NEC GT1150 Series Installation and user guide

Visual Systems
Rev 3.0
GT1150/2150 Installation Data
Desktop and Ceiling Mount
Definitions: H = Horizontal Screen Width (4:3)
Page 1
Contents
Product Description, Lens Specs, Notes and Formulas Page 1
Projection Distances and Screen Sizes
Ceiling Mount Installation Page 2
DesktopSetup Page 3
Lens Shift Adjustable Range Page 4
Cabinet Dimensions
Top, Front and Right Side Page 5
Bottom, Back and Left Side Page 6
Ceiling Mount Dimensions
Top, Front and Left Side Page 7
Bottom, Back and Right Side Page 8
PC Control Codes Page 9
Product Description
Type: 3 panel, 1.3” p-Si TFT w/MLA LCD projector Dimensions: 16.5”(W) x 8.25”(H) x 19.45”(D)
Native Resolution: GT1150: 1024 x 768 Weight: GT1150: 22.1 lbs w/o lens
GT2150: 1366 x 1024 GT2150: 28.3 lbs w/o lens
Brightness: GT1150: 3000 ANSI Lumens Power Lens Shift/Power Zoom/Power Focus
GT2150: 2500 ANSI Lumens
Lens Specifications
GT10RL Throw Ratio: 1.0:1(approx.) Focal Length: 27mm
Screen Sizes: 40”-300” F/#: 2.3
GT13ZL Throw Ratio: 1.3 - 1.6:1(approx.) Focal Length: 34.5 - 42.5mm
Screen Sizes: 40” - 300” F/#: 2.3 - 2.8
GT19ZL Throw Ratio: 1.8 - 2.4:1(approx.) Focal Length: 48.9 - 63.7mm
Screen Sizes: 40” - 300” F/#: 2.0 - 2.5
GT24ZL Throw Ratio: 2.4 - 3.4:1(approx.) Focal Length: 64.0 – 92.8mm
Screen Sizes: 60” - 400” F/#: 2.5 - 3.2
GT34ZL Throw Ratio: 3.4 - 5.2:1(approx.) Focal Length: 92.4 - 140.6mm
Screen Sizes: 80” - 500” F/#: 2.5 - 3.4
Notes
 For screen sizes not indicated on the projection tables, use the formulas below.
 If the figures on the tables do not match the results of formulas, use the figures in the table.
 The ceiling must be strong enough to support the LCD projector and the installation must be in accordance with any local
building codes.
• All calculations are based on 4:3 aspect ratio.
• Distances are in inches, for millimeters multiply by 25.4.
• Distances may vary ±5%.
Formulas
Units: Inches (for millimeters multiply final number by 25.4)
V= Vertical Screen Height (4:3)
C= Throw Distance
Projection Formulas: ScreenFormulas:
GT10RL: C = 1.027H – 2.468 H= Screen Diagonal x 4/5
GT13ZL: C(Wide) = 1.3099H – 2.325 ------- C(Tele) = 1.6111H – 2.325 V= Screen Diagonal x 3/5
GT19ZL: C(Wide) = 1.8639H – 3.228 ------- C(Tele) = 2.4231H – 3.228 Screen Diagonal = H x 5/4
GT24ZL: C(Wide) = 2.4282H – 4.799 ------- C(Tele) = 3.5209H – 4.799
GT34ZL: C(Wide) = 3.5523H – 6.786 ------- C(Tele) = 5.3284H – 6.786

