New Air AW-281E User manual

28 Bottle Freestanding
Thermoelectric Wine Cooler
AW-281E
OWNERS MANUAL
Read and save these instructions.

2
http://www.NewAir.com
A Name You Can Trust
Trust has to be earned and we will earn yours. Customer happiness is
the focus of our business.
From the factory to the warehouse, from the sales floor to your home,
the whole NewAir family promises to provide you with innovative
products, exceptional service, and support when you need it the most.
Count on NewAir.
As a proud NewAir owner, welcome to our family. There are no robots
here, real people shipped your product and real people are here to help
you.
Thank you for your purchase and remember NewAir, A Name You Can
Trust.
Call us today at 855-963-9247
Or email [email protected]om
For future reference, we recommend you attach a copy of your sales receipt
here and record the following information. You will need this information if it
becomes necessary to contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________
Serial Number: ___________________________________
Model Number: ___________________________________
Connect with us online.

3
Love Your Home
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Safety Information & Warnings ...................................................... 4
Parts List.......................................................................................... 5
Parts Diagram........................................................................... 5
Assembly & Installation .................................................................. 6
Handle Assembly...................................................................... 6
Installation................................................................................ 6
Operating Instructions .................................................................... 7
Operating Environment............................................................ 7
How to use the Buttons on the Display Panel.......................... 7
Cleaning & Maintenance................................................................. 8
Cleaning Your Cooler................................................................ 8
Moving Your Cooler.................................................................. 8
Wine Storage Guide ........................................................................ 8
Troubleshooting.............................................................................. 9
Limited Manufacturer’s Warranty ................................................ 12
SPECIFICATIONS
MODEL NO.
AW-281E
RATED VOLTAGE:
115V / 60Hz
POWER CONSUMPTION:
70W
STORAGE CAPACITY:
28 bottles
TEMPERATURE RANGE:
54°F - 66°F

4
http://www.NewAir.com
SAFETY INFORMATION & WARNINGS
When using any electrical appliance, basic safety
precautions must be followed in order to reduce the risk
of fire, electrical shock and/or injury to persons or
property. Be sure to read all instructions before using
this appliance and observe the following safety tips:
Attention: To prevent the risk of child entrapment, do not allow
children to operate, play with, or crawl inside the unit. If the unit
will not be used for an extended period of time, remove the door
and leave the shelves in place so that children cannot crawl inside.
Also remove the door when disposing of the unit.
Never clean the appliance parts with flammable fluids, as the fumes
can create a fire hazard or explosion. Do not store or use gasoline or
any other flammable vapors and liquids near this or any other
appliance.
Do not store perishable foods in the wine cooler, as the interior
temperature will not be low enough to prevent food spoilage.
Shock Hazard –Electrical Grounding Required
This cooler should be properly grounded for your safety, and in
order to minimize the possibility of electrical shock, the power cord
of this unit is equipped with a 3-prong plug which fits 3-prong wall
outlets. Improper use of the grounded plug can result in electrical
shock.
If the power cord appears to be damaged, have it replaced by an
authorized service center.
Never cut or remove the ground wire from the supplied power cord.
The use of an extension cord is not recommended.
The cord should be secured behind the cooler. Also, to prevent
accidental injury, do not expose or dangle the cord.

5
Love Your Home
PARTS LIST
When you receive your unit, carefully remove the exterior and interior
packaging. It is recommended that you retain the packaging for future use.
Check to make sure the following parts are included:
6 slide-out shelves
1 door handle and 2 screws
1 instruction manual
PARTS DIAGRAM
1. Door Hinge
2. Internal Light
3. Fan
4. Wine Racks
5. Feet
6. Water Reservoir
7. Light Switch
8. Control Panel
9. Magnetic Seal
10. Glass Door
11. Door Handle
12. Door Frame

