LOGAN WHITE BAR TABLE
H55 x W45x D45cm
Actual product size
Assembly instructions
IMPORTANT - RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd.
Need Help ?
With: Assembly instruction
Missing or damaged parts
CALL: 0333 777 8999

LOGAN WHITE BAR TABLE
418025
15min
Assembly instructions
TO NO TIME
418025-2016-V1.

418025
LOGAN WHITE BAR TABLE
418025-2016-V1.
Assembly instructions
2
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
1
2
6
5
4
15
13
16
14
10
10
9
11
12
7
3
8
8

418025
LOGAN WHITE BAR TABLE
418025-2016-V1.
1
Assembly instructions
3
Components supplied. Please use this guide if you require replacement parts.
Produced in China for Next Retail Ltd.
Ref Dimensions Visual Qty Ctn Ref Dimensions Visual Qty Ctn
42 x 21cm 1 1
242 x 6cm 1 1
3
4
42 x 6cm 1 1
5
42 x 22cm 1 1
6
42 x 22cm 1 1
7
43 x 40cm 1 1
8
45 x45cm 1 1
9
42 x 10cm 2 1
10
1 1
11
21x 21cm 2 1
12
1 1
13
1 1
14
21x 21cm 1 1
15
21x 21cm 1 1
16
42 x 21cm 1 1
1 1
21x 21cm
42 x 21cm
42 x 22cm
42 x 22cm

LOGAN WHITE BAR TABLE
418025
Assembly instructions
N/A
Ø8 x 38mm 2
N/A
D6 Ø8 x 30mm 2
B8
Ref Dimensions Qty Spare Qty
N/A
Ø15 x 12mm 2B3
8
V50 Ø6 x 28mm 1
N/A
Q3 1
418025-2016-V1.

5
LOGAN WHITE BAR TABLE
418025-2016-V1.
Assembly instructions
1
Produced in China for Next Retail Ltd.
418025
TURN THE CAM IN A CLOCKWISE DIRECTION
PUSH THE TWO PANELS TOGETHER ALLOWING THE
DOWEL TO ALIGN WITH THE HOLE
1
2
WHEN TIGHTENING THE CAM
TURN THE CAM IN A CLOCKWISE DIRECTION UNTIL THE
ARROW POINTS IN THE POSITIONS SHOWN IN THE
DIAGRAMS BELOW
START MINIMUM
LOCK
MAXIMUM
LOCK

6
418025-2016-V1.
2
418025
LOGAN WHITE BAR TABLE
Assembly instructions
Produced in China for Next Retail Ltd.
3
1
3
4
5

7
418025-2016-V1.
4
418025
LOGAN WHITE BAR TABLE
Assembly instructions
Produced in China for Next Retail Ltd.
5
6
7
5
5
Gloss side

7
8
418025-2016-V1.
6
418025
LOGAN WHITE BAR TABLE
Assembly instructions
Produced in China for Next Retail Ltd.
8
8
V50 Ø6 x 28mm
Q3 N/A
7
911
T1 N/A

8
9
418025
LOGAN WHITE BAR TABLE
418025-2016-V1.
9
Assembly instructions
Produced in China for Next Retail Ltd.
12
10
10
11
T10 N/A
T10 N/A

16
10
10
418025
LOGAN WHITE BAR TABLE
418025-2016-V1.
11
Assembly instructions
Produced in China for Next Retail Ltd.
13
14
15

13
11
418025-2016-V1.
12
418025
LOGAN WHITE BAR TABLE
Assembly instructions
Produced in China for Next Retail Ltd.
25mm 8

12
418025-2016-V1.
14
418025
LOGAN WHITE BAR TABLE
Assembly instructions
Produced in China for Next Retail Ltd.
WHEN LOOSENING THE CAM
TURN THE CAM IN A COUNTERCLOCKWISE DIRECTION
UNTIL THE ARROW POINTS IN THE POSITION SHOWN
IN THE DIAGRAMS BELOW
TURN UNLOCKED
MAXIMUM
LOCK TO UNLOCK

418025-2016-V1.
418025
LOGAN WHITE BAR TABLE
H55 x W45x D45cm
Produced in China for Next Retail Ltd.
Actual product size
339mm
419mm
450mm
450mm
550mm
342mm
190mm
190mm
190mm
143mm 143mm
187mm

418025
LOGAN WHITE BAR TABLE
418025-2016-V1.
