netvox R718PQA User manual

Wireless Toilet Occupancy Sensor
R718PQA
Wireless Toilet Occupancy Sensor
R718PQA
User Manual
Copyright©Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It shall
be maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written
permission of NETVOX Technology. The specifications are subject to change without prior notice.

1
Table of Content
1. Introduction .............................................................................................................................................................2
2. Appearance ..............................................................................................................................................................3
3. Main Features..........................................................................................................................................................3
4. Set up Instruction ....................................................................................................................................................4
5. Data Report .............................................................................................................................................................5
5.1 Example of ReportDataCmd............................................................................................................................6
5.2 Example of ConfigureCmd..............................................................................................................................6
5.3 Example for MinTime/MaxTime logic............................................................................................................8
6. IR Disable Time and Detection Time ...................................................................................................................10
7. Information about Battery Passivation .................................................................................................................11
7.1 To determine whether a battery requires activation ......................................................................................11
7.2 How to activate the battery ............................................................................................................................11
8. Important Maintenance Instruction.......................................................................................................................12

2
1. Introduction
R718PQA is a long-range wireless occupancy and door sensor for Netvox Class A type devices based on LoRaWAN open
protocol.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other
communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.
Widely used in long-distance, low-data wireless communications. For example, automatic meter reading, building automation
equipment, wireless security systems, industrial monitoring. Main features include small size, low power consumption,
transmission distance, anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and
gateways from different manufacturers.

3
2. Appearance
3. Main Features
⚫Compatible with LoRaWAN protocol
⚫2 sections ER14505 3.6V AA size Lithium battery
⚫Detect occupancy status
⚫Simple operation and setting
⚫Protection level IP65 / IP67 (optional)
⚫Compatible with LoRaWANTM Class A
⚫Frequency hopping spread spectrum technology
⚫Configuration parameters can be configured through third-party software platforms, data can be read and alarms can be set
via SMS text and email (optional)
⚫Available third-party platform: Actility / ThingPark, TTN, MyDevices/Cayenne
⚫Low power consumption and long battery life
Note*: Battery life is determined by the sensor reporting frequency and other variables, please refer to
http://www.netvox.com.tw/electric/electric_calc.html
On this website, users can find battery life time for varied models at different configurations.

4
4. Set up Instruction
On/Off
Power on
Insert batteries. (users may need a screwdriver to open)
Turn on
Press and hold the function key for 3 seconds till the green indicator flashes once.
Turn off (Restore to factory setting)
Press and hold the function key for 5 seconds till green indicator flashes for 20 times.
Power off
Remove Batteries.
Note:
1. Remove and insert the battery; the device is at off state by default.
2. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor
inductance and other energy storage components.
3. At 1st -5th second after power on, the device will be in engineering test mode.
Network Joining
Never joined the network
Turn on the device to search the network to join.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Had joined the network
(not at factory setting)
Turn on the device to search the previous network to join.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Fail to join the network
(when the device is on)
Suggest to check the device verification information on the gateway or consult your
platform server provider.
Function Key
Press and hold for 5 seconds
Restore to factory setting / Turn off
The green indicator flashes for 20 times: success
The green indicator remains off: fail
Press once
The device is in the network: green indicator flashes once and sends a report
The device is not in the network: green indicator remains off
Sleeping Mode
The device is on and in the
network
Sleeping period: Min Interval.
When the reportchange exceeds setting value or the state changes: send a data report
according to Min Interval.
Low Voltage Warning
Low Voltage
3.2V

5
5. Data Report
Data report configuration and sending period are as following:
Min Interval
(Unit:second)
Max Interval
(Unit:second)
Reportable Change
Current Change≥
Reportable Change
Current Change＜
Reportable Change
Any number between
1~65535
Any number between
1~65535
Can not be 0.
Report
per Min Interval
Report
per Max Interval
The device will immediately send a version packet report along with an uplink packet including occupied status.
The device sends data in the default configuration before any configuration is done.
Default setting:
Maximum time: 3600s (1H)
Minimum time: 3600s (1H) (The current voltage and occupied are detected every Min Interval)
Battery change: 0x01 (0.1V)
Disable time: 30s
Detection time: 5min
* If there is special custom shipment, the setting is changed according to customer’s requirements.
* IRDisableTime must ≥ 5 s and IRDectionTime ≥ IRDisableTime
Occupancy alarm:
If there are movements of people, animals or any organism in the detected area, the infrared sensor detects the infrared
signal. And, if the closing event happen in the following 10seconds, the device will report Occupy status.
Occupy status = 1
Unoccupy. status = 0
Note:
The data transmission period of the device is subject to the programming configuration before shipment.
The interval between two reports must be the mintime
The data parsing reported by the device is referenced by the Netvox LoraWAN Application Command document and
http://www.netvox.com.cn:8888/page/index

