Next 117741 User manual

H172 x W110 x D44,5cm
Actual product size
IMPORTANT - RETAIN FOR FUTURE REFERENCE
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999
HARTFORD PAINTED WINE LARDER
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741

BEFORE YOU START
Warnings
We suggest you retain these instructions for future reference.
Keep fittings out of children’s reach and keep children well
away from the construction area.
This product should only be used on firm, level ground.
Please periodically check all fittings and re-tighten as
necessary.
Please do not sit or stand on your furniture.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause deterioration of the colour.
Unwrap all packaging materials and place the components
on top of the carton box or on a clean floor to protect it from
damage.
Do’s
We suggest you spend a short time reading through this leaflet
before you start.
When you are ready to start, make sure that you have the
right tools and plenty of space.
Unwrap all packaging materials and place the components
on a clean surface to protect it from damage.
We recommend that the packaging is used to protect the
surfaces during assembly.
Carefully check that you have all the parts before beginning
assembly
Due to the size of the product we recommend that it is
assembled in the room intended for use.
Ensure the product is fully assembled as illustrated and all
fixings are fully tightened before use.
Wipe occasionally with a soft cloth slightly dampened with
water. Then buff with a dry clean soft cloth.
Wood will mellow and change colour over time, we recommend
that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
Don’ts
Do not drag or pull your furniture.
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Do not place hot items (e.g. hot drinks) directly on to the wood
surface. Please make sure you use a placement or coaster.
Number of people required to assemble
Two persons are required to assemble this item.
Time to assemble
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To View our full furniture range please visit www.next.co.uk
120min
Tools required
PH2
not supplied not supplied
HARTFORD PAINTED WINE LARDER
1
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741

GETTING TO KNOW YOUR PRODUCT
1
3
4
15
5
14
19
20
27
2
16
18
17
13
12
22
28
23
6
9
8
7
11
10
24
25
26
9
10
18
21 21 21
28
2
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER

Ref
1110.6 x 44.5cm 1
Qty
Dimensions Visual
2
4
168.7 x 11cm
168.7 x 11cm
1
1
25 113.3 x 40.8cm
1
11 97.4 x 34.7cm 1
12 82 x 20.5cm 2
10 34.9 x 9.1cm 2
18 97.3 x 36cm 2
16 33.2 x 3cm 2
15 78.9 x 34.2cm 2
Ref
887.6 x 5cm 1
QtyDimensions Visual
9
27
34.9 x 9.1cm
70.5 x 93.2cm
2
1
5168.7 x 6.9cm 1
22 22 x 30.8cm
1
23 22 x 30.8cm
3
Components supplied. Please use this guide if you require replacement parts.
3 168.7 x 6.9cm 1
17 34.7 x 13.4cm 2
19 97.4 x 36cm
28 163.7 x 34.1cm
1
20 97.4 x 31.1cm
1
26 93.8 x 93.2cm
1
21 22 x 30.8cm
6 90.8 x 7cm 1
782.6 x 3.2cm 1
24 113.3 x 40.8cm
1
1
2
13 34.7 x 13.4cm 2
14 77.5 x 13.4cm 2
3
Ctn
3
1
1
2
3
3
3
3
1
1
3
3
3
3
Ctn
2
2
3
2
3
2
2
3
2
2
3
2
2
1
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER

Fixtures and fittings
supplied (actual size)
mm 13012011 0100908070605040302010
DimensionsRef Qty
12G
34
I
H
N/A
Visual QtyRef Dimensions
M4 x 22mm
70B 8 x 25mm
Fixtures and fittings supplied (not to scale)
8X 4 x 50mm
8
A6 x 30mm
8
C3,5 x 14mm
46
D3,5 x 16mm
42
E4 x 30mm
8
JN/A
4
K N/A
4
L N/A
4
M N/A
5
N N/A
2
6
R
QN/A
Visual QtyRef Dimensions
2
S N/A
12
T N/A
2
UN/A
6,0 x 30mm
2
AA N/A
*extra
2
1
1
1
2
2
*extra *extra
2
1
1
4
* Extra Fittings included
in case of loss or damage
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
2
34
N/A 2

