Netti 4U CED XL User manual

GMDN 41620
UM0002 UK 2021-03
4U CED
4U CED S
4U CED XL
This product conforms to
2017/745/EU for medical products.
User Manual

2 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
CONTENTS
1. INTRODUCTION 4
1.1 AREAS OF USE/INDICATIONS FOR NETTI 4U CED, CEDS AND CED XL 5
1.2 CONTRAINDICATIONS 5
1.3 QUALITY AND DURABILITY 5
1.4 THE ENVIRONMENT AND WASTE DISPOSAL 5
1.5 INFORMATION FOR REUSE 6
1.6 ABOUT THIS MANUAL 6
1.7 VITAL MEASURES 7
2. QUICK REFERENCE 8
3. DESCRIPTION 9
4. FEATURES OF NETTI 4U CED / CEDS / CED XL 10
5. ACCESSORIES 11
5.1 ASSEMBLING OF HIP BELT 13
6. ASSEMBLING AND ADJUSTMENT 13
6.1 UNPACKING 13
6.2 MAIN WHEEL 13
6.3 FRONT CASTORS 14
6.4. SEAT HEIGHT ADJUSTMENT 14
6.5 BACKREST 15
6.6 SEAT DEPTH ADJUSTMENT AT THE REAR. 16
6.7 SEAT DEPTH ADJUSTMENT IN FRONTI 16
6.8 ANTITIPS 16
6.9 SEAT CUSHION 17
6.10 BACK REST CUSHION* 17
6.11 LEG SUPPORTS 17
6.12 HEAD SUPPORT 20
6.13 ARM SUPPORT 22
6.14 ADJUSTING THE PARKING BRAKES 22
6.15 PUSH BOW 24
7. SEAT ANGLE / TILT AND BACK ANGLE / RECLINE 25
7.1 SEAT ANGLE 25
7.2 BACKREST ANGLE 25
7.3 KEY WORDS REGARDING TILT AND RECLINE
OF STATIC COMFORT WHEELCHAIRS AND COMMON FEATURES OF DYNAMIC WHEELCHAIRS 25
7.4 DECREASE THE POSSIBILITY OF SLIDING SHEAR AND PRESSURE SORES: 25
7.5 OPERATING TILT HANDLE: TILTING THE SEATING UNIT 26
7.6 OPERATING RECLINE HANDLE: RECLINING THE BACK 26

3
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
8. MANOEUVRING 27
8.1 GENERAL TECHNIQUES 27
8.2 DRIVING TECHNIQUES 27
8.3 DRIVING TECHNIQUES 27
8.4 DRIVING TECHNIQUES 28
8.5 DRIVING TECHNIQUES 28
8.6 DRIVING TECHNIQUES 29
8.7 TRANSFER 29
8.8 LIFTING THE WHEELCHAIR 30
8.9 PUSH RIM 30
9. TRANSPORT 30
9.1 TRANSPORT IN CAR 30
9.2 FOLDING FOR TRANSPORT 31
9.3 TRANSPORT IN AIRPLANE 32
9.4 TRAVELLING ON PUBLIC TRANSPORT 32
10. MAINTENANCE 32
10.1 MAINTENANCE INSTRUCTIONS 32
10.2 CLEANING AND WASHING 33
10.3 LONG TERM STORING 33
11. TROUBLESHOOTING 34
12. TESTS & WARRANTY 35
12.1 TESTS 35
12.2 WARRANTY 35
12.3 CLAIM
35
12.4 NETTI CUSTOMIZED / INDIVIDUAL ADAPTATIONS 36
12.5 COMBINATIONS WITH OTHER PRODUCTS 36
12.6 SERVICE AND REPAIR 36
13. MEASURES & WEIGHT 37

