Introduction
Thank you for purchasing the LCD Projector NP350/NP50/NP150/NP350W.
This guide explains how to set the enhanced wireless LAN security (authentication
method) on the projector as shown on the table below.
Set the projector according to the security environment of your network.
Authentication
method
Encryption
type EAP type Digital certi- cate
Format of
certicate
Wireless LAN
WPA-PSK,
WPA-PSK
(→ Page 5)
TKIP
AES – Not used –
WPA-EAP,
WPA-EAP
(→ Page 9)
TKIP
AES
EAP-TLS Client certicate PKCS#1
CA Certicate DER
PEAP-
MSCHAPv CA Certicate DER
Important:
• Please note that instructions and explanation on security functions on the above table is
not included in the supplied “User’s Manual” or within the “Wired and Wireless Network
Setup Guide”.
• When you set WPA-EAP or WPA-EAP, be sure to set [DATE, TIME PRESET] before
installing digital certicates. (→ page 8)
If setting of [DATE, TIME PRESET] is not correct, a message “authentication error” will be
displayed.
• To install digital certicates on the projector, use a USB memory device in the market.

4
Other Notes
• Contact your network administrator for information about access point and settings
for authentication server (authentication method, encryption type, EAP type, and
digital certicates).
• For using the on-screen menu on the projector, see the “User’s Manual” (PDF) on
the supplied CD-ROM.
• See the supplied “Wired and Wireless Network Setup Guide” for instructions on set-
ting IP address, subnet mask, SSID, and WEP on the projector.
• WPA-PSK, WPA-EAP, WPA-PSK and WPA-EAP are available only when [INFRA-
STRUCTURE] is selected in [NETWORK TYPE] of the [CONNECTION] page. They
are not available when [AD HOC] is selected.
• WPA-PSK stands for “Wi-Fi Protected Access-Pre-Shared Key”, TKIP for “Temporal
Key Integrity Protocol”, AES for “Advanced Encryption Standard”, EAP for “Extensible
Authentication Protocol”, TLS for “Transport Layer Security”, PEAP for “Protected
Extensible Authentication Protocol”, MSCHAPv for “Microsoft Challenge Hand-
shake Authentication Protocol version ”, DER for “Distinguished Encoding Rules”,
PKCS for “Public-Key Cryptography Standards”.

5
1. Setting WPA-PSK or WPA2-PSK
From the on-screen menu on the projector, select [SETUP] → [INSTALLATION()] tab
→ [NETWORK SETTINGS] screen and follow the instructions below.
➊ Display the [NETWORK SETTINGS]
screen.
• See page 17 of “Wired and Wireless Network
Setup Guide” for setting wireless LAN.
➋ Use the SELECT ▶ button to select the
[WIRELESS] tab.
The [WIRELESS] page will be displayed.
➌ Set items such as PROFILE, DHCP, IP
ADDRESS, SUBNET MASK and others
as required.
• Select [PROFILE 1] or [PROFILE ] for
[PROFILES]. If [EASY CONNECTION] is se-
lected, WPA-PSK, WPA-PSK, WPA-EAP, or
WPA-EAP is not available.
➍ Use the SELECT ▼ button to select
[ADVANCED SETTINGS] and press the
ENTER button.
The [ADVANCED SETTINGS] screen will be
displayed.
➎ Select [SITE SURVEY] and press the
ENTER button.
The “SSID” list will be displayed.


➏ Use the SELECT ▼▲ button to select
a connecting SSID, and then press the
SELECT ▶ button to select [OK].
Finally press the ENTER button.
• Select the SSID for which WPA-PSK or
WPA-PSK is set.
• Select [INFRASTRUCTURE ( )] for [NET-
WORK TYPE]. WPA-PSK, WPA-PSK,
WPA-EAP, or WPA-EAP is not available
when [AD HOC ( )] is selected.
➐ Use the SELECT ▲ button to select the
[CONNECTION] tab and then SELECT ▶
button to select the [SECURITY] tab.
The [SECURITY] page will be displayed.
➑ Use the SELECT ▼ button to select the
[SECURITY TYPE] eld and press the
ENTER button.
The pull-down list will be displayed.
➒ Use the SELECT ▼▲ button to select
[WPA-PSK] or [WPA2-PSK] and press
the ENTER button.
❿ Use the SELECT ▼ button to select the
[TKIP/AES] eld and press the ENTER
button.
The pull-down list will be displayed.
⓫ Use the SELECT ▼▲ button to select
[TKIP] or [AES] and press the ENTER
button.
Select [TKIP] or [AES] according to the setting
for your access point.

