NewLine 900 User manual

Pivot Shower
1. When you receive your Newline shower check contents for any freight damage.
2. Advise Newline on 0508 639 5463 if any damage has occurred within 8 hours of
receiving the goods so this is can rectied.
3. Do not proceed with installation until resolved.
Important!
INSTRUCTION MANUAL
December 2018 V2
INCLUDES: 2 SIDED SHOWERS AND 3 SIDED ALCOVE 900 / 1000 / 1200 DOORS

2
WARRANTY
Faulty goods are covered under warranty for 5 years. Visit www.newline.co.nz for warranty information.
Breakages incurred during construction are not covered under warranty.
Installations must conform to the instructions to be covered by the warranty.
INSTRUCTIONS
Tray and liner instructions: Come with the specic tray supplied
Shower waste and supply ttings: Must be installed by a registered plumber.
HEALTH AND SAFETY
Toughened Glass:
• Do not rework precut glass panels. Cutting or altering a glass panel will cause it to explode without warning.
• Unpack all glass assemblies. Stand glass on soft packaging on the oor and against a wall. Care must be taken
not to strike any edge or corner against a hard surface as this will chip and destroy the glass panel.
Installation:
• Glass panels and assemblies are heavy. Two man lifting is recommend for handling and installation.
• Determine positioning of wiring and piping within wall cavities before shower installation. Mark their positions to
ensure electrical and piping areas are avoided.
• Wear appropriate protective clothing and eye protection during installation.
MATERIALS REQUIRED
Sika Silaex NG translucent Silicone.
TOOLS REQUIRED
AFTERCARE
The shower must be squeegeed down after each shower. Thoroughly clean weekly with a microber cloth, mild
detergent and water. Rinse with clean water and squeegee and wiped dry.
NEWLINE RECOMMENDS A SKILLED TRADESMAN ACQUAINTED WITH
SHOWER INSTALLATIONS IS USED TO ENSURE THE VERY BEST OUTCOME.
PIVOT DOOR SETS 2 SIDED & ALCOVE APPLICATIONS

3
PREPARATION CHECKLIST
ENSURE YOU TICK THE SPECIFIC BOXES THAT APPLY AS YOU PROGRESS
2 Sided Shower: Ensure the oor is level and the walls are plumb and at.
Position all framing for solid xing for the shower tray, shower and plumbing ttings. Wall proles require a
stud centred 20mm back from tray outside edge.
Ensure all plumbing items have been installed prior to the lining being attached.
Alcove Shower: Critical that the walls are constructed plumb and at. Request the specic width of the Acrylic
Tray prior to framing.
ACRYLIC TRAY AND LINER OPTION
• Detailed installation instructions are packed with the shower tray for tray and lining installation.
• Alcove application will require specic detailing of framing and is based on 10mm plasterboard lining.
• Shower waste and supply ttings must be installed by a registered plumber.
PREPARATION CHECKLIST
Page 4 - 2 Sided Shower
Page 8 - 3 Sided Alcove Shower
INDEX
BEFORE YOU START
• These Pivot Showers are designed to t different acrylic trays, so it is important to identify your application from
Table A and wall channel location to outside of tray.
TABLE A
DOOR SET RETURN PANEL TRAY EDGE TO WALL CHANNEL
75mm STANDARD TRAY
750mm 900mm 13mm
900mm 750mm 13mm
900mm 900mm 13mm
1000mm 1000mm 13mm
1200mm 900mm 13mm
40mm LOW PROFILE TRAY
750mm 915mm* 13mm
915mm+750mm 13mm
915mm 915mm 21mm
1000mm 1000mm 13mm
1200mm 915mm* 13mm
NOTES:
RETURN PANELS MARKED *The 915 return panels will be extended to nearly maximum. Check table “b” to assess what changes
on opposite side will reduce return extension.
DOOR SET MARKED +Use adjustment at outside corner to reduce wall extension.
TABLE B MINIMUM TO MAXIMUM
DOOR & RETURN DOOR SET Return Panel
750mm x 900mm 720mm to 740mm 870mm to 890mm
900mm x 750mm 870mm to 890mm 720mm to 740mm
900mm x 900mm 870mm to 890mm 870mm to 890mm
1000mm x 1000mm 970mm to 990mm 970mm to 990mm
1200mm x 900mm 1170mm to 1190mm 870mm to 890mm
Notes: Minimum/Maximum range is limited to Tray sizes, Wall alignments & Tray being level.

4
PIVOT 2 SIDED SHOWER
COMPONENT LIST: RETURN PANEL
10
12
12
Wall Channel K7102 Back Door Seal K7072 Magnet Stop K3829 Pivot Block K2004
Handle
Replacement Screw Pack - 2 & 3 Sided Chrome & White K2271
4x35mm Screws Washer & Caps 4x10mm screwsWall plug
1200 Door
900 & 1000 Door
Lower door seals
K6808
15 PCS

5
Walls out of Plumb will not allow for Full minimum / maximum options.
1
Apply silicone
bead down back
of channel prior to
fastening.
Mark wall prole
Acrylic Shower Lay-out
Ensure you read “Before you
start” section on page 3
Refer to Page 3
Table A & B will give
measurements for your
specic installation.
A B
Fasten wall prole

6
2
3
Fit return panel
12
BA
A
• Connect door set to return panel
• Drill and fasten the corner prole.
(Additional adjustment is available at
corner if needed)
B
• Finally adjust shower door in wall
proles and square up doors.
• Drill and fasten door frame to wall
prole

7
4
5
Apply silicone to
join as indicated
Seal the join
between wall prole
and frame. 150mm
up from base on
both sides

8
PIVOT 3 SIDED ALCOVE SHOWER
COMPONENT LIST: 3 SIDED ALCOVE
4x35mm Screws Washer & Caps
6 sets
12 PCS
4x10mm screws
Lower door seals
K6808
Wall plug
Replacement Screw Pack - Chrome & White K2271
Wall Channel K7102 Back Door Seal K7072 Magnet Stop K3829 Pivot Block K2004
Handle
1200 Door
900 & 1000 Door

9
Walls out of Plumb will not allow for Full minimum / maximum options.
1
Fit seal to back of door
channel and fasten
end caps (05) to top
and bottom.
Back of Door
Position wall proles
onto door frame.
2
Shower Type Wall Channel Adjustment
900mm 870mm (minimum) to 890mm (maximum)
1000mm 970mm (minimum) to 990mm (maximum)
1200mm 1170mm (minimum) to 1190mm (maximum)

10
3
Layout
Mark wall proles
B
A
Fasten wall proles
Apply silicone
bead down back
of channel prior to
fastening.

11
4
5
Fasten details
Square up door set and
adjust to wall proles.
Fasten frame to wall
proles as indicated.
up the door and install bottom seal.

12
6Apply silicone to outer join as indicated
Seal the join
between wall prole
and frame. 150mm
up from base on
both sides
7

13
