NETGEAR WAG511 - 802.11a/b/g Dual Band Wireless PC... User manual

202-10041-03
March 2007
NETGEAR, Inc.
4500 Great America Parkway
Santa Clara, CA 95054 USA
NETGEAR Dual Band
Wireless PC Card 32-bit
CardBus WAG511 User
Manual

ii
v4.0, March 2007
Technical Support
See the support information card that shipped with your product. By registering your product at
http://www.netgear.com/register, we can provide you with faster expert technical support and
timely notices of product and software upgrades.
NETGEAR, INC. Support Information
Phone: 1-888-NETGEAR, for US & Canada only. For other countries, see your Support
information card.
E-mail: [e-mail]
website: http://www.netgear.com
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to
make changes to the products described in this document without notice. NETGEAR does not assume any liability that
may occur due to the use or application of the product(s) or circuit layout(s) described herein.
© 2007 NETGEAR, Inc.
NETGEAR, the NETGEAR logo, The Gear Guy and Everybody's Connecting are trademarks or registered trademarks
of NETGEAR, Inc. in the United States and/or other countries. Microsoft and Windows are registered trademarks of
Microsoft Corporation in the United States and/or other countries. Other brand and product names are trademarks or
registered trademarks of their respective holders. Information is subject to change without notice. All rights reserved.
Maximum Wireless Signal Rate Derived from IEEE Standard 802.11 Specifications
Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic,
building materials and construction, and network overhead, lower actual data throughput rate.
Safety and Regulatory Notices
FCC Statement
The WAG511 has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the
FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment or devices

v4.0, March 2007
iii
• Connect the equipment to an outlet other than the receiver’s
• Consult a dealer or an experienced radio/TV technician for assistance
FCC Caution: Any change or modification to the product not expressly approved by NETGEAR could void the user’s
authority to operate the device.
FCC RF Radiation Exposure and SAR Statements
SAR Statement
The NETGEAR WAG511 has been tested for body-worn Specific Absorption Rate (SAR) compliance. The FCC has
established detailed SAR requirements and has established that these requirements have been met while installed in a
host notebook computer.
RF Exposure Information
The radio module has been evaluated under FCC Bulletin OET 65C (01-01) and found to be compliant to the
requirements as set forth in CFR 47 Sections, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency
devices. This model meets the applicable government requirements for exposure to radio frequency waves. The highest
SAR level measured for this device was 0.74 W/kg.
Canadian Department of Communications Industry Canada (IC) Notice
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Cet appareil numérique de la classe B
est conforme à la norme NMB-003 et CNR-210 du Canada.
“To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from
windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to
licensing.”
“Pour empêcher que cet appareil cause du brouillage au service faisant l’objet d’une licence, il doit être utilisé à
l’intérieur et devrait être placé loin des fenêtres afin de fournir un écran de blindage maximal. Si le matériel (ou son
antenne d’émission) est installé à l’extérieur, il doit faire l’objet d’une licence.”
Europe - EU Declaration of Conformity
A printed copy of the EU Declaration of Conformity certificate for this product is provided in the WAG511 product
package.
Èesky
[Czech] NETGEAR, Inc. tímto prohlašuje, že tento NETGEAR Dual Band Wireless PC Card 32-
bit CardBus WAG511 je ve shodì se základními požadavky a dalšími pøíslušnými
ustanoveními smìrnice 1999/5/ES.
Dansk
[Danish] Undertegnede NETGEAR, Inc. erklærer herved, at følgende udstyr NETGEAR Dual
Band Wireless PC Card 32-bit CardBus WAG511 overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF.
Deutsch
[German] Hiermit erklärt NETGEAR, Inc., dass sich das Gerät NETGEAR Dual Band Wireless PC
Card 32-bit CardBus WAG511 in Übereinstimmung mit den grundlegenden Anforderungen
und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.

