NEC MultiSync VT540JK User manual

MultiSync VT440/VT540
LCD Projector
User’s Manual
English

E–2
IMPORTANT INFORMATION
Precautions
PleasereadthismanualcarefullybeforeusingyourNEC
MultiSyncVT440/VT540 Projector and keep the manual
handy for future reference.
Your serial number is located under the name plate label
ontheright side of yourMultiSyncVT440/VT540.Record
it here:
CAUTION
To turn off main power, be sure to remove the
plug from power outlet.
The power outlet socket should be installed
as near to the equipment as possible, and
should be easily accessible.
CAUTION
TO PREVENT SHOCK, DO NOT OPENTHE
CABINET.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED NEC
SERVICE PERSONNEL.
This symbol warns the user that uninsulated
voltage within the unit may be sufficient to
cause electrical shock. Therefore, it is dan-
gerous to make any kind of contact with any
part inside of the unit.
This symbol alerts the user that important in-
formationconcerningtheoperationandmain-
tenance of this unit has been provided. The
information should be read carefully to avoid
problems.
WARNING
TO PREVENT FIRE OR SHOCK, DO NOT EXPOSETHIS
UNIT TO RAIN OR MOISTURE.
DO NOT USE THIS UNIT’S GROUNDED PLUG WITH AN
EXTENSION CORD OR IN AN OUTLET UNLESS ALL
THREE PRONGS CAN BE FULLY INSERTED.
DO NOT OPEN THE CABINET.THERE ARE HIGH-VOLT-
AGE COMPONENTS INSIDE. ALL SERVICING MUST BE
DONE BY QUALIFIED NEC SERVICE PERSONNEL.
DOC Compliance Notice
This Class B digital apparatus meets all requirements of
the Canadian Interference-Causing Equipment Regula-
tions.
3. GSGV Acoustic Noise Information Ordinance:
The sound pressure level is less than 70 dB (A) accord-
ing to ISO 3744 or ISO 7779.
RF Interference
WARNING
The Federal Communications Commission does not
allowany modificationsor changestothe unitEXCEPT
those specified by NEC Technologies in this manual.
Failureto complywith thisgovernmentregulation could
void your right to operate this equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.These limits are designed
to provide reasonable protection against harmful in-
terference in a residential installation.This equipment
generates, uses, and can radiate radio frequency en-
ergy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guaran-
tee that interference will not occur in a particular in-
stallation.If this equipment does cause harmful inter-
ference to radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected.
• Consult the dealeror an experienced radio /TV tech-
nician for help.
In UK, a BS approved power cable with moulded plug
has a Black (five Amps) fuse installed for use with this
equipment.Ifapowercableisnotsuppliedwith thisequip-
ment please contact your supplier.
• IBM is a registered trademark of International Business Machines
Corporation.
• Macintosh and PowerBook are registered trademarks of Apple
Computer, Inc.
• Otherproduct and company names mentionedin thisuser's manual
may be the trademarks of their respective holders.

E–3
Important Safeguards
These safety instructions are to ensure the long life of
yourprojector and to prevent fire and shock.Please read
them carefully and heed all warnings.
Installation
1. For best results, use your projector in a darkened room.
2. Placethe projector on aflat, level surface in a dry areaaway
from dust and moisture.
3. Do not place your projector in direct sunlight, near heaters
or heat radiating appliances.
4. Exposure to direct sunlight, smoke or steam can harm in-
ternal components.
5. Handleyourprojectorcarefully.Droppingorjarring can dam-
age internal components.
6. Do not place heavy objects on top of the projector.
7. If you wish to have the projector installed on the ceiling:
a. Do not attempt to install the projector yourself.
b. The projector must be installed by qualified technicians
in order to ensure proper operation and reduce the risk
of bodily injury.
c. In addition, the ceiling must be strong enough to support
the projector and the installation must be in accordance
with any local building codes.
d. Please consult your dealer for more information.
Power Supply
1. The projector is designed to operate on a power supply of
100-120 or 200-240V 50/60 Hz AC.Ensure that your power
supply fits this requirement before attempting to use your
projector.
2.Handle the power cable carefully and avoid excessive bend-
ing. A damaged cord can cause electric shock or fire.
3. If the projector is not to be used for an extended period of
time, disconnect the plug from the power outlet.
Cleaning
1. Unplug the projector before cleaning.
2. Clean the cabinet periodically with a damp cloth. If heavily
soiled, use a mild detergent. Never use strong detergents
or solvents such as alcohol or thinner.
3. Use a blower or lens paper to clean the lens, and be careful
not to scratch or mar the lens.
CAUTION
Do not unplug the power cable from the wall outlet under any
one of the following circumstances. Doing so can cause damage
to the projector:
* While the Hour Glass icon appears.
* While the message "Please wait a little." appears. This mes-
sage will be displayed after the projector is turned off.
* Immediately after the power cable is plugged into the wall
outlet(the POWER indicatorhas notchanged toasteady amber
glow).
* Immediately after the cooling fan stops working (The cooling
fan continues to work for 30 seconds after the projector is
turned off with the POWER OFF button).
* While the POWER and the STATUS indicators are alternately
flashing.