4 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
1. INTRODUCTION
Netti 4U CED, CEDS and CED XL are comfort
wheelchairs meant for both indoor and outdoor
use. They are tested to DIN EN 12183:2014. The tests
were carried out by TÜV SÜD Product Service GmbH
in Germany.
In Alu Rehab we believe that wheelchairs should be
chosen based on a thorough assessment focusing
on the needs of the user and demands from the
environment. Therefore, it is important to know about
the possibilities and restrictions of the wheel-chair.
Netti 4U CED, CEDS and CED XL are wheelchairs
designed for users with the need for comfort
and relief. The combination between the seating
system and the ergonomical solutions in the frame
construction, oers many possibilities for adaptation
and adjustments.
The wheelchairs are constructed for indoor and
outdoor use, and oers the possibility to vary the
sitting position from activity to rest using tilt and
recline functions.
Netti 4U CED is available in 3 versions:
Max user weight: 160 kg:
Netti 4U CED with standard seat depths.
Netti 4U CED XL with seat widths 550 and 600 mm
Max user weight: 130 kg:
Netti 4U CEDS with shorter seat depth
When mounting accessories such as power
kit, external seating systems etc., the weight
of the accessories must be subtracted from
the max user weight.
Specications varies between countries.

5
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
1.3 QUALITY AND DURABILITY
The Netti 4U CED wheelchairs are
tested at TÜV SÜD Product Service
GmbH in Germany, following the
European Standard
DIN EN 12183:2014.
As manufacturer, Alu Rehab A.S evaluates the test to
be equal to 5-6 years of normal use of the chair.
The disability of the user, the toughness of use as
well as the level of maintenance done, foremost
decides the durability of the wheelchair. Thus, the
durability will vary depending on these three factors
1.4 THE ENVIRONMENT AND WASTE
DISPOSAL
Alu Rehab and its suppliers wish to protect the
environment.
This means:
• That we avoid using environmentally harmful
substances and processes to the greatest extent
possible.
• That Alu Rehab’s products are ensured a long
service life and a high degree of exibility - to
benet the environment and economy.
• That all packaging can be recycled.
• That the wheelchair was designed to be
separated into its component materials - to make
recycling easier.
Contact your local recycling agent to get
correct information how to handle in you
area.
Netti 4U CED, CEDS and CED XL are designed
for temperature range from -10°C to +40°C.
1.1 AREAS OF USE/INDICATIONS FOR
NETTI 4U CED, CEDS AND CED XL
Netti 4U CED, CEDS and CED XL are multi-function
wheelchairs for partially or fully immobile youth
and grown up persons with physical and/or mental
disabilities. These disabilities may have multiple
causes. Netti 4U CED, CEDS and CED XL have an
adjustable seat and back angle, thus facilitating for
the user change of position, mobilisation or posture
correction (stabilisation), wherever the following
functional impediments with their multiple possible
causes are present:
• limited or lacking mobility
• limited or lacking muscle power
• limited movement range
• lacking or limited trunk and body stability
• hemiplegia
• rheumatic-type disorders
• craniocerebral injuries
• amputations
• other neurological or geriatric disorders.
1.2 CONTRAINDICATIONS
Netti 4U CED, CEDS and CED XL are not suited
for persons with a strongly enhanced muscular
spasticity and unvoluntary movements. In this
case we recommend the Netti Dynamic System,
which oers a frame construction that follows the
movement pattern of the user. Ignoring this advice
could in unfavorable circumstances lead to the
deformation or fracture of metal parts in the area of
the back tube, the leg support or the arm support.

6 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
1.5 INFORMATION FOR REUSE
All products from Alu Rehab are designed to give
years of maintenance-free service. All products can
be adapted for re-use by an authorised dealer. In or-
der to guarantee performance and safety, Alu Rehab
recommends the following tests prior to any re-use.
Please examine the following components for func-
tion, integrity etc. and replace parts as necessary:
• Wheels (tyre tread)
• Wheelchair frame
• Front castors and quick release
• Hubs
• Brake function
• Directional stability of wheels
• Bearings: test for wear and lubrication.
• Cushions
• Leg supports
• Arm supports
• Recline/tilt function
• Push bar / handles
• Anti tip
Please also note the content of chapter 10.2 Clea-
ning and washing instructions.
For hygienic reasons: please replace the head sup-
port for a new user.
Anti-tip
Correctly tted, the anti-tip will secure the chair from
tipping backwards. We strongly recommend use of
the anti-tips.
A refurbishment manual for Netti
Wheelchairs can be downloaded at
My-Netti.com
A recycling manual for Netti Wheelchairs
can be downloaded at My-Netti.com
1.6 ABOUT THIS MANUAL
In order to avoid damages while using the Netti 4U
CED, CEDS or CED XL wheelchair, please read this
manual carefully before starting to use the chair.
Symbol of forbidden actions.
No warranty can be claimed whenever
these actions are implemented.
Symbol of warning.
Whenever this symbol is used, caution has
to be taken.
Symbol for important information.
Symbol for useful tips.
Symbol for tools.
7
°
Symbol for parking brake safe slope.
Max.
135 kg
Symbol for max user weight.
Please note that this manual is updated according to
the year and date stated on each page.
User Manual on web www.my-netti.com
For enhanced readability (advantageous for users
with visibility challenges) please nd our user
manual om our web page: www.My-Netti.com -
manuals - user manual Netti 4U BASE.
Latest user manual updates, product safety notes,
addresses and other product information like recalls
etc. will be published on our web page.

