Nexta Tech PRG-M24 User manual

Electronic control unit for the automation of outdoor pergolas with rotating slats and board for optional LED
management.
24 Vdc power supply.
Output for 1 or 2 x 24 VDC motors max 120 W each.
433.92 MHz receiver for radio transmitters.
PRG-M24

CONTENTS
1 - PRODUCT FEATURES
1.1 - TECHNICAL DATA page 3
2 - ELECTRICAL CONNECTIONS page 4
3 - SETTING UP CONTROL UNIT page 5
4 - SETTING OPERATING MODE page 6
5 - REMOTE CONTROL MANAGEMENT page 7
6 - SETTING WORKING TIME OF MOTORS page 8
7 - MANAGEMENT OF SENSORS
7.1 - SETTING WIND SENSOR
7.2 - SETTING RAIN SENSOR
7.3 - SETTING TEMPERATURE SENSOR
7.4 - SETTING SNOW ALARM
7.4 - SETTING SUN SENSOR
page 9
page 10
page 11
page 12
page 13
8 - RESETTING CONTROL UNIT page 14
2

1 - PRODUCT FEATURES
1.1 TECHNICAL DATA
Power supply (Input) 24 Vdc
Type of load (Output) 1 or 2 x 24 VDC motors
Max load power (Output) Max 120 W per output
Number of programmable transmitters 150
Receiver frequency RF 433.920MHz
Operating temperature -10° +55°
Dimensions (board only) 127 X 70 h 22 mm
3

2 - ELECTRICAL CONNECTIONS
WARNINGS
• Installation must be carried out only by qualied technicians in compliance with the electrical and safety standards in
force.
• All connections must be made with the power turned off.
• Use suitable cables.
• Do not cut through the aerial
• A suitably sized disconnection device must be set up on the electric power line that supplies
the product
• Disposal of waste materials must fully respect local standards.
• Do not exceed the load limits shown and use protected power supply units of the correct size for the load.
NOTE:
• Connect maximum 120 W per output.
• Operation of the inputs is manual
• The control unit can manage either the wind sensor (wind gauge) or the sun sensor. The two sensors cannot be
connected in parallel
(1-2)
24 Vdc power
supply
(3-4)
Motor 1,
24 Vdc max 120W
(5-6)
Motor 2,
24 Vdc max 120W
Snow contact
(max 30 VDC 2A) output
(8)
(7)
(13)
(12)
(15)
(14)
(20)
(19)
(18)
(17)
(16)
(9)
(10)
(11)
Sensors 12 VDC power supply
Rain sensor input (signal)
Rain sensor input (GND)
Wind gauge / sun sensor input (GND)
Wind gauge / sun sensor input (signal)
Temperature input (GND)
Temperature input (signal)
Open button input
GND button input
Close button input
Aerial sleeve input
Aerial input
4

3 - SETTING UP CONTROL UNIT
The following functions are the default settings for the control unit:
- Manual management of a motor Ouvrir / Arrêter / Fermer
- Wired inputs enabled manually (operation cannot be set)
- No transmitter programmed
- No sensor enabled
Some functions can be set via the keys, LEDs and trimmers.
USE OF PROGRAMMING INTERFACE:
By using the SEL and SET keys you can move around inside the menus and change the various functions.
Each time you press the SEL key you move between LEDs. Each LED indicates a function (see following table for
specic functions).
To select the parameter press the SET key and then select the value that appears on the display with the SEL key (the
display’s LED ashes).
Conrm the selected value by pressing the SET key again (the display’s LED stays on).
After 20 seconds the control unit goes back into stand-by.
LED DESCRIPTION DEFAULT PARAGRAPH
Motor type Selecting motors and operating mode 1 motor, manual 3.1
Code Remote control management No associated remote control 3.2
T.motor Setting motor time No motor time 3.3
Wind Management of wind sensor Disabled 3.4
Rain Management of rain sensor Disabled 3.5
Temperature Management of temperature sensor Disabled 3.6
Snow Management of snow sensor Disabled 3.7
Sun Management of sun sensor Disabled 3.8
After making the connections automation is already in operation with manual commands via wire.
Display
Display led
SEL key
VR1 trimmer to adjust obstacle sensitivity
VR2 trimmer to adjust duration of snow
contact closure
SET key
5