E–4
Lamp Replacement
• To replace the lamp, follow all instructions provided on page
E-33.
• Be sure to replace the lamp when the message "The lamp
has reached the end of its usable life. Please replace the
lamp."appears.Ifyoucontinue to use thelampafterthe lamp
has reached the end of its usable life, the lamp bulb may
shatter, and pieces of glass may be scattered in the lamp
case. Do not touch them as the pieces of glass may cause
injury. If this happens, contact your NEC dealer for lamp
replacement.
• Allow a minimum of 30 seconds to elapse after turning off
theprojector.Thendisconnect the powercable and allow60
minutes to cool the projector before replacing the lamp.
Fire and Shock Precautions
1. Ensure that there is sufficient ventilation and that vents are
unobstructed to prevent the build-upof heat inside yourpro-
jector. Allow at least 3 inches (10 cm) of space between
your projector and a wall.
2. Prevent foreign objects such as paper clips and bits of pa-
per from falling into your projector. Do not attempt to re-
trieve any objects that might fall into your projector. Do not
insert any metal objects such as a wire or screwdriver into
your projector. If something should fall into your projector,
disconnect it immediately and have the object removed by a
qualified NEC service personnel.
3. Do not place any liquids on top of your projector.
• Do not look into the lens while the projector is on. Serious
damage to your eyes could result.
• Keep any items such as magnifying glass out of the light
path of the projector.The light being projected from the lens
is extensive, therefore any kind of abnormal objects that
can redirect light coming out of the lens, can cause unpre-
dictable outcome such as fire or injury to the eyes.
• Do not cover the lens with the supplied lens cap or equiva-
lentwhile the projector is on. Doing so can lead tomelting of
the cap and possibly burning your hands due to the heat
emitted from the light output.

E–5
TABLE OF CONTENTS
1. INTRODUCTION
Introduction to the MultiSync VT440/VT540 Projector .................E-6
Getting Started ............................................................E-6
What’s in the Box.........................................................E-7
Getting to KnowYour MultiSync VT440/VT540 Projector ..................E-8
Front / Side Features ..............................................E-8
Rear / Side Features...............................................E-9
Top Features ......................................................... E-10
Terminal Panel Features ....................................... E-11
Remote Control Features......................................E-12
2. INSTALLATION
Setting UpYour Projector........................................... E-14
Selecting a Location .................................................. E-14
Using a Tabletop or Cart ............................................E-14
Distance Chart........................................................... E-15
Ceiling Installation ..................................................... E-16
Reflecting the Image.................................................. E-16
Wiring Diagram.......................................................... E-17
Connecting Your PC .............................................. E-18
ConnectingYour Macintosh Computer .................. E-19
Connecting an External Monitor............................E-21
ConnectingYour DVD Player................................. E-22
ConnectingYour VCR or Laser Disc Player .......... E-23
3. OPERATION
General Controls ....................................................... E-24
Enlarging and Moving a Picture................................. E-24
Using the Menus........................................................E-25
Menu Tree.................................................................. E-26
Menu Elements.......................................................... E-27
Menu Descriptions & Functions................................. E-28
Source Select ............................................................ E-28
RGB/Video/S-Video
Picture .......................................................................E-28
Brightness/Contrast/Color/Hue/Sharpness
Volume....................................................................... E-28
Image Options ........................................................... E-28
Keystone ............................................................... E-28
Color Temperature ................................................ E-28
Lamp Mode ........................................................... E-29
Gamma Correction................................................ E-29
Aspect Ratio..........................................................E-29
Noise Reduction....................................................E-29
Color Matrix........................................................... E-29
White Balance....................................................... E-30
Auto Adjust ............................................................ E-30
Position/Clock .......................................................E-30
Resolution .............................................................E-30
Factory Default ...................................................... E-30
Menu.......................................................................... E-31
Menu Mode ........................................................... E-31
Basic/Advanced................................................ E-31
Language ..............................................................E-31
Projector Pointer ................................................... E-31
Source Display ...................................................... E-31
Volume Bar (Direct Button) ...................................E-31
Menu Display Time................................................ E-31
Setup .........................................................................E-31
Orientation ............................................................ E-31
Background ...........................................................E-31
Signal Select ......................................................... E-32
Auto Start ..............................................................E-32
Power Management .............................................. E-32
Power Off Confirmation.........................................E-32
Keystone Save ......................................................E-32
Clear Lamp Hour Meter ........................................ E-32
Help ...........................................................................E-32
Contents................................................................E-32
Information ............................................................E-32
4. MAINTENANCE
Replacing the Lamp...................................................E-33
Remote Control Battery Installation........................... E-34
Cleaning or Replacing the Filters ..............................E-34
5.TROUBLESHOOTING
Power / Status Light Messages ................................. E-35
Common Problems & Solutions.................................E-35
6. SPECIFICATIONS
Optical/Electrical/Mechanical.....................................E-36
Cabinet Dimensions ..................................................E-37
D-Sub Pin Assignments.............................................E-38
Timing Chart..............................................................E-39
PC Control Codes......................................................E-40
Cable Connection ...................................................... E-40