6
5.1 Example of ReportDataCmd
FPort：0x06
Bytes
1
1
1
Var(Fix=8 Bytes)
Version
DeviceType
ReportType
NetvoxPayLoadData
Version–1 byte –0x01——the Version of NetvoxLoRaWAN Application Command Version
DeviceType–1 byte –Device Type of Device
The devicetype is listed in Netvox LoRaWAN Application Devicetype doc
ReportType – 1 byte –the presentation of the NetvoxPayLoadData，according the devicetype
NetvoxPayLoadData– Fixed bytes (Fixed =8bytes)
Uplink :0197012201000000000000
Byte
Value
Attribute
Result
Resolution
1st
01
Version
1
-
2nd
97
DeviceType
97
-
3rd
01
ReportType
1
-
4th
22
Battery
3.4v
22(HEX)=34(DEC),34*0.1v=3.4v
5th
01
Status
on
-
6th~11th
000000000000
Reserved
-
-
5.2 Example of ConfigureCmd
FPort：0x07
Bytes
1
1
Var (Fix =9 Bytes)
CmdID
DeviceType
NetvoxPayLoadData
CmdID–1 byte
DeviceType–1 byte –Device Type of Device
NetvoxPayLoadData– var bytes (Max=9bytes)
Device
Device
Type
Report
Type
NetvoxPayLoadData
R718PQ
0x97
0x01
Battery
(1Byte, unit:0.1V)
Status
(1Byte 0:off 1:on)
Reserved
(6Bytes,fixed 0x00)

7
Description
Device
Cmd
ID
Device
Type
NetvoxPayLoadData
Config
ReportReq
R718PQA
0x01
0x97
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
BatteryChange
(1byte Unit:0.1v)
Reserved
(4Bytes,Fixed 0x00)
Config
ReportRsp
0x81
Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
ReadConfig
ReportReq
0x02
Reserved
(9Bytes,Fixed 0x00)
ReadConfig
ReportRsp
0x82
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
BatteryChange
(1byte Unit:0.1v)
Reserved
(4Bytes,Fixed 0x00)
Set
IRDisableTImeReq
0x03
IRDisableTime
(2bytes Unit:s)
IRDectionTime
(2bytes Unit:s)
Reserved
(5Bytes,Fixed 0x00)
Set
IRDisableTImeRsp
0x83
Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
Get
IRDisableTImeReq
0x04
Reserved
(9Bytes,Fixed 0x00)
Get
IRDisableTImeRsp
0x84
IRDisableTime
(2bytes Unit:s)
IRDectionTime
(2bytes Unit:s)
Reserved
(5Bytes,Fixed 0x00)
(1) Configure device parameters MinTime = 1min, MaxTime = 1min, BatteryChange = 0.1v
Downlink: 0197003C003C0100000000
Device returns:
8197000000000000000000 (configuration succeeded)
8197010000000000000000 (configuration failed)
(2) Read device parameters
Downlink: 0297000000000000000000
Device returns:
8297003C003C0100000000 (device current configuration parameter)
(3) Configure IRDisableTIme and IRDectionTime
IRDisableTime= 30s、IRDectionTime= 30s // IRDectionTime >= IRDisableTime
. Downlink: 0397001E001E0000000000
Devices return:
8497000000000000000000 (the configuration is successful)
8497010000000000000000 (the configuration is failed)

8
(4) Read IRDisableTIme and IRDectionTime
Downlink: 0497000000000000000000
Devices return:
8497001E001E0000000000 (current device configuration parameters)
5.3 Example for MinTime/MaxTime logic
Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V
MaxTime MaxTime
Sleeping(MinTime) Sleeping(MinTime)
Note: MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BatteryVoltageChange
value.
Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
Sleeping(MinTime) sleeping sleeping sleeping
0H 15th M 30th M 45th M 1H 2H
Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
sleeping sleeping ...
0H 15th M 30th M 45th M 1H 1H 10th M 1H 25th M 1H 40th M 1H 55th M 2H 10th M
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
REPORTS 3.6V
Wakes up and
collects data
REPORT 3.6V
Wakes up and
collects data
REPORTS 3.6V
Wakes up and collects data
3.5V |3.5-3.6|=0.1
REPORTS 3.5V
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data 3.5V
Does not report
Wakes up and
collects data
3.5V
Does not report
Wakes up and
collects data
REPORTS 3.5V
Wake up and collects data
REPORTS 3.6V
Wakes up and collects data
REPORTS 3.6V
Wakes up and collects data
REPORTS 3.6V
Wakes up and
collects data
3.6V
Does not report
Users push the button,
REPORTS 3.5V.
Recalculate MaxTime.