7
⓬ Use the SELECT ▼ button to select the
[KEY] eld and press the ENTER but-
ton.
The character entry screen (software keyboard)
will be displayed. Set a key.
• A key must be between 8 and 3 characters
in length.
• See page  of “Wired and Wireless Network
Setup Guide” for using the software keyboard
to enter a key.
⓭ Use the SELECT ▼ button to select [OK]
and press the ENTER button.
The [WIRELESS] page will be returned.
⓮ Use the SELECT ▼ button to select [RE-
CONNECT] and press the ENTER but-
ton.
⓯ Use the SELECT ▼ button to select [OK]
and press the ENTER button.
This completes the WPA-PSK or WPA2-
PSK settings.

8
Before installing a digital certicate on the projector, you are required to set [DATE,
TIME PRESET] for checking the expiration date of the digital certicate.
Set the current date and time (i.e., local time), and the time zone.
Important:
• If setting of [DATE, TIME PRESET] is not correct, a message “authentication error” will be
displayed because of failure of checking the expiration date of the digital certicate when
you install a digital certicate. (→ page 1)
• The projector has a built-in clock. The clock will keep working for about  weeks after the
main power is turned off. If the main power is off for  weeks or more, the built-in clock
will cease. If the built-in clock ceases, set the date and time, and the time zone again.
The built-in clock will not cease while in the standby mode.
❶ Display the [DATE, TIME PRESET] set-
ting screen.
• From the on-screen menu, select [SETUP]
→ [BASIC] tab → [TOOLS] → [DATE, TIME
PRESET].
❷ Set the DATE, TIME and TIME ZONE.
❸ After setting, select [OK] and press the
ENTER button.
The DATE, TIME PRESET time has been set.
2. Setting DATE, TIME PRESET

9
Select a wireless LAN compliant WPA-EAP or WPA-EAP authentication and install a
digital certicate on the projector.
❶ Set [DATE, TIME PRESET] on the pro-
jector. (See previous page)
❷ Use a computer to save digital certi-
cates (les) for WPA-EAP or WPA2-EAP
setting to your USB memory device.
After completing saving the file, remove the
USB memory device from the computer.
Important:
• The file formats of digital certificate that are supported by the projector are DER and
PKCS#1 only.
• The projector cannot handle any digital certicate whose le size exceeds 8 KB.
• CRL (Certicate Relocation List) is not supported.
• Client certicate chain is not supported.
❸ Plug the USB memory device into the
USB port of the projector.
❹ Repeat steps ❶ on page 5 to ❽ on page
6.
The pull-down list will be displayed.
❺ Use the SELECT ▼▲ button to select
[WPA-EAP] or [WPA2-EAP] and press
the ENTER button.
❻ Use the SELECT ▼ button to select the
[TKIP/AES] eld and press the ENTER
button.
The pull-down list will be displayed.
LAMP
STATUS
POWER
ON/STAND BY
SOURCE
AUTO ADJUST
3D REFORM
SELECT
USB
LENS SHIFT
LEFT RIGHT
DOWN
UP
WIRELESS
WIRELESS
LENS SHIFT
LEFT RIGHT
DOWN
UP
LAMP
STATUS
POWER
ON/STAND BY
SOURCE
AUTO ADJUST
3D REFORM
SELECT
USB
LENS SHIFT
LEFT RIGHT
DOWN
UP
WIRELESS
WIRELESS
LENS SHIFT
LEFT RIGHT
DOWN
UP
3. Setting WPA-EAP or WPA2-EAP
USB port

