NEC NC1200C
Order Code: 60002948 NEC NC1200C Digital Cinema Projector
Bring your establishment into the future with the NEC
NC1200C DLP® Digital Cinema Projector. Delivering
exceptional image quality, brightness, resolution, contrast and
colours together with a wealth of new revenue generation
opportunities and backed by the trusted performance of one of
the biggest names in Digital Cinema technology.
An ideal solution for smaller cinemas screens, screening rooms
and post production facilities.
DELIVERING GENUINE BENEFITS
Bring Your Establishment Into The IT Age - easy distribution
of movies and media, copyright and licensing management
offered in all IT formats.
Enjoy Lower TCO - with easy servicing, more durable
components and advanced servicing options. You can enjoy
better quality imaging whilst experiencing an overall lower cost
of ownership.
Generate Greater Per Seat Revenue - achieve additional
income from showing higher quality, more entertaining media
and arranging alternative sports, broadcast and education
media during off-peak operational times.
Play Captivating 3D Content - take your establishment into
the next generation and stay ahead of the competition with the
latest digital content, an increasingly essential element of the
latest movies and media.
OUTSTANDING PERFORMANCE
Suitable for Smaller Venues. Create outstanding images for screens up to 14 m wide,
with assured brightness of 9.700 Lumens using 2.0KW high-efficiency lamp.
•
High Resolution and Content utilising DLP® Cinema Technology from Texas
Instruments. Exceptional image and colour quality with contrast ratio of 2200:1 or
higher by using DMD chips that support a resolution of 2048 x 1080. This projector
faithfully reproduces digital cinema and high-definition input sources requiring superior
colour reproduction and wide gradation.
•
High Reliability. Newly designed separate cooling system creates positive air pressure
internally to prevent contaminations from entering the optical system and lamp area.
Lamp cooling air flow is separate from the main optics and electronics.
•
Auto Lamp Brightness and Control minimise fluctuations that occur during the life of
the lamp. The brightness level will not decrease as the lamp is consumed. These
projectors optimise lamp performance and ensure the brightest and most uniform
image possible for the life of the lamp.
•
This document is © copyright 2013 NEC Display Solutions Europe GmbH.
All rights reserved in favour of their respective owners. DLP Cinema and the DLP Cinema logo are registered trademarks of Texas Instruments. All other hardware and software names are
brand names and/or registered trademarks of the respective manufacturers. All specifications are subject to change without notice. Errors and omissions are excepted. 27.09.2013
www.nec-display-solutions.com

NEC NC1200C
OUTSTANDING PERFORMANCE
Minimal Maintenance and trouble-free lamp
replacement. Technicians can replace lamps simply
from the back of the projector even in cramped space.
•
Simple Operation. One touch operation, ergonomic
keyboard layout and memory functions. Optional scaler/
switcher for alternative content processing.
•
Built-in Web Server. Access and control projectors from
any authorised web browser.
•
Wide Converter Lens and Motorized Turret
•
Full Panel 3D triple-flash Capability. Amazing 3D
brightness.
•
SPECIAL CHARACTERISTICS
Latest digital technology, reduced costs, stunning and varied
content, additional security, unsurpassed quality.
Ecological Materials Eliminate waste and landfill implications
associated with 35mm media
Technical Specification NEC NC1200C
OPTICAL
Projection Method 3-chip DMD reflection method
Screen Size [m] 4 to 14
Brightness 9700 lumens when using 2KW high-efficiency Xenon lamp bulb
Contrast Ratio 2200 : 1 or above (full on / off)
Lamp High-efficiency Xenon lamp option (2 KW)
Lens Zoom / Focus: Motorized; Motorized
Shift: Horizontal/Vertical Motorized
Other: Dowser (light shutter); Lens memory stores lens setting (shift/zoom/
focus); Range of shift is dependent on lens
Primary Lenses: 1.2 to 1.8:1 zoom; 1.3 to 1.75:1 zoom; 1.4 to 2.05:1 zoom; 1.59 to
2.53:1 zoom; 1.9 to 3.25:1 zoom; 2.4 to 3.9:1 zoom; 3.9 to 6.5:1 zoom
DMD Specifications 2048 x 1080
Chip: 0.98" DLP
Tilt Angle [°]: 12
Cooling Method Liquid: Liquid cooling inside, air cooling with dust-preventing electrostatic filter
Total thermal dissipation [BTU]: 10600
Projector exhaust [m3/min]: 10
Demand of exhaust duct: Yes
CONNECTIVITY
External Controls 1 x D-Sub 37 pin (GPIO); 1 x D-Sub 15-pin (3D); 1 x D-Sub 9 pin (RS-232); 1 x
Remote control connector; 1 x USB port (TypeA); 1 x RJ45
Input Terminals 4 x HDSDI (BNC); 2 x DVI-D
ELECTRICAL
Power Supply Projector Power Supply Unit: C1 Connection (single cable): 200 to 240V AC,
50/60Hz, single phase; C2 Connection (separate cable): 100 to 240V AC,
50/60Hz, single phase
Lamp power supply unit [KVA]: C1 Connection (single cable): 200 to 240V AC,
50/60Hz, single phase; C2 Connection (separate cable): 200 to 240V AC,
50/60Hz, single phase
Power Consumption [W] 2680 max.
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] 5 to 35
Operating Humidity [%] 10 to 85 - non-condensing
Storage Temperature [°C] -10 to 50
MECHANICAL
External Dimensions (W x H x D) [mm] Projector Head 1: 700 x 503 x 990
Weight [kg] 92 (without lense)
Fan Noise [dB (A)] < 62
Regulations Europe EN55022 1998, Class A; EN55024 1998; EN61000-3-11; EN61000-3-12
OPTIONAL ACCESSORIES
Optional Accessories Air filter; Built-in alternative content processor; Optional input boards for
alternative content processor; Wide converter lens and motorized turret
WARRANTY
Warranty 2 year, parts warranty
1Excluding lens, lens hood and exhaust stack