v4.0, March 2007
iv
Eesti
[Estonian] Käesolevaga kinnitab NETGEAR, Inc. seadme NETGEAR Dual Band Wireless PC Card
32-bit CardBus WAG511 vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
English Hereby, NETGEAR, Inc., declares that this NETGEAR Dual Band Wireless PC Card 32-
bit CardBus WAG511 is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Español
[Spanish] Por medio de la presente NETGEAR, Inc. declara que el NETGEAR Dual Band Wireless
PC Card 32-bit CardBus WAG511 cumple con los requisitos esenciales y cualesquiera
otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek] ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ NETGEAR, Inc. ΔΗΛΩΝΕΙ ΟΤΙ NETGEAR Dual Band Wireless
PC Card 32-bit CardBus WAG511 ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ
ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French] Par la présente NETGEAR, Inc. déclare que l'appareil NETGEAR Dual Band Wireless
PC Card 32-bit CardBus WAG511 est conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE.
Italiano
[Italian] Con la presente NETGEAR, Inc. dichiara che questo NETGEAR Dual Band Wireless PC
Card 32-bit CardBus WAG511 è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian] Ar šo NETGEAR, Inc. deklarç, ka NETGEAR Dual Band Wireless PC Card 32-bit
CardBus WAG511 atbilst Direktîvas 1999/5/EK bûtiskajâm prasîbâm un citiem ar to
saistîtajiem noteikumiem.
Lietuviø
[Lithuanian] Šiuo NETGEAR, Inc. deklaruoja, kad šis NETGEAR Dual Band Wireless PC Card 32-bit
CardBus WAG511 atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch] Hierbij verklaart NETGEAR, Inc. dat het toestel NETGEAR Dual Band Wireless PC Card
32-bit CardBus WAG511 in overeenstemming is met de essentiële eisen en de andere
relevante bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese] Hawnhekk, NETGEAR, Inc., jiddikjara li dan NETGEAR Dual Band Wireless PC Card 32-
bit CardBus WAG511 jikkonforma mal-tiijiet essenzjali u ma provvedimenti orajn relevanti li
hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian] Alulírott, NETGEAR, Inc. nyilatkozom, hogy a NETGEAR Dual Band Wireless PC Card
32-bit CardBus WAG511 megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/
EC irányelv egyéb elõírásainak.
Polski [Polish] Niniejszym NETGEAR, Inc. oœwiadcza, ¿e NETGEAR Dual Band Wireless PC Card 32-
bit CardBus WAG511 jest zgodny z zasadniczymi wymogami oraz pozosta³ymi
stosownymi postanowieniami Dyrektywy 1999/5/EC.
Português
[Portuguese] NETGEAR, Inc. declara que este NETGEAR Dual Band Wireless PC Card 32-bit
CardBus WAG511 está conforme com os requisitos essenciais e outras disposições da
Directiva 1999/5/CE.
Slovensko
[Slovenian] NETGEAR, Inc. izjavlja, da je ta NETGEAR Dual Band Wireless PC Card 32-bit CardBus
WAG511 v skladu z bistvenimi zahtevami in ostalimi relevantnimi doloèili direktive 1999/5/
ES.

v4.0, March 2007
v
Product and Publication Details
Slovensky
[Slovak] NETGEAR, Inc. týmto vyhlasuje, že NETGEAR Dual Band Wireless PC Card 32-bit
CardBus WAG511 spåòa základné požiadavky a všetky príslušné ustanovenia Smernice
1999/5/ES.
Suomi
[Finnish] NETGEAR, Inc. vakuuttaa täten että NETGEAR Dual Band Wireless PC Card 32-bit
CardBus WAG511 tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä
koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish] Härmed intygar NETGEAR, Inc. att denna [utrustningstyp] står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv
1999/5/EG.
Model Number: WAG511
Publication Date: March 2007
Product Family: wireless adapter
Product Name: NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511
Home or Business Product: Business
Language: English
Publication Part Number: 202-10041-03

