NetComm NTC-4000 series User manual

NetCommWireless
Quick Start Guide
NTC-4000 Series -
M2M Intelligent Serial Router

| Wireless M2M
2
NetCommWireless
Quick Start Guide
This guide covers the NTC-4000 Series M2M WiFi Rotuers. This guide
provides a series of step by step instructions to ensure the conguration
of your router goes as smoothly as possible.
Please check that you have received all the items in your package:
The NTC-4000 series package consists of:
NTC-4000 Series Modem Device
RS-232 Data/Power Cable 1m
SMA Antenna
Mounting bracket
Quick Start Guide
If any of these items are missing, please contact NetComm Wireless
Technical Support.
Reset
Button
SIM card Tray
Cellular Data LED
Power LED
RJ-45 port
(serial RS-232 data and
DC power input)
Mini
USB port SMA
antenna
connector

| Wireless M2M
3
NTC-4000 Series - M2M Intelligent Serial Router
Installing your Router
Inserting the SIM card
Please ensure that the NTC-4000 is not connected to the power
cable before proceeding.
Push the small yellow button besides the SIM card holder.
Insert the SIM card into the holder with the SIM conductor pins
facing up.

| Wireless M2M
4
NetCommWireless
Insert the SIM card holder with the SIM conductor pins facing
down into the NTC-4000.

| Wireless M2M
5
NTC-4000 Series - M2M Intelligent Serial Router
Connecting the Data/
Power cable
Connect the included antenna to the SMA connector of the
NTC-4000.
Plug the included RS-232 data/power cable into the RJ-45
socket of the NTC-4000 and then plug the serial port (DB9) end
of the same cable into the COM port of the device you would like
to connect to.
Connect a compatible power adapter to the DC power jack
(2.1mm barrel) of the RS-232 data/power cable and then plug the
power adapter into a power outlet.
WARNING
Please note: It is not possible to utilise the mini-USB and Serial connection concurrently.
Make sure any open connection on the Serial port is disabled before connecting via the
mini-USB cable.

| Wireless M2M
6
NetCommWireless
Connecting via mini USB
Please refer to the NTC-4000 Series User Manual for instructions on
utilising the mini USB connection.
Please note: The mini USB cable is not supplied with the NTC-4000 Series.

| Wireless M2M
7
NTC-4000 Series - M2M Intelligent Serial Router
Communicating with the
NTC-4000 Series
Any terminal emulator can be utilised to facilitate communication
to the NTC-4000 Series. In the example below, HyperTerminal from
Windows XP is shown.
Click on the Start button and then navigate to the Accessories
item and then Communications.
Click on the HyperTerminal item.
Enter a name for the connection prole (for example: NTC-4000)
and click OK.
On the Connect to window, select the COM port the NTC-4000
Series is connected to in the Connect using dropdown menu.

| Wireless M2M
8
NetCommWireless
On the COM port settings window that appears, select 115200 in
the Bits per second dropdown menu.
The terminal window should then display indicating a connection is
open to the NTC-4000 Series. This can be tested by entering the
command at+i and receiving the response I/OK as shown below:
You can now use the enhanced AT command set to congure
or perform tasks on the NTC-4000 Series. Please refer to the AT
Command Set guide for more information on the functions available.
If you are unable to type at+i, check that you have selected the correct
COM port to attempt to connect on. This should be the physical COM
port with the supplied DB-9 cable attached.

| Wireless M2M
9
NTC-4000 Series - M2M Intelligent Serial Router
AT Commands
Please refer to the AT Command Set guide available from the Downloads
tab at: www.netcommwireless.com/product/m2m/ntc-4000
This guide contains a full list of the supported AT Commands available
with the NTC-4000 series.

| Wireless M2M
10
NetCommWireless
Mounting Options
The NTC-4000 series modem can be mounted on the wall or a DIN rail
by using the mounting bracket. The mounting bracket is made from
polyamide, which is a exible material.
Mounting the NTC-4000 series modem is as simple as bending the
mounting bracket to snap into place on the Type-O (Top Hat) DIN rail.
This holds the NTC-4000 series modem in place securely.
Alternatively, the mounting bracket can be screwed onto a wall to
provide a permanent xture.
DIN rail mounting
The NTC-4000 Series mounting bracket has been designed to t a TS
35 Type-O DIN rail with a 25mm core.
Bend / Flex the mounting bracket at the bend line so that
the ridges are able to hold onto the DIN rail edges as per
the diagram above. You also have the option of securing the
mounting backet further by screwing it into place on the rail.
DIN Rail
