NETGEAR DS309 User manual

™
NETGEAR
The DS309 Dual Speed Hub connects PCs to share printers, files,Internet access,
and e-mail communications. One can mix and match 10 and 100 Mbps PCs, servers,
and peripherals with ease and without the high cost and complexity of multiple hubs
and bridges. A switched port enables any number of DS309s to be stacked together
with simple Cat 5 UTP cable for
network expansion
KEY FEATURES
•Auto-sensing
dual-speed ports
•Switched port for
network expansion
•Full connectivity
among devices
•Status indicators
on front and back
•Home and home
office friendly
•Easy, plug-and-play
installation
•Free, 24-hour
phone support
Auto-sensing dual-speed ports
One can connect 10 or 100 Mbps network
devices to the hub. Each port individually
senses and adjusts to run at the proper speed.
Switched port for network expansion
Any number of DS309s can be stacked together
or to other hubs or switches using simple Cat 5
UTP cable.
Full connectivity among devices
Each unit has a built-in self-learning bridge which
provides the communications link between the 10
and 100 Mbps network devices.
Status indicators on front and back
With status indicators on the front and back
and network cables coming off the back, the user
can easily monitor network operation without
having cables clutter up the desktop.vista network
ports with built-in LEDs help with network setup
and troubleshooting.
Home and home office friendly
The DS309 is Class B EMI compliant which
means it does not electronically interfere with
your home appliances.It features a small, 10-inch
design and can be inconspicuously placed on the
desktop or be tucked away. It provides an internal
power supply, eliminating the need for a bulky
wall transformer.
Easy, plug-and-play installation
Once powered on, the unit starts to operate with
no configuration required.
Free, 24-hour phone support
in English, with local language support in
selected countries.
SMALL OFFICE
HOME OFFICE
SOHO
designed for
MODEL
10/100Mbps DualSpeedHubDS309
PORT
9
http://netgear.baynetworks.com

Standards Compliance
IEEE 802.3i 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Network Ports
Eight 10 or 100 Mbps RJ-45 ports for PCs
One switched (separate collision domain) 10 or 100 Mbps RJ-45 port for server,
backbone, or PC connection
Status LEDs
Unit Power
10 Mbps segment Utilization %, collision
100 Mbps segment Utilization %, collision
Each hub port 10 or 100 Mbps operations
link, receive data
Switched port 10 or 100 Mbps operations
link, activity (receive or
transmit data)
Dimensions
W 253 mm (10”)
D 180 mm (7”)
H 35 mm (1.4”)
Weight
1.3 kg (2.8 lb)
AC Power
0.15A max
Autosensing 100 to 240V, 50/60 Hz
North America, Japan, UK, Europe, Australia
Electromagnetic Compliance
FCC Part 15 Class B
VCCI Class B
EN55022 (CISPR 22), Class B
C-Tick
Safety Agency Approvals
UL listed (UL 1950)/cUL
IEC950/EN60950
Warranty
Switch - 5 years
Power supply - 1 year
PACKAGE
CONTENTS
•Hub
•Power cord
•User guide
•Warranty card
NETGEAR™is a trademark of Bay Networks, Inc. Other brand and product
names are trademarks or registered trademarks of their respective holders.
Information is subject to change without notice. All rights reserved.
I
S
O
-
9
0
0
1
•
I
S
O
-
9
0
0
1
•
I
S
O
-
9
0
0
1
•
I
S
O
-
9
0
0
1
•
IS
O
-
9
0
0
1
•
•
•
•
•
•
•
•
•
ISO-9001
REGISTERED
QUALITY
LISTED
ITE
E151382
4C93 C
NETGEAR Inc.
A Nortel Networks Company
4401 Great America Parkway
Santa Clara,CA 95054
USA
Phone: 1-888-NETGEAR
http://netgear.baynetworks.com
Technical Support
Australia 1800-142046
Austria 00800-06384327
France 0800-90-2078
Germany 00800-06384327
Japan 0120-66-5402
Korea 00308-11-0319
New Zealand 0800-444-626
Sweden 020-790086
Switzerland 00800-06384327
UK 171-571-5120
US/Canada 1-800-211-2069
SPECIFICATIONS