v4.0, March 2007
vi

vii
v4.0, March 2007
Contents
About This Manual
Conventions, Formats and Scope .................................................................................... ix
How to Use This Manual ...................................................................................................x
How to Print this Manual ....................................................................................................x
Chapter 1
Basic Setup
What You Need Before You Begin ..................................................................................1-1
Observe Wireless Location and Range Guidelines ..................................................1-2
Default Wireless Settings .........................................................................................1-2
Installation ......................................................................................................................1-3
Connecting to Wireless Networks and the Internet ........................................................1-6
WAG511 Icon Colors ................................................................................................1-6
Smart Wizard Status Bar ..........................................................................................1-7
WAG511 LEDs .........................................................................................................1-8
Removing the WAG511 Software ...................................................................................1-8
Upgrading the WAG511 Software ...................................................................................1-8
Chapter 2
Network Connections and Wireless Security
Disabling the Windows Zero Configuration Utility ...........................................................2-1
Understanding the Smart Wireless Utility .......................................................................2-2
Viewing Wireless Networks in Your Area ........................................................................2-2
Profiles ............................................................................................................................2-4
Adding Profiles .........................................................................................................2-4
Setting up a Profile to Connect to an Access Point or Router ..................................2-5
Setting up a Computer-to-Computer (Ad Hoc) Profile ..............................................2-6
Starting a Computer-to-Computer (Ad Hoc) Network Connection ...........................2-7
Wireless Security ............................................................................................................2-8
Wireless Network Name (SSID) and Security Settings ............................................2-9
Setting up WEP Encryption Security ......................................................................2-10

viii
v4.0, March 2007
Setting up Advanced Security ................................................................................2-11
Advanced Settings ........................................................................................................2-12
Statistics Page ..............................................................................................................2-13
About Page ...................................................................................................................2-14
Chapter 3
Troubleshooting
Troubleshooting Tips ......................................................................................................3-1
Ad Hoc Mode is Not Working Correctly ..........................................................................3-2
XP Professional and XP Home occasional connection problems ..................................3-3
Appendix A
Factory Default Settings and Technical Specifications
Factory Default Settings ................................................................................................ A-1
Technical Specifications ................................................................................................. A-2
Appendix A
Related Documents

ix
v4.0, March 2007
About This Manual
The NETGEAR®Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual describes
how to install, configure, and troubleshoot the NETGEAR Dual Band Wireless PC Card 32-bit
CardBus WAG511. The information in this manual is intended for readers with intermediate
computer and Internet skills.
Conventions, Formats and Scope
The conventions, formats, and scope of this manual are described in the following paragraphs:
•Typographical Conventions. This manual uses the following typographical conventions:
•Formats. This manual uses the following formats to highlight special messages:
•Scope. This manual is written for the WAG511 Wireless PC Card according to these
specifications:
Italics Emphasis, books, CDs, URL names
Bold User input
Note: This format is used to highlight information of importance or special interest.
Tip: This format is used to highlight a procedure that will save time or resources.
Product Version NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511
Manual Publication Date March 2007

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
x
v4.0, March 2007
For more information about network, Internet, firewall, and VPN technologies, see the links to the
NETGEAR website in Appendix A, “Related Documents”.
How to Use This Manual
The HTML version of this manual includes the following:
• Buttons, and , for browsing forwards or backwards through the manual one page
at a time
• A button that displays the table of contents and an button. Double-click on a
link in the table of contents or index to navigate directly to where the topic is described in the
manual.
• A button to access the full NETGEAR, Inc. online knowledge base for the product
model.
• Links to PDF versions of the full manual and individual chapters.
How to Print this Manual
To print this manual you can choose one of the following several options, according to your needs.
•Printing a Page in the HTML View.
Each page in the HTML version of the manual is dedicated to a major topic. Use the Print
button on the browser toolbar to print the page contents.
Note: Product updates are available on the NETGEAR, Inc. website at
http://kbserver.netgear.com/products/WAG511.asp.
Tip: If your printer supports printing two pages on a single sheet of paper, you can save
paper and printer ink by selecting this feature.

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
xi
v4.0, March 2007
•Printing a Chapter.
Use the PDF of This Chapter link at the top left of any page.
– Click the PDF of This Chapter link at the top left of any page in the chapter you want to
print. The PDF version of the chapter you were viewing opens in a browser window.
– Your computer must have the free Adobe Acrobat reader installed in order to view and
print PDF files. The Acrobat reader is available on the Adobe Web site at
http://www.adobe.com.
– Click the print icon in the upper left of the window.
•Printing the Full Manual.
Use the Complete PDF Manual link at the top left of any page.
– Click the Complete PDF Manual link at the top left of any page in the manual. The PDF
version of the complete manual opens in a browser window.
– Click the print icon in the upper left of the window.

