Installation projector in WIDE SCREEN FORMAT –
with extended warranty for continuous use (3 years at 24/7**).
• Native Resolution: 1,280 x 768 (WXGA)
• Brightness: 4,500 ANSI Lumens
• Contrast Ratio: 2,100:1 (with DynamicBlack™)
• Motorized lens shift (vertical and horizontal)
• Quick lens replacement and 5 optional lenses
LCDs
•
Projectors
•
Plasmas
•
LCDs
•
Projectors
•
Plasmas
•
LCDs
•
Projectors
NEC NP4001

www.nec-display-solutions.com
NEC Display Solutions Europe GmbH
TECHNICAL SPECIFICATIONS
Article No.
Display
Lamp
Lamp Life
Brightness
Contrast Ratio
Standard-Lens
Minimum Diagonal
Maximum Diagonal
Projection Distance
Projection Factor
Frequency
Native Resolution
Supported Resolutions
INPUT/OUTPUT TERMINAL:
Computer Analog
Computer Digital
Component
Video
S-Video
Audio Output
LAN
Control
Video Signals
Audio Functions
Zoom Adjustment
Focus Adjustment
Benefits
Remote Control (RD-432E)
Dimensions (W x H x D)
Weight
Power Supply
Power Consumption
Calorific value
Fan Noise
Safety/Ergonomics
Warranty
Shipping Contents
Optional Accessories
5003 2331
1 x 1.78 cm (0.7") DMD Chip - DLP™ Technology (Aspect Ratio 15:9)
2 lamp system (2 x 260 W AC)
2,000 hrs (2,500 hrs Eco Mode)
4,500 ANSI Lumens (normal dual lamp mode); 2,200 ANSI Lumens (normal single lamp mode)
2.100:1 DynamikBlack™
NP08ZL, F= 1.7 - 1.9 (optional lense)
102 cm (40") with zoom lense
1,270 cm (500") with zoom lense
1.54 - 26.45 m (with NP08ZL)
1.78 - 2.35:1 (with NP08ZL)
Horizontal: 15, 31 - 90 kHz, vertical: 50 - 85 Hz
1,280 x 768 (WXGA)
1,600 x 1,200 (UXGA), 1,400 x 1,050 (SXGA+), 1,280 x 1,024 (SXGA), 1,152 x 870 (Mac), 1,920 x
1,080 (HDTV 1,080i@50/60 Hz) compressed signal, 1,280 x 768 (WXGA), 1280 x 960, 1,280 x 720
(HDTV 720p), 1,024 x 768 (XGA), 800 x 600 (SVGA), 832 x 624 (Mac), 640 x 480 (VGA/Mac), NTSC,
PAL, PAL60, SECAM
1 input: Mini D-SUB 15-pin, shared with component signal (YPbPr)
1 input: 5BNC, shared with component signal (YPbPr)
2 inputs: Audio 3.5 mm stereo mini jack
1 output: Mini D-SUB 15-pin
1 input: DVI-I with HDCP, 1 input: Audio 3.5 mm stereo mini jack
1 input: 3 x RCA (phono jack), 1 input: Audio 2 x RCA (L/R)
1 input: RCA (phono jack), 1 input: Audio 2 x RCA (phono jack) for S-Video or video
1 input: mini DIN 4-pin
1 output: 3.5 mm stereo mini jack variable, for computer 1, 2, 3 (DVI-D), component, S-video, video
1 input: RJ45, 10/100 base-T
1 input: PC control (RS-232): D-SUB, 9-pin ( male)
1 input: Remote1 : D-Sub, 9-pin for external control device (GPIO)
1 input: Remote 2: 3.5 mm stereo mini jack
1 output: 3.5 mm stereo mini jack for screen trigger
1 input: Type B (for service)
PAL/PAL60/NTSC/SECAM/NTSC 4.43/PAL-N/PAL-M/PAL-B,G,H,I
2 x 3 W stereo speaker
Motorized
Motorized
Lens shift (vertical 0.5 max., horizontal ± 0.1 max.), optional lenses (5 types), quick lense replace-
ment, Direct-Power-Off function, 3x security functions, Keystone Correction (H= ±35°, V= ±40°),
LAN function, remote control with laser pointer, help function, Plug&Play
Laser pointer, zoom/focus and lens shift control, source select, automatic picture adjustment, picture
mute-, freeze-, aspect ratio- and help-function, lamp mode-, page- and mouse control
505 x 197 x 385 mm (without lens and feet)
16.5 kg/17 kg (with NP08ZL)
100 - 240 V AC/50 - 60 Hz
640 W (normal dual lamp mode, 540W ECO Dual lamp mode)
340 W (normal single lamp mode, 310W ECO single lamp mode)
<30 W Stand-by normal Mode, < 5 W Power Saving Mode
Max: 2,235 BTU (1 kWh= 3,412.14 British Thermal Unit)
ECO mode: 30dB(A) (single lamp), 34dB(A) (dual lamp);
Normal mode: 34dB(A) (single lamp), 36dB(A) (dual lamp)
CE, TÜV, GS
Projector: 3 years pan-European premium service, Lamp: 6 months**, 24 x 7 Warranty**
Projector, remote control (RD-432E), 6-segment colour wheel, power cord (3.6 m), remote control
cable (10 m), lens cap, users manual in 6 languages
Lamp NP04LP, lenses: NP06FL (0.77:1), NP07ZL (1.33 - 1.79:1), NP08ZL (1.78 - 2.35:1), NP09ZL
(2.22 - 4.43:1), NP10ZL (4.43-8.3:1), ceiling mount kit NP06CM
NP4001-UK_8/07
NEC NP4001
LCDs
•
Projectors
•
Plasmas
•
LCDs
•
Projectors
•
Plasmas
•
LCDs
•
Projectors
•
Plasmas
•
LCDs
•
Projectors
•
Plasmas
•
LCDs
* Eco Mode
** please refer to our warranty conditions under www.nec-display-solutions.com