7
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
1.7 VITAL MEASURES
Netti 4U CED, CEDS and CED XL are comfort
wheelchairs designed for both outdoor and
indoor use. Min. dimensions in the table refer to
seat width 350mm. Max. dim refers to seat width
600mm.
Specications varies between countries.
Total weight: 29 Kg
(450 mm width chair)
Seat width:
CEDS: 350, 400, 430 mm
CED: 350, 400, 430, 450, 500 mm
CED XL: 550 & 600 mm
Seat depth:
(From back rest cushion to front
of seat plate)
CED and CED XL:
425, 450, 475, 500 mm
CEDS 375, 400, 430 mm
Seat height:
(From oor to top seat plate
using 24”main wheels in upper
hole position).
465 mm*
*By changing position of main wheels, it is possi-
ble to achieve seat height of 500 mm.
whewheel
Backrest height:
500 mm
* Using back rest extender gives
backrest height of 600 mm
Specication min. max.
Overall length with legsup-
port
1160 mm 1160 mm
Overall length without leg
support
960 mm 960 mm
Overall width 530 mm 780 mm
Height without head rest 1100 mm 1100 mm
Folded length 610 mm 645 mm
Folded width ex wheels 530 mm 780 mm
Folded height ex wheels 570 mm -
Total mass 28 kg 32 kg
Mass heaviest part-frame 18 kg -
Static stability uphill 0 28°
Seat plane angle -5° 20°
Eective seat depth 425 mm
375 mm
500 mm
500 mm
Eective seat width 330 mm
330 mm
580 mm
480 mm
Seat surface height at front 465 mm 500 mm
Backrest angle 90° 135°
Backrest height - with Netti
Seating System
480 mm -
Foot plate to seat distance 280 mm 560 mm
Leg to seat surface angle 98° 176°
Arm support to seat distance 265 mm 365 mm
Front location of arm support
structure
265 mm 355 mm
Push rim diameter 535 mm 535
Horizontal axle location 70 mm 100 mm
Parking brake safe slope 0° 7°
Minimum turning radius R860 mm -
Measured with 24”main wheels.
Measured without cushions.
Netti 4U CED and Netti 4U CEDS are identical
chairs except for the shorter seat depth by Netti 4U
CEDS.

8 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
2. QUICK REFERENCE
The content of this page is a summary of the whole
manual. It gives a brief introduction to the use and
care of the Netti 4U Base wheelchair.
The quick reference is not a replacement for
the manual, only a reminder/check list.
• Unpack the wheelchair (Chapter 6.1)
• Mount the main wheels (Chapter 6.2)
• Mount the front castors (Chapter 6.3)
• Put the back rest back, and mount the recline
as strut to the back rest using the locking bolt.
(Chapter 6.5)
• Mount the leg supports (Chapter 6.11)
• Mount the head support (Chapter 6.12)
• Set anti-tip in active position (Chapter 6.6)
• Mount accessory. (See chapter 5 for more
information. Mounting descriptions will
accompany the accessory.)
Adjust the wheelchair to the user:
Adjust seat depth and eventually the wheelchair
balance, leg support height, arm support height,
head support height and depth.
For more information about adapting the wheelchair
to the user, please see:
My-Netti.com Knowledge centre.
Announcements to product safety and
eventually product recalls will be published
on our home page www.My-Netti.com
For troubleshooting, see chapter 11.
For mounting and adjustments see chapter 6.
For visually impaired people, manuals and
catalogues can be downloaded at
www.My-Netti.com
Drive carefully!
Be aware that friction against pushrims can
create a warm surface.
Surface temperature of metal parts in frame
structure might increase when exposed to
direct sunlight.
Salt water can increase risk of corrosion
further precautions related to
environmental conditions not needed.
The anti-tips should always be used for the
safety of the user.
When the chair is tilted rearwards, the anti
tips and brakes must always be in use.
Be sure to lock all handles properly.
Watch out for pinching danger when folding
and unfolding, tilting, reclining and all other
adjustment movements.
Charge the battery daily.
If the chair has pneumatic tires: Make sure to
check tyre pressure every week and inate
to keep 35 psi /2,4 bar
Never stand on the foot plates due to risk of
tipping forwards.
Never lift the wheelchair by the leg
supports, arm supports or head support.
llustrations may dier from the delivered
product.
If in doubt - contact your dealer!

