Field Sprayer Specifications
S1050 S1070
P ge 1 of 2
MODEL S1050 S1070
Tank Sizes, U.S. gallons (L) 1000 (3785) 1600 (6056)
BOOMS
Suspended, ft. (m)...............................................................................80 (24.4) 48 nozzles at 20" (50.8 cm) spacing [optional 30" (76.2 cm)].....................................................
.....................................................................................................90 (27.4) 54 nozzles at 20" (50.8 cm) spacing [optional 30" (76.2 cm)].....................................................
....................................................................................................100 (30.5) 60 nozzles at 20" (50.8 cm) spacing [optional 30" (76.2 cm)]....................................................
— 120 (36.6) 72 nozzles at 20" (50.8 cm) spacing
— [optional 30" (76.2 cm)], no windscreen
134 (40.8) 80 nozzles at 20" (50.8 cm) spacing
[optional 22" (56 cm)], no windscreen
Wheeled, ft. (m)
4 section — 80 (24.4) 48 nozzles at 20" (50.8 cm) spacing
— 84 (25.6) 50 nozzles at 20" (50.8 cm) spacing
— 90 (27.4) 54 nozzles at 20" (50.8 cm) spacing
— 94 (28.7) 56 nozzles at 20" (50.8 cm) spacing
— 100 (30.5) 60 nozzles at 20" (50.8 cm) spacing
— 104 (31.7) 62 nozzles at 20" (50.8 cm) spacing
6 section — 110 (33.5) 66 nozzles at 20" (50.8 cm) spacing
— 114 (34.8) 68 nozzles at 20" (50.8 cm) spacing
— 120 (36.6) 72 nozzles at 20" (50.8 cm) spacing
— 124 (37.8) 74 nozzles at 20" (50.8 cm) spacing
— 130 (39.6) 78 nozzles at 20" (50.8 cm) spacing
— 134 (40.8) 80 nozzles at 20" (50.8 cm) spacing
CART TIRES/TRACKING WIDTHS
Single, in. (cm) 18.4-26 3 / 80-120 (203-305) 480/80 38 1/ 72-120 (183-305)
380/80 38 / 62-120 (157-305) 380/90 46 1 / 72-120 (183-305)
320/90 46 / 60-120 (152-305) 380/85 46 1 /72-120 (183-305)
Duals, in. (cm) ................................................................................................320/90 46 / 22 (56) rows, 132 (335) outer spacing max.................................................................
....................................................................................................................380/90 46 / 30 (76) rows, 120 (305) outer spacing ....................................................................
TRANSPORT WIDTH
Suspended, ft. in. (m)..................................................................................11' (3.35) without windscreens, 11'2" (3.4) with windscreens.............................................................
Wheeled, ft. in. (m)......................................................................................................11'2" (3.4) wheeled boom fold arm width ............................................................................
CLEARANCE
Cart axle, in. (cm).........................................................................................................33-36 (84-91) depending on tire options .............................................................................
SUSPENDED BOOM HEIGHT RANGE
in. (cm).............................................................................................................................................18-70 (46-178)..................................................................................................
PUMPS, HYDRAULIC CENTRIFUGAL, U.S. gpm (L/min)
...................................................................................................................Hypro™ HM1C for hydraulic oil flows of 8-15 (30-57)...................................................................
...................................................................................................................Hypro HM3C for hydraulic oil flows of 15-23 (57-87) ...................................................................
........................................................................................................................Ace™ 206 for hydraulic oil flows of 6-9 (23-34)........................................................................
PLUMBING
Boom control valves, in. (cm)...................................................................TeeJet™ 450 Series ball valve manifold system (flanged fittings)...........................................................
...........................................................................................................................1 (2.5) hose boom control valves to booms...........................................................................
Hand/eye wash tank, U.S. gallons (L)....................................................................................................3.2 (12) .......................................................................................................
inse tank, U.S. gallons (L)..................................................................................................120 (454) Integrated in frame......................................................................................
Agitation .....................................................................................................................................Four horizontal jet-type ...........................................................................................
Spray booms, in. (cm) ............................................................................................1 (2.5) schedule 80 PVC pipe (wheeled boom).........................................................................
.....................................................................................................................1 (2.5) schedule polypropylene (suspended boom) .....................................................................
.....................................................................................................1 (2.5) schedule 40 stainless steel (wheeled and suspended – optional).....................................................

New Holland
Field Sprayer Specifications
S1050 S1070
P ge 2 of 2
MODEL S1050 S1070
NOZZLES .........................................................................................TeeJet™ visaflo flat fan, standard or extended range, 80 or 110 (degree) tips.................................................
...........................................................................................................................TeeJet™ single- or triple-head nozzle bodies...........................................................................
................................................................................................................................Swivel-Jet double-head nozzle bodies................................................................................
........................................................................................................Combo-Jet ™ single-, double- or triple-head nozzle bodies and tips ........................................................
OPTIONS
• Induction tank 12 U.S. gal. (45 L) with c-seal and screw lid • Low-pressure wash wand
• Endscreens (standard on suspended boom modes with windscreens) • Fender (for single tires)
• End nozzles • Chemical container rinse standard on induction tank
• Windscreens • Foam marker
• Extra ball valve kit • Hydraulic fold out (wheeled boom)
Hypro™ is a trademark of Hypro Corporation. Ace™ is a trademark of Ace Pump Corporation. TeeJet ™ is a trademark of Spraying Systems Co. Combo-Jet™ is a trademark of Wilger Industries Ltd.
Intelliview™ II 7-in. color screen, soft button navigation, on-the-go rate changes, animated graphics, configurable display, compatible with New Holland
air carts, tractors and combines
Intelliview™ Plus II 10-in. color screen, touch screen navigation, on-the-go rate changes, animated graphics, configurable display, compatible with New Holland
air carts, tractors and combines