10
❼ Use the SELECT ▼▲ button to select
[TKIP] or [AES] and press the ENTER
button.
Select [TKIP] or [AES] according to the setting
for your access point.
❽ Use the SELECT ▲ button to select the
[SECURITY] tab and press the SELECT
▶ button.
The [AUTHENTICATION] page will be dis-
played.
Select either [EAP-TLS] or [PEAP-MSCHAPv] for [EAP TYPE]. The setting items vary
depending on the EAP type.
See the table below.
EAP Type Setting Item Note
EAP-TLS
User Name 1 character or more and 3 characters or
less
Client Certicate PKCS#1 format le
CA Certicate
(Certicate authority’s certicate) DER format le
PEAP-MSCHAPv
User Name 1 character or more and 3 characters or
less
Password 1 character or more and 3 characters or
less
CA Certicate
(Certicate authority’s certicate) DER format le
① Selecting [EAP-TLS] for [EAP TYPE]:
The following section explains the operation for selecting [EAP-TLS].
For selecting [PEAP-MSCHAPv], go on to Step ➒ on page 13.
❾ Use the SELECT ▼ button to select
[USER NAME] eld and press the EN-
TER button.
The character entry screen (software keyboard)
will be displayed. Set a user name.
• A user name must be 1 character or more
and 3 characters or less.
• See page  of “Wired and Wireless Network
Setup Guide” for using the software keyboard
to enter characters.

11
❿ Use the SELECT ▼ button to select
[CLIENT CERTIFICATE] and press the
ENTER button.
A list of files (thumbnail screen) will be dis-
played.
• For operating the thumbnail screen, see “5.
Using the Viewer” in the “User’s Manual”
(PDF).
• To return to the [AUTHENTICATION] page,
press the EXIT button.
NOTE:
Installing a digital certicate
You can install each digital certicate (client certicate and CA certicate) for [PROFILE 1 (or
)] on a le-by-le basis.
• Install a root CA certicate for a CA certicate.
• If you install a digital certicate over your existing digital certicate, the existing digital cer-
ticate will be overwritten with the new digital certicate.
• Once a digital certicate has been installed, its information cannot be deleted even if you
stop setting WPA-EAP or WPA-EAP.
⓫ On the thumbnail screen, select a
digital certicate (PKCS#12 format le)
saved in your USB memory device and
press the ENTER button.
The password screen will be displayed.
⓬ Select [PASSWORD] eld and press the
ENTER button.
The character entry screen (software keyboard)
will be displayed. Set the password of the pri-
vate key. A password must be 1 character or
more and 3 characters or less.
The selected digital certificate file will be in-
stalled on the projector.
• When the root CA certicate is not included in
the le that was selected in Step ⓫, proceed
to Step ⓭. When the root certication author-
ity certicate is included, proceed to Step ⓯.
① Select a USB memory and
press the ENTER button. ② Highlight a digital certificate
and press the ENTER button.

1
⓭ Use the SELECT ▼ button to select [CA
CERTIFICATE] and press the ENTER
button.
A list of files (thumbnail screen) will be dis-
played.
⓮ On the thumbnail screen, select a digi-
tal certicate (DER format le) saved in
your USB memory device and press the
ENTER button.
• Select your root CA certicate here.
The selected digital certicate will be installed
on the projector.
⓯ After completing required settings, use
the SELECT ▼ button to select [OK] and
press the ENTER button.
The [WIRELESS] page will be returned.
⓰ Use the SELECT ▼ button to select [RE-
CONNECT] and press the ENTER but-
ton.
⓱ Use the SELECT ▼ button to select [OK]
and press the ENTER button.
This will complete setting [EAP-TLS] for
[EAP TYPE] in [WPA-EAP] or [WPA2-EAP].
HINT:
Clearing the digital certicate that is installed on the projector
To clear the digital certicate installed on the projector, follow the steps below.
By doing the following procedure, all the digital certicates for the currently displayed prole
will be cleared.
❶ Select [CLEAR CERTIFICATES] in the bot-
tom left of the [ADVANCED SETTINGS]
screen and press the ENTER button.
A message for conrmation will be displayed.
❷ Select [YES] and press the ENTER button.
The digital certicates will be cleared.

