NavLinkz RL4-MIB-HA User manual

Version 25.06.2019 HW: CAM(V98)/UP(V20) RL4-MIB-HA
r.LiNK Video inserter
RL4-MIB-HA
Compatible with
Audi vehicles with MMI Radio (Plus)
or MMI Navigation (Plus)
with 8.8inch or 10.1inch monitor
Video-inserter for front- and rear-view camera
and two more video inputs
Product features
Video-inserter for factory-infotainment systems
1 CVBS Input for rear-view camera
1 CVBS Input for front camera
2 CVBS Video-inputs for after-market Video sources (e.g. USB-Player, DVB-T Tuner)
Automatic switching to rear-view camera input on engagement of the reverse gear
Automatic front camera switching after reverse gear for 5 seconds
Video-in-motion (ONLY for connected video-sources)
Video-inputs NTSC compatible

Version 25.06.2019 HW: CAM(V98)/UP(V20) RL4-MIB-HA
Page2
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Checking the compatibility of vehicle and accessories
1.3. Boxes and connectors –video interface
1.4. Settings - 8 Dip switches (black)
1.4.1. Activating the front camera (dip 1)
1.4.2. Enabling the interface’s video inputs (dip 2-3)
1.4.3. Rear-view camera setting (dip 5)
1.4.4. Monitor selection (dips 6-8)
1.5. Settings - 4 Dip switches (CAN function –red)
2. Installation
2.1. Place of installation
2.2. Connection schema
2.3. Connection - factory head unit
2.3.1. Connection - picture signal cable
2.3.1.1. Connection –picture signal cable to Harman head unit
2.3.1.2. Connection –picture signal cable to other head units except Harman
2.3.2. Connection - Quadlock - CAN
2.3.3. Connection - Power
2.3.4. Analog power supply
2.4. Power supply output
2.5. Connection - video-sources
2.5.1. Audio insertion
2.5.2. After-market front camera
2.5.3. After-market rear-view camera
2.5.3.1. Case 1: Interface receives the reverse gear signal
2.5.3.2. Case 2Interface does not receive the reverse gear signal
2.6. Connection - video-interface and external keypad
2.7. Picture settings
3. Interface operation
3.1. By factory infotainment button
3.2. By keypad
4. Specifications
5. FAQ –Trouble Shooting-Interface functions
6. Technical support

Version 25.06.2019 HW: CAM(V98)/UP(V20) RL4-MIB-HA
Page3
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. Apart from using this
product in an unmoved vehicle, it should only be used to display fixed menus or rear-view-
camera video when the vehicle is moving (for example the MP3 menu for DVD upgrades).
Changes/updates of the vehicle’s software can cause malfunctions of the interface. Up to
one year after purchase we offer free software-updates for our interfaces. To receive a free
update, the interface has to be sent in at own cost. Wages for de-and reinstallation and
other expenditures involved with the software-updates will not be refunded.
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
video interface’s place of installation must be free of moisture and away from heat sources.
Before the final installation in the vehicle of the video sources, we recommend a test-run
to ensure the compatibility of vehicle and interface. Due to changes in the production of
the vehicle manufacturer there’s always a possibility of incompatibility.
1.1. Delivery contents
Take down the serial number of the interface and store this manual for support
purposes: ____________________

Version 25.06.2019 HW: CAM(V98)/UP(V20) RL4-MIB-HA
Page4
Requirements
Brand
Compatible vehicles
Compatible systems
Audi
A1 (GB) since 11/2018-
Q3 (F3) since 08/2018-
MMI Radio Plus or MMI Navigation Plus with MMI
Touch und 8.8 or 10.1inch monitor
Limitations
Video only The interface inserts ONLY video signals into the infotainment. For
inserting Audio signals either the possibly existing factory audio-AUX-
input or a FM-modulator can be used. If 2 audio sources shall be
connected to the infotainment, an additional electronic is necessary to
switch them.
Factory rear-view camera Automatically switching-back from inserted video to factory rear-view
camera is only possible while the reverse gear is engaged. To delay the
switch-back an additional electronic part is required.
After market front camera The front camera will automatically be switched for 5 seconds after
disengaging the reverse gear. A manually front camera switching is
possible by external keypad.
Video input signal Only NTSC video sources compatible
1.2. Checking the compatibility of vehicle and accessories
1.3. Boxes and connectors –video interface
The video-interface converts the video signals of connected after-market sources in a factory
monitor compatible picture signal which is inserted in the factory monitor, by using separate
trigger options. Further it reads the vehicle’s digital signals out of the vehicle’s CAN-bus and
converts them for the video interface.

Version 25.06.2019 HW: CAM(V98)/UP(V20) RL4-MIB-HA
Page5
1.4. Settings - 8 Dip switches (black)
Some settings have to be selected by the dip-switches on the
video interface. Dip position down is ON and position up is OFF.
In case of a non-optimal displayed picture with the mentioned dip settings of dips 6, 7 and
8, we recommend to try each other possible dip switch combination.
After each Dip-switch-change a power-reset of the Can-box has to be performed!
*The front camera will automatically be switched for 10 seconds after disengaging the
reverse gear.
See the following chapters for detailed information.
Dip
Function
ON (down)
OFF (up)
1
Front camera
enabled*
disabled
Power supply
output
(red wire)
+12V (max. 3A) when reverse
gear is engaged incl. 10 seconds
delay and +12V by manual
switching to front camera by
keypad
+12V (max. 3A) ACC
2
Video 1-input
enabled
disabled
3
Video 2-input
enabled
disabled
4
No function
set to OFF
5
Rear-view cam
type
after-market
factory or none
6
Monitor
adjustment
8.8 und 10.1inch monitor with Harman HU
dip6 ON/ dip7 OFF/ dip8 OFF
7
8.8 Zoll monitor except Harman HU: dip6 OFF/ dip7 ON/ dip8 OFF
8
10.1 Zoll monitor except Harman HU: dip6 OFF/ dip7 OFF/ dip8 OFF