6
http://www.NewAir.com
ASSEMBLY & INSTALLATION
HANDLE ASSEMBLY
Tools Required for Assembly: Phillips screwdriver (not included)
Estimated Assembly Time: 5 minutes
Before installation, attach the handle to the front of the unit with the included
screws. It may be necessary to push aside the rubber seal on the inside of the
door to reveal the screw holes.
Caution: Avoid over-tightening the screws, or you may cause damage to the
unit.
INSTALLATION
This cooler is a freestanding unit and should not be installed inside a cabinet or
other built-in enclosure.
For proper ventilation, allow 5 inches clearance between the back of the unit
and any adjacent walls.
Before operating your wine cooler for the first time, follow these steps:
Clean the interior surface of the unit with lukewarm water and a soft cloth.
Place the cooler on a level surface that will be strong enough to support the
unit when it is fully loaded. To level your cooler, adjust the front feet located
at the bottom of the unit.
Install the cooler away from direct sunlight and heat sources such as stoves,
heaters, or radiators. Direct sunlight may affect the unit’s acrylic coating,
and nearby heat sources can increase electrical consumption. Extreme cold
or hot ambient temperatures may also prevent proper performance.
Please note: this cooler is only designed for home use, and is not designed to
be placed in a garage, basement, or outdoor area.

7
Love Your Home
FACTORY ODOR REMOVAL
Wash the interior of the cooler with a mild detergent and warm water. Leave
the door open and allow it to air dry thoroughly. If a “plastic” smell persists,
place a dish of baking soda in the unit or stuff the cooler with newspapers
overnight. When finished, let the unit run a full day to complete the airing out
process.
OPERATING INSTRUCTIONS
OPERATING ENVIRONMENT
It is recommended that the wine cooler be installed in an area where the
ambient temperature is between 50°- 80°F. If the ambient temperature is
above or below the recommended ranges, the unit’s performance may be
affected, and extreme cold or hot conditions may cause the interior
temperature to fluctuate. This will prevent the optimal range of 50°- 60°F from
being reached. In addition, keep in mind that the temperature may fluctuate
depending on whether the interior light is on or off, and whether the bottles
are located on the upper, middle, or lower racks.
HOW TO USE THE BUTTONS ON THE DISPLAY PANEL



Raise the desired
temperatures.*
Lower the desired
temperature. *
Turn the light on
and off.
* The interior temperature can be adjusted in increments of 1 degree between
54° and 66°F.
After turning on the wine cooler, the LED display will show the ambient
temperature first, and then the internal cabinet temperature.

8
http://www.NewAir.com
After you set the desired temperature, this set temperature will flash for 5
seconds on the display and then revert back to the internal cabinet
temperature.
CLEANING & MAINTENANCE
CLEANING YOUR COOLER
To clean your cooler:
Unplug the cooler and remove anything inside.
Wash the inside of the unit with a solution made of warm water and baking
soda solution (2 tablespoons of baking soda to one quart of water).
Unscrew the water reservoir at the bottom of the unit and rinse with water.
To clean the outside of the unit, use a mild detergent and warm water.
MOVING YOUR COOLER
To move your cooler:
Remove anything stored inside.
Securely tape down all loose parts located inside the unit.
Turn the leveling feet up to the base in order to avoid damage.
Tape the door shut.
Be sure the cooler stays in an upright position during transportation.
WINE STORAGE GUIDE
The ideal temperature for storing red or white wines is 55°F, with humidity
between 60% and 75% RH.
Store corked bottles on their sides, to keep the cork from drying out and
allowing air into the bottle.
UV rays make wine age faster, so keep bottles out of direct sunlight.
Avoid heavy vibrations from motors, etc.
Store wine separately from strong odors that might contaminate the flavor
of the wine.

