font also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames and extensions, and code excerpts.
What You Need to Get Started
To set up and use the SCXI-1382 battery pack, you need the following:
❑SCXI-1382 kit
– SCXI-1382 battery pack
– Mounting bracket for the SCXI-1382 battery pack (attached to the
battery pack)
– Screws, 8-32 ×5/16 in. flathead
– Screw, 6-32 ×1/4 in. flathead
–SCXI-1382 Battery Pack Installation Guide
–Read Me First: Safety and Radio-Frequency Interference
Notes Some kits also contain the SCXI-1383 power supply/float charger, a power cord
U.S. 120 VAC/Japan 100 VAC, and the SCXI-1383 Power Supply/Float Charger
Installation Guide.
If your kit is missing any of its components, contact NI. You can download NI documents
from ni.com/manuals.
❑Required, sold separately
– SCXI-1000DC chassis
– Phillips number 2 screwdriver
❑Recommended, sold separately with country appropriate power cord
options
– SCXI-1383 power supply/float charger
Before using the SCXI-1382 battery pack for the first time, charge it for at
least 24 hours to reach the full charge capacity.
Note Refer to the Charging the Battery Pack section for charging instructions.
©National Instruments Corporation 3 SCXI-1382 Battery Pack Installation Guide
Battery Pack Safety Information
Note Refer to the Read Me First: Safety and Radio-Frequency Interference document
before removing equipment covers or connecting or disconnecting any power wires or
signal wires.
Cautions The battery pack contains a sealed lead-acid non-wet, nonspillable battery.
Do not ship the battery pack without proper packaging or if it is damaged. Retain the
original packaging for future shipping.
Do not carry the battery pack onto a passenger plane. You must ship the battery pack as
cargo.
You must recycle or properly dispose of the battery. In the United States, call
1-800-RE-USE-Pb (1-800-738-7372) for more information.
Never expose the battery to fire or short-circuit the battery.
Do not use the battery pack if it appears damaged.
Always use the supplied charger to charge the battery pack. Follow the documentation
instructions. You can obtain NI documents at ni.com or by contacting an NI sales
representative.
Charging the Battery Pack
The SCXI-1382 battery pack requires 12 to 14 VDC and at least 3.7 A of
power for at least 12 to 14 hours to reach a full charge. Charge the battery
pack as soon as possible after use. If the battery is fully charged, it can
power the SCXI-1000DC chassis for more than five hours. However,
NI recommends that you charge the battery after every three hours of use
to extend the life of the battery pack.
Note NI recommends using the SCXI-1383 power supply/float charger to charge the
SCXI-1382 battery pack. Refer to the SCXI-1383 Power Supply/Float Charger
Installation Guide for charging instructions.
Caution The battery pack contains a sealed lead-acid battery that contains toxic material
(lead) and corrosive fluid (sulfuric acid). Charging can produce explosive gases. Do not
charge the battery in gas-tight enclosures. Charge the battery in a well ventilated area away
from sparks, flames, or smoke. Do not short the battery pack terminals, as this can cause
an explosion or fire. Do not store the battery pack in a discharged state. Do not puncture,
disassemble, mutilate, or incinerate the battery pack. Recycle the battery or dispose of the
SCXI-1382 Battery Pack Installation Guide 4 ni.com
battery pack with automotive battery scrap. The battery charger dissipates heat. Use the
charger in an area with ample air circulation.
Connecting the SCXI-1382 to the SCXI-1000DC Chassis
Caution Only qualified personnel should install the SCXI-1382 battery pack.
To connect the SCXI-1382 battery pack to the SCXI-1000DC, refer to
Figure 1 and complete the following steps:
1. Power off the SCXI-1000DC chassis by switching the power switch on
the SCXI-1000DC front panel to the Οposition.
2. Remove the four 8-32 ×7/16 in. screws that hold the mounting bracket
to the SCXI-1382 battery pack.
3. Using the 8-32 ×5/16 in. and 6-32 ×1/4 in. screws, attach the
mounting bracket to the SCXI-1000DC. Apply a torque of
1.2–1.4 N · m (10.5–12.3 lb · in.) to the screws to secure them.
4. Slide the battery pack assembly onto the mounting bracket and reinsert
the four 8-32 ×7/16 in. screws. Apply a torque of 1.2–1.4 N · m
(10.5–12.3 lb · in.) to the screws to secure them.
5. The chassis and the battery pack are ready for electrical connections.
Connect the green DC power connector (P1) at the end of the cord on
the SCXI-1382 battery pack to the corresponding connector (J1) on the
rear panel of the SCXI-1000DC chassis.
Caution The SCXI-1382 battery pack connector, J2, is an input-only connector for the
SCXI-1383 power supply/float charger. Do not connect the SCXI chassis to this connector.
6. Power on the SCXI-1000DC chassis using the power switch on the
front panel of the chassis.
Note If the SCXI-1000DC chassis does not power up, check the fuse (F3) on the
SCXI-1382 battery pack.
Caution Always replace a bad fuse with a fuse of the same size and rating for continued
fire protection.