9
6 5
4
3
7
1
8 2
19
9
18
12 17
16
10 11 15
13 14
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
3. DESCRIPTION
Standard version*
1. Lock for push bow
2. Release handle
3. Push bow
4. Head support bracket
5. Angle and depth adjustment for
head support
6. Head support
7. Back rest
8. Arm support with pad
9. Seat cushion
10. Angle adjustable leg support
11. Calf support bracket
12. Calf support
13. Foot plate
14. Front castors
15. Front fork
16. Brakes
17. Anti-tip
18. Main wheel
19. Knee upholstery
If any of these parts are missing, please
contact your dealer.
Product conguration may vary between
dierent countries.
Netti 4U CED, CEDS and CED XL are similar
chairs except for dierent seat widths and
the shorter seat depth by Netti 4U CEDS..

10 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
STANDARD
SEAT
• Pressure distributive cushion Netti Uno
• Tilt -5° to +20°
• Adjustable seat depth 425-500 mm
WHEELS
• 16 x 1 3/4” drum brake puncture proof main
heels
• 7” Puncture proof front castors with quick
release axle
Standard main wheels may vary between
countries
PUSH BOW
• Angle adjustable push bow
BRAKES  USER BRAKES
ANTITIP  UPWARDS SWINGABLE
BACKREST
• Netti Uno Back with 3D cove
• Height: 500 mm
• Angle: 92° to 137°
LEG SUPPORT
• Angle adjustable leg support
• Height- and angle adjustable foot plates.
• Removable
ARM SUPPORT
• Height and depth adjustable
• Revolvable
HEAD SUPPORT
• A - Height, depth and angle adjustable
• Removable
ACCESSORIES
BELTS
• AHip belts ( see chapter 5)
SEAT
• Pressure distributive cushions
• Hip belts (See chapter 5)
WHEELS
• Puncture proof PU wheels 12”x1 3/4”, 16”x1 3/4”and
24x1 3/8”with drum brake (See chapter 5)
• 24x1”standard puncture proof main wheels
• Push rim: Aluminium on 24” wheels
• 7”x 145 mm Puncture proof Flexel front castors with
quick release axle
PUSH HANDLE
• Height and angle adjustable push handles
BRAKES • Drum brakes
BACKREST
• Backrest extender
• Dierent backrest cushions
• Lumbar support and wedge (See chapter 5)
LEG SUPPORT
• Universal leg support
• Amputation support
• Upholstery for leg supports
ARM SUPPORT
• Hemi cushions (See chapter 5)
HEAD SUPPORT
• Dierent head support models
(See chapter 5)
4. FEATURES OF NETTI 4U CED / CEDS / CED XL

11
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
NETTI 4U CED
FRAME
Anti-tip with tramp pedal
Brake extender
long 310 mm
Frame extender
Increases distance between
main wheels and front castors.
Reduces tipping risk.
Eye bolt set
for xing wheelchair in a car
BACK
Backrest Cushions
Several models
Please contact your dealer.
Wedge
Increases side support.
Lumbar support
Increases lumbar curvature.
Back rest extender
120 mm extender. To be used
together with 600 mm backrest
cushion. Watch out that the chair
does not become unstable when
the back is reclined
Side support Correction
Meant for correction of
bad postures in theupper
trunk.
Pad for side support
Side support Stable
Meant for users with de-
creased stability of the
upper trunk.For optimal
function use together with
Stable cushion.
Pad
for side support Stable
SEAT
Seat Cushions
Many to choose from.
Please contact your dealer.
Pelvic stabilizer.
Abduction block
The block reduces
abduction.
Small: 80 mm width
Medium: 110 mm width
Large: 140 mm width
BELTS AND HARNESSES
Several models: Hip belts
with or without upholstery
and with plastic lock or
car lock. (chapter 5.1 for
mounting)
5. ACCESSORIES
The anytime updated complete accessory and
spare part catalogue can be downloaded from our
home page www.My-Netti.com order forms,

