netvox ZigBee Z311G User manual

ZigBeeTM- Light Sensor
User Manual
Light Sensor
Model: Z311G
FW V1.3
HW V1.1

1
Table of Contents
1. Introduction.............................................................................................................................................................. 2
2. Product Appearance.................................................................................................................................................3
3. Specification.............................................................................................................................................................. 4
4. Installation.................................................................................................................................................................4
5. Setting up Z311G...................................................................................................................................................... 5
5-1. Turn On/ Turn Off Z311G...............................................................................................................................5
5-2. Join the ZigBee Network................................................................................................................................ 5
5-3. Sleeping Mode................................................................................................................................................ 5
5-4. Wake up Z311G...............................................................................................................................................6
5-5. Battery............................................................................................................................................................. 6
5-6. Change the Light Source Mode...................................................................................................................... 6
5-7. Calibration.......................................................................................................................................................6
5-8. Light Level Report..........................................................................................................................................6
5-9. Restore to Factory Setting...............................................................................................................................6
5-10. Report Configuration.................................................................................................................................... 7
6. Home Automation Clusters for Z311G.................................................................................................................. 8
7. Netvox APP Control Interface.................................................................................................................................9
8. Important Maintenance Instructions................................................................................................................... 12

2
1. Introduction
Netvox Z311G, a ZigBee light sensor, acts as an End Device in ZigBee network. It does not perform permit-join
function as a coordinator or a router for other devices to join the network. Z311G detects and reports the
surrounding light level periodically to the ZigBee network for automation controlling applications. Z311G’s
operating temperature is -10℃~50℃. It is suitable to be installed at the location which users have difficulty to stay
for a long time such as walk-in cooler, so that people could monitor the light level in these places easier.
What is ZigBee?
ZigBee is a short range wireless transmission technology based on IEEE802.15.4 standard and supports multiple
network topologies such as point-to-point, point-to-multipoint, and mesh networks. It is defined for a
general-purpose, cost-effective, low-power-consumption, low-data-rate, and easy-to-install wireless solution for
industrial control, embedded sensing, medical data collection, smoke and intruder warning, building automation
and home automation, etc.

3
2. Product Appearance
Indicator (Red/Green)
Light Sensor
 
Binding Key
Auxiliary Key

4
3. Specification
Fully IEEE 802.15.4 compliant
Utilizes 2.4GHz ISM band; up to 16 channels
Power supply: 2 CR2450 button cell batteries. 715 days battery life*
Operating consumption: ≤ 43mA
Standby consumption: ≤ 0.8uA
Sensing level range: 1~3000 lux
Sensing accuracy: Natural light: 5%@1~600 lux; 10%@600~1000 lux
Energy saving lamp: 10%@1~1000 lux
Filament lamp: 5%@1~600 lux; 11%@600~1000 lux
At a certain calibration environment, it can not adapt to another environment. Under different
light sources, it is required to be calibrated
Up to 220 meters wireless transmission range in non-obstacle space
Easy installation and configuration
* Battery life may vary based on operating conditions.
4. Installation
Remove the battery cover, insert the batteries, and then mount the cover to complete the installation.
Z311G is not waterproof. It is suitable for indoor installation.

5
5. Setting up Z311G
5-1. Turn On/ Turn Off Z311G
Under the circumstances Z311G is first time used or after resetting, when it is powered on and cannot
successfully search a network, Z311G will go into turn-off mode.
To manually turn on or turn off Z311G, please use the following instructions:
A. Turn it on: Press the Binding Key once. The indicators will flash red once, and the device is ready to
be used.
B. Turn it off: Press the Binding Key. The indicator will flash 10 times within 5 seconds. Press the
Binding Key again within the 10 flashes to turn the device off.
5-2. Join the ZigBee Network
After Z311G is turned on, it will search for an existing ZigBee network and send a request to join the network
automatically. While Z311G is under the coverage from a coordinator or a router whose permit-join feature is
enabled, Z311G will be permitted to join the network.
Step1. Enable the permit-join function (valid for 60 seconds) of a coordinator or a router (please refer to
the user manual of the coordinator or the router to enable the permit-join feature).
Step2. Turn on Z311G. It will start to search and join the network.
Step3. The indicator will flash green once when it finds out a network to join.
Step4. The indicator will flash green 5 times after it is joined successfully. Otherwise, the indicator will
not flash.
5-3. Sleeping Mode
Z311G is designed to go into sleeping mode for power-saving in some situations:
A. While the device is in the network → the sleeping period is 5 minutes; it will wake up every 5
minutes to keep online.
B. When it doesn’t find a network to join → Z311G will go to sleeping mode. It will wake up every 15
minutes to search a network to join.
C. Once Z311G was joined to a network and by any chance the network is no longer existed or the
device is out of the network → Z311G will wake up every 15 minutes to find the network it joined
before.
It never keeps in sleeping mode and continues to find out a network every 15 minutes. This condition would
consume up to 30 times power spending compared to normal-operating status. To prevent this unwanted power
consumption, we recommend that users remove the batteries to power off the device.

