netvox R718PQA User manual

Model：R718PQA
Wireless Occupancy and Door Sensor
Wireless Occupancy and Door Sensor
R718PQA
User Manual

1
Table of Content
1. Introduction.............................................................................................................................................................................................................................................................. 2
2. Appearance............................................................................................................................................................................................................................................................... 2
3. Main Features...........................................................................................................................................................................................................................................................2
4.Set up Instruction...................................................................................................................................................................................................................................................... 3
5. Data Report.............................................................................................................................................................................................................................................................. 4
6. Disabletime and Detectiontime................................................................................................................................................................................................................................6
7. Installation................................................................................................................................................................................................................................................................6
8.Important Maintenance Instruction...........................................................................................................................................................................................................................6

2
1. Introduction
R718PQA is a long-range wireless occupancy and door sensor for Netvox Class A type devices based on LoRaWAN open protocol.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other communication methods,
LoRa spread spectrum modulation method greatly increases to expand the communication distance. Widely used in long-distance, low-data wireless
communications. For example, automatic meter reading, building automation equipment, wireless security systems, industrial monitoring. Main
features include small size, low power consumption, transmission distance, anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and gateways from different
manufacturers.
2. Appearance
Fig.1 R718PQA Appearance
3. Main Features
Compatible with LoRaWAN protocol
2 sections ER14505 3.6V Lithium AA battery
Detect occupancy status
Protection level IP65 / IP67 (optional)
Compatible with LoRaWANTM Class A
Frequency hopping spread spectrum technology
Configuration parameters can be configured through third-party software platforms, data can be read and alarms can be set via SMS text and
email (optional)
Available third-party platform: Actility / ThingPark, TTN, MyDevices/Cayenne
Low power consumption and long battery life
Note*: Battery life is determined by the sensor reporting frequency and other variables, please refer to
http://www.netvox.com.tw/electric/electric_calc.html
On this website, users can find battery life time for varied models at different configurations.

3
4.Set up Instruction
On/Off
Power on Insert batteries.
(users may need a flat blade screwdriver to open)
Turn on Press and hold the function key for 3 seconds till the green indicator flashes once.
Turn off
(Restore to factory setting) Press and hold the function key for 5 seconds till green indicator flashes for 20 times.
Power off Remove Batteries.
Note:
1. Remove and insert the battery; the device is at off state by default.
2. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor inductance and other
energy storage components.
3. At 1st -5th second after power on, the device will be in engineering test mode.
Network Joining
Never joined the network
Turn on the device to search the network to join.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Had joined the network
(not at factory setting)
Turn on the device to search the previous network to join.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Fail to join the network
(when the device is on)
First two mins: wake up every 15 seconds to send request.
After two mins: enter sleeping mode and wake up every 15 minutes to send request.
Note: Suggest to remove batteries if the device is not used to save power.
Suggest to check the device verification information on the gateway
or consult your platform server provider.
Function Key
Press and hold for 5
seconds
Restore to factory setting / Turn off
The green indicator flashes for 20 times: success
The green indicator remains off: fail
Press once The device is in the network: green indicator flashes once and sends a report
The device is not in the network: green indicator remains off
Sleeping Mode
The device is on and in the
network
Sleeping period: Min Interval.
When the reportchange exceeds setting value or the state changes: send a data report according to Min Interval.
The device is on but not in
the network
First two mins: wake up every 15 seconds to send request.
After two mins: enter sleeping mode and wake up every 15 minutes to send request.
Note: Suggest to remove batteries if the device is not used.
Suggest to check device verification on gateway.
Low Voltage Warning
Low Voltage 3.2V

4
5. Data Report
The device automatically sends a version package Report and a report data with the occupied status.
The device sends data in the default configuration before any configuration is done.
Maximum time: Max Interval
Minimum time: Min Interval (by default, the current voltage value is detected every Min Interval)
Default reportchange:
Battery --- 0x01 (0.1V)
Occupancy alarm:
(Requires door magnet and infrared to detect someone at the same time)
Occupy status = 1
Vacant status = 0
Note: The data transmission period of the device is subject to the programming configuration before shipment.
The interval between two reports must be the minimum time
R718PQA default Max Interval = 15min, Min Interval = 15min
(if there is special custom shipment, the setting is changed according to customer requirements)
The data parsing reported by the device is referenced by the Netvox LoraWAN Application Command document and
http://www.netvox.com.cn:8888/page/index
Data report configuration and sending period are as following:
Report Configuration Example:
(1) Configure device parameters MinTime = 1min, MaxTime = 1min, BatteryChange = 0.1v
Downlink: 0197003C003C0100000000
Device returns:
8197000000000000000000 (configuration succeeded)
8197010000000000000000 (configuration failed)
Min Interval
(Unit:second)
Max Interval
(Unit:second)
Reportable
Change
Current Change≥
Reportable Change
Current Change ＜
Reportable Change
Any number between
1~65535
Any number between
1~65535 Can not be 0. Report per Min Interval
Report
per Max Interval
Description Device CmdID DeviceTy
pe NetvoxPayLoadData
ConfigReportRe
q
R718PQ
A
0x01
0x97
MinTime(2b
ytes Unit:s)
MaxTime(2byt
es Unit:s)
BatteryChange(1b
yte Unit:0.1v) Reserved (4Bytes,Fixed 0x00)
ConfigReportRs
p
0x81 Status(0x00_
success) Reserved (8Bytes,Fixed 0x00)
ReadConfigRepo
rtReq
0x02 Reserved (9Bytes,Fixed 0x00)
ReadConfigRepo
rtRsp
0x82 MinTime(2b
ytes Unit:s)
MaxTime(2byt
es Unit:s)
BatteryChange(1b
yte Unit:0.1v) Reserved (4Bytes,Fixed 0x00)

