Neatech EVO3 User manual

USER MANUAL
2019-01

DECLARATION OF CONFORMITY
The manufacturer
Neatech.it
Via A. de Curtis 4/A, 80040, Cercola (NA), Italy
declares that
the wheelchair EVO 3
(reference code: S042)
other names: EVO 3 –EVO3 FWD –EVO3 RWD –EVO 3 FWD –EVO 3 RWD
satisfies the requirements laid down by the European Directive 93/42;
according to the criteria for classification of Annex IX of this Directive, it is classified as:
class I medical device;
It also complies with the requirement of the harmonized standards:
EN ISO 14971:2012
UNI EN 12182:2012
UNI EN 12184:2009

Index
1PRODUCT INFORMATION ....................................................................................................... 1
2PREPARATION FOR FIRST USE ................................................................................................ 2
2.1 Checks to be made on delivery .......................................................................................2
2.2 Unpacking ........................................................................................................................ 2
2.1 Software description ....................................................................................................... 3
3ADJUSTMENTS ........................................................................................................................ 4
3.1 Seating system description..............................................................................................4
3.2 List of adjustments .......................................................................................................... 6
3.2.1 Version of the wheelchair with biomechanics movements.....................................6
3.2.2 Version of the wheelchair without biomechanics movements ...............................7
3.3 Armrests height - Version with biomechanical movements ...........................................8
3.4 Vertical armrests angle - Version with biomechanical movements .............................10
3.5 Horizontal armrests angle - Version with biomechanical movements .........................12
3.6 Backrest height - Version with biomechanical movements.........................................13
3.7 Joystick position - Version with biomechanical movements ........................................15
3.7.1 Standard support - Depth.......................................................................................15
3.7.2 Retractable support S045-V263 - Depth ................................................................16
3.8 Seat depth- Version without biomechanical movements.............................................17
3.9 Backrest angle- Version without biomechanical movements.......................................19
3.10 Armrests depth- Version without biomechanical movements .................................21
3.11 Armrests height- Version without biomechanical movements.................................24
3.12 Sidepad height- Version without biomechanical movements...................................26
3.13 Footplates height- Version without biomechanical movements .............................. 28
3.14 Footplates depth and angle- Version without biomechanical movements ..............30
3.15 Joystick position- Version without biomechanical movements ................................32
3.15.1 Standard support - Depth and height....................................................................32
3.15.1 Retractable support - Depth and height................................................................33
3.16 Default position..........................................................................................................34
4USE OF THE PRODUCT ..........................................................................................................35
4.1 Rnet 80 A control system ..............................................................................................41

4.2 Manual brake release lever ...........................................................................................43
4.3 Use as seat in a motor vehicle.......................................................................................45
4.3.1 Securing the wheelchair with Four points tie-down system..................................52
4.3.2 Dahl engineering docking station...........................................................................54
4.4 Powered functions.........................................................................................................56
4.5 Main switch ...................................................................................................................63
4.6 Battery charging ............................................................................................................65
4.7 Transport and storage ...................................................................................................67
4.7.1 Batteries removal ...................................................................................................67
5MAINTENANCE .....................................................................................................................71
5.1 Maintenance and cleaning ............................................................................................71
5.2 Controls to be performed on the product.....................................................................72
5.3 Tire puncture .................................................................................................................73
5.3.1 User information .................................................................................................... 73
5.4 Wiring diagram ..............................................................................................................77
5.5 Batteries replacement ................................................................................................... 78
5.6 Reuse .............................................................................................................................84
5.7 Spare parts.....................................................................................................................85
5.7.1 Antitip wheels.........................................................................................................87
5.7.2 Cover A....................................................................................................................89
5.7.3 Cover B....................................................................................................................91
5.7.4 Standard joystick support.......................................................................................93
5.7.5 Retractable joystick support...................................................................................95
5.7.6 Joystick....................................................................................................................97
5.7.7 Castor light kit.........................................................................................................99
5.7.8 Mudguard light kit ................................................................................................ 102
5.7.9 Bumpers for motors .............................................................................................104
5.7.10 Legrest cover ........................................................................................................106
5.7.11 Footplate...............................................................................................................108
5.7.12 Backrest cover ......................................................................................................110
5.7.13 Ruler for armrest adjustment...............................................................................111
5.7.14 Armrest joint.........................................................................................................113

5.7.15 Armrest .................................................................................................................115
6SPECIFICATIONS ..................................................................................................................117
6.1 Maximum user weight.................................................................................................118
6.2 Other provided information ........................................................................................119
6.3 Dimensions ..................................................................................................................120
6.3.1 - Version with biomechanical movements........................................................... 120
6.3.2 - Version with biomechanical movements........................................................... 121
7Warranty terms ..................................................................................................................122
7.1 Serial number ..............................................................................................................122

Symbols in this manual
WARNING
This symbol means presence of danger for the user or damage for the
product. Always follow instructions when this symbol is present.
PINCH HAZARD
This symbol means presence of pinch hazard.
ELECTRICAL WARNING
This symbol means presence of danger related to the presence of electrical
energy. Please pay special attention when this symbol is present.
INFORMATION
This symbol means general information intended to simplify or best explain
the use of the product.
CONTACT INFORMATION
This symbol means the need of contacting an authorized service center or
the manufacturer.