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
xii
v4.0, March 2007

1-1
v4.0, March 2007
Chapter 1
Basic Setup
The WAG511 Wireless PC Card lets you connect a PC computer to wireless networks. It is
designed for PC computers running Microsoft Windows. For information about product features
and compatible NETGEAR products, please see the NETGEAR website at
http://www.netgear.com.
This chapter describes how to install your NETGEAR Dual Band Wireless PC Card 32-bit
CardBus WAG511 and set up basic wireless connectivity on your Wireless Local Area Network
(WLAN). Advanced wireless network settings are covered in Chapter 2, “Network Connections
and Wireless Security” in this manual.
What You Need Before You Begin
You must verify that your computer meets the minimum system requirements and identify the
wireless network settings of the wireless network where you will connect before you can set up
your wireless PC card and connect.
Verify System Requirements
Before installing the WAG511 Wireless PC Card, make sure that these minimum requirements
have been met. You must have a computer with:
• A Pentium®300 MHz or higher compatible processor with an available CardBus slot.
•ACDdrive.
• 5 Mbytes of free hard disk space.
• Microsoft Vista, Windows XP Home, XP Professional, or Windows 2000
Some versions of Windows may ask for the original Windows operating system installation
files to complete the installation of the WAG511 driver software.

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
1-2
v4.0, March 2007
Observe Wireless Location and Range Guidelines
Computers can connect over wireless networks indoors at a range that can vary significantly based
on the location of the computer with the WAG511 Wireless PC Card. For best results, avoid
potential sources of interference, such as:
• Large metal surfaces
• Microwave ovens
• 2.4 GHz cordless phones
In general, wireless devices can communicate through walls. However, if the walls are constructed
with concrete, or have metal, or metal mesh, the effective range will decrease if such materials are
between the devices.
What Is in the Box
The product package should contain the following items:
• NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511
• Installation Guide for the NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511
• NETGEAR CD, including:
– Driver and Utility Software
–NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual (this
document)
– Animated Network Properties Configuration Tutorial
– PC Networking Tutorial
• Warranty card
• Support information card
If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the
carton, including the original packing materials, in case you need to return the product for repair.
Default Wireless Settings
If this is a new wireless network installation, use the factory default settings to set up the network
and verify wireless connectivity. If this is an addition to an existing wireless network, you need the
wireless network and wireless security settings that are already defined.

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
1-3
v4.0, March 2007
Your WAG511 Wireless PC Card factory default basic settings are:
• Network Name Service Set Identification (SSID): ANY
• Network Mode (Infrastructure or Ad-hoc): Infrastructure
• Data security WEP, WPA2-PSK, or WPA-PSK encryption: Disabled
The section below provides instructions for setting up the WAG511 Wireless PC Card for basic
wireless connectivity to an access point.
Installation
This chapter explains how to install the WAG511 to connect to a network with an access point or
router. For wireless security and advanced settings, Chapter 2, “Network Connections and
Wireless Security”.
To install the WAG511 Wireless PC Card:
1. First, install the WAG511 software.
a. Insert the NETGEAR CD. If the CD main page does not appear, double click Autorun.exe
on the CD.
b. Click Install Driver & Utility.
Note: In order for the WAG511 Wireless PC Card to communicate with a wireless
access point or wireless adapter, all devices must be set up to use the same
wireless network name (SSID).
Figure 1-1

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
1-4
v4.0, March 2007
c. The InstallSheild wizard screen opens.
d. Follow the wizard prompts to install the Smart Wizard Wireless Utility. When the
Installation Complete message appears, click Finish.
2. Next, install the WAG511 Wireless PC Card.
a. Hold the PC Card with the NETGEAR logo facing up and insert it into a CardBus slot.
After a short delay, the Found New Hardware Wizard displays.
Figure 1-2
Figure 1-3
Note: If a Windows XP logo testing warning appears, click Continue Anyway to
proceed.