9
Love Your Home
HOW LONG SHOULD ISTORE MY WINE?
While most wines today are meant to be drunk “young” (within a few years of
production) some fine wines are best served by proper aging. But aging too
long can decrease the flavor of the wine. Generally speaking, red wines can age
longer than white wines, but here is a storage guide for some popular vintages.
Cabernet Sauvignon…………
7-10 years
Pinot Noir………………………….
5 years
Merlot……………………………….
3-5 years
Zinfandel……………………………
2-5 years
Beaujolais………………………….
Drink now
Chardonnay……………………….
2-3 years
Riesling………………………………
3-5 years
Sauvignon Blanc………………
18 months –2 years
Pinot Gris…………………………..
1-2 years
Champagne ………………………
Ready to drink
TROUBLESHOOTING
Problem
Possible Causes
Solution
The cooler will not
operate.
The unit may be plugged
in using a different
voltage.
Check if using the wrong
voltage.
The circuit breaker may
be tripped or there is a
blown fuse.
Reset the circuit breaker
or check for a broken
fuse.

10
http://www.NewAir.com
Problem
Possible Causes
Solution
The cooler is not cold
enough.
The external
environment may
require a higher setting.
Lower the temperature
of the cooler.
The door may be
opened too frequently.
Open the door less
frequently.
The door is not closed
completely.
Make sure the door is
closed securely.
The door seal does not
seal properly.
Replace the seal on the
door. Replacements can
be acquired from the
manufacturer.
The wine cooler does
not have sufficient
clearance.
Make sure there is at
least 5 inches clearance
between the back of the
unit and any adjacent
walls.
The light does not
work.
There may be a problem
with the display board.
Contact the
manufacturer.
The cooler vibrates
while operating.
The unit is not sitting on
a level floor, or the
unit’s feet are not
correctly installed.
Make sure the unit’s feet
are in the proper position
and tightened securely.
The cooler produces a
lot of noise.
The unit is not leveled.
See above.
The fan may be
obstructed.
Check the fan to make
sure there is no debris or
obstruction. If not,
contact the
manufacturer.
The door will not close
properly.
The unit is not leveled.
See above.
The door is not properly
installed.
Check the door hinges to
make sure they are
properly installed.

11
Love Your Home
Problem
Possible Causes
Solution
The seal is weak.
Replace the seal on the
door.
Replacements can be
acquired from the
manufacturer.
The shelves are out of
position.
Make sure the shelves
slide all the way into the
unit.
The LED display does
not work.
There may be a problem
with the main control
board.
Contact the
manufacturer.
There is an LED display
error, or the LED
displays “LO”.
The cooling kit is no
longer working properly.
Contact the
manufacturer.
The PC Board is faulty.
Contact the
manufacturer.
The buttons do not
function.
The temperature control
panel may be damaged.
Contact the dealer or an
authorized service
center.

12
http://www.NewAir.com
LIMITED MANUFACTURER’S WARRANTY
This appliance is covered by a limited manufacturer’s warranty. For one year
from the original date of purchase, the manufacturer will repair or replace any
parts of this appliance that prove to be defective in materials and
workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms:
During the first year, any components of this appliance found to be defective
due to materials or workmanship will be repaired or replaced, at the
manufacturer’s discretion, at no charge to the original purchaser. The
purchaser will be responsible for any removal or transportation costs.
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
Power failure
Damage in transit or when moving the appliance
Improper power supply such as low voltage, defective household
wiring or inadequate fuses
Accident, alteration, misuse or abuse of the appliance such as using
non-approved accessories, inadequate air circulation in the room or
abnormal operating conditions (extreme temperatures)
Use in commercial or industrial applications
Fire, water damage, theft, war, riot, hostility or acts of God such as
hurricanes, floods, etc.
Use of force or damage caused by external influences
Partially or completely dismantled appliances
Excess wear and tear by the user
Obtaining Service:
When making a warranty claim, please have the original bill of purchase with
purchase date available. Once confirmed that your appliance is eligible for
warranty service, all repairs will be performed by a NewAir™ authorized repair
facility. The purchaser will be responsible for any removal or transportation
costs. Replacement parts and/or units will be new, re-manufactured or
refurbished and is subject to the manufacturer’s discretion. For technical
support and warranty service, please email [e-mail].