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 2
Projection Distance and Screen Size for Ceiling Mount
The following shows the proper relative position of the projector and screen. Refer to the table for installation data.
Distances are in inches. For millimeters multiply by 25.4.
Ceiling Mount Installation
GT
Vertical Offset
Screen Ctr
Throw Distance
6.6"
9.7"
Lens Centered
with Mount
Note: Lens shift is not available on GT10RL(rear lens). GT10RL should be used only for “zero degree/no-offset” applications.
Distance Chart
rear lens
GT10RL
Diagonal Width(H) Height (V) 1.0:1
inches inches inches inches
40 32 24 30.4 39.6 - 49.2 56.4 - 74.3
60 48 36 46.8 60.6 - 75.0 86.2 - 113.1 111.8 - 164.2
67 53.6 40.2 52.6 67.9 - 84.0 96.7 - 126.7 125.4 - 183.9
72 57.6 43.2 56.7 73.1 - 90.5 104.1 - 136.3 135.1 - 198.0
84 67.2 50.4 66.6 85.7 - 105.9 122.0 - 159.6 158.4 - 231.8 231.9 - 351.3
90 72 54 71.5 92.0 - 113.7 131.0 - 171.2 170.0 - 248.7 249.0 - 376.9
100 80 60 79.7 102.5 - 126.6 145.9 - 190.6 189.5 - 276.9 277.4 - 419.5
120 96 72 96.1 123.4 - 152.3 175.7 - 229.4 228.3 - 333.2 334.2 - 504.7
150 120 90 120.8 154.9 - 191.0 220.4 - 287.5 286.6 - 417.7 419.5 - 632.6
180 144 108 145.4 186.3 - 229.7 265.2 - 345.7 344.9 - 502.2 504.7 - 760.5
210 168 126 170.1 217.7 - 268.3 309.9 - 403.9 403.1 - 586.7 590.0 - 888.4
240 192 144 194.7 249.2 - 307.0 354.6 - 462.0 461.4 - 671.2 675.3 - 1016.3
270 216 162 219.4 280.6 - 345.7 399.4 - 520.2 519.7 - 755.7 760.5 - 1144.1
300 240 180 244.0 312.1 - 384.3 444.1 - 578.3 578.0 - 840.2 845.8 - 1272.0
400 320 240 NA 772.2 - 1121.9 1130.0 - 1698.3
500 400 300 NA 1414.1 - 2124.6
Screen Size (4:3)
Throw Distance
NA
zoom lenses
3.4 - 5.2:1
NA
GT13ZL GT19ZL
NA
NA
GT24ZL GT34ZL
2.4 - 3.4:1
inches inches
NA
1.3 - 1.6:1 1.8 - 2.4:1
inchesinches
NA
NA NA
NANA
Note: For screen sizes not indicated on the projection tables, use the formulas on page 1.

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 3
Projection Distance and Screen Size for Desktop
The following diagram shows the relationship between projector position and the screen.
Distances are in inches. For millimeters multiply by 25.4.
Desktop Setup
Throw Distance
Screen Ctr
4.65"
Note: Lens shift is not available on GT10RL(rear lens). GT10RL should be used only for “zero degree/no-offset” applications.
Distance Chart
rear lens
GT10RL
Diagonal Width(H) Height (V) 1.0:1
inches inches inches inches
40 32 24 30.4 39.6 - 49.2 56.4 - 74.3
60 48 36 46.8 60.6 - 75.0 86.2 - 113.1 111.8 - 164.2
67 53.6 40.2 52.6 67.9 - 84.0 96.7 - 126.7 125.4 - 183.9
72 57.6 43.2 56.7 73.1 - 90.5 104.1 - 136.3 135.1 - 198.0
84 67.2 50.4 66.6 85.7 - 105.9 122.0 - 159.6 158.4 - 231.8 231.9 - 351.3
90 72 54 71.5 92.0 - 113.7 131.0 - 171.2 170.0 - 248.7 249.0 - 376.9
100 80 60 79.7 102.5 - 126.6 145.9 - 190.6 189.5 - 276.9 277.4 - 419.5
120 96 72 96.1 123.4 - 152.3 175.7 - 229.4 228.3 - 333.2 334.2 - 504.7
150 120 90 120.8 154.9 - 191.0 220.4 - 287.5 286.6 - 417.7 419.5 - 632.6
180 144 108 145.4 186.3 - 229.7 265.2 - 345.7 344.9 - 502.2 504.7 - 760.5
210 168 126 170.1 217.7 - 268.3 309.9 - 403.9 403.1 - 586.7 590.0 - 888.4
240 192 144 194.7 249.2 - 307.0 354.6 - 462.0 461.4 - 671.2 675.3 - 1016.3
270 216 162 219.4 280.6 - 345.7 399.4 - 520.2 519.7 - 755.7 760.5 - 1144.1
300 240 180 244.0 312.1 - 384.3 444.1 - 578.3 578.0 - 840.2 845.8 - 1272.0
400 320 240 NA 772.2 - 1121.9 1130.0 - 1698.3
500 400 300 NA 1414.1 - 2124.6
Screen Size (4:3)
Throw Distance
NA
zoom lenses
3.4 - 5.2:1
NA
GT13ZL GT19ZL
NA
NA
GT24ZL GT34ZL
2.4 - 3.4:1
inches inches
NA
1.3 - 1.6:1 1.8 - 2.4:1
inchesinches
NA
NA NA
NANA
Note: For screen sizes not indicated on the projection tables, use the formulas on page 1.

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 4
Lens Shift Adjustable Range
Normal Position
0.5V
(0.43V)
Desktop/Front
Vertical
0.5V
(0.43V)
Normal Position
Ceiling/Front
Vertical
+ -
+ -
Normal Position
0.25H
Horizontal
Lens Shift Range for Desktop and Ceiling Mount
Application
The diagram below shows the location of the image position
in the lens. The lens can be shifted within the shaded area as
shown using the normal projection position as a starting
point.
Note: Lens shift feature is not available with GT10RL (rear
lens). GT10RL should be used only for “zero degree” / “no-
offset” applications.
Maximum Possible Range
for GT19ZL/GT24ZL/GT34ZL (GT13ZL):
Up: 0.5V (0.43V)
Down: 0.5V (0.43V)
Right: 0.25H
Left: 0.25H
(H: width of projected image, V: height of projected image)
Note: If lens is shifted in two directions combined, maximum
range in either direction cannot be obtained due to rounded
off area near edge of lens. (example: shift up and right)
0.25H
0.25H
0.25H
0.25H
0.50V
0.50V 0.50V
0.50V
(0.43V) (0.43V)
(0.43V) (0.43V)
Normal projection
position
See diagram below.