13
HINT:
• The PKCS#1 format digital certicate including a CA certicate will be installed as a root
CA certicate.
② Selecting [PEAP-MSCHAPv2] for [EAP TYPE]:
❾ From the [AUTHENTICATION] page, use
the SELECT ▼ button to select [EAP
TYPE] eld and press the ENTER but-
ton.
The pull-down list will be displayed.
❿ Use the SELECT ▼▲ button to select
[PEAP-MSCHAPv2] and press the EN-
TER button.
⓫ Use the SELECT ▼ button to select
[USER NAME] eld and press the EN-
TER button.
The character entry screen (software keyboard)
will be displayed. Set a user name.
• A user name must be 3 characters or less.
• See page  of “Wired and Wireless Network
Setup Guide” for using the software keyboard
to enter characters.
⓬ After completing setting a user name,
use the SELECT ▼ button to select the
[PASSWORD] eld and press the EN-
TER button.
The character entry screen (software keyboard)
will be displayed. Set a password.
• A password must be 3 characters or less.

14
⓭ After completing setting the password,
use the SELECT ▼ button to select [CA
CERTIFICATE] eld and press the EN-
TER button.
A list of files (thumbnail screen) will be dis-
played.
• For operating the thumbnail screen, see “5.
Using the Viewer” in the “User’s Manual”
(PDF).
• To return to the [AUTHENTICATION] page,
press the EXIT button.
NOTE:
Installing a digital certicate
You can install each digital certicate (client certicate and CA certicate) for [PROFILE 1 (or
)] on a le-by-le basis.
• Install a root CA certicate for a CA certicate.
• If you install a digital certicate over your existing digital certicate, the existing digital cer-
ticate will be overwritten with the new digital certicate.
• Once a digital certicate has been installed, its information cannot be deleted even if you
stop setting WPA-EAP or WPA-EAP.
⓮ On the thumbnail screen, select a digi-
tal certicate (DER format le) saved in
your USB memory device and press the
ENTER button.
• Select your root CA certicate here.
The selected digital certicate will be installed
on the projector.
⓯ After completing required settings, use
the SELECT ▼ button to select [OK] and
press the ENTER button.
The [WIRELESS] page will be returned.
⓰ Use the SELECT ▼ button to select [RE-
CONNECT] and press the ENTER but-
ton.
① Select a USB memory and
press the ENTER button. ② Highlight a digital certificate
and press the ENTER button.

15
⓱ Use the SELECT ▼ button to select [OK]
and press the ENTER button.
This will complete setting [PEAP-
MSCHAPv2] for [EAP TYPE] in [WPA-EAP]
or [WPA2-EAP].
HINT:
Clearing the digital certicate that is installed on the projector
To clear the digital certicate installed on the projector, follow the steps below.
By doing the following procedure, all the digital certicates for the currently displayed prole
will be cleared.
❶ Select [CLEAR CERTIFICATES] in the bot-
tom left of the [ADVANCED SETTINGS]
screen and press the ENTER button.
A message for conrmation will be displayed.
❷ Select [YES] and press the ENTER button.
The digital certicates will be cleared.

1
4. Checking Authentication Status on [INFORMATION] Screen
You can check your authentication status on the [INFORMATION] screen from the on-
screen menu.
❶ Display the [INFORMATION] screen.
• Use the first tab (main menu) to select [IN-
FORMATION].
❷ Select the [WIRELESS LAN(1)] tab.
The current authentication status will be dis-
played in the [AUTHENTICATION] eld.
The meanings of these status statements are described below.
Statement Authentication status
Authenticated Authentication is done correctly.
Failure Authentication failed.
Authenticating… Authentication is in process.
Expired The digital certicate is expired. Or [DATE, TIME PRESET] is
not set correctly.
Time Error The [DATE, TIME PRESET] has been cleared. Set the correct
date and time.