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
1-5
v4.0, March 2007
b. Follow the Found New Hardware Wizard prompts, and click Finish when done.
c. Windows 2000 users go to Step 3. Windows XP or Vista users can set up the wireless
adapter with the NETGEAR Smart Wireless Settings Utility (recommended) or the
Windows configuration utilities.
•NETGEAR Smart Wireless Settings Utility: Reveals more information about each
network and makes it easier to troubleshoot network connection problems.
•Windows configuration utilities: See the Windows documentation or “Using
Windows XP and Vista Wireless Configuration Utilities” at:
http://documentation.netgear.com/reference/enu/winzerocfg/index.htm
d. Click Next to accept the NETGEAR Smart Wireless Settings Utility.
3. Now, configure the WAG511 and save the Profile.
The WAG511 icon appears in the system tray and on the desktop. The wizard initiates
your wireless connection. It could take up to a minute to establish your wireless connection.
The Smart Wireless Utility Settings page opens.
4. Use the status bar to verify your wireless connectivity.
For more details about connecting, see “Connecting to Wireless Networks and the Internet” on
page 1-6.
Figure 1-4

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
1-6
v4.0, March 2007
Connecting to Wireless Networks and the Internet
The WAG511 has indicators in three locations that show the status of your connection to a wireless
network and to the Internet:
• Icon: After you install the software, this icon appears on the desktop and in the lower
right of the Windows task bar. It is color coded to show the status of the connection. See
“WAG511 Icon Colors” on page 1-6.
•Smart Wizard Status Bar: Clicking on the system tray icon opens the Smart Wizard. The
status bar at the bottom of the page shows details about your wireless and Internet connection.
See “Smart Wizard Status Bar” on page 1-7.
•WAG511 Wireless PC Card LED: The LED on the wireless PC card shows the network
connection. See “WAG511 LEDs” on page 1-8.
WAG511 Icon Colors
The WAG511 icon is on the desktop and in the Windows System Tray (SysTray). The System Tray
is located on one end of the taskbar in the Microsoft Windows desktop.
Color Condition Description
Red The wireless PC card has no
connection to any other
wireless node.
The wireless PC card is not able to link to any other wireless
node or the link is lost. Check your configuration or try moving
to a location where the wireless signal quality is better.
Yellow The wireless PC card has a
connection with another
wireless node.
The wireless link is weak. You may need to move to a better
spot, such as closer to the wireless access point. Also, look
for possible interference such as a 2.4 GHz cordless phone or
large metal surface.
Green The wireless PC card has a
connection with another
wireless node.
The wireless PC card has established good communication
with an access point and the signal quality is strong.

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
1-7
v4.0, March 2007
Smart Wizard Status Bar
Click the icon to open the Smart Wizard so you can view the status bar. The Smart Wizard
Settings page opens. The status bar is located at the bottom of the Settings page.
The following table describes how to interpret the Smart Wizard status bar.
Figure 1-5
Understanding the Status Bar
Wireless network Identifies which wireless network you have joined.
Security • Locked: security enabled.
• Unlocked: security not enabled.
Channel The wireless channel used by the network. If many wireless networks in your
area use the same channel they can interfere with one another.
Throughput Wireless throughput measured in Mega bits per second.
Signal strength More dots indicates a stronger signal. Usually, you will experience higher
throughput when the signal is strongest.
Note: To optimize throughput, connect to a network with a high-speed router or access
point, and a high-speed Internet connection.
Wireless
network
Security Channel Throughput
Signal
strength

NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 User Manual
1-8
v4.0, March 2007
WAG511 LEDs
The two LEDs on the NETGEAR Dual Band Wireless PC Card 32-bit CardBus WAG511 indicate
the condition of the wireless link.
Removing the WAG511 Software
If necessary, you can remove the wireless adapter software in these two ways:
• Navigate the Windows Start menu to the WAG511 Wireless PC Card program group, select
the uninstall option, and follow the screen prompts.
• Navigate the Windows Start menu to the Control Panel Add or Remove Program item, select
the WAG511 Wireless PC Card option, and follow the screen prompts.
Upgrading the WAG511 Software
Upgrades may be available at the NETGEAR website.
To install an upgrade:
1. Write down the settings for any profiles that you want to save. They will not be retained.
2. Download the upgrade from the NETGEAR website Support page.
3. Remove the WAG511 software from your computer.
4. Remove the WAG511 adapter from your laptop computer, and if prompted restart your
computer.
5. Run the installer that you downloaded (the file ends in .exe).
LED 1 LED 2 Meaning
Slow blink OFF Power save mode (default from power up or reset)
Alternate
blink Alternate blink Looking for network association
Slow blink Slow blink Associated or joined with network; no activity
Fast blink Fast blink Associated or joined with network; blink rate increases with activity on the
network over the air or locally on the network
Off Off No power applied to the card