9
Notes:
1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not
collect data.
2) The data collected is compared with the last data reported. If the data variation is greater than the ReportableChange
value, the device reports according to MinTime interval. If the data variation is not greater than the last data reported, the
device reports according to MaxTime interval.
3) We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up
frequently and the battery will be drained soon.
4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another
cycle of MinTime/MaxTime calculation is started.

10
6. IR Disable Time and Detection Time
If there are movements of people, animals or any organism in the detected area, the infrared sensor detects the infrared signal.
And, if the closing event happen in the following 10seconds, the device will report occupy status=1.
After IRDetectionTime(Default 30s), if there is to no longer people, animals or any organism movement detected by the R718PQA
within the monitoring range and the reed switch status is detected as open, the device will report occupy status=0.
To save the power, when R718PQA detects the infrared signal, it will enter IRDetectionTime period. If there is no infrared signal
detected in IRDetectionTime period. It will report un-occupy.
IRDisableTime is the sampling period during IRDetectionTime (IRDisableTime are 30 seconds by default setting that PIR is off
for first 70% of the period; on for rest 30% of the period).
For example, after triggered, the PIR will turn off the infrared probe for 21 (30 * 70%) seconds to save the power, living objects
within this period will not be detected. PIR will re-open detection function after 21 seconds, if it detects living objects in this
period, the IR delay time will be extended for another 30 seconds till no infrared signal is detected and IRDetectionTime period is
due and R718PQA will then report un-occupy
Note：IRDisableTime >=5 s, IRDetectionTime>= IRDisableTime
Default disabletime：30s detectiontime：5min
Example1:
The IRDetectionTime is 60 seconds and the IRDisableTime is 30 seconds, no living creature is detected during the two 9-second
detection period (the yellow parts shown below). R718PQA will report “unoccupied” after 60 seconds (IRDetectTime).
Example2:
The IRDetectionTime is 60 seconds and IRDisableTime is 30 seconds, living creature is detected at the 25th second of the first 30
seconds. R718PQA will restart the IR detecting procedure (IRDetectionTime).
No living creature is detected during the next IRDetectionTime and R718PQA therefore report “unoccupied.”
Note: Occupancy status (status =1) requires both reed switch and infrared to detect close/someone and interval between both less than 10 seconds.

11
7. Information about Battery Passivation
Many of Netvox devices are powered by 3.6V ER14505 Li-SOCl2 (lithium-thionyl chloride) batteries that offer many
advantages including low self-discharge rate and high energy density.
However, primary lithium batteries like Li-SOCl2 batteries will form a passivation layer as a reaction between the lithium
anode and thionyl chloride if they are in storage for a long time or if the storage temperature is too high. This lithium chloride
layer prevents rapid self-discharge caused by continuous reaction between lithium and thionyl chloride, but battery passivation
may also lead to voltage delay when the batteries are put into operation, and our devices may not work correctly in this situation.
As a result, please make sure to source batteries from reliable vendors, and it is suggested that if the storage period is more
than one month from the date of battery production, all the batteries should be activated.
If encountering the situation of battery passivation, users can activate the battery to eliminate the battery hysteresis.
ER14505 Battery Passivation:
7.1 To determine whether a battery requires activation
Connect a new ER14505 battery to a resistor in parallel, and check the voltage of the circuit.
If the voltage is below 3.3V, it means the battery requires activation.
7.2 How to activate the battery
a. Connect a battery to a resistor in parallel
b. Keep the connection for 5~8 minutes
c. The voltage of the circuit should be ≧3.3, indicating successful activation.
Brand
Load Resistance
Activation Time
Activation Current
NHTONE
165 Ω
5 minutes
20mA
RAMWAY
67 Ω
8 minutes
50mA
EVE
67 Ω
8 minutes
50mA
SAFT
67 Ω
8 minutes
50mA
Note:
If you buy batteries from other than the above four manufacturers, then the battery activation time, activation current, and
required load resistance shall be mainly subject to the announcement of each manufacturer.

12
8. Important Maintenance Instruction
Kindly pay attention to the following in order to achieve the best maintenance of the product:
• Keep the device dry. Rain, moisture, or any liquid might contain minerals and thus corrode electronic circuits. If the device gets
wet, please dry it completely.
• Do not use or store the device in dusty or dirty environment. It might damage its detachable parts and electronic components.
• Do not store the device under excessive heat condition. High temperature can shorten the life of electronic devices, destroy
batteries, and deform or melt some plastic parts.
• Do not store the device in places that are too cold. Otherwise, when the temperature rises to normal temperature, moisture will
form inside, which will destroy the board.
• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate structures.
• Do not clean the device with strong chemicals, detergents or strong detergents.
• Do not apply the device with paint. Smudges might block in the device and affect the operation.
• Do not throw the battery into the fire, or the battery will explode. Damaged batteries may also explode.
All of the above applies to your device, battery and accessories. If any device is not working properly, please take it to the nearest
authorized service facility for repair.