5
(2) Read device parameters
Downlink: 0297000000000000000000
Device returns:
8297003C003C0100000000 (device current configuration parameter)
Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V
MaxTime MaxTime
Sleeping(MinTime) Sleeping(MinTime)
Note: MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BtteryVoltageChange value.
Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
Sleeping(MinTime) sleeping sleeping sleeping
0H 15th M 30th M 45th M1H 2H
Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
sleeping sleeping ...
0H 15th M30th M45th M 1H 1H 10th M1H 25th M 1H 40th M 1H 55th M2H 10th M
Notes :
1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect data.
2) The data collected is compared with the last data reported. If the data variation is greater than the ReportableChange value, the device reports according to MinTime interval. If the data
variation is not greater than the last data reported, the device reports according to MaxTime interval.
3) We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up frequently and the battery will be drained soon.
4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle of MinTime/MaxTime calculation is started.
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
3.6V
Does not report
Wakes up and
collects data
REPORTS
3.6V
Wakes up and
collects data
REPORT 3.6V
Wakes up
and collects
data
REPORTS
3.6V
Wakes up and collects data
3.5V |3.5-3.6|=0.1
REPORTS 3.5V
Wakes up and
collects data
3.5V Does not
report
Wakes up and
collects data
3.5V Does not
report
Wakes up and
collects data
3.5V Does not
report
Wakes up and collects data
3.5V Does not report
Wakes up and
collects data
3.5V Does not
report
Wakes up and
collects data
REPORTS 3.5V
Wake up and collects data
REPORTS 3.6V
Wakes up and collects data
REPORTS 3.5V
Wakes up and collects data
REPORTS 3.6V
Wakes up and
collects data
3.6V Does not
report
Users push the button,
REPORTS 3.5V.
Recalculate MaxTime.

6
6. Disabletime and Detectiontime
IRDisableTime is the sampling period while IRDetectionTime is detecting period.
Both IRDisableTime and IRDetectionTime are 30 seconds in default.
To save power, IR detection will be turned off for first 70% of IRDisableTime and turned on for rest 30% of IRDisableTime.
If living creature is detected during the rest 30% of IRDisableTime, the IR delay time will be extended for another IRDetectionTime till no infrared signal is detected.
If no living creature is detected during IRDetectionTime, RB11E will report un-occupy along with other sensor status, such as temperature,illumination, etc.
Example1:
While IRDetectionTime is 60 secs and IRDisableTime is 30 secs, no living creature is detected after triggered.
RB11E will report un-occupy after 60 secs(IRDetectTime).
Example2:
While IRDetectionTime is 60 secs and IRDisableTime is 30 secs, living creature is detected during 25th sec.
RB11E will restart IR detect procedure(IRDetectionTime).
No living creature is detected during next IRDetectionTime and RB11E therefore report un-occupy.
Remarks:
Occupancy status (status =1) requires both door magnet and infrared to detect someone
7. Installation
This product comes with waterproof function. When using it, the back of it can be adsorbed on the iron surface, or the two ends can be fixed to the wall
with screws.
Note: To install the battery, use a screwdriver or similar tool to assist in opening the battery cover.
8.Important Maintenance Instruction
Your device is a product of superior design and craftsmanship and should be used with care. The following suggestions will help you use the warranty
service effectively.
• Keep the equipment dry. Rain, moisture, and various liquids or moisture may contain minerals that can corrode electronic circuits. In case the device
is wet, please dry it completely.
• Do not use or store in dusty or dirty areas. This can damage its detachable parts and electronic components.
• Do not store in excessive heat. High temperatures can shorten the life of electronic devices, destroy batteries, and deform or melt some plastic parts.
• Do not store in a cold place. Otherwise, when the temperature rises to normal temperature, moisture will form inside, which will destroy the board.
• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate structures.
• Do not wash with strong chemicals, detergents or strong detergents.
• Do not apply with paint. Smudges can block debris in detachable parts and affect normal operation.
• Do not throw the battery into a fire to prevent the battery from exploding. Damaged batteries may also explode.
All of the above suggestions apply equally to your device, battery and accessories. If any device is not working properly.
Please take it to the nearest authorized service facility for repair.
IRDisableTime = 30 secs
Turn on IR for 9 secs.
PIR is off for 21 secs.
IRDisableTime = 30 secs
Turn on IR for 9 secs.
PIR is off for 21 secs.
IRDetectionTime = 60 secs
25 secs
9 secs.
21 secs.
IRDisableTime = 30 secs
IRDetectionTime = 60 secs
IRDisableTime = 30 secs
Triggered
9 secs.
21 secs.
21 secs.
4 secs.