TEMPERATURE
The temperature of some surfaces may increase when the product is
exposed to external heat sources as direct sunlight.
TIPPING HAZARD
Tipping hazard is strongly reduced because of the design of the product
according to EN 12182.
In any case, please pay special attention during the adjustments and use of
the product to prevent any damage to the user or product itself.
Any transport on a slope greater than the maximum safety slope can be
dangerous.
Please don’t seat on armrests.
ANTI-TIP DEVICES
Using anti-tippers substantially reduces your risk of falling over, which can
cause serious injury. The Anti-Tippers will keep you from falling over, but
they will limit your ability to be pulled up curbs and some other maneuvers.
IT IS NOT POSSIBLE TO HAVE THIS WHEELCHAIR WITHOUT ANTITIP
DEVICES.
Center of balance of the wheelchair and so its stability cab be affected by:
•User position
•Us of a backpack
•Tilting of the seat
PINCH HAZARD
Make sure your feet do not hang up or get caught in the space between the
footrests. In general, make sure you have proper space in areas you will
travel through to minimize pinching or entrapment of body parts.

ELECTROMAGNETIC RADIATION DANGER
The behavior of the wheelchair while driving may be affected by
electromagnetic fields created by transceivers such as: Citizens band (CB)
radios, walkie-talkies, fire and police radios, cellular phones, lap-top
computers, commercial radio and television broadcast antennas. PLEASE
USE CAUTION in the presence of these devices.
Electromagnetic radiation can cause your chair, without warning, to:
• release its brakes
• move by itself
• move in unintended directions
If any of these occur, it could result in severe injury to you or others.
Electromagnetic radiation can damage the control system of your chair.
There is no way to know the effect on electromagnetic immunity if you add
accessories or modify this chair. Any change to your chair may increase the
risk related to electromagnetic radiation. Parts from other suppliers have
unknown electromagnetic properties. The wheelchair might disturb the
operation of devices in its environment.
INFORMATION
For information on how to obtain information and instructions in a format
appropriate for use by visually impaired people please contact the
manufacturer.

Service manual is intended for technical personnel to maintain and repair wheelchairs. It is
important to follow the instructions contained in this manual in order to professionally work
with the product.
The qualified personnel who works with wheelchairs must comply with all provisions of
occupational safety and common sense in order to preserve his own safety.
The manufacturer declines all responsibility for any accidents occurring during the working with
the product.
WARNING: It is prohibited to use the product or its parts for any purpose other
than that indicated. For a correct use please follow the instructions given in this
manual. The manufacturer disclaims any responsibility for damages caused by
improper use of the product.
The manufacturer disclaims any responsibility for inappropriate selection of product model and
configuration.

Information in this manual may be subject to change without notice. All information, pictures and
specifications are based on the product details that were available at the time of preparation of this
document. They are representative examples and they are not intended to be exactly as the actual product.
MODIFICATIONS
Any unauthorized modification to the product may increase the risk of personal injury and damage to the
product itself. All modifications should be done by an authorized service center.
Do not use any unauthorized accessories or spare parts on the product. Do not use the product in
combination with other medical devices without first having considered any risk due to combination of
more products.
MANUFACTURER
For any need not expressly explained in this manual, please contact the manufacturer.
Neatech.it SRL
via A. de Curtis 4/A, 80040, Cercola (NA), Italy
www.neatech.it –[e-mail] - [phone]
INCIDENT REPORTING
If an incident occurs, please contact an authorized service center. For a list of authorized service center
please contact the manufacturer.
DISPOSING
This product and all its components can not be treated as household waste. For
more detailed information on how recycling and disposal this product contact your
local waste disposal service.

www.neatech.it
1/122
1PRODUCT INFORMATION
The EVO 3 offers a sleek design and superior performance, the top of its category, providing a
perfect combination of stability and maneuverability.
Born from the passion of Neatech for high engineering, which allows it to offer a broader
spectrum of choices than in the past; it is a quality product that features an elegant design and
performance.
Total length
Total width
Seat height
1100 mm
MIN 560 mm –MAX 615 mm
MIN 460 mm –MAX 480 mm
Total wheelchair weight
Maximum user weight
MAX 125 kg
MAX 80 kg
Seat width
MIN 300 mm –MAX 420 mm
Batteries
Charger
Power module
Motors
2x 55 Ah GEL
6 A
Rnet 80 A
2x 220 W

