NCR 7358-K111 User manual

Kit Instructions
1-Bag Bagwell Upgrade
7358-K111
Issue A

The product described in this document is a licensed product of NCR Corporation.
NCR is a registered trademark of NCR Corporation. NCR FastLane SelfServ™ Checkout is a trademark of NCR Corporation in
the United States and/or other countries. Other product names mentioned in this publication may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing LLC in the United States and other countries.
Where creation of derivative works, modifications or copies of this NCR copyrighted documentation is permitted under the terms
and conditions of an agreement you have with NCR, NCR's copyright notice must be included.
It is the policy of NCR Corporation (NCR) to improve products as new technology, components, software, and firmware become
available. NCR, therefore, reserves the right to change specifications without prior notice.
All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances,
photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR
office for information that is applicable and current.
To maintain the quality of our publications, we need your comments on the accuracy, clarity, organization, and value of this book.
Please use the link below to send your comments.
Email: [e-mail]
Copyright © 2020
By NCR Corporation
Global Headquarters
864 Spring St. NW
Atlanta, GA 30308
United States
All Rights Reserved

i
Revision Record
Issue Date Remarks
AOct 2019 First Issue

1-Bag Bagwell Upgrade
This publication provides procedures for upgrading an NCRFastLane SelfServ™
Checkout (7358), either a No-Bag unit or a unit with an existing Bagwell, with a 1-Bag
Bagwell.
The NCRFastLane SelfServ™ Checkout (7358) R6L Plus with a Bagging Area (Bagwell)
Module or Large Basket (Basket) Module can be configured for either Left-hand (LH)
orientation or Right-hand (RH) orientation, which refers to the direction customers
scan and bag items.
•Left-hand (LH) orientation—Customers scan from left to right.
•Right-hand (RH) orientation—Customers scan from right to left.
Note: The orientation of the unit is determined by the position of the Lower Core
(Cabinet) Module in relation to the Bagging Area (Bagwell) Module or Large Basket
(Basket) Module.
Example: The Left-hand (LH) unit has the Cabinet positioned on the left side of the
Bagwell or Basket.

2 1-Bag Bagwell Upgrade
Kit Contents
Part Number Description
497-0526492 Kit - 1 Bagwell Module, Bumpers, Skirts (Dark White)
795-0283431 Assembly - 1 Bag Door (NCR Dark White)
795-0137231 Panel - Backsplash - 1 Bag (NCR Dark White)

1-Bag Bagwell Upgrade 3
Part Number Description
795-0137131 Panel - 1 Bag - Front (NCR Dark White)
795-0133331 Panel - 1/2/3 bagwell side (NCR Dark White)
795-0281601 Hole Cover Label - (NCR Dark White)
497-0466204 Skirt-Mini BOM package
497-0464170 Assembly - 1 bagger frame with leveling feet and casters
497-0472267 1-Bag scale tray with bag rack hardware
497-0467814 Assembly - Scale Controller and Pods
497-0457365 Plastic deflector - backsplash side - 1-Bag
497-0457054 Black Nylon Spacer 15mm OD x 10.4mm ID x 10mm L (8 pcs)
497-0455519 Plastic deflector - core side
497-0518271 Bumper - 1-Bag Upper
497-0445077 Cable: (Black) 4M USB +Power (12V) to 2x4 Latch-N-Lok
009-0005930 Cable Tie-Snap in Mounting
006-8612492 Screw - ¼-20 x 0.750 in, Phillips Flat Head, 82 Degree, Machine
Thread, Zinc-Plated Steel (8 pcs)
006-8612446 Screw - 8-32 x 0.375 in Phil Pan, Self Tapping - Type F (7 pcs)
006-8616060 Screw - ¼-20 x 0.75 in, Pan Head, Phillips, Zinc Plated Steel (8
pcs)
006-8623998 Screw - ¼-20 x 1-21/64 in, Phillips Flat Head, 82 Degree, Machine
Thread, Zinc-Plated Steel (4 pcs)
006-8611505 Bushing, Nylon (2 pcs)
006-8611143 Nut Keps, 8-32, Steel, Blue Zinc (5 pcs)
006-8604541 Screw, ¼-20 x ½, Pan Head, Phillips (4 pcs)
497-0421485 Power Strip, IEC 4-POS, Plastic Case
497-0426042 Bag - 2 and 3.5 Bagger, LHC and RHC, Input Belt
497-0518277 Bumper - 1, 2, 3 Bag Side, Wrap Around Corner
007-9714414 Tiestrap Plain 5.60 LG (4 pcs)
* 497-0423108 Instructions - Kit (Reference Sheet)
* Items marked with an asterisk are not called out on the image.

