NEC VT540/650
Commitment to Economy
The ultra portable VT projectors are the best presentation partners for
marketing and advertising, schools, training and entertainment. With a
resolution of 1024 x 768 pixels and a light intensity up to 1500 ANSI
lumens these projectors manage every presentation with a clear and
bright display even in a well-lit room. Images are so realistic and vivid
you’ll think you are looking at the real thing.
These are one touch no hassle projectors. Just plug in the power cable
and connect to your computer or video signal. Set up is so easy. All the
features and functions are available at your fingertips.
They support a wide range of inputs including RGB, Component,
Composite Video and S-Video.
The VT650 with its Micro Lens Array provides a bright image and its
Colour Management System allows easy adjustment to Gamma
Correction, White Balance and Colour corrections, so fine colour tuning
to your liking is now even easier. Two user memories are available for
storing your personalized settings, and three adjustment modes plus
sRGB to give you a wide choice of settings.
application
• Mobile – On site training, Award Presentaions
• Business – Conferences and Presentations
• Education – Classrooms and Seminars
• Public Display – Galleries and Shops
special features
•VT
540/VT650 1280 x 1024 (SXGA) capable with Advanced
AccuBlend™ technology
• Brightness: VT540 1000 ANSI lumens, VT650 1500 ANSI lumens
• Lightweight: 3.9 kg
• Digital zoom up to 400%
•16:9 aspect ratio for video
• Keystone Correction
• Automatic setup
• Picture adjustment and source selection with only one button
• Fan ventilation to the front
• 3 year pan-European 24 hour on site replacement guarantee
Empowered by Innovation
NEC 650

SPECIFICATION
Display: 3 x 0.9” with LCD Micro Lens Array
Lamp: 160W NSH Lamp (130W Eco Mode)
Lamp life: 2000 hours, 3000 hours in Eco Mode
Lens: Manual Zoom and focus
F2.0 – 2.3, f = 35.8 – 43 mm / F1.7-2.0
f = 33.5 – 40.1 mm
Minimum Image Diagonal: 63 cm
Maximum Image Diagonal: 762 cm
Throwing Distance: 11 – 11.2 m
Projection factor: 1.95-2.3/1.8-2.15
Brightness (ANSI lumen): 1000 (800 in Eco Mode) / 1500 (1200 in
Eco Mode)
Contrast ratio: 400:1
Colour reproduction: 16.77 million
Frequency: Horizontal: 15-100 kHz Vertical: 50-120 Hz
Native resolution: 1024 x 768 (XGA)
Support resolutions: 1280 x 1024 (SXGA) with advanced Accu Blend™
1600 x 1200 (UXGA), 1280 x 1024 (SXGA), 1024
x 768 (XGA), 800 x 600 (SVGA), 640 x 480 (VGA)
Terminals: RGB Input: Mini D-Sub 15-pin
(shared with YCbCr)
RGB Output; Mini D-Sub 15-pin
Video Input: RCA
S-video Input: DIN 4-pin
Audio Input: RCA, Mini Jack
Audio Output:Mini Jack
(Shared with RGB, Video and S-Video)
PC Control Input/Output DIN 8-pin
Video Signals: PAL / NTSC / SECAM / NTSC 4.43 PAL-N,
PAL-M, PAL60, S-Video
Audio Functions: 1 Watt integrated speaker
Benefits: Colour Management sRGB-VT650, Keystone
Correction up to ±30°
Remote Control: Source select, auto picture adjustment, magnify,
help function, aspect ratio, volume and power
Dimensions (W x H x D): 243 x 103 x 284 mm
Weight: 3.9 kg
Power Supply: 100-120W / 200-240 VAC ±10% 50/60 Hz
Power Consumption: 240 W (205 W in Eco Mode / 225 W (190 W
in Eco Mode)
Fan Noise: Normal: <38 dB: <35 dB in Eco Mode
Safety/Ergonomics: CE, TUV GS, EN60950, EN55022: 1994,
A1/2:1994 Class B, EN50082-1, EN61000-3-2,
EN61000-3-3
Guarantee: Projector: 3 year pan –European 24 hour on
site replacement
Lamp 2000 hours or 6months
Optional Items and Spares: VT40CM Ceiling Mounting Kit, PR51 Remote
Control Kit, ADP-CV1 Component Video Adaptor
Lead, VT50 LP Replacement Lamp VT40HC
Hard Carrying Case
All specifications are subject to change without notice.
*NSH = New Short arc High Pressure
243 mm
103 mm
284 mm
NEC VT540/650
NEC (UK) Ltd
NEC House
1 Victoria Road
London W3 6BL
Telephone: [phone]
e-mail: [email protected].com
www.nec.co.uk
April02
243 mm
Carry Case Remote Control
VT650
