LM5000 Series Telehandler Specifications
LM5040 LM5060 LM5080
P ge 1 of 1
MODEL LM5040 LM5060 LM5080
PERFORMANCE
Max. lift height, ft. (m) 20.0 (6.1) 23.0 (7.0) 31.5 (9.6)
Max. lift capacity, lbs. (kg) 7700 (3500) 8800 (4000) 7250 (3300)
Lift capacity to full height, lbs. (kg) 7700 (3500) 6600 (3000) 4400 (2000)
ENGINE
Model ..........................................................................CNH NEF Tier III-F4BE0484F..........................................................................
Engine power, H (kW) 120 (88) 120 (88) 120 (88)
Displacement, cu. in. (L) 275 (4.5) 275 (4.5) 275 (4.5)
Aspiration ...........................................................................Turbocharged / intercooled ...........................................................................
DRIVELINE
owershift transmission, F/R 4 / 3 4 / 3 4 / 3
Max speeds in gears: 1 - mph, (kph) 3.1 (5.0) 3.1 (5.0) 3.1 (5.0)
2 - mph, (kph) 6.6 (10.7) 6.6 (10.7) 6.6 (10.7)
3 - mph, (kph) 13.2 (21.3) 13.2 (21.3) 13.2 (21.3)
4 - mph, (kph) 23.0 (37.2) 23.0 (37.2) 23.0 (37.2)
Service brakes ...................................................................Hydraulic wet disc, 4 discs per wheel...................................................................
arking brake .............................................................................Mechanical driveline disc.............................................................................
Selectable 3-mode steering ...........................................................................Front wheel, crab, 4-wheel ...........................................................................
HYDRAULICS
Cab models ....................................................................Load sensing piston pump, 37 G M....................................................................
RO S model Gear pump, 34 G M
ressure, SI (Bar) 3550 (245) 3550 (245) 3550 (245)
Aux. boom hydraulic circuit Standard Standard Standard
TIRES AVAILABLE
17.5LR 24 17.5LR 24 17.5LR 24
15.5R 25 15.5R 25 15.5R 25 (cab only)
13.00 x 24 (RO S only)
DIMENSIONS w/ 17.5 tires
Length, no attachment, ft. (m) 15.7 (4.79) 16.2 (4.95) 16.7 (5.08)
Overall width, in.(mm) 95 (2400) 95 (2400) 95 (2400)
Overall height, in. (mm) 97 (2470) 97 (2470) 97 (2470)
Ground clearance, in. (mm) 16.5 (420) 16.5 (420) 16.5 (420)
Wheelbase, in. (mm) 117.7 (2990) 117.7 (2990) 118.5 (3010)
Turn radius over tires, ft. (m) 11.3 (3.4) 11.3 (3.4) 11.3 (3.4)
Cab width, inside, in. (mm) 39 (985) 39 (985) 39 (985)
Weight, approx., lbs. (kg) 15,875 (7200) 16,300 (7400) 17.500 (7950)
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