12 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
Upholstery for
calf support bracket
Reduces pressure.
Calf pad hinged
The user does not
have to lift the leg
when mounting or
dismounting the
foot supports.
Foot board with lock
The foot support can
be swung to the side
like standard foot
supports.
Foot box
Upholstered. Grandis foot
box when used as seat
in a car.
WHEELS
Main wheels
12”, 16”, 22”and 24” with
drum brake
Front castors
6”and 7”-175x45 Flexel
Spoke protectors
For 20”, 22”and 24”.
Transparent
TRAYS ETC.
2 tray models:
Swingable and ockable
Upholstery for tray
Oers a soft base for
the arm resting on the tray.
TOOL SET
HEAD SUPPORTS
Support C Large.
Support A Side support
Support B Small
Support D pressure
distribution
Support E side support adjustable
Support F with cheek support
Hygiene cover
Protects the core of the
head support.
Head cushion Comfort
Cushion with Kospoex
lling to pull onto head rest.
ARM SUPPORT
Hemi arm support
An accommodating support
for hemiplegic users.
LEG SUPPORT
Angle adjustable
Universal
Adjustable in xed positions
between 33° to 105° using an
adjustment wheel.
Foot board
upholstery
Ankle huggers

13
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
6. ASSEMBLING AND
ADJUSTMENT
For information about adapting the wheelchair to
the user, please see: My-Netti.com Knowledge center.
Tools needed are described under each chapter.
Accessories described in chapter 5 is a presentation of
options and will be delivered with separate mounting
descriptions
6.1 UNPACKING
1. Unpack all the parts, and check that everything is
there according to the packing list.
2. Mount the main wheels (Chapter 6.2)
3. Mount the front castors (Chapter 6.3)
4. Check and adjust the seat dept (Chap. 6.7)
5. Mount the back rest (Chapter 6.5)
6. Mount the seat cushion (Chapter 6.9)
7. Mount the leg supports (Chapter 6.10)
8. Mount the head support (Chapter 6.11)
9. Mount any accessories (Chapter 5).
Weight of components (450 mm chair width):
Main wheels: 1,9 kg each
Anti tip: 0,1 kg each
Front castors: 0,8 kg each
Leg support angle adj.: 2 kg each
Netti Seat cushion: App. 1 kg
Head support A: 1 kg
Head support C: 0,9 kg
6.2 MAIN WHEEL
To mount a 24” main wheel the hub bushing must be
moved to correct hole in the main wheel bracket.
• To mount the main wheel, remove the quick release
bolt from the hub bushing.
Lead it through the center of the main wheel and into
the hub bushing while pressing the knob in center.
Insert the
quick release
bolt through
the centre of
the main wheel
and into the hub
bushing while
pressing the knob
in centre.
5.1 ASSEMBLING OF HIP BELT
• Pull the belt through the hole in the hip belt
bracket.
• Thread the belt back through the belt clamp.
• Fix the hip belt bracket to the back rest hinge
in the rearmost hole, using the enclosed
screws and nut
2pcs 13 mm open-end spanner.

14
24”main wheel
24”,16”and
12”main wheel 24”
16”
12” main wheel
24”main wheel
My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
6.4. SEAT HEIGHT ADJUSTMENT
The seat height at the rear depends on:
• Size of main wheel.
• Position of main wheel.
• Using 24”main wheels in the upper hole, the
seat height is 465 mm from the oorto the
seating plate. Using 24” main wheels in the next
lower position, the height will measure 500 mm
to the seating plate.
Main wheels and front castors should be mounted
according to the positions described below
If it is required to change position of the main
wheels or to change to a dierent size of main
wheels, unx the hub bushing including washer
and nut. Remove the hub bushing and mount it in
the required position.
2 pcs 24 mm open-end spanners
Make sure that the nut on inside of frame
totally wreathes the wheel bushing.
12”& 16” main wheels with drum brake. are installed by
your dealer.
To check that the 24”main wheel is properly
attached to the hub, remove the nger from the
central knob and pull at the main wheel.
If the main wheel doesn’t lock, do not use the
wheelchair but contact your dealer.
LSand and sea water (salt used for gritting in the
winter) can damage the bearings of the main
wheels and front castors.
Clean the wheelchair thoroughly after exposure.
6.3 FRONT CASTORS
Are equipped with quick release axle.
To remove:
• Press the release button on top of the front fork
bearing house - located under the silicon cap..
To mount
• Lead the quick release axle into the bearing house.
Pull the fork slightly to ensure that the fork is fully
locked.