E–6
1. INTRODUCTION
Introduction to the MultiSync VT440/VT540 Projector
This section introduces you to your new MultiSyncVT440 (SVGA)/
VT540 (XGA) Projector and describes the features and controls.
Congratulations on Your Purchase of The MultiSync VT440/
VT540 Projector
The MultiSyncVT440/VT540 is one of the very best projectors avail-
able today. The MultiSyncVT440/VT540 enables you to project pre-
cise images up to 300 inches across (measured diagonally) from your
PCor Macintosh computer(desktop or notebook),VCR,DVDplayer,
document camera, or even a laser disc player.
You can use the projector on a tabletop or cart, you can use the pro-
jector to project images from behind the screen, and the projector can
be permanently mounted on a ceiling*1. The remote control can be
used wirelessly.
Features you’ll enjoy:
• Simple set up and operation.
• Front ventilation directs hot air away from your audience.
• Ahigh-performance 160 wattNSH(130 wattin Eco mode) lamp.
The lamp life can be extended up to 3000 hours by using the Eco
mode.
• The supplied wireless remote control that operates the projector
from any angle.
• Manual zoom control enables you to adjust the image between
25 (0.63 m) and 300 inches (7.6 m) (measured diagonally).
• Keystone correction allows you to correct trapezoidal distortion
so that the image is square.
• You canchoose betweenvideo modes dependingon yoursource:
“normal” for a typical picture, “natural” for true color reproduc-
tion.
• An image can be projected from in front or behind a screen, and
the projector can even be installed on the ceiling.
• NEC Technologies’ exclusive Advanced AccuBlend intelligent
pixel blending technology - an extremely accurate image com-
pression technology - offers a crisp image with SXGA (1280 x
1024) resolution*3.
• Supports most IBM VGA, SVGA, XGA*2, SXGA(with Ad-
vanced AccuBlend)*3, Macintosh, component signal (YCbCr /
YPbPr) or any other RGB signals within a horizontal frequency
range of 15 to 100 kHz and a vertical frequency range of 50 to
117 Hz. This includes NTSC, PAL, PAL60, SECAM and
NTSC4.43 standard video signals.
NOTE: Composite video standards are as follows:
NTSC: U.S. TV standard for video in U.S. and Canada.
PAL: TV standard used in Western Europe.
PAL60: TV standard used for NTSC playback on PAL TVs.
SECAM: TV standard used in France and Eastern Europe.
NTSC4.43: TV standard used in Middle East countries.
• The supplied remote control can be used without a cable.
• You can control the projector with a PC using the PC Control
port.
• The contemporary cabinet design is light, compact, easy to carry,
and complements any office, boardroom or auditorium.
• Eight pointers are available for your presentation.
*1 Do not attempt to mount the projector on a ceiling yourself.
The projector must be installed by qualified technicians in order
to ensure proper operation and reduce the risk of bodily injury.
In addition, the ceiling must be strong enough to support the pro-
jector and the installation must be in accordance with any local
building codes. Please consult your dealer for more information.
*2 An XGA image (10242768) is converted into an 8002600 crisp
image with NEC technology’s Advanced AccuBlend on VT440.
*3 An SXGA image (128021024) is converted into a 10242768
crisp image with NEC technology’s Advanced AccuBlend on
VT540.
Getting Started
The fastest way to get started is to take your time and do everything
right the first time. Take a few minutes now to review the user’s
manual. This may save you time later on. At the beginning of each
section of the manual you’ll find an overview. If the section doesn’t
apply, you can skip it.

E–7
What's in the Box?
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
Please save the original box and packing materials if you ever need to ship your MultiSync VT440/VT540 Projector.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
OFF
SOURCE AUTO ADJUST
RGB
INPUT
OUTPUT
AUD
IN
OUT
PC-CONTROL S-VIDEO VID
Lens cap
Projector
String and rivet
SELECT
POINTER
POWER
HELP
RD-366E
PIC.
MUTE
MAGNIFY
SOURCE
AUTO
ADJ.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
Vol.
Vol.
Card remote control
Power cable Signal cable
1
ON DIP
23456
Pin adapter for Macintosh
Quick
Connect
Guide
User's
Manual

E–8
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
STAND BY
SOURCE AUTO ADJUST
RGB
INPUT
OUTPUT
AUD
IN
OUT
PC-CONTROL S-VIDEO VID
Getting to Know Your MultiSync VT440/VT540 Projector
Front/ Side Features
Controls
Focus Ring
Adjustable Tilt Foot Button
AC Input
Connectthesuppliedpower
cable’s three-pin plug here.
Air-Filter (inlet)
Remote Sensor
Zoom Lever
Slot for Kensington
MicroSaver
Security System
Air-Filter (inlet)
Terminal Panel
Carrying Handle
Remote Sensor
Ventilation (outlet)
Adjustable Tilt Foot
Lens
Lens Cap
NOTE: Built-in Security Slot ( )
This security slot supports the MicroSaver®Security System.
MicroSaver®is a registered trademark of Kensington Microware
Inc.The logo is trademarked and owned by Kensington Microware
Inc.
Carrying the Projector:
Raise the carrying handle up. Always carry your projector by the
carrying handle.
NOTE:When moving the projector or when it is not in use, cover the
lens with the lens cap.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
OFF
SOURCE AUTO ADJUST
RGB
INPUT
OUTPUT
AUD
IN
INOUT
OUT
PC-CONTROL S-VIDEO VIDEO

