NEC M361X
Order Code: 60003406 NEC M361X Professional Desktop Projector
Get great performance while saving the environment.
Advanced Eco features help to substantially lower your
operating cost without compromising on quality and flexibility.
Go wide with your presentations and play video content in
native format.
The M361X is particularly suited for classrooms and small to
medium sized meeting rooms.
DELIVERING GENUINE BENEFITS
Get Great Performance - while not compromising on quality
and ease of use.
Intuitive Use - of latest Eco and projection technology due to
user-centric design.
Large Flexibility - in positioning the projector and minimized
cost for replacements.
Save the Environment - with latest Eco technology by
minimizing your power consumption and consumables
replacements.
Free DisplayNote Presenter Licence - present, share,
collaborate with multiple participants across multiple devices
(available until March 2014). Visit www.displaynote-nec.com.
Free Download of Multi-Display Management Software - with
NaViSet Administrator 2 you can manage all your connected
display devices from a centralized location.
OUTSTANDING PERFORMANCE
Maximum Flexibility with large 1.7x optical zoom
•
Minimized Cost of Ownership due to long lamp life and filter cleaning intervals
•
Innovative ECO Functions to reduce power consumption
•
Great Connectivity due to numerous analog and digital connection terminals as well as
network capability
•
Intuitive and Easy Operation with user centric design and lens cover
•
This document is © copyright 2013 NEC Display Solutions Europe GmbH.
All rights reserved in favour of their respective owners. All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All
specifications are subject to change without notice. Errors and omissions are excepted. 18.09.2013
www.nec-display-solutions.com

NEC M361X
SPECIAL CHARACTERISTICS
Auto Eco Mode, Automatic and manual Keystone Correction (V=
+/-30°), Carbon Savings Meter, Colour Management, Content
Transmission via Network, Contrast Ratio 3000:1 with Iris, Control
and administration via LAN, Crestron RoomView, DICOM
Simulation, Direct Power-Off Function, FREE DisplayNote
Presenter, High Altitude Mode, Kensington security slot, Keypad
Lock, Lens Cover, Magnify, NaViSet Administrator 2, Optional User
Logo, Optional WLAN, OSD with 29 languages, Password Security
System, Quick On/Off, RS-232 Control, Security Bar, USB Display,
USB Viewer for JPEG, Virtual Remote for direct PC control, Wall
Colour Correction, 100% recyclable packaging, Auto ECO Mode,
Green one touch ECO and AV mute button, 75% AV mute function,
Downloadable manuals, ECO scheduler, RoHs compliant, ECO
packaging, ErP compliant, Intelligent Power Management, WEEE,
Longer lamp life, Reduced power consumption. Only 0.4W stand-
by, Software scheduling
Energy
Efficiency
Auto ECO Mode; Green one touch ECO and AV
mute button; 75% AV mute function; ECO
scheduler; Intelligent Power Management;
Longer lamp life; Reduced power consumption.
Only 0.4W stand-by; Software scheduling
Ecological
Materials
100% recyclable packaging; Downloadable
manuals; ECO packaging
Ecological
Standards
RoHs compliant; ErP compliant; WEEE
Technical Specification NEC M361X
Display 3 x 1.6 cm (0.63") p-Si LCD Panel with MLA
Native Resolution 1024 x 768 (XGA)
Aspect Ratio 4:3
Contrast Ratio 13000:1
Brightness 13600 High Bright / 2700 Normal / 2160 Eco ANSI Lumens
Lamp 230 W AC (175 W AC Eco Mode)
Lamp Life [hrs] 8000 Eco / 5000 Normal / 4000 High Bright Mode
Lens F= 1.7–2.2, f= 17.5–29 mm
Projection Factor 1.3 – 2.2 : 1
Projection Distance [m] 0.6 – 13.8
Screen Size (diagonal) [cm] / [inch] Minimum: 63.5 / 25"; Maximum: 762 / 300"
Zoom Manual
Focus Adjustment Manual
Supported Resolutions 1920 x 1200 (WUXGA); 1920 x 1080 (HDTV 1080i/60; HDTV 1080i/50); 1680 x
1050 (WSXGA+); 1600 x 1200 (UXGA); 1600 x 900 (WXGA++); 1440 x 900 (WXGA
+); 1400 x 1050 (SXGA+); 1366 x 768 (WXGA); 1280 x 1024 (SXGA); 1280 x 960
(SXGA); 1280 x 800 (WXGA); 1280 x 768 (WXGA); 1280 x 720 (HDTV 720p); 1152
x 870 (MAC 21"); 1152 x 864 (XGA); 1024 x 768 (XGA); 832 x 624 (MAC 16"); 800 x
600 (SVGA); 720 x 576 SDTV 480p/480i; 720 x 576 (SDTV 576p/576i); 720 x 480
SDTV 576p/576i; 720 x 480 (SDTV 480p/480i); 640 x 480 (VGA/MAC 13")
Frequency Horizontal: 15–100 kHz (RGB: 24 kHz– 100 kHz); Vertical: 50 – 120 Hz
CONNECTIVITY
RGB (analog) Input: 2 x Mini D-sub 15-pin, compatible to component (YPbPr)
Output: 1 x Mini D-sub 15 pin
HDMI™ Input: 1 x HDMI™ (Deep Color, Lip sync)
Video Input: 1 x RCA
S-Video Input: 1 x Mini DIN 4-pin
Audio Input: 2 x 3.5 mm Stereo Mini Jack; 2 x RCA Stereo
Output: 1 x 3.5 mm Stereo Mini Jack (variable)
PC Control Input: 1 x D-Sub 9 pin (RS-232) (male)
LAN 1 x RJ45
USB 1 x Type B; 2 x Type A (USB 2.0 high speed)
Video Signals PAL; PAL60; NTSC; SECAM; NTSC 4.43; PAL-N; PAL-M
REMOTE CONTROL
Remote Control Aspect Ratio; Audio Control; Auto Adjust; AV Mute; Digital Zoom; Freeze; Help
Eco Mode; ID set; Optional Presentation and Mouse Control; Picture Adjust;
Picture Mode; Source Select
ELECTRICAL
Power Supply 100-240 V AC; 50 - 60 Hz
Power Consumption [W] 302 (High Bright); 236 (Normal) / 211 (Eco) / 8 (Network Stand-by) / 0.4 (Stand-
by)
MECHANICAL
Dimensions (W x H x D) [mm] 339 x 99 x 257 (without lens and feet)
Weight [kg] 2.99
Fan Noise [dB (A)] 28 / 28 / 35 (ECO / Normal / High Bright)
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] 5 to 40
Operating Humidity [%] 20 to 80
Storage Temperature [°C] -10 to 50
Storage Humidity [%] 20 to 80
ERGONOMICS
Safety and Ergonomics CE; ErP; TÜV GS; RoHS; Gost-R
Speakers [W] 1 x 10 (mono)
WARRANTY
Projectors 3 years pan-European service
Lamp 6 months, max. 1000 hrs
SHIPPING CONTENT
Shipping Contents IR Remote Control (RD-448E); Mini D-SUB Signal Cable (1.8 m); Power Cord (1.8
m); Utility software; Security Sticker; Soft Case; Users Manual on CD-ROM; Quick
Setup Guide
OPTIONAL ACCESSORIES
Optional Accessories DisplayNote; Lamp (NP16LP); Wireless LAN module NP02LM2 (Europe),
NP02LM3 (Russia)
1Compliance with ISO21118-2005
