Omron E32-L25T User manual

E32-L25T
A-365E32-L25T
Fluid level sensor (fiber pipe type)
E32-L25T
For installation of thin pipe (thick-
ness of 10 mm) that can be used
even in combustible atmospheres
●Easy post-installation on unit or pipe using band.
●Affordable pricing makes a big contribution to cost
reduction when upgrading equipment.
●Thin pipe of thickness = 10 mm. Contact mounting is
possible to enable detection of level differences to a
minimum of 4 mm.
●Can also be used in combustible atmospheres.*
* Plastic is used in the lens, unit case, and fiber coating. Avoid contact
with solvents as these will cause corrosion and deterioration (cloud-
ing).
Ordering Information
Rating/performance
Fiber Units
Sensor type Shape Model
Reflective model E32-L25T
Applicable amplifier unit
Model
E3X-DA-N
E3X-NA
Sensing method Reflective model
Item Model E32-L25T
Clamping pipe
(outer diameter) Transparent pipe, 8 mm to 10 mm dia. (6 mm to 8 mm inner diameter)*1
Applicable pipe material Transparent pipe (FEP or with equivalent transparency)
Sensing object Fluid *2
Repetition precision 1 mm max.
Ambient temperature Operating/storage: -40 to +70°C (no ice formation or condensation)
Ambient humidity Operating: 35% to 85% RH, Storage: 35% to 95% RH (with no icing or condensation)
Permissible bending
radius 10 mm min.
Material Sensors Polycarbonate
Fiber Plastic (polyethylene coating)
Protective structure IEC 60529 IP50
Weight (Packed state) Approx. 10 g
Accessories Band, anti-reflection sheet, fiber cutter
*1. The E32-L25T6 for a 6 mm dia. transparent pipe is also available. The model type is E32-L25T6.
*2. When using an opaque fluid, test detection with the unit before using.

A-366 Advanced Photoelectric Sensors
Principle of operation
Precautions
Dimensions (Unit: mm)
PipePipe
Emitter
Receiver Emitter Receiver
Fluid
If there is detection fluid, set so that
dark state is effective.
No fluid
If no detection fluid, light state.
Installation
• If only the Fiber Unit is installed, proceed according to the fol-
lowing basic procedure.
• Detection of level differences to a minimum of 4 mm is pos-
sible with the following installations.
• Do not expose the fiber unit to undo forces such as pulling
or compression (no more than 0.1 Nm).
• The bending radius of the fiber unit should be no less than the
allowed bending radius (both rated and performance).
• When securing with the band, take care that the fiber is not de-
formed.
• If an opaque pipe is used, this may result into incorrect opera-
tion.
• Water drops, air bubbles, or clouding in the pipe may cause in-
correct operation.
• If the background exerts an effect, use the anti-reflection
sheet (accessory) (see the diagram below). The anti-reflec-
tion sheet also serves to prevent shifting due to fiber unit vi-
bration.
Miscellaneous
Polycarbonate is used in the case. Do not allow contact with
chemicals such as alkalis, aromatic hydrocarbon, or chloro-al-
iphatic hydrocarbon, as these will dissolve the case.
Correct Use
E32-L25T
Binding band
Pipe
4mm
E32-L25T
E32-L25T
Binding band
Binding band Pipe Binding band
Antireflection sheet
Pipe
E32-L25T
10
6
Sensing head (PC)
Mounting holes
15.2
(13)
1.2
2.8
64
16
18 2,000
25
Two, fiber attachment E39-F9
Optical fiber two, 1 dia.
7.63
40˚
Lens Two, 3.2 dia. (PC)
Optical axis
E32
-
L2
5
T
In the interest of product improvement, specifications are subject to change without notice.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. E03E-EN-01