4 1-Bag Bagwell Upgrade
Installation Procedures
Installing the Bagwell upgrade involves the following procedures:
•Removing Existing Bagwell on the facing page.
•Changing Bagwell Orientation on page10.
Note: This procedure may be optional.
•Installing New Bagwell on page16.
•Installing Bagwell Skirt Panels on page23.
•Routing Cables on page25.

1-Bag Bagwell Upgrade 5
Removing Existing Bagwell
To remove an existing 1-Bag Bagwell, follow these steps:
Note: To remove a 2-Bag Bagwell, refer to . To remove a 3-Bag Bagwell, refer to .
1. Detach the Scale Tray from the Bagwell by removing four (4) flat head screws.
Note: Remove bag racks if present.

6 1-Bag Bagwell Upgrade
2. Remove the clear plastic deflectors from the Backsplash and side of the Core.
Note: Leave the Core side deflector in its place if the new Bagwell is attached on the
same side.

1-Bag Bagwell Upgrade 7
3. Disconnect the following cables:
• USB Power Cable from the Scale Controller
• Local Area Network (LAN) Cable from the Customer Interface
• ACPower Out Cables from the Power Strip
• AC Power In Cable from the Power Strip
Note: Remove cables from any routing clips or tie wraps if needed.
4. Route the following cables through the cable access hole:
Bagwell Cable Access Hole
• AC Power In Cable
Core Cable Access Hole
• USB Power Cable
• Local Area Network (LAN) Cable
• AC Power Out Cables
Note: The Local Area Network (LAN) Cable and ACPower In Cable may be routed
differently depending on the installation conditions.

8 1-Bag Bagwell Upgrade
5. Remove the upper rear screw attaching the Backsplash to the Core.
6. Remove the Bagwell by doing the following:
a. Remove the two (2) bottom screws attaching the Bagwell to the Core. Screws are
located on either side of power strip.

1-Bag Bagwell Upgrade 9
b. Loosen the two (2) upper screws, but do not remove.
c. Lift Bagwell up and away from the Core Cabinet. The upper screw heads will
pass through the key holes in the Bagwell side support.
Note: The two (2) upper screws may be left in place if a new Bagwell will be
installed in the same orientation. Otherwise, remove the screws from the side of
the Core.

10 1-Bag Bagwell Upgrade
Changing Bagwell Orientation
To change the Bagwell orientation, follow these steps:
Note: These steps should be done before attaching the Bagwell to the Core. For the
purpose of illustration only, this procedure shows images using Left-hand (LH)
orientation.
1. Detach the Scale Tray from the Bagwell by removing four (4) flat head screws.

1-Bag Bagwell Upgrade 11
2. Remove the bumpers by doing the following:
Note: Do not remove the front access door bumper.
a. Detach the lower-rear bumper from the Bagwell by removing two (2) flat head
screws.

12 1-Bag Bagwell Upgrade
b. Detach the Backsplash from the Bagwell by removing four (4) flat head screws.
c. Detach the upper bumper from the Bagwell by removing five (5) flat head screws
and spacers, as shown in the image below.

1-Bag Bagwell Upgrade 13
d. Detach the wrap-around side bumper by removing three (3) flat head screws and
spacers, as shown in the image below.
3. Remove two (2) nuts securing the front panel to the Bagwell frame located at the
inside corner posts.

14 1-Bag Bagwell Upgrade
4. Pull down the front panel and then pull out to disengage from the slots in the
Bagwell frame base, as shown in the image below.
5. Install the front panel on the opposite side of the Bagwell and secure it with two (2)
nuts.
Note: Ensure that the lower hook features are properly aligned with the slots in the
Bagwell frame base.

1-Bag Bagwell Upgrade 15
6. Install the bumpers to the Bagwell by doing the following:
Note: Do not reinstall Scale Tray, Backsplash panel, and rear lower bumper (if
present). For more information, refer to Installing New Bagwell on the next page.
a. Attach the upper stainless steel bumper to the Bagwell by using five (5) flat head
screws and spacers.
b. Attach the wrap-around bumper to the Bagwell by using three (3) flat head
screws and spacers.

16 1-Bag Bagwell Upgrade
Installing New Bagwell
To install the new Bagwell, follow these steps:
Note: If changing the Bagwell orientation (Left-Hand or Right-Hand), ensure that the
orientation is changed before installing the new Bagwell to the Core. For the purpose of
illustration only, this procedure shows images using a Left-hand (LH) orientation unit.
1. Remove the Scale Tray from the Bagwell.
2. Remove the lower access panel from the Core side where the new Bagwell will be
attached. Reinstall the access panel on the opposite side of the Core.
Note: This panel does not need to be reinstalled when attaching a Bagwell to a No-
Bag Unit.

1-Bag Bagwell Upgrade 17
3. Lower all the leveling feet of the Bagwell slightly beyond the height of the casters to
assist in lining up the Core and the Bagwell mounting holes.
4. Install the new Backsplash panel using four (4) screws, as shown in the image below.