6
5-4. Wake up Z311G
When users would like to setup or acquire data from the device which is in sleeping mode, we have to wake
up the device as the following steps:
Step1. Press and hold both Binding Key and Auxiliary Key.
Step2. Until the indicator flashes red twice, release both buttons.
Step3. The indicator will flash 5 times while broadcasting.
5-5. Battery
When the operating voltage is lower than 2.1V, the indicator will flash red once per hour. Z311G will send a
low-power report to the ZigBee network.
5-6. Change the Light Source Mode
Users could change the Light Source Mode via ZiG-BUTLER to enhance the light sensing accuracy. It
includes:
1. Natural Light
2. Energy Saving Lamp
3. Filament Lamp
4. User-defined
5-7. Calibration
Users could change the calibration setting via ZiG-BUTLER while the default Light Source Mode does not
suit your needs.
5-8. Light Level Report
Z311G detects the light level every 5 minutes by default after binding. To assign the reporting conditions,
users can modify the settings via netvox ZigBee application ZiG-BUTLER (please refer to Chapter 7).
5-9. Restore to Factory Setting
To restore it to factory setting, please follow the steps:
Step1. Press and hold both Binding Key and Auxiliary Key for 5 seconds.

7
Step2. Release the button after the indicator shows fast red flashes.
Step3. The indicator will flash red 20 times, and the restore is completed.
5-10. Report Configuration
10 seconds after powering on, Z311B will detect battery voltage, if the device report has been previously
configured, it will issue 1 or 2 reports within 1-60 seconds randomly on the device, and thereafter it will report
according to the configuration.
If the device was already bound related report clusterID to report according to configuration, it would issue a
corresponding report (Max! = 0xFFFF) immediately after completed configuration.
Battery voltage report Default: min = 3600s, max = 3600s, reportchange = 0.1,
Battery status report Default: min = 3600s, max = 0xFFFF (off), reportchange = 0.
Report setting table：
Min Interval
(Unit:second)
Max Interval
(Unit:second)
Reportable
Change
Change rate≥ Reportable
Change
Change rate＜
Reportable Change
1-65534 1-65534
≠0To report per Minimum
interval
To report per Maximum
interval
0To report per Minimum
interval
To report per Minimum
interval
0 1-65534
≠0 To report instantly To report per Maximum
interval
0 To report per second To report per second
1-65534 0
≠0To report per Minimum
interval No report
0To report per Minimum
interval
To report per Minimum
interval
0 0
≠0 To report instantly No report
0 To report per second To report per second
Any 65535 Any Stop reporting
65535 Any Any Stop reporting
Note：(1) It is not suggested to set:
Min Interval =0,
Reportable Change=0.
Otherwise, ZB311B will report very densely (every second) to block up the network.
(2) Different attributes have different units, please refer to the product specific
instructions for units of reportable change.

8
6. Home Automation Clusters for Z311G
A cluster is a set of related attributes and commands which are grouped together to provide a specific function. A
simple example of a cluster would be the On/Off cluster which defines how an on/off switch behaves. This table
lists the clusters which are supported by Z311G.
1.End Point(s)0x01
2.Device IDLight Sensor0x0106
3.EndPoint Cluster ID
Cluster ID for Z311G
Server side Client side
EP 0x01 (Device ID: Light Sensor0x0106)
Basic(0x0000) None
Identify(0x0003)
Commissioning(0x0015)
Illuminance Measurement (0x0400)
power configure(0x0001)
Diagnostics Information(0x0B05)
Poll Control(0x0020)
This lists the attributes of the basic information.
Identifier Name Type Range Access Default Mandatory
/ Optional
0x0000 ZCLVersion Unsigned
8-bit integer
0x00 –
0xff
Read only 0x03 M
0x0001 ApplicationVersion Unsigned
8-bit integer
0x00 –
0xff
Read only 20 O
0x0002 StackVersion Unsigned
8-bit integer
0x00 –
0xff
Read only 51 O
0x0003 HWVersion Unsigned
8-bit integer
0x00 –
0xff
Read only 0x0B O
0x0004 ManufacturerName Character
string
0 – 32
bytes
Read only netvox O
0x0005 ModelIdentifier Character
string
0 – 32
bytes
Read only Z311GE3ED O

9
0x0006 DateCode Character
string
0 – 16
bytes
Read only 20131227 O
0x0007 PowerSource 8-bit
Enumeration
0x00 –
0xff
Read only 0x03 M
0x0010 LocationDescription Character
string
0 – 16
bytes
Read/write O
0x0011 PhysicalEnvironment 8-bit
Enumeration
0x00 –
0xff
Read/write 0x00 O
0x0012 DeviceEnab Boolean 0x00 –
0x01
Read/write 0x01 M
7.Netvox APP Control Interface
1. After the device is added in Netvox App system, IEEE address will show up at device management interface in
APP. Z311B shows an EP which is Light Sensor as below figure:

10
2. Select EP1（Light Sensor）into configuration interface. In the setting interface, users are able to configurate
respectively, as shown below:
3. In the control center interface, it displays the luminance value of current environment and the light sensor
operation options of Z311G. As shown below:

11
4. Click EP1 into the basic information interface, by clicking on the bottom of the "Basic Information" "Settings"
"About Device" interface to switch interfaces to check detail information of the device. As shown below.

12
8. Important Maintenance Instructions
Please keep the device in a dry place. Precipitation, humidity, and all types of liquids or moisture can contain
minerals that corrode electronic circuits. In cases of accidental liquid spills to a device, please leave the device
dry properly before storing or using.
Do not use or store the device in dusty or dirty areas.
Do not use or store the device in extremely hot temperatures. High temperatures may damage the device or
battery.
Do not use or store the device in extremely cold temperatures. When the device warms to its normal
temperature, moisture can form inside the device and damage the device or battery.
Do not drop, knock, or shake the device. Rough handling would break it.
Do not use strong chemicals or washing to clean the device.
Do not paint the device. Paint would cause improper operation.
Indoor use only.
Handle your device, battery, and accessories with care. The suggestions above help you keep your device
operational. For damaged device, please contact the authorized service center in your area.

13
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.

14