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 5
Cabinet Dimensions
The following diagrams show the cabinet dimensions for the GT1150/2150.
Dimensions are in inches. For millimeters multiply by 25.4.
IN
OUT
PC CONTROL
IN
OUT
REMOTE@1
GT
1150
REMOTE
@2
SC TRIGGER
AC IN`
DVI L/MONO R
L/MONO R
MONITOR OUT RGB 1
RGB 2 R/Cr G/Y B/Cb
VIDEO 1
VIDEO 2
L/MONO R L/MONO R
L/MONO R L/MONO R
S-VIDEO AUDIO OUT
H/HV V
LAMPSTATUSPOWER
ON/STANDBY
AUTO
ADJUST
SOURCE
SELECT
¥
£
£
¥
MENU
ENTER
CANCEL
¥
£
¥
£
LENSSHIFT
+-
RIGHT
LEFT
UP
DOWN
+
-
+
-
FOCUSZOOM
16.50
19.45
GT2150 GT1150

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 6
Cabinet Dimensions (continued)
The following diagrams show the cabinet dimensions for the GT1150/2150.
Dimensions are in inches. For millimeters multiply by 25.4.
Ø0.41
0.039
8.25
4.65
4.09
5.51 8.47
19.45
9.84
9.45
16.50
MAX 4-M4X8
Ø0.41
12.21
11.22
12.504.33
4-Ø1.34

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 7
Optional Ceiling Mount Dimensions (Model #: GT50CM)
The following diagrams show ceiling mount dimensions for the GT1150/2150.
Dimensions are in inches. For millimeters multiply by 25.4.
10.04
9.50
9.79
4.25
45°
2.44
2.21
10.04
2.22
8.22

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 8
Optional Ceiling Mount Dimensions (Model #: GT50CM) (continued)
The following diagrams show ceiling mount dimensions for the GT1150/2150.
Dimensions are in inches. For millimeters multiply by 25.4.
10.686
10.50
10.775
10.00
1.355
.835

Visual Systems
GT1150/2150 Installation Data
Desktop and Ceiling Mount Rev 3.0
Page 9
PC Control Codes
Function Code Data
POWERON 02H 00H 00H 00H 00H 02H
POWER OFF 02H 01H 00H 00H 00H 03H
INPUT SELECT RGB 1 02H 03H 00H 00H 02H 01H 01H 09H
INPUT SELECT RGB 2 02H 03H 00H 00H 02H 01H 02H 0AH
INPUT SELECT VIDEO 1 02H 03H 00H 00H 02H 01H 06H 0EH
INPUT SELECT VIDEO 2 02H 03H 00H 00H 02H 01H 07H 0FH
INPUT SELECT S-VIDEO 02H 03H 00H 00H 02H 01H 0BH 13H
INPUT SELECT DVI (DIGITAL) 02H 03H 00H 00H 02H 01H 1AH 22H
INPUT SELECT DVI (ANALOG) 02H 03H 00H 00H 02H 01H 03H 0BH (GT1150 ONLY)
INPUT SELECT PC CARD VIEWER 02H 03H 00H 00H 02H 01H 1FH 27H (GT1150 ONLY)
PICTURE MUTE ON 02H 10H 00H 00H 00H 12H
PICTURE MUTE OFF 02H 11H 00H 00H 00H 13H
SOUND MUTE ON 02H 12H 00H 00H 00H 14H
SOUND MUTE OFF 02H 13H 00H 00H 00H 15H
ON SCREEN MUTE ON 02H 14H 00H 00H 00H 16H
ON SCREEN MUTE OFF 02H 15H 00H 00H 00H 17H
Cable Connection
Communication Protocol:
Baud Rate: 38400 bps (for cable lengths longer than 20’, it is recommended changing to 9600 bps in setup menu)
Data Length: 8 bits
Parity: No Parity
Stop Bit: One bit
X on/off: None
Communications: Full duplex
PC Control Connector (D-Sub 9P)
12345
67 8 9
To GND of PC
To RxD of PC
To TxD of PC
To CTS of PC
To RTS of PC
NOTE:Pins 1, 4, 6, and 9 are used inside the projector.
Jumper “Request to send” and “Clear to Send” together on both ends of the cable to simplify cable connection.