E–9
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
STAND BY
SOURCE AUTO ADJUST
Remote Sensor
Rear/ Side Features
Remote Sensor
Rear Foot
Built-in Monaural Speaker (1W)
Rear Foot
Lamp Cover
Lamp Cover Screw
Card Remote Slot
SELECT
Vol.
Vol.
POINTER
POWER
HELP
RD-366E
PIC.
MUTE
MAGNIFY
SOURCE
AUTO
ADJ.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
Slot for Card Remote Control
The supplied card remote control can be stored in the cabinet.
To store the card remote control:
1. Insert the card remote control STRAIGHT into the slot.
2. Push the card remote control until it is into place.
Attaching the lens cap to the lens hood with the sup-
plied string and rivet
1. Thread the string through the hole on the lens cap and then tie a
knot in the string.
2. Tie a knot again
3. Use the rivet to attach the string to the bottom of the lens hood.
Lens Cap
String
RGB
INPUT
OUTPUT
AUD
IN
OUT
PC-CONTROL S-VIDEO VID
B
UT
PUT
AUD
IN
OUT
L S-VIDEO VID
To pull out the card remote control:
1. Push the bottom of the card remote control straight to eject the
card remote control.
2. Pull out the card remote control.
RD-366E
NOTE: Do not push or pull the card remote control in a slanting
direction. Unless you push the card remote control straight, you may
not eject the card remote control. Should this happen,try pushing the
card remote control straight again.
Rivet

E–10
Top Features
1 Source Button
Use this button to select a video source such as a PC,VCR or DVD
player.
2 Auto Adjust Button
Use this button to adjust Position-H/V and Pixel Clock/Phase for
an optimal picture. Some signals may not be displayed correctly or
take time to switch between sources.
3 Menu Button
Displays the menu.
4 Select (▲▼§ ©) / Volume (+) (–) Buttons
▲▼: Use these buttons to select the menu of the item you wish
to adjust.
§ ©: Use these buttons to change the level of a selected menu
item.
A press of the ©button executes the selection. When no menus
appear, these ▲▼ buttons work as a volume control.
When the pointer is displayed, these § © ▲▼ buttons move the
pointer.
5 Enter Button
Executes your menu selection and activates items selected from
the menu.
6 Cancel Button
Press this button to exit the menu. Press this button to return the
adjustments to the last condition while you are in the adjustment
or setting menu.
7 Status Indicator
When this is lit red (orange in Eco mode) continually, it’s warning
you that the projection lamp has exceeded 2000 hours (up to 3000
hours in Eco mode) of service.After this light appears, it is advis-
able to replace the projection lamp as soon as possible. (See page
E-33). In addition the message “The lamp has reached the end of
itsusable life.Pleasereplace thelamp.”appears continually until
the lamp is replaced.
If this light blinks red rapidly, it indicates that the lamp cover or
filter cover is not attached properly or the projector is overheated.
See the Power / Status Light Messages on page E-35 for more
details.
8 Power Indicator ( )
When this indicator is green, the projector is on; when the indica-
tor is orange, it is in standby mode.
9 Power Button (ON / STAND BY)
Use this button to turn the power on and off when the power is
supplied and the projector is in standby mode.
NOTE: To turn off the projector, press and hold this button for
minimum of two seconds.
9
1
5
7
86
4
3
2
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
STAND BY
SOURCE AUTO ADJUST

E–11
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
STAND BY
SOURCE AUTO ADJUST
RGB
INPUT
OUTPUT
AUDIO
IN
INOUT
OUT
PC-CONTROL S-VIDEO VIDEO
Terminal Panel Features
1
1. RGB Input Connector(Mini D-Sub 15 pin)
Connect your PC or other RGB equipment. Use the supplied sig-
nal cable to connect to a PC.
2. RGB Monitor Output Connector (Mini D-Sub 15 pin)
You can use this connector to loop your computer image to an
external monitor from the RGB input source.
3. Audio Input / Output Mini Jack
This is where you connect audio output from your computer. Or
connect additional external speakers here to listen to audio coming
from your Video or S- Video input.
4. Audio Input / Output Connector (RCA)
This is where you connect audio output from aVCR, DVD player,
or laser disc player. Or connect additional external speakers to lis-
ten to audio coming from your RGB source.
NOTE:Either connector 3 or 4 can be used for input or output, how-
ever they cannot both be used for input simultaneously. It can dam-
age your equipment.
5.Video Input (RCA)
Connect aVCR, DVD player, laser disc player, or document cam-
era here to project video.
6. S-Video Input Port (Mini DIN 4 Pin)
Connect the S-Video input from an external source like a VCR.
7. PC Control Port (Mini DIN 8 Pin)
Use this port to connect your PC to control your projector. This
enables you to use your PC and serial communication protocol to
control the projector. If you are writing your own program, typical
PC control codes are on page E-40.
A cap is put on the port at the factory. Remove the cap when using
the port.
8. Built-in Security Slot ( )
This security slot supports the MicroSaver ® Security System.
MicroSaver ® is a registered trademark of Kensington Microware
Inc.The logo is trademarked and owned by Kensington Microware
Inc.
7
Slot for Kensington
MicroSaver Security System
8
2
3
5
6
4