www.neatech.it
2/122
2PREPARATION FOR FIRST USE
2.1 Checks to be made on delivery
•Check for the integrity of the original packaging.
•Check for any anomalies on shipping documents.
•Check for the functionality and integrity of the device in all its parts, at the time of delivery
or immediately thereafter, to ensure that no damage has resulted from a careless transport.
•Make sure the surface of the device is not damaged, scratched, bent, etc.
•Any fault or damage found must be immediately reported on the shipping documents and
promptly communicated to the shipper.
2.2 Unpacking
Inside the box there are:
•Evo3 wheelchair
•Documents and manual
•Charger
The wheelchair is delivered already mounted and ready to use. Before starting to use the
wheelchair please check if all described components are present. If not, please contact as soon
as possible the vendor.
PACKAGING DISPOSAL
To properly recycle the packaging materials follow instructions provided
by your local waste disposal service.

www.neatech.it
3/122
2.1 Software description
The software of the wheelchair can be categorized into these classes:
•Kernel software of power module.
There is no required access, modification or customization of this part of the software
In case a reprogramming of the wheelchair is required, please contact the
manufacturer to have instructions and the most suitable version of the
software.
In case of problems with this part of the software please contact the
manufacturer.
•Kernel software of seating module.
There is no required access, modification or customization of this part of the software
In case a reprogramming of the wheelchair is required, please contact the
manufacturer to have instructions and the most suitable version of the
software.
In case of problems with this part of the software please contact the
manufacturer.
•Software parameters of the wheelchair.
This part of the software is made by the manufacturer. It is intended to assure driving and
seating function of the wheelchair. It is responsibility of the manufacturer to correct program
parameters regarding the structure of the wheelchair.
Qualified personnel of an authorized service center are able to customize this part of the
software to best fulfill single user requirements.
Programming must be conducted only by qualified personnel with in-
depth knowledge of the wheelchair and power module system.
Any change to this part of the software may result in a hazardous situation
for the user.

www.neatech.it
4/122
3ADJUSTMENTS
3.1 Seating system description
•Seat height (B): this is the height of seat measured starting from the chassis (line a). When
seat angle is different from zero, you should have two different values for front and back
seat height.
Figure 1
•Seat angle (C): this is the angle between the seat and the chassis (line a). Seat angle is
positive when the seat is tilted rearward, zero when the seat is horizontal and negative when
the seat is tilted forward.
•Absolute backrest angle (D): this is the angle between the backrest and the seat.
•Backrest angle (E): this is the angle between the backrest and the chassis of the wheelchair
(line a). Only when seat angle is zero, absolute backrest angle is equal to backrest angle.
Figure 2
•Absolute legrest angle (F): this is the angle between the legrest and line perpendicular to
the seat (g).
•Legrest angle (H): this is the angle between the legrest and the line perpendicular to the
chassis of the wheelchair (line m). Only when seat angle is zero, absolute legrest angle is
equal to legrest angle.
B
a
D
C
a
E

www.neatech.it
5/122
Figure 3
g
F
H
m
a

www.neatech.it
6/122
3.2 List of adjustments
Type of operation
A
Operation intended to be performed by the user.
B
Operation intended to be performed by an assistant.
C
Operation intended to be performed by an authorized
service center.
Table 1
3.2.1 Version of the wheelchair with biomechanics movements
Adjustment
Section
Type of operation
Seat depth
Service Manual
C - Service
Armrests height
3.3
B - Assistant
Horizontal armrest angle
3.5
B - Assistant
Vertical armrest angle
3.4
B - Assistant
Footplates height
Service Manual
C - Service
Backrest height
3.6
B - Assistant
Joystick position
3.7
B - Assistant
Table 2

www.neatech.it
7/122
3.2.2 Version of the wheelchair without biomechanics movements
Adjustment
Section
Type of operation
Seat depth
3.8
B - Assistant
Backrest angle
3.9
B - Assistant
Armrests depth
3.10
B - Assistant
Armrests height
3.11
B - Assistant
Sidepad height
3.12
B - Assistant
Footplates height
3.13
B - Assistant
Footplates angle and depth
3.14
B - Assistant
Joystick position
3.15
B - Assistant
Table 3

www.neatech.it
8/122
3.3 Armrests height - Version with biomechanical movements
RANGE
It is not easy to provide a range for this adjustment because there are too
many configuration and possibilities.
Average needed
time:
<5 min
Difficulty level:
Easy
WARNING
As this adjustment is carried out, it is necessary to compensate by adjusting
also the armrest vertical angle.

www.neatech.it
9/122
Figure 4
•Loosen the 4 screws shown in figure.
ALLEN WRENCH
5 mm
Figure 5
•Adjust the bolt shown in figure in order to adjust
armrests height. Rotate it clockwise to rise the
armrest and counterclockwise to lower it.
•When finished, tighten again the 4 screws previously
loosen.
ALLEN WRENCH
5 mm
