Nautel NX5 User manual

2: INSTALLATION MANUAL
NX5/NX3
AM TRANSMITTER
Document ID: NHB-NX3-NX5-INS
Version: 3.1
Issue Date: 2021-04-22
Status: Standard

VERSION 3.1 2021-04-22 PAGE 2.III
NX5/NX3 INSTALLATION MANUAL
Contact Information
Nautel Limited
10089 Peggy’s Cove Road
Hackett’s Cove, NS Canada B3Z 3J4
Toll Free: +1.877.6NAUTEL (662.8835)
(Canada & USA only) or
Phone: [phone] or
Fax: [phone]
Nautel Inc.
201 Target Industrial Circle
Bangor, Maine USA 04401
Phone: [phone]
Fax: [phone]
Customer Service (24-hour support)
+1.877.628.8353 (Canada & USA only)
+1.902.823.5100 (International)
Email: [email protected]
Web: www.nautel.com
The comparisons and other information provided in this document have
been prepared in good faith based on publicly available information.
For verification of materials, the reader is encouraged to consult the
respective manufacturer's most recent publication on the official
website or through contact with Customer Service.
© Copyright 2021 NAUTEL. All rights reserved.

NX5/NX3 INSTALLATION MANUAL TABLE OF CONTENTS
VERSION 3.1 2021-04-22 PAGE 2.V
CONTENTS
Contact Information 2.1.iii
Release Control Record 2.vii
Preparing for installation 2.1.1
Unpacking and Positioning 2.2.1
Connecting the Station Reference Ground 2.3.1
Connecting Ac Power 2.4.1
Adjusting the Spark Gap 2.5.1
Installing Audio Inputs 2.6.1
Planning Complete? 2.6.1
Routing Cables and Connecting Audio Inputs 2.6.1
Installing Control/Monitor Wiring 2.7.1
Planning Complete? 2.7.1
Routing Cables 2.7.1
Configuring Remote Inputs 2.7.5
Commissioning Tasks 2.8.1
Pre-Commissioning Tasks 2.8.1
Commissioning 2.8.2
Going On-Air 2.8.9
Network Setup 2.8.10

NX5/NX3 INSTALLATION MANUAL TABLE OF CONTENTS
PAGE 2.VI VERSION 3.1 2021-04-22
Parts and tools 2.9.1
Contacting Nautel 2.9.1
Parts Supplied by Nautel 2.9.2
Parts Not Supplied by Nautel 2.9.2
Parts Ordering 2.9.2
Module Replacement Program 2.9.2
Tools for Installation 2.9.3
Pre-installation / Installation assistance 2.10.1
Pre-Installation Consulting 2.10.1
Installation and Commissioning Service 2.10.1
Online Documentation 2.10.2
On-Site Support 2.10.3
Training 2.10.3
Standard Warranty 2.10.4
Extended Warranties 2.10.7
List of terms 2.11.1

NX5/NX3 INSTALLATION MANUAL
VERSION 3.1 2021-04-22 PAGE 2.VII
Release Control Record
ISSUE DATE REASON
3.0 2019-06-01 Supports NX5/NX3 hardware NARA66B implementing
NAP39C RF Power modules and a shielded arc detector
assembly. Supports NX SW version 5.0 and higher.
3.1 2021-04-22 Implemented Castor Kit update.