E–12
Remote Control Features
1 Source Button
Press to select a video source.
2 Auto Adjust Button
Use this button to adjust Position-H/V and Pixel Clock/Phase for
an optimal picture. Some signals may not be displayed correctly,
or in some cases it may take some time for a source to switch be-
tween sources.
3 Menu Button
Displays the menu.
4 Select (▲▼§ ©) / Volume (+) (–) Buttons
▲▼: Use these buttons to select the menu of the item you wish
to adjust.
§ ©: Use these buttons to change the level of a selected menu
item.
A press of the ©button executes the selection. When no menus
appear, these ▲▼ buttons work as a volume control.
When the pointer is displayed, these § © ▲▼ buttons move the
pointer.
5 Enter Button
Use this button to enter your menu selection.
6 Cancel Button
Press this button to exit “Menus”. Press this button to return the
adjustments to the last condition while you are in the adjustment
or setting menu.
7 Magnify Button
Use the (+) or (–) button to adjust the image size up to 400%.
When the Pointer is displayed, the magnified image is displayed at
the center of the Pointer. When the Pointer is not displayed, the
magnified image is displayed at the center of the screen.
When the image is magnified, the pointer is changed to the magni-
fying icon.
8 Pointer Button
Press this button to display one of the eight pointers; press again to
hide the pointer. You can move your pointer icon to the area you
want on the screen using the Select button.
9 Picture Mute Button
This button turns off the image and sound for a short period of
time. Press again to restore the image and sound.
10 Help Button
Provides information about operation and adjustment procedures
or the set information for the current menu or adjustment during
menuoperation.This also displaysinformation howto use the Help.
11 Power Button
If power is applied, you can use this button to turn your projector
on and off.
NOTE: To turn off the projector, press and hold the POWER but-
ton for a minimum of two seconds.
12 InfraredTransmitter
Direct the remote control toward the remote sensor on the projec-
tor cabinet.
Remote Control Precautions
• Handle the remote control carefully.
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• Do not place the battery upside down.
NOTE: Before you use the card remote control for the first time, be
sure to remove the insulation tape from the card remote control.
* Keep the coin cell battery out of reach of children so as not to
allow them to swallow the cell battery.
CAUTION:
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by
the manufacturer.
Dispose of used batteries according to your local regulations.
Remote Control
SELECT
POINTER
Vol.–
Vol.+
POWER HELP
RD-366E
PIC.
MUTE
MAGNIFY
SOURCE
AUTO
ADJ.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
1
3
5
7
10
2
4
6
8
9
11
NOTE: Remove the transparent insulation tape before use. See
page E-34 for battery installation.
M
n
O
2
-
L
i
C
E
L
L
3
V
O
L
T
S
J
A
P
A
N
H
CR2025
12

E–13
Operating Range
7m
30˚
30˚
7m7m
22 feet
22 feet

E–14
2. INSTALLATION
This section describes how to set up your MultiSyncVT440/VT540
projector and how to connect video and audio sources.
Setting up Your Projector
Your MultiSyncVT440/VT540 Projector is simple to set up and use.
But before you get started, you must first:
1. Determine the image size.
2. Set up a screen or select a non-glossy white wall onto which you
can project your image.
Carrying the Projector: Always carry your projector by the handle.
Ensure that the power cable and any other cables connecting to video
sources are disconnected before moving the projector.
When moving the projector or when it is not in use, cover the lens
with the lens cap.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
OFF
SOURCE AUTOADJUST
Screen
Top view
Screen
Side view
Using a Tabletop or Cart
1. Place your projector on a flat level surface at the optimal distance
from the screen or wall so you realize the size image you want.
(Avoid having bright room lighting or sun light directly on the
screen or wall where you’ll be projecting the image.)
2. Connect the power cable, remove the lens cap and turn the projec-
tor on. (If no input signal is available, the projector will display a
background image.)
3. Ensure that the projector is square to the screen.
4. Move the projector left or right to center the image horizontally
on the screen.
5. To center the image vertically, lift the front edge of the projector
and press the One-Touch Tilt button on the front side of the pro-
jector to release the Front Adjustable foot.
(There is approximately 10 degrees of up and down adjustment
for the front of the projector.)
Selecting a Location
The further your projector is from the screen or wall, the larger the
image. The minimum size the image can be is approximately 25"
(0.64 m) measured diagonally when the projector is roughly 4 feet
(1.2 m) from the wall or screen. The largest the image can be is 300"
(7.6 m) when the projector is about 39.3 feet (12.0 m) from the wall
or screen.
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
OFF
SOURCE AUTO ADJUST
RGB
INPUT
OUTPUT
AUD
IN
INOUT
OUT
PC-CONTROL S-VIDEO VIDEO
M
E
N
U
E
N
T
E
R
C
A
N
C
E
L
SELECT
POWER
STATUS ON
/
OFF
SOURCE AUTO ADJUST
RGB
INPUT
OUTPUT
AUD
IN
OUT
PC-CONTROL S-VIDEO VID
2
1
M
E
N
U
E
L
LE
CT
SOURCE AUTO ADJUST
RGB
INPUT
OUTPUT
AUD
IN
OUT
PC-CONTROL S-VIDEO VID
Adjusting theTilt Foot
1) Press and hold the Tilt button on the front of the projector.
2) Lift the front edge of the projector to the height you want, and
release the button to lock the Adjustable Tilt Foot.
To fine-tune the image’s position vertically on the screen, rotate the
foot.Each of the rear feet height can be changed up to 0.6”(4mm).
6. If the projected image does not appear square to the screen then
use keystone correction for proper adjustment.
7. Adjust the size of the image using the Zoom ring on the lens.
Carrying handle
POW
ER
S
TA