©National Instruments Corporation 5 SCXI-1382 Battery Pack Installation Guide
Figure 1. Connecting the SCXI-1382 to the SCXI-1000DC Chassis
1 SCXI-1000DC Chassis
2 8-32 x 7/16 in. Screws
3 Mounting Bracket
4 8-32 x 5/16 in. Screws
5 SCXI-1382 Battery Pack
6F3
7P1
8 6-32 x 1/4 in. Screw
9J1
1
2
3
4
5
7
9
2
6
8
SCXI-1382 Battery Pack Installation Guide 6 ni.com
Connecting the SCXI-1382 to the SCXI-1000DC Chassis
and SCXI-1383 Power Supply/Float Charger in
Float-Charging Mode
Note Refer to the SCXI-1383 Power Supply/Float Charger Installation Guide and the
SCXI-1383 label for more information about the LEDs.
Caution Always power off the SCXI-1000DC and the SCXI-1383 before connecting or
disconnecting to each other or to the SCXI-1382.
To connect the SCXI-1383 power supply/float charger to the
SCXI-1000DC and the SCXI-1382 battery pack in float-charging mode,
refer to Figures 1 and 2 and complete the following steps:
1. Follow steps 1 to 6 in the Connecting the SCXI-1382 to the
SCXI-1000DC Chassis section.
2. Connect the green DC power connector of the SCXI-1383 power
supply/float charger (P2) to its corresponding connector (J2) on the
rear panel of the SCXI-1382 battery pack.
3. Connect the IEC 320-style connector of the power cord to its mating
connector on the SCXI-1383 power supply/float charger.
4. Connect the AC power plug of the power cord to a 100 to 240 VAC,
50/60 Hz power source. Switch on the AC power source.
5. The SCXI-1383 power supply/float charger is now powered up
and is float-charging the SCXI-1382 battery pack. Power on the
SCXI-1000DC chassis using the power switch on the front panel.
Note While in float-charging mode, the green LED on the top of the SCXI-1383 case
illuminates only if the battery is not fully charged.
©National Instruments Corporation 7 SCXI-1382 Battery Pack Installation Guide
Figure 2. Connecting the SCXI-1382 in the Float-Charging Mode to the SCXI-1000DC
Chassis and the SCXI-1383 Power Supply/Float Charger
Specifications
All specifications are typical at 25 °C unless otherwise specified.
Note Refer to the SCXI-1383 Power Supply/Float Charger Installation Guide for its
specifications.
Battery Pack
Battery type ..............................Sealed lead-acid
Voltage .....................................12 V
Capacity at 20 hr rate ...............26 Ah
Dimensions...............................15.8 by 17.8 by 21.8 cm
(6.2 by 7 by 8.6 in.)
Weight......................................11 kg (24 lb)
1 SCXI-1000DC Chassis
2J1
3J2
4 SCXI-1382 Battery Pack
5 SCXI-1383 Power Supply/Float
Charger
6 To VAC Power Source
7P2
8P1
4
8
1
5
6
2
7
3
SCXI-1382 Battery Pack Installation Guide 8 ni.com
Environmental
Operating temperature ............. 0 to 50 °C
Storage temperature................. –20 to 70 °C
Humidity.................................. 10 to 90% RH, noncondensing
Maximum altitude.................... 2,000 meters
Pollution Degree ...................... 2
(indoor use only)
Safety
The SCXI-1382 is designed to meet the requirements of the following
standards of safety for electrical equipment for measurement, control and
laboratory use:
• IEC 61010-1, EN 61010-1
• UL 3111-1, UL 61010B-1
• CAN/CSA C22.2 No. 1010.1
Note For UL and other safety certifications, refer to the product label or to ni.com.
Electromagnetic Compatibility
Emissions................................. EN 55011 Class A at 10 meters.
FCC Part 15A above 1 GHz
Immunity ................................. EN 61326:1997 + A2:2001, Table 1
EMC/EMI ................................ CE, C-Tick and FCC Part 15 (Class A)
Compliant
Note For EMC compliance, you must operate this device with shielded cabling.
©National Instruments Corporation 9 SCXI-1382 Battery Pack Installation Guide
CE Compliance
The SCXI-1382 meets the essential requirements of applicable European
Directives, as amended for CE marking, as follows:
Low-Voltage Directive ............73/23/EEC
(safety)
Electromagnetic .......................89/336/EEC
Compatibility Directive (EMC)
Note Refer to the Declaration of Conformity (DoC) for this product for any additional
regulatory compliance information. To obtain the DoC for this product, click Declarations
of Conformity Information at ni.com/hardref.nsf/.
Artisan
Technology
Group
is
an independent supplier
of
quality pre-owned equipment
Gold-standard
solutions
Extend the life
of
your
critical industrial,
commercial, and military systems
with
our
superior service and support.
We
buy
equipment
Planning to
upgrade
your current
equipment? Have surplus equipment taking
up shelf space? We'll give it a
new
home.
Learn
more!
Visit us at artisantg.com for more info
on price quotes, drivers, technical
specifications, manuals, and documentation.
Artisan Scientific
Corporation
dba
Artisan
Technology
Group
is
not
an affiliate,
representative,
or
authorized
distributor
for
any
manufacturer
listed herein.
We're here to make your life easier.
How
can
we
help you today?
(217)
352-9330
Isales@artisantg.com Iartisantg.com
Other manuals for SCXI-1382
1
Table of contents
Other National Instruments Batteries Pack manuals