NX5/NX3 INSTALLATION MANUAL
PAGE 2.VIII VERSION 3.1 2021-04-22

NX5/NX3 INSTALLATION MANUAL PREPARING FOR INSTALLATION
VERSION 3.1 2021-04-22 PAGE 2.1.1
SECTION 2.1: PREPARING FOR INSTALLATION
Before installing your NX5/NX3 transmitter, perform the following steps:
1. Ensure that you have performed the pre-installation tasks described in the
NX5/NX3 Pre-Installation Manual .
2. Make sure that you received all the components. (Check your packing list.)
3. Inspect all crates and packages for damage. Inspect the tip and drop indicators attached to the
crates to determine if a crate has been tipped over or has been subjected to excessive shock (see
Figure 2.1.1).
Figure 2.1.1: Tip and drop indicators
4. Report any damage immediately to your Nautel sales representative and the carrier.
5. Move the crates as close as possible to the transmitter’s planned location.
6. Unpack the crates in accordance with the instructions provided on the outside of the crates.
For each crate, remove the panel labelled open this side. The panel is attached using Phillips
head screws.
Remove any visible packing material, including braces, from the crate's interior.
Remove the remaining outer plywood shell by unscrewing the outer wood panels from the
pallet under the transmitter.

NX5/NX3 INSTALLATION MANUAL PREPARING FOR INSTALLATION
PAGE 2.1.2 VERSION 3.1 2021-04-22
7. Review any assembly notes or instructions contained inside the transmitter crates. (For sites
requiring custom configurations, the instructions provided with the transmitter replace the
instructions provided here.)
8. Assemble your parts and tools. For a list of required tools, see “Parts and tools” on page 2.9.1.
9. When you are ready to install the NX5/NX3 transmitter, follow the steps shown in Figure 2.1.2 on
page 2.1.2.
Figure 2.1.2: Flowchart - Installing the transmitter
TIP When you have completed a task or step, put a check mark beside the step number.
CAUTION! FAILURE TO COMPLY WITH RECOMMENDATIONS MAY VOID YOUR
MANUFACTURER’S WARRANTY. FOR MORE INFORMATION, REVIEW YOUR
WARRANTY DOCUMENT.
Unpacking and Positioning - see page 2.2.1
Connecting the Station Reference Ground - see page 2.3.1
Installing Control/Monitor Wiring - see page 2.7.1
Commissioning Tasks - see page 2.8.1
Perform operational tasks:
“Commissioning”, “Modulation Checks” and “Going On-Air”, beginning on page 2.8.2
Connecting Ac Power - see page 2.4.1
Installing Audio Inputs - see page 2.6.1
Adjusting the Spark Gap - see page 2.5.1

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
VERSION 3.1 2021-04-22 PAGE 2.2.1
SECTION 2.2: UNPACKING AND POSITIONING
To install an NX5/NX3 transmitter, perform the following tasks:
NOTE: The NX5/NX3 is housed in a single cabinet, which includes the power transformer. The cabinet is
designed for installation with or without a forklift. Both methods of installation are described in this
section. Crated and uncrated cabinet weights are shown in Table 2.2.1.
Table 2.2.1: NX5/NX3 Weight
1. Ensure the NX5/NX3’s outer plywood shell has been removed.
2. Lift the transmitter off the pallet, using a forklift or sufficient manpower. If you are using a forklift,
lift the NX5/NX3 from the front or rear of the cabinet (see Figure 2.2.1 on page 2.2.2).
NOTE: If you are using a forklift, ensure the two forks will fit together in the space provided.
3. Move the NX5/NX3 into its final position, using one of the following methods:
using a forklift, if available, and go to Step 5.
using a pallet jack, and go to Step 5.
NOTE: If you are using a pallet jack, ensure that one fork of the pallet jack is centered under
the transmitter cabinet and that an additional person is available to assist with stabilizing the
transmitter while it is being lifted and moved.
installing the optional casters to roll the transmitter, as detailed in Step 4.
WARNING! DO NOT ATTEMPT TO MOVE THE TRANSMITTER CABINET
UNLESS SUFFICIENT MANPOWER OR MECHANICAL ASSISTANCE IS
AVAILABLE TO MOVE IT INTO POSITION WITHOUT DAMAGING THE CABINET
OR CAUSING INJURY TO PERSONNEL.
CAUTION! THE NX5/NX3 CONTAINS ADJUSTABLE FEET THAT ALLOW
LEVELING OF THE CABINET IN ITS FINAL POSITION. ENSURE THE LEVELING
FEET ARE FULLY RETRACTED (UP) BEFORE MOVING THE NX5/NX3. FAILURE
TO DO SO MAY CAUSE DAMAGE TO THE LEVELING FEET AND ATTACHED
METALWORK.
CRATED WEIGHT UNCRATED WEIGHT
317 kg (696 lbs) 261 kg (573 lbs)
NOTE: Weights assume standard method of shipping, which includes power transformer in cabinet.

