2. Installation1. Technical Specifications
Product type On/off control microwave motion sensor
Operating voltage 220-240VAC 50Hz
Rated load 1200W (resistive); 400W (capacitive)
Power consumption < 1W
Detection angle 360o
Detection area (DxH) 12 x 6m (Maximum)
Detection range 10% / 50% / 75% / 100%
Hold time 2s / 30s / 1min / 5min / 10min / 15min / 20min / 30min
Daylight threshold 2 ~ 500Lux, Disable
Warmming up time 20s
Operating temperature -20oC ~ +60oC
3. Rotary Switch Settings
A rotary switch is built inside the sensor for
scene selection / fast programming. Total
16 channels are available:
Note: settings can also be changed by remote control HRC-11. The last action controls.
FLUSH MOUNT MICROWAVE MOTION SENSOR HMW20
Installation and Instruction Manual
Rotary switch preset (Please
see the location in 2. Installation)
Warnings:
1. Installation of the sensor involves connecting it to the mains supply. This work
must be carried out by a specialist in accordance with electrotechnical regulations.
2. Disconnect power supply before installing.
Detection
range
Channel
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
100%
100%
100%
100%
100%
100%
100%
100%
100%
100%
100%
75%
50%
100%
100%
100%
5s
30S
1min
5min
5min
5min
5min
5min
10min
10min
10min
10min
10min
30min
30min
5s
Disable
2Lux
10Lux
2Lux
10Lux
30Lux
50Lux
Disable
10Lux
30Lux
50Lux
30Lux
10Lux
10Lux
50Lux
2Lux
Hold
time
Daylight
threshold
4. Functions
This sensor is a motion switch, which turns on the light on detection of people movement, and turns off
after a pre-selected hold-time when there is no people around. A daylight sensor is also built-in to prevent
the light switching on when there is sufficient natural light.
4.1 On/off Control
Designed in the software, sensor switches on/off the load right at the zero-cross point, to ensure the
in-rush current is minimised, enabling the maximum lifetime of the relay.
4.2 Zero-cross relay operation
The motion sensor is employed, but only activated on the manual press of the push switch,
light remains keeps on in the presence, switches off automatically in the long absence.
4.3 Semi-auto Function (Absence Detection)
HMW20-20181218-A1
Note: this function can be chosen by remote controller only, please refer to detailed explanations
in part 7.
With the help of push-switch, this sensor maybe over-ridden by the end-users to switch on/off
the lights manually. This makes the product more user-friendly and offers more options to fit for
extra ordinary demands.
* Push: on/off function;
ON →OFF: the light turns off immediately and cannot be lightened for a certain time (equals to
hold time preset) even movement is detected. After this period, the sensor goes back to auto
sensor mode.
OFF →ON: the light turns on and goes to auto sensor mode.
4.4 Manual Override / Push Function (Default)
Infrared receiver
Photocell
LED indicator
Rotary switch preset
Lens
1
3
4
2
(1) Sensor inset
(2) Lens pluggable
(3) Protection cover (covers the
high-voltage terminals).
(4) Ceiling (drill hole Ф70mm).
70mm 64.7
o85
65
56
16
9
8. Troubleshooting
MALFUNCTION CAUSE REMEDY CAUSE REMEDY
The fixture does not light up
The fixture is always on
Check detection area setting
The fixture is on when it should not
Incorrect daylight threshold setting
Continous movement in the detection zone
Sudden change in temperature due to weather (wind, rain, snow) or air
expelled from fans, open windows
Detection zone not targeted
Faulty fixture
No power supply
Adjust daylight threshold setting
Replace fixture
Check power to sensor
Check detection area setting
Adjust zone, change installation site
Descriptions of the
Button Functions
(remote control HRC-11)
7.
Permanent ON/OFF [ ]
Press button to select permanent ON or permanent OFF mode.
* Press button / to resume automatic operation.
The mode will change to AUTO Mode after power failure.
Semi-auto Mode [ button & ]
Power output [ button ]
All buttons in zone are disabled.
Ambient daylight threshold [ button ]
Detection range [ zone ]
Press buttons in zone to set detection range at 100% / 75% /
50% / 10%.
Daylight threshold [ zone ]
Press buttons in zone to set the daylight sensor at 2Lux / 10Lux /
50Lux / 100Lux / 300Lux / 500Lux or Disable.
Note: To set daylight sensor at 100Lux / 300 Lux / 500Lux, press
button Shift at first.
button
Auto Mode [ button ]
Brightness +/- [ button ]
All buttons in zone are disabled.
Scene prog. [ zone ]
(One-key-commissioning)
1. Press button Shift, the red LED is on for indication.
2. Press button , the ambient lux level is sampled and set as the
new daylight threshold.
Hold time [ zone ]
Press buttons in zone to set the hold time at 2s / 30s / 1min /
5min / 10min / 15min / 20min / 30min.
Note: 1.To set hold-time at 30s / 5min / 15min / 30min, press button
Shift at first.
2. 2s is for testing purpose only, stand-by period and daylight
sensor settings are disabled in this mode.
*To exit from Test mode, press button or any button in zone .
Note
: all buttons in zone are disabled.
Ceiling mounted detection pattern (m)
Ceiling mounted height(m)



10%
10%
30%
30%
75%
75%
50%
50%
Detection Pattern5.
Shift [ button ]
RESET [ button ]
Press button , all settings go back to the rotary switch settings.
Press button to initiate automatic mode. The sensor starts working
and all settings remain as before the light was switched ON/OFF.
1. Press button “Start” to program.
2. Select the buttons in “Detection range”, / “Daylight threshold”,
“Hold time” to set all parameters.
3. Press button “Memory” to save all the settings programmed in the
remote control.
4. Press button “Apply” to set the settings to each sensor unit(s).
For example, to pre-set detection range 100%, daylight threshold
Disable, hold time 5min, the steps should be as follows:
Press button Start, button 100%, Disable, Shift, 5min,
Memory. By pointing to the sensor unit(s) and pressing Apply,
all settings are passed on the sensor(s).
Press button , the LED on the top left corner is on for indication.
All values / settings in RED are valid for 20 seconds.
1. Press button Shift (the red LED is on for indication),
2. press button to initiate semi-auto mode. The fixture is manually on
by push-switch and automatically off in semi-auto mode.
18
3
3
2
9
10
11
12
11
11
10
9
8
2
2
3
3
3
3
4
4
4
5
6
7
7
7
7
38
8 9
10
10 11
11
6
5
4
1
2 4
3
HMW20-20181218-A1
Hytronik Industrial Ltd. | www.hytronik.com
3rd Floor, block C, complex building, 155#, Bai'gang road south,
Bai'gang village, Xiao Jin Kou town, Huicheng district, Huizhou 516023
Tel: 86-752-2772020 Fax: 86-752-2777877
6. Wiring Diagram
LED Driver
HMW20
220~240VAC
L
LNNL’Push N
LED+
LED-
HRC-11
&
A

III
12
6
8
10
11
2
4
1
3
7
9
5
