Next GRAND COUNTRY CORNER TV UNIT U22227 User manual

Assembly instructions
Actual product size:
H50 x W110 x D45 cm
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999
IMPORTANT ─RETAIN FOR FUTURE REFERENCE
Produced in India for Next Retail Ltd. 2
GRAND COUNTRY CORNER TV UNIT
U22227
U22227-2022-V1

Warnings
We suggest you retain these instructions for future reference
Keep fittings out of children’s reach and keep children well away from
construction area.
This product should only be used on firm, level ground.
Please periodically check all fittings and re-tighten as necessary.
Please do not sit or stand on your table.
Avoid exposing the furniture to excessive heat or direct sunlight as this
can cause cracking of the wood and deterioration of the colour.
Do’s
We suggest you spend a short time reading through this leaflet before
you start.
When you are ready to start, make sure that you have the right tools and
plenty of space.
Unwrap all packaging materials and place the components on a clean
surface to protect it from damage, We recommend that the packaging is
used to protect the surfaces during assembly.
Carefully check that you have all the parts before beginning assembly.
Due to the size of the product we recommend that it is assembled in the
room intended for use.
Ensure the product is fully assembled as illustrated and all fixings fully
tightened before use.
Check fixings regularly to ensure they remain tight.
Wood will mellow and change colour over time, we recommend that
ornaments and items placed on the surface are moved regularly for the
first few months to prevent uneven mellowing.
To clean your item, please use a soft cloth slightly dampened with water
and wipe clean. Then buff with a dry clean cloth.
Don’ts
When moving furniture never drag the pieces across the floor, as this will
cause damage to the joints.
Apply Adhesive substrates for example, sticky tape to the product.
Do not use silicone based furniture polish. Silicone in furniture polishes
can break down the lacquer finish.
Ensure that the product is protected with mats & coasters when items are
placed on to its surface.
Never put hot dishes directly onto wooden or glass surfaces as this may
mark the furniture.
Never allow any kind of liquid to remain on your furniture. Absorption can
cause finishes to de-laminate and or stain.
Number of people required to assemble
Two persons are required to assemble this item.
Time to assemble
Tools required
Missing parts
If you are missing any fixtures and fittings for your product please
contact our customer service team on 0333 777 8999 and they will
be happy to arrange for a replacement to be sent to you free of
charge.
Home service technicians
If you have a fault with your product please contact our customer
service team on 0333 777 8999. If you have had the product for 28
days or less you may be offered a replacement, refund or for a fully
trained home service technician to visit your home to assess the
fault and repair the product where possible. If you have had the
product for more than 28 days we will send an independent home
service technician to review and repair the product where possible
and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To view our full furniture range please visit
www.next.co.uk
Assembly instructions
BEFORE YOU START
Produced in India for Next Retail Ltd. 3
30mins
“2 PERSON BUILD”
GRAND COUNTRY CORNER TV UNIT
U22227
U22227-2022-V1

Assembly instructions
GETTING TO KNOW YOUR PRODUCT
Produced in India for Next Retail Ltd. 4
1
2
Components supplied. Please use this guide if you require replacement parts.
Ref Description Visual Qty Ctn
1110 x 45 x 37.5cm 1 1
2 42 x 14.5 x 22cm 2 1
GRAND COUNTRY CORNER TV UNIT
U22227
U22227-2022-V1

Assembly instructions
Produced in India for Next Retail Ltd. 5
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty *Extra
A
B
6 x 30mm 6 +1
mm 10 20 30 40 50 60 70 80 90 100
Fixtures and fittings supplied (not to scale)
Ref Visual Dimensions Qty *Extra
C
6 x 17mm 6 +1
N/A 2 N/A
N/A 1 N/A
D
GRAND COUNTRY CORNER TV UNIT
U22227
U22227-2022-V1

Assembly instructions
Produced in India for Next Retail Ltd. 6
1Note: Do not fully ghten un l
all fings are in posi on
2
GRAND COUNTRY CORNER TV UNIT
U22227
U22227-2022-V1
1
Match the number mentioned
on both carcass & legbefore assembly
2
A x 6 Nos
B x 6 Nos
A
DETAIL A
SCALE 1 : 1
A
B
C

Assembly instructions
Produced in India for Next Retail Ltd. 7
3
supplied
We recommend the use of wall strap
provided for safety reasons.
Please fix one end of the strap onto the wall
and secure the furniture by fing other end
at the back of the furniture.
N.B. Wall fixings are not included, please
source suitable fixings for your wall type. If
in doubt, please consult a qualified
tradesperson.
WARNING: Always ensure the wall to be
drilled is free from hidden electrical wires,
water and gas pipes.
Periodically check all fings and wall fixings
to ensure they have not come loose and re-
ghten as necessary.
Note: Fit the anp straps on both top corners of the rear side of
the product and fix the other end of the strap to wall.
WALL FURNITURE
Fit an-p
kit here
Fit an-p
kit here
GRAND COUNTRY CORNER TV UNIT
U22227
U22227-2022-V1

Assembly instructions
Produced in India for Next Retail Ltd. 8
Actual product size:
H50 x W110 x D45 cm
45cm
110cm
50cm
12.5cm
15.8cm
GRAND COUNTRY CORNER TV UNIT
U22227
U22227-2022-V1