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
PAGE 2.2.2 VERSION 3.1 2021-04-22
Figure 2.2.1: Lifting Access for Forklift or Pallet Jack
Partial Front View
(lower dress panel
removed for clarity)
Dimensions of opening:
17 in (430 mm) wide
3.5 in (90 mm) high
Extends through rear of cabinet

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
VERSION 3.1 2021-04-22 PAGE 2.2.3
4. Nautel can provide an optional NX-LP Caster Kit (Nautel part # 212-8055) to aid in moving the
transmitter into position. If you are using the casters to roll the NX5/NX3 into position, perform the
following (see Figure 2.2.2 on page 2.2.4):
Open the front and rear doors of the NX5/NX3. Remove the four hole plugs from each bottom
corner to expose the top of the threaded leveling feet.
Use the 3/16-inch hex bit socket (Nautel Part # HY120, provided in the ancillary kit) and a 3/8-
inch drive ratchet (user provided) to extend each leveling foot to the transmitter room floor.
Continue to extend the levelers so that the NX5/NX3 is approximately 1” (25 mm) above the
floor.
Obtain the four casters (Nautel Part # HAW73), eight spacers (Nautel Part # 212-8166),
sixteen (16) M8 x 30-mm hex bolts, and M8 nuts and washers from the Caster kit (Nautel part
# 212-8055).
Use two spacers, four M8 bolts, nuts and washers to secure each caster to the bottom of the
NX5/NX3 (see Figure 2.2.2 on page 2.2.4).
NOTE: It may not be possible to install all four (4) bolts in the front casters. Install at least two
(2) bolts, in opposite corners, taking care not to damage the power transformer.
Use the 3/16-inch hex bit socket to retract the levelers until the casters rest on the floor.
Continue to retract the levelers a further 1” (25 mm).
Roll the NX5/NX3 into its final position. Extend the levelers to elevate the casters off the floor.
Remove the casters and associated hardware. Store them for future use.
Adjust the levelers until the NX5/NX3 rests on the floor.
5. If you are not anchoring your transmitter, adjust the levelers until the NX5/NX3 is level. If you are
anchoring your transmitter against seismic activity, obtain four 2-1/4 inch square washers (Nautel
Part # HPS30) from the ancillary kit. Position the transmitter over the four pre-drilled mounting
holes in the floor (see Figure 1.2.1 of the NX5/NX3 Pre-Installation Manual for pre-drilled hole
locations) and install four anchoring bolts (user-provided), with square washers, in the holes
provided in the bottom of the transmitter cabinet (see Figure 2.2.3 on page 2.2.5).
NOTE: The maximum bolt length that can be used for seismic anchoring is dependent on the height
of the cabinet opening above the anchor holes [3.5 inches (9 cm)] and the tool you are using to
anchor the bolts. If the bolts are too long, try jacking up the transmitter cabinet (by adjusting the
levelers), then installing the bolts while slowly dropping the height of the transmitter until it rests
on the floor.
6. Obtain the front dress panel (Nautel Part # 212-8122-01) and rear dress panel (Nautel Part #
212-8122-02) from the ancillary kit. Install the panels as shown in Figure 2.2.4 on page 2.2.5.