4 - SETTING OPERATING MODE
Default: 1 motor, manual
This procedure is used to set the number of motors connected and the type of control.
There can be 1 or 2 motors (synchronised operation).
Operation via radio can be:
MANUAL the motor moves in the direction selected until the transmitter key is held down
NOTE: sensors not enabled
AUTOMATIC each time the key is pressed the motor moves 30% of the total travel in the selected direction
VENETIAN press and release the key and the motor moves slightly in the selected direction, press and hold (>2sec) and
it moves fully in the selected direction
OPEN/STOP/CLOSE each time the key is pressed the motor moves fully in the selected direction
Note: if automatic, Venetian or OPEN/STOP/CLOSE operation is set it will be necessary to notify the control unit of the
working time of the motor(s) with the procedure in paragraph 6 every time that the parameter is changed
PROCEDURE
STEP 1
Keep pressing and releasing the SEL key until the
«Mot. Type» LED comes on.
The display shows the current setting.
STEP 2
Press and release the SET button to conrm. The LED on
the display ashes.
STEP 4
Press and release the SET button to conrm.
Wait 20 seconds or press the SEL button until
a horizontal line appears on the display.
Note: if automatic or Venetian operation is set it will be necessary to notify the control unit of the
working time of the motor(s) with the procedure in paragraph 6 every time that the parameter is
changed
STEP 3
By pressing and releasing the SEL key, select the value
corresponding to the setting you want, according to the
following table.
DISPLAY NO. DESCRIPTION
1 1 motor manual operation
2 1 motor automatic operation
3 1 motor Venetian operation
4 1 motor Open/Stop/Close operation
5 2 motors manual operation
6 2 motors automatic operation
7 2 motors Venetian operation
8 2 motors Open/Stop/Close operation
E Exit
6
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

5 - REMOTE CONTROL MANAGEMENT
Default: no transmitter associated / remote programming enabled
With this procedure it is possible to:
- Associate a compatible transmitter
- Delete the programmed transmitters
PROCEDURE
STEP 1
Keep pressing and releasing the SEL key until the
«Code» LED comes on.
STEP 2
Press and release the SET button to conrm.
The «Code» LED ashes.
STEP 3
By pressing and releasing the SEL key, select the value
corresponding to the setting you want, according to the
following table.
DISPLAY NO. DESCRIPTION
1 Save remote control
8 Not used
9 Deleting all remote controls
E Exit
STEP 4a
Press and release the SET key and
the LED on the display ashes, then
send an “UP” command with the
transmitter to be saved.
The display will show:
S = remote control saved
P = remote control already saved
r = remote control not recognised
F = remote control memory full
Wait 20 seconds or press the SEL
button until an E (exit) appears on
the display and conrm with the
SET button.
STEP 4b
Not used
STEP 4c
Press and hold the SET key (about
5 seconds) to conrm the deletion.
The control unit will beep.
Wait 20 seconds or press the SEL
button until an E (exit) appears on
the display and conrm with the
SET button.
1 (save remote control) 8 9 (deleting)
7
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

6 - SETTING WORKING TIME OF MOTORS
Default: no time set
NOTE: Before carrying out this procedure programme a remote control (see paragraph 5)
Also check that the motor stops when it gets to the limit and the letter “L” appears on the display (the limit is detected if
there is a mechanical stop or where there is a built-in limit switch).
If that does not occur, adjust the movement threshold with the VR1 trimmer “Sens.” (the trimmer adjusted full scale to “-”
disables the movement threshold).
To obtain non-manual operation via radio set the operation to automatic, Venetian or Open-Stop-Close (see paragraph
3.1).
PROCEDURE
STEP 1
Keep pressing and releasing the SEL key until the
«T.MOT.» LED comes on.
STEP 2
Press and release the SET button to conrm. The LED on
the display ashes.
STEP 3
By pressing and releasing the SEL key you can select value
"0" on the display
STEP 4
Press and release the SET button to start automatic programming.
The control unit will make a closing movement followed by opening
and closing cycles at the end of which the maneuver times will be
programmed.
ATTENTION: if the rst movement is opening instead of closing, press
the SET button to interrupt the programming of the run and invert the
phases of the motor. Then repeat the procedure.
8
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

7 - MANAGEMENT OF SENSORS
7.1 - SETTING WIND SENSOR
Default: not enabled
NOTE:
-The input into terminals 12-13 is designed for either the wind sensor or the sun sensor. Therefore activate only the
sensor you want once it is connected.
- The sensor works only if the operating mode is set at automatic or Venetian, see paragraph 4.
If the wind sensor is activated a speed threshold must be set. Above this, the sensor will put the control unit into alarm
mode.
ALARM: the control unit detects a wind speed higher than the one set, for 10 seconds. Then the control unit turns the
pergola slats to 33% of complete opening and disables the reception of remote commands and of any commands from
apps until the alarm is over.
ALARM NOT PRESENT/END OF ALARM: the control unit detects a wind speed lower than the one set, for 60 seconds.
ALARM TEST: the control unit makes a brief opening movement followed by a brief closing movement. When the test is
completed the control unit will beep 4 times in conrmation.
PROCEDURE:
STEP 1
Keep pressing and releasing the SEL key until the
«Wind (Vento)» LED comes on.
The display shows the current setting.
STEP 2
Press and release the SET button to conrm.
The LED on the display ashes.
STEP 3
By pressing and releasing the SEL key, select the value corresponding
to the setting you want, according to the following table.
DISPLAY NO. DESCRIPTION
d Wind sensor disabled
0 Wind sensor test
1 Wind sensor intervention 5km/h
2 Wind sensor intervention 10km/h
3 Wind sensor intervention 15km/h
4 Wind sensor intervention 20km/h
5 Wind sensor intervention 25km/h
6 Wind sensor intervention 30km/h
7 Wind sensor intervention 35km/h
8 Wind sensor intervention 40km/h
9 Wind sensor intervention 45km/h
E Exit
STEP 4a
Press and release the
SET key and the LED
on the display will stop
ashing.
STEP 4b
Press and release the SET key and the LED on the display
will stop ashing.
To carry out the test turn the wind sensor (wind gauge)
blades by hand: the control unit will make a brief opening
movement followed by a brief closing movement. When the
test is completed the control unit will beep 4 times.
NOTE: when the test is completed remember to activate/
deactivate the sensor to exit test mode.
d (disabled) 0 (test) 1-9 (enabled)
STEP 4c
Press and release the
SET key and the LED
on the display will stop
ashing.
When the wind sensor
puts the control unit into
alarm mode, the letter “A”
appears on the display.
9
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