E–15
H
Screen (inch)
Distance Chart
αdegree 9.01 8.93 8.85 8.82 8.81 8.79 8.78 8.77 8.75 8.74 8.74 8.73 8.72 8.72
β(=sinα) 0.16 0.16 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15
γ(=cosα) 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99
Screen Size H-Width inch 24 32 48 56 64 72 80 96 120 144 160 192 216 240
4:3 Diagonal inch 30 40 60 70 80 90 100 120 150 180 200 240 270 300
A mm 1171 1575 2384 2789 3193 3598 4002 4811 6025 7238 8047 9666 10879 12093
inch 46 62 94 110 126 142 158 189 237 285 317 381 428 476
C mm 1156 1556 2356 2756 3155 3555 3955 4755 5955 7154 7954 9554 10753 11953
inch 46 61 93 108 124 140 156 187 234 282 313 376 423 471
D mm -15 2 34 50 66 82 98 130 179 227 259 324 372 420
inch -1 0 1233457910131517
E mm 246 307 430 491 552 613 674 796 980 1163 1285 1530 1713 1896
inch 10 12 17 19 22 24 27 31 39 46 51 60 67 75
NOTE: Distances may vary +/–5%.
Distance Chart
Throwing Distance Screen Size (inch)
(inch) (m) Wide Tele
45 1.2 30 25
61 1.6 40 33
93 2.4 60 50
108 2.8 70 58
124 3.2 80 67
140 3.6 90 75
156 4.0 100 83
187 4.8 120 100
234 6.0 150 125
282 7.2 180 150
313 8.0 200 167
376 9.6 240 200
423 10.8 270 225
471 12.0 300 250
wide tele
A
C
E
D
α
A: Distance between the
lensandthescreencen-
ter
C: Horizontal throw dis-
tance between screen
surface and the lens
D: Vertical distance be-
tween projector base
and base of image
E: Vertical distance be-
tween projector base
and screen center
αdegree 6.28 7.46 7.39 7.37 7.36 7.35 7.34 7.32 7.31 7.30 7.30 7.29 7.29 7.28
β(=sinα) 0.11 0.13 0.13 0.13 0.13 0.13 0.13 0.13 0.13 0.13 0.13 0.13 0.13 0.13
γ(=cosα) 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99
Screen Size H-Width inch 20 32 48 56 64 72 80 96 120 144 160 192 216 240
4:3 Diagonal inch 25 40 60 70 80 90 100 120 150 180 200 240 270 300
A mm 1396 1883 2851 3334 3818 4302 4785 5753 7204 8655 9623 11558 13009 14460
inch 55 74 112 131 150 169 188 226 284 341 379 455 512 569
C mm 1387 1867 2827 3307 3787 4266 4746 5706 7146 8585 9545 11464 12904 14344
inch 55 74 111 130 149 168 187 225 281 338 376 451 508 565
D mm -23 2 34 50 66 82 98 130 179 227 259 324 372 420
inch -1 0 1233457910131517
E mm 216 307 430 491 552 613 674 796 980 1163 1285 1530 1713 1896
inch 8 12 17 19 22 24 27 31 39 46 51 60 67 75
Zoom Lens (Wide)
Zoom Lens (Tele)
Throwing Distance (inch)
Screen Size (inch)
300
250
200
150
100
50
00 100 200 300 400
300
250
200
150
100
50
0024681012
Throwing Distance (m)
Screen Size (inch)
Formulas(mm) Formulas(inch)
"H = Horizontal Screen Width "H = Horizontal Screen Width
A = C/cosαA = C/cosα
C (wide) = 36.8712 × (diagonal screen size/ 0.92205) – 43.5689 C (wide) = (36.8712 × (diagonal screen size/0.92205) – 43.5689) / 25.4
C (tele) = C(wide) ×1.2 C (tele) = C (wide) × 1.2
D = 1.45 × M – 62.9 D = 1.45 × M – 62.9 / 25.4
E = 62.9 + 5.5M E = (62.9 + 5.5M) / 25.4
M = 1.25H / 22.86 M = 1.25H / 0.9
4:3 Diagonal