15
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
To check that the back rest is locked, grip
the push bow and press the back rest
forward.
If the back rest falls forward - repeat the
locking procedure or contact your local
SEAT DEPTH
• The wheelchair is set to a standard seat depth,
and the plastic bracket has 4 holes of which three
are temporarily blocked with plastic plugs
• The back rest hinge has 4 holes. The hole
positions are in accordance with the holes in
the plastic bracket. If the locking head of the
gas spring is mounted in the inner hole of the
plastic bracket, the back rest hinge should also be
mounted in the inner hole etc.
When the seat height is changed ensure that
the front castors are placed so that the lower
frame tube is parallel with the ground.
Check the position of the anti-tip and
readjustthe brakes after mounting the main
wheels or changing the main wheel position.
6.5 BACKREST
To mount the gas spring, lift the push bow with one
hand, and lead the gas spring locking head into the
plastic bracket with the other.
• If the gas spring seems to be too long it must be
compressed. Press the horizontal lower back tube
towards the end of the gas spring while you pull
the handle for the back recline. The gas spring will
be compressed and t into the plastic bracket.
• Check that the hole in the locking head is parallell
with the open holes in the plastic bracket.
• Lock the backrest by pushing the locking bolt
through the plastic bracket and gas spring locking
head

16 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
6.6 SEAT DEPTH ADJUSTMENT AT THE
REAR.
• If the seat depth should be adjusted at the rear,
release the locking bolt from the plastic bracket.
• Find the required position for the locking head in
the plastic bracket, and remove the plastic plug
from this hole.
• Lock the back rest by pushing the locking bolt
through the plastic bracket and the gas spring
locking head.
• After changing the hole position in the plastic
bracket, the hole position in the back rest hinge
must be changed into the parallel / corresponding
position.
Check that the hole in the back rest hinge and
the plastic bracket are mounted in parallel
position.
6 mm Allen-key
6.7 SEAT DEPTH ADJUSTMENT IN
FRONTI
It is possible to adjust the seat depth with up to
100 mm in front to get the knee pivot point aligned
with leg support pivot point. Do the following.
• Screw out the screws in the adjustment piece
• Place the adjustment piece in the wanted
position
• Replace and tighten the screws
6 mm Allen-key
If the user has spastic tendencies the
adjustment piece should not be pulled
out more than 50 mm.
6.8 ANTITIPS
The anti-tips should be mounted according to the
mounting description which is enclosed with the
chair upon arrival.
• Use of the anti-tip
• Pull the anti-tip out
• Turn it up or down 180°.
• Lock it in position

17
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
6.10 BACK REST CUSHION*
Backrest cushions are xed and adjusted onto the
wheelchair using the Velcro.
Backrest
cushions are
attached
with a Velcro
system.
It is imperative to correctly set-up the cushion
in order to ensure good seating comfort.
The seat and back rest cushion covers are
washable and thereby reusable. Follow
the instruction on the cushions for correct
maintanance and washing of the cushions.
ADJUSTING THE VELCRO BACK
• Loosen the straps and place the back rest cushion
so that the user gets room for the bottom and the
integrated lumbar support in correct position.
• Tighten the straps so that they follow the
curvature of the spine and gives a little extra
support at the top of the sacrum.
6.11 LEG SUPPORTS
Netti 4U CED is delivered with manual Angle
Adjustable leg support.
Universal leg support can be ordered instead,
shown to the right.
Adjusting the height of the anti-tips
The anti-tip can be adjusted in two xed positions.
The short position is for 12”& 16”main wheels and
24”in upper position. The long position is for 24”main
wheels in lower position.
• Unx the screw in the adjustable extension piece
as shown in picture below.
• This extension piece has two holes. Place it in the
required position and tighten the screw.
5 mm Allen key
The anti-tip should always be used for the
safety of the user.
6.9 SEAT CUSHION
The seat cushion is xed on the wheelchair with
Velcro.
It is very important to place the cushion in
the wheelchair before use.
The cushion cover is washable and reusable.