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
PAGE 2.2.4 VERSION 3.1 2021-04-22
Figure 2.2.2: Installing Casters and Leveling the Cabinet
Spacer plates
M8 hardware
(212-8166)
(bolt,
flat,
split,
nut)
Caster
(HAW73)

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
VERSION 3.1 2021-04-22 PAGE 2.2.5
Figure 2.2.3: Seismic Anchoring Hole Locations
Figure 2.2.4: Installing Dress Panels
Partial Front View Partial Rear View
Dress Panel 212-8122-01
Align hooks in panel with
slots in transmitter cabinet
Dress Panel 212-8122-02
M5 screws (HMSP32F)
Install panel using six

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
PAGE 2.2.6 VERSION 3.1 2021-04-22
7. If you are using a closed air cooling configuration (see the NX5/NX3 Pre-Installation Manual for
details):
Obtain the cover plate (Nautel Part # 212-5052) that was packed with the NX5/NX3
ancillaries.
Loosen the four (4) quarter-turn fasteners that secure the filter bracket to the rear door and
remove the filter bracket (see Figure 2.2.5 on page 2.2.7).
Install the cover plate in its place and tighten its quarter-turn fasteners.
Remove the cover plate from the top of the NX5/NX3 (see Figure 2.2.5 on page 2.2.7) and
attach the user-provided air intake duct.
8. Verify that the ac power cable from the ac power disconnect switch is long enough to reach
through the entry point at the top or bottom of the NX5/NX3, to the transformer’s primary
terminals at the bottom of the NX5/NX3.
9. Install the RF output connector as follows (see Figure 2.2.6 on page 2.2.8 or Figure 2.2.7 on page
2.2.9):
NOTE: The RF output connector for an NX5/NX3 can be configured for an 1-5/8 inch or 7/8 inch EIA
connector. An output connector kit for the predetermined connector is provided with the ancillaries. The
user must provide the appropriate inner male (bullet) connector and field flange connector to complete
the RF output connector.
Obtain the appropriate output connector kit (Nautel Part # 212-6200 for 1-5/8 inch or Nautel
Part # 212-6200-01 for 7/8 inch), which was packed with the ancillary crate. Install the output
cup, spacer plate and stud plate as shown in Figure 2.2.6 on page 2.2.8 (1-5/8 inch EIA) or
Figure 2.2.7 on page 2.2.9 (7/8 inch EIA), using hardware provided in the kit.
Install the user-provided inner male (bullet) connector in the RF output cup and install the
user-provided field flange on top of the stud plate. Secure using provided hardware. RF feed
cable installation is completed later in this manual.
10. Verify that the RF feed cable reaches the RF output connector on the top of the NX5/NX3.
11. Remove the rear door’s securing screws and open the rear door. Locate the arc detector assembly
(A24) (see Figure 2.2.8 on page 2.2.10) and remove the protective packing material that was added
to prevent shipping damage. Close and secure the rear door.

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
VERSION 3.1 2021-04-22 PAGE 2.2.7
Figure 2.2.5: Installing Rear Plate and Removing Top Cover Plate - Closed Air Cooling only
Loosen 4 quarter-turn
fasteners to
remove filter bracket.
Use same holes to install
cover plate. Tighten its 4
quarter-turn fasteners
Partial Rear View
Remove top cover
plate.
Partial Top View

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
PAGE 2.2.8 VERSION 3.1 2021-04-22
Figure 2.2.6: RF Output Connector Detail: 1-5/8-inch EIA
TORQUE to 44 in-lbs (4.9 N-m)

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
VERSION 3.1 2021-04-22 PAGE 2.2.9
Figure 2.2.7: RF Output Connector Detail: 7/8-inch EIA
TORQUE to 44 in-lbs (4.9 N-m)

NX5/NX3 INSTALLATION MANUAL UNPACKING AND POSITIONING
PAGE 2.2.10 VERSION 3.1 2021-04-22
Figure 2.2.8: Location of Arc Detector Assembly
Arc Detector Assembly (A24)
Partial Rear View; Rear Door Removed for Clarity