E–16
RGB
INPUT
OUTPUT
AUDIO
IN
INOUT
OUT
PC-CONTROL S-VIDEO VIDEO
WARNING
• Installingyour projectoron theceiling must be done bya quali-
fied technician. Contact your NEC dealer for more informa-
tion.
* Do not attempt to install the projector yourself.
• Only use your projector on a solid, level surface. If the projec-
tor falls to the ground, you can be injured and the projector
severely damaged.
• Do not use the projector where temperatures vary greatly. The
projector must be used at temperatures between 32˚F (0˚C)
and 95˚F (35˚C).
• Do not expose the projector to moisture, dust, or smoke. This
will harm the screen image.
• Ensure that you have adequate ventilation around your pro-
jector so heat can dissipate. Do not cover the vents on the side
or the front of the projector.
If your projector is mounted on the ceiling and your image is upside
down, use the “Menu” and “Select” buttons on your projector cabi-
net or ▲▼ button on your remote control to correct the orientation.
(See page E-31.)
Reflecting the Image
Using a mirror to reflect your projector’s image enables you to enjoy
a much larger image. Contact your NEC dealer if you need a mirror.
If you’re using a mirror and your image is inverted, use the “Menu”
and “Select” buttons on your projector cabinet or ▲▼ buttons on
your remote control to correct the orientation. (See page E-31.)
Ceiling Installation
A: Distance between the lens and the screen center
B: Vertical distance between the top of the supplied ceiling mount and the screen center
C: Horizontal throw distance between screen surface and the lens
F: Vertical distance between projector base and top of image
Formulas(mm)
H” = Horizontal Screen Width (inch)
A = C/cosα
B = 94 + 5.5 ×M
C (wide) = 36.8712 × (diagonal screen size/ 0.92205) – 43.5689
C (tele) = C(wide) ×1.2
F = 1.4516 ×M – 94
M = 1.25H” / 22.86
Formulas(inch)
H” = Horizontal Screen Width
A = C/cosα
B = (T.B.D. +5.5 ×M) / 25.4
C (wide) = (36.8712 × (diagonal screen size/0.92205) – 43.5689) / 25.4
C (tele) = C (wide) × 1.2
F = 1.4516 ×M – 94/25.4
M = 1.25H / 0.9
αdegree 9.01 8.93 8.85 8.82 8.81 8.79 8.78 8.77 8.75 8.74 8.74 8.73 8.72 8.72
β(=sinα) 0.16 0.16 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15
γ(=cosα) 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99
Screen Size H-Width inch 24 32 48 56 64 72 80 96 120 144 160 192 216 240
4:3 Diagonal inch 30 40 60 70 80 90 100 120 150 180 200 240 270 300
A mm 1171 1471 2242 2628 3013 3399 3785 4556 5713 6870 7641 9184 10341 11498
inch 46 58 88 103 119 134 149 179 225 270 301 362 407 453
C mm 1156 1452 2214 2595 2976 3357 3738 4500 5644 6787 7549 9074 10217 11360
inch 46 57 87 102 117 132 147 177 222 267 297 357 402 447
B mm 277 338 461 522 583 644 705 827 1011 1194 1316 1561 1744 1927
inch 11 13 18 21 23 25 28 33 40 47 52 61 69 76
F mm -46 -29 3 19 35 51 67 100 148 196 229 293 341 390
inch -2 -1 011234689121315
αdegree 6.28 7.1 7.0 7.0 7.0 7.0 6.9 6.9 6.9 6.9 6.9 6.9 6.9 6.9
β(=sinα) 0.11 0.12 0.12 0.12 0.12 0.12 0.12 0.12 0.12 0.12 0.12 0.12 0.12 0.12
γ(=cosα) 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99 0.99
Screen Size H-Width inch 20 32 48 56 64 72 80 96 120 144 160 192 216 240
4:3 Diagonal inch 25 40 60 70 80 90 100 120 150 180 200 240 270 300
A mm 1396 1902 2900 3399 3898 4397 4896 5893 7390 8887 9885 11881 13378 14875
inch 55 75 114 134 153 173 193 232 291 350 389 468 527 586
C mm 1387 1887 2878 3373 3869 4364 4860 5851 7337 8823 9814 11796 13282 14768
inch 55 74 113 133 152 172 191 230 289 347 386 464 523 581
B mm 247 338 461 522 583 644 705 827 1011 1194 1316 1561 1744 1927
inch 10 13 18 21 23 25 28 33 40 47 52 61 69 76
F mm -54 -29 3 19 35 51 67 100 148 196 229 293 341 390
inch -2 -1 011234689121315
Zoom Lens (Wide)
Zoom Lens (Tele)
A
C
F
Bα

