P1000 Series Air Cart Specifications
P1030 P1040 P1050 P1060
Page 1 of 1
MODEL P1030 P1040
Capacity, bu. (l) 280 (9866) 330 (11628)
Compartments ...........................................................................................................................................Two...........................................................................................................
plits, bu. (l) 169/118 (5955/4158) 186/142 (6554/5004)
DIMENSIONS
Ground clearance, in. (m) .....................................................................................................................25 (0.64) ......................................................................................................
Height, ft. in. (m) 14’ 11” (4.3) 15’ 3” (4.65)
Overall width, ft. in. (m)
ingle wheels..................................................................................................................................12’ 6” (3.81)....................................................................................................
Dual wheels ....................................................................................................................................16’ 8” (5.08)....................................................................................................
Tow-behind length, ft. in. (m).............................................................................................................25’ 4” (7.72)....................................................................................................
Tow-behind weight (empty), lb. (kg) 10,013 (4546) 10,052 (4569)
Tow-between length, ft. in. (m).............................................................................................................26’ 4” (8) ......................................................................................................
Tow-between weight (empty), lb. (kg) 10,013 (4546) 10,052 (4569)
TIRES
Front caster ...............................................................................................................................................Dual ..........................................................................................................
(on tow-behind model only).......................................................................................................22.5 L x 16.1 TII tires ...........................................................................................
Rear axle, in. (m)........................................................................................30.5L x 32, 12 ply AWT single tire @ 120 (3.05) tracking width ...........................................................
Valves........................................................................................................................................... ingle-/double-shoot .............................................................................................
Primary lines...........................................................................................................................................Up to 8........................................................................................................
Fan drive.........................................................................................................................................Hydraulic dual fan ...............................................................................................
Meter drive system ...................................................................................................................Mechanical ground drive ..........................................................................................
Fill auger, in. (cm) x ft. (m)..........................................................................................................10” (25.4) x 19’ (5.8).............................................................................................
............................................................................................................................................ teel cupped flighting ............................................................................................
MODEL P1050 P1060
Capacity, bu. (l) 380 (13390) 430 (15153)
Compartments..........................................................................................................................................Three .........................................................................................................
plits (tow between), bu. (l) 169/93/118 (5955/3277/4158) 186/102/142 (6554/3594/5004)
plits (tow behind), bu. (l) 118/93/169 (4158/3277/5955) 142/102/186 (5004/3594/6554)
DIMENSIONS
Ground clearance, in. (m) .....................................................................................................................25 (0.64) ......................................................................................................
Height, ft. in. (m) 14’ 11” (4.55) 15’ 3” (4.65)
Overall width, ft. in. (m)
ingle wheels 12’ 8” (3.86) 12’ 8” (3.86)
Dual wheels 16’ 2” (4.93) 16’ 2” (4.93)
Tow-behind length, ft. in. (m) 28’ 3” (8.61) 28’ 3” (8.61)
Tow-behind weight (empty), lb. (kg) 10,900 (4955) 11,090 (5040)
Tow-between length, ft. in. (m) 29’ 4” (8.94) 29’ 4” (8.94)
Tow-between weight (empty), lb. (kg) est. 10,900 (4955) 11,090 (5040)
TIRES
Front caster ...............................................................................................................................................Dual ..........................................................................................................
(on tow-behind model only) ........................................................................................................22.5 x 16.1 TII tires.............................................................................................
Rear axle, in. (m)........................................................................................30.5L x 32, 12 ply AWT single tire @ 120 (3.05) tracking width ...........................................................
Valves...................................................................................................................................... ingle-/double-/triple-shoot........................................................................................
Primary lines...........................................................................................................................................Up to 8........................................................................................................
Fan drive.........................................................................................................................................Hydraulic dual fan ...............................................................................................
Meter drive system ...................................................................................................................Mechanical ground drive ..........................................................................................
Fill auger, in. (cm) x ft. (m)........................................................................................10” (25.4) x 19’ (5.8) steel cupped flighting...........................................................................
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
