Next IRVINE KING 965098 User manual

1
Produced in China for Next Retail Ltd.
965098-2014-V1
Actual product size
H118 x W158 x L222cm
IMPORTANT - RETAIN FOR FUTURE REFERENCE
IRVINE BLK METAL BED - KING
965098
Assembly instructions
NEED HELP?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999

2
Produced in China for Next Retail Ltd.
965098-2014-V1
IRVINE BLK METAL BED - KING
965098
Assembly instructions
BEFORE YOU START
Number of people required to assemble
Two persons are required to assemble this item.
Time to assemble
Tools required
Missing parts
If you are missing any fixtures and fittings for your
product please contact our customer service team on
0333 777 8999 and they will be happy to arrange for a
replacement to be sent to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have
had the product for 28 days or less you may be offered a
replacement, refund or for a fully trained home service
technician to visit your home to assess the fault and
repair the product where possible. If you have had the
product for more than 28 days we will send an
independent home service technician to review and
repair the product where possible and recommend
further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
Warnings
We suggest you retain these instructions for future reference.
Keep fittings out of children’s reach and keep children well away
from construction area.
This product should only be used on firm level ground.
Please periodically check all fittings and re-tighten as necessary
Please do not jump or stand on your bed.
Avoid exposing the furniture to excessive heat or direct sunlight
as this can cause damage to the materials and deterioration of
the colour.
Do’s
We suggest you spend a short time reading through this leaflet
before you start.
When you are ready to start, make sure that you have the right
tools and plenty of space.
Due to the size of the product we recommend that it is
assembled in the room intended for use.
Unwrap all packaging materials and place the components on a
clean surface to protect it from damage, we recommend that the
packaging is used to protect the surfaces during assembly.
Carefully check that you have all the parts before beginning
assembly.
Ensure the product is fully assembled as illustrated and all
fixings fully tightened before use. Check fixings regularly to
ensure they remain tight.
When moving your assembled bed, it is best to lift the bed and
never to drag it. Please check that the centre support rail is
securely fixed in place.
When adjusting the support legs ensure that the foot is set
5-10mm from the floor surface without the mattress in place.
When in use the legs will create the required support for the
product.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause materials to warp or finishes to
de-laminate.
Wipe occasionally with a soft cloth dampened with water. Then
buff with a dry clean soft cloth.
Don’ts
Do not drag or pull your furniture
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the finish
Do not stand or jump on this product
Please note:
Periodically check the condition of your bed slats and plastic
locating caps to ensure they are in good condition and have not
become loose.

3
GETTING TO KNOW YOUR PRODUCT
Components supplied. Please use this guide if you require a replacement parts.
Ref Dimensions Visual Qty Ctn
1 158 x 118 cm 1 1
2 158 x 35 cm 1 1
3 9 x 203 cm 2 2
4 9 x 195 cm 1 2
5 4 x 151 cm 2 1
IRVINE BLK METAL BED - KING
965098
Assembly instructions
Produced in China for Next Retail Ltd.
965098-2014-V1
Ref Dimensions Visual Qty Ctn
6 4 x 27 cm 2 1
7 3 x 7 cm 32 3
8 6 x 7 cm 16 3
9 6 x 75 cm 32 3
10 3 x 230 cm 2 3
3
3
1
2
6
9
5
5
4
10
7
9
10
8
7

4
IRVINE BLK METAL BED - KING
965098
Assembly instructions
Fixtures and fittings supplied (actual size)
Ref
A
B
C
D
E
F
G
Fixtures and fittings supplied (not to scale)
Ref Dimensions Visual Qty
H 4mm 1
I 5mm 1
Produced in China for Next Retail Ltd.
965098-2014-V1
Dimensions
6 x 16 mm
6 x 42 mm
8 x 30 mm
12.5x0.8 mm
17x1.5 mm
24 x 1.5 mm
12.5 x 2 mm
Qty
8
2
8
10
8
8
8
mm 10 20 30 40 50 60
Spare
fitting
1
1
1
1
1
1
1

5
IRVINE BLK METAL BED - KING
965098
Assembly instructions
Produced in China for Next Retail Ltd.
965098-2014-V1
1
2
8
x
30
mm
1
G
8 x
30
mm
12.5 x 2 mm
17 x 1.5 mm
3
3
E
F
12.5 x2 mm
G x 4
F x 4 24 x 1.5 mm
C
I
3
E x 4
E x 4 17 x 1.5 mm
C x 4
G x 4
C x 4
I x 1 5 mm
F x 4 24 x1.5 mm
2
I x 1 5 mm
I
C
G
E
F
3
3

6
IRVINE BLK METAL BED - KING
965098
Assembly instructions
Produced in China for Next Retail Ltd.
965098-2014-V1
3
4
6
x
42
mm
5
6
x
16
mm
D x 4
H x 1
Ax 4
D x 2
B x 2
H x 1 4 mm
12.5 x 0.8 mm
4 mm
12.5 x 0.8 mm
5
D
A
H
5
4
H
B
D
4
6
4
6

7
IRVINE BLK METAL BED - KING
965098
Assembly instructions
Produced in China for Next Retail Ltd.
965098-2014-V1
5
6
10
00
10
9
9
A x 4
D
12.5 x 0.8 mm
D x 4
5
5
5
A
H
4 mm
H x 1

8
IRVINE BLK METAL BED - KING
965098
Assembly instructions
3 x7 CM
Produced in China for Next Retail Ltd.
965098-2014-V1
7
8
9
7
7
9
8
5
x 32
7
8
x 16
6 x7 CM

9
IRVINE BLK METAL BED - KING
965098
Assembly instructions
Produced in China for Next Retail Ltd.
965098-2014-V1
9IMPORTANT: Once the feet (part
6) have been assembled and
attached they should be adjusted
to ensure they do not touch the
floor (5mm above floor) to allow
for movement once the mattress
is placed on the bed frame.
It is important to note that when
moving the bed ensure that it is
not dragged into its new position
to prevent the possibility of these
feet being twisted or angled to
one side which could lead to the
collapse of the centre of the bed.
Remove the mattress and lift the
bed into its new position to avoid
damaging the bed. Ensure the
feet are at 90 to the floor before
replacing the mattress.

Actual product size
H118 x W158 x L222cm
IRVINE BLK METAL BED - KING
965098
Produced in China for Next Retail Ltd.
965098-2014-V1
200cm
202cm
1 81 mc
52 mc
53 mc
150cm
154.5cm