18 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
Mounting of leg support
• Mount the leg support by holding onto the
hinge point of the leg support.
• Hold it in an angle of app. 20° to the side frame.
Put it into the leg support black plastic lock.
Swing it in and push down.
UNIVERSAL LEG SUPPORT
The Universal leg support is xed with the
possibility of angle adjustment. It is swingable and
removable. The foot plates are foldable and can be
angled in xed positions. They are delivered with
height and depth adjustable calf support.
Adjusting the angle - Universal leg support
The angle of the leg support can be adjusted using
the star wheel in centre
of the
hinge point.
Loosening this star
wheel enables you to
adjust the leg support
to the required angle.
• Fix the angle by
tightening the star
wheel.
ANGLE ADJUSTABLE LEG SUPPORT
The angle adjustable leg support is freely adjustable
in angle. It is swingable and removeable. The foot
plates are foldable and can be angled in xed
positions. They are delivered with height and depth
adjustable calf support.
Adjusting the angle - Angle adjustable leg
support
• The angle of the leg support can be adjusted
using the star wheel
• Loosening this star wheel enables you to adjust
the leg support to the required angle.
• Fix the angle by tightening the star wheel.
Squeeze hazard.
When adjusting leg supports angle, do not put
the ngers in the adjusting mechanism between
the moving parts.
Adjusting the length of the leg support
• Losen the screw (A ill. next page) to make the
adjustment tube move
• Adjust the leg support in required position and
x the screw properly.

19
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03 My-Netti.com
In some markets a star wheel is used in-stead of the
adjustment screw.
Adjusting the angle of the footplate
• The foot plates angle can be adjusted.
• Losen the screw (B) and adjust the foot plate to
the required angle. Fix the screw properly.
5 mm Allen key
Locking and releasing the foot plates
• The foot plates come with a locking mechanism
which makes the plates stronger.
• To lock the foot plates pull the plastic lock on the
right foot plate and place the lock over the bolt on
the left foot plate.
• To release the foot plate, pull the plastic lock and
lift the right foot plate up.
For outdoor use, there should be a clearance
of 40-50 mm between the foot plate and the
ground.
While making the adjustment there must be
no load on the foot plates.
Removing the leg support:
• Pull the plastic lock on the foot plate rearwards, so
that the pin is released, and the foot plate can be
folded up.
• Release the leg support by pulling it slightly
straight up.
• Swing the leg support outwards.
• Lift and remove the leg support.
ADJUSTING THE CALF SUPPORT
The calf support is height and depth adjustable. To
adjust height unx the nut on the outside of the calf
support bracket, nd the required height and x the
nut again (Ill. A).
10 mm open-end spanner
To adjust in depth, the calf
pad is removed from the
bracket by using an
open-end spanner between
the pad and the bracket.
Find the required position
and rex it (Ill.B)
13 mm open-end spanner
Never stand on the foot plates!
Never lift the wheelchair by the leg supports.

20 My-Netti.com
Model: Netti 4U CED, CEDS & CED XL
Language: English Version: 2021-03
Adjusting the calf support
The calf support is height and depth adjustable.
To adjust height unx the nut on the outside of the
calf support bracket, nd the required height and x
the nut again (A).
10 mm open-end spanner
To adjust in depth, the calf pad is removed from the
bracket by using an open-end spanner between the
pad and the bracket. Find the required position
and rex it (B)
13 mm open-end spanner
Never stand on the foot plates!
Never lift the wheelchair by the leg supports.
6.12 HEAD
SUPPORT
A - Lever for depth adjustment
B - Wheel for angle adjustment
C - Lever for height adjustment
D - Head support bracket
• Place the squared nut in the slot of the head
support bracket as shown above.
• Place the head support in the head support
bracket.
• The height and the depth of the head support is
set to the required positions and tightened.
• The head support bracket is xed by tightening
the four screws two by two diagonally so the
bracket is xed with the same strength divided on
the four screws.