E–17
PC CONTROL S-VIDEO VIDEO
IN
OUT
OUT
IN
RGB OUTPUT
AUDIORGB INPUT
Wiring Diagram
Optional Component V cable
To video, S-video, and audio
inputs on the projector.
Pin adapter for Macintosh (supplied)
Signal cable (supplied)
To mini D-Sub 15-pin connector on the
projector. It is recommended that you
use a commercially available distribution
amplifier if connecting a signal cable
longer than the supplied cable.
IBM VGA or Compatibles
(Desktop type or notebook type)
Macintosh or Compatibles
(Desktop type or notebook type)
Document Camera
DVD Player (with component output)
VCR, DVD Player or LaserDisc Player
NOTE: When using with a notebook PC, be sure to connect between the projector and the notebook PC
before turning on the power to the notebook PC. In most cases signal cannot be output from RGB output
unless the notebook PC is turned on after connecting with the projector.
NOTE:
* If the screen goes blank while using your remote control, it may be the result of the computer’s screen-
saver or power management software.
* If you accidentally hit the POWER button on the remote control, wait 30 seconds and then press the
POWER button again to resume.
NOTE: If using video, S-video, or audio cables, the cables should be 3 m (9.8 feet) or shorter.
Monitor
Speaker System

E–18
RGB
INPUT
OUTPUT
AUDIO
IN
INOUT
OUT
PC-CONTROL S-VIDEO VIDEO
RGB INPUT AUDIO
Connecting Your PC
IBMVGA or Compatibles
(Notebook type)
Signal cable (supplied)
To mini D-Sub 15-pin connector on the projector. It is recom-
mended that you use a commercially available distribution ampli-
fier if connecting a signal cable longer than the supplied one.
IBMVGA or Compatibles
(Desktop type)
Audio cable
(not supplied)
Connecting your PC to your MultiSync VT440 (SVGA)/VT540 (XGA) projector will enable you to project your computer’s screen image for
an impressive presentation.
To connect to a PC, simply:
1. Turn off the power to your projector and computer.
2. Use the supplied signal cable to connect your PC to the projector.
3. Turn on the projector and the computer.
4. If the projector goes blank after a period of inactivity, it may be caused by a screen saver installed on the computer you’ve connected to the
projector.

E–19
RGB
INPUT
OUTPUT
AUDIO
IN
INOUT
OUT
PC-CONTROL S-VIDEO VIDEO
RGB INPUT AUDIO
1
ON DIP
23456
To connect to a Macintosh, simply:
1. Turn off the power to your projector and your Macintosh com-
puter.
2. Use the supplied signal cable to connect your Macintosh com-
puter to the projector.
3. Turn on the projector and the Macintosh computer.
Connecting Your Macintosh Computer
Macintosh (Desktop type)
Audio cable
(not supplied)
For older Macintosh,
use the supplied pin
adapter to connect to
your Mac's video
port. Pin adapter for Macintosh
(supplied)
Signal cable
(supplied)
NOTE: The new Macintosh computer
such as G3 will have the 15 pin HD con-
nector. The VT440/VT540's "Plug and
Play" data will be downloaded to the
Macintosh. Therefore, the Mac adapter
will not be necessary.
Macintosh (Notebook type)

E–20
When using a Macintosh computer with the projector, set the DIP
switches of the supplied pin adapter according to your resolution.
After setting, restart your Macintosh computer.
See the following pages for setting of the DIP switches.
• When using with a Macintosh, SVGA(8002600 :VT440)/
XGA(10242768 : VT540) is recommended if your Macintosh
supports this mode.
• When using with a Macintosh PowerBook, output may not be
set to 8002600 unless “mirroring” is off on your PowerBook.
Refer to owner’s manual supplied with your Macintosh com-
puter for mirroring.
NOTE: A Video Adapter cable manufactured by Apple Computer is
needed for a PowerBook which does not have a mini D-Sub 15-pin
connector.
Settings for Monitor Mode
Number of DIP switch 1 23 456
Resolution
13" multi-scan mode /16"-13" ON ON ON ON
17" multi-scan mode /19"-13" ON ON ON
21” multi-scan mode /21"-13" ON ON ON
13" fixed mode /640x480 ON ON
VGA/SVGA mode ON ON
16" fixed mode /832x624 ON ON
19" fixed mode /1024x768 ON ON
21" fixed mode /1152x870 ON ON ON ON
NOTE: For settings other than display modes supported by your
Macintosh and the projector, use of the DIP switch may bounce an
image slightly or may display nothing. If this happens, set the DIP
switch to the 13" fixed mode and then restart your Macintosh. After
that, restore to a displayable mode and then restart the Macintosh
again. Make sure that the projector and your Macintosh are con-
nected with the pin adapter and the supplied signal cable (mini D-
Sub 15-pin connector) and then restart your Macintosh.
Examples of DIP switch setting
17" multi-scan mode VGA/SVGA mode 19" fixed mode
NOTE: Refer to your computer’s owner’s manual for more informa-
tion about your computer’s video output requirements and any spe-
cial identification or configuring your projector’s image and moni-
tor may require.
321
ON
654321
ON
654 321
ON
654