FRAGILE!
HANDLE WITH CARE.
Components
21 22 2320
1
2
B x 12
8 x 25mm T x 12
T
T
B
B
T
T
T
T
B
B
B
B
x2
x2
H
B
B
B
B
B
B
B
BB
B
B
B
B
B
B
B
B
B
B
B
H
H
H
x3
9
10
21
22
23
11
19
20
5
D
D
D
DM
M
B x 28
8 x 25mm
PH2 H x 4
PH2 D x 4 3,5 x 16mm M x 2
D
DM
M
D
D
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER

D
D
M
3
4
B x 14
8 x 25mm PH2 D x 4 3,5 x 16mm M x 2
D
D
D
DM
M
B
B
BB
B
B
BB
B
B
x2
x2
U x 2
PH2 H x 12 L x 4 PH2 D x 8 3,5 x 16mm
D
D
L
Tighten until shoulder is flush
with panel. Do not overtighten
or undertighten (see example below)
CAM-LOCK
NO GAP
Shoulder
Panel
Panel
H
H
H
H
H
H
H
H
H
H
HH
H
D
LD
D
L
D
D
LD
D
L
D
U
U
4
2
8
7
6
17
13
6
M
D
D
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER

5
6
H
AA x 2
PH2 H x 10
H
AA
H
H
H
H
H
H
H
H
H
AA
B x 16
8 x 25mm
B
B
BB
B
B
B
B
B
BB
BB
B
B
B
3
5
28
28
7
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER

7
9 10
8
PH2 H x 8
HHHH
HHHH
1
8
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
X
X
X x 2
4 x 50mm
PH2
X x 4
4 x 50mm
PH2
X
X
X
X
21
11
23
22 21
21
FRAGILE!
HANDLE WITH CARE.
Components
21
FRAGILE!
HANDLE WITH CARE.
Components
22 23
FRAGILE!
HANDLE WITH CARE.
Components
21

11
12
9
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
20
FRAGILE!
HANDLE WITH CARE.
Components
20
I x 4
PH2
WHEN FITTING CAMS
ENSURE STARTING POSITION IS CORRECT
BEFORE YOU INSERT CONNECTING CAM-PILLAR
TURN CLOCKWISE UNTIL SECURE
CORRECT WRONG
I
I
I
19

13
14
E x 6
4 x 30mm
PH2 I x 10
I
E
I
I
I
I
I
I
I
I
I
E
E
E
E
E
28
4
5
10
10
10
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
PH2 D x 2 3,5 x 16mm N x 1
D
N
D
D
D
N
19

16
15
17
X
E x 1
4 x 30mm
PH2
I x 1
X x 1
4 x 50mm
PH2
I
E
E
E x 2
4 x 30mm
PH2
E
7
8
6
11
11
2
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
E x 6
4 x 30mm
PH2 I x 10
E
I
I
E
E
E
E
E
I
I
I
I
I
I
I
I
28
2
3
9
9

18
20
19
I x 8
PH2
I
4 x 30mm
E x 4
PH2
E
1
12
E
E
E
IIII
26
27
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
I
E
E
E
4
X
E x 3
4 x 30mm
I x 1
X x 1
4 x 50mm
PH2
PH2

21
23 24
22
A x 4
6 x 30mm A
A
A
J x 8
J
J
J
E x 8
4 x 30mm
PH2
E
E
E
x2
J
12
17
13
13
J
J
A
A
A
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
PH2 D x 18 3,5 x 16mm
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D

25
27
26
E x 8
4 x 30mm
PH2 x2
E x 4
4 x 30mm
PH2 x2
E
E
E
E
EE
Q x 4 G x 8
M4 x 22mm
PH2 x2
G
Q
G
14
16
14
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
28
G
Q
G
x2
15

29
30
D
PH2 D x 8 3,5 x 16mm
PH2 C x 8 3,5 x 14mm
N x 4
K x 4
K
C
N
D
C
D
K
D
D
K
C
ND
C
D
K
D
!
24
25
25
24
15
C
N
C
C
N
C
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER

31
32
Q x 2 G x 4
M4 x 22mm
PH2
GQ
G
Q
G
G
A
A
A x 4
6 x 30mm
A
16
18
18
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER

33
R x 2 6 x 30mm S x 2
S
R
D
S
R
D
17
S
R
D
PH2 D x 2 3,5 x 16mm
Produced in Brazil for Next Retail Ltd.
117741-2015-V1
117741
HARTFORD PAINTED WINE LARDER