7.2 - SETTING RAIN SENSOR
Default: not enabled
NOTE
- The sensor works only if the operating mode is set at automatic, Venetian or Open/Stop/Close, see paragraph 4.
When the sensor detects water, it puts the control unit into alarm mode.
ALARM: the sensor detects water: then the control unit turns the pergola slats to close completely and disables the
reception of remote commands until the alarm is over.
ALARM NOT PRESENT/END OF ALARM: the sensitive part of the rain sensor is dry.
ALARM TEST: the control unit makes a brief opening movement followed by a brief closing movement. When the test is
completed the control unit will beep 4 times in conrmation.
PROCEDURE:
STEP 1
Keep pressing and releasing the SEL key until the
«Rain (Pioggia)» LED comes on.
The display shows the current setting.
STEP 2
Press and release the SET button to conrm.
The LED on the display ashes.
STEP 3
By pressing and releasing the SEL key, select the value corresponding
to the setting you want, according to the following table.
DISPLAY NO. DESCRIPTION
d Rain sensor disabled
0 Rain sensor test
y Rain sensor enabled
E Exit
STEP 4a
Press and release the
SET key and the LED
on the display will stop
ashing.
STEP 4b
Press and release the SET key and the LED on the display
will stop ashing.
To carry out the test wet the sensitive part of the rain
sensor: the control unit will make a brief opening movement
followed by a brief closing movement. When the test is
completed the control unit will beep 4 times.
NOTE: when the test is completed remember to activate/
deactivate the sensor to exit test mode.
d (disabled) 0 (test) y (enabled)
STEP 4c
Press and release the
SET key and the LED
on the display will stop
ashing.
When the sensor puts
the control unit into alarm
mode, the letter “A”
appears on the display.
10
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

7.3 - SETTING TEMPERATURE SENSOR
Default: not enabled
NOTE
- The sensor works only if the operating mode is set at automatic, Venetian or Open/Stop/Close, see paragraph 4
When the sensor detects a temperature below 2°C, it puts the control unit into alarm mode to stop ice forming.
ALARM: the sensor detects a temperature below 2°C and the pergola is closed: then the control unit turns the pergola
slats to 4% of full opening and activates the snow contact (terminals 7 and 8) for a period from 30 minutes to 4 hours, that
can be set with the VR2 trimmer “Snow Delay”
ALARM NOT PRESENT/END OF ALARM: the temperature detected is above 3°C or a command is received
ALARM TEST: the control unit makes a brief opening movement followed by a brief closing movement. When the test is
completed the control unit will beep 4 times in conrmation.
PROCEDURE:
STEP 1
Keep pressing and releasing the SEL key until the
«Temp» LED comes on.
The display shows the current setting.
STEP 2
Press and release the SET button to conrm.
The LED on the display ashes.
STEP 3
By pressing and releasing the SEL key, select the value corresponding
to the setting you want, according to the following table.
DISPLAY NO. DESCRIPTION
d Temperature sensor disabled
0 Temperature sensor test
y Temperature sensor enabled
E Exit
STEP 4a
Press and release the
SET key and the LED
on the display will stop
ashing.
STEP 4b
Press and release the SET key and the LED on the display
will stop ashing.
To carry out the test grasp the sensor between your ngers
so as to change the temperature detected by a few °C: the
control unit will make a brief opening movement followed
by a brief closing movement. When the test is completed
the control unit will beep 4 times.
NOTE: when the test is completed remember to activate/
deactivate the sensor to exit test mode.
d (disabled) 0 (test) y (enabled)
STEP 4c
Press and release the
SET key and the LED
on the display will stop
ashing.
When the sensor puts
the control unit into alarm
mode, the letter “A”
appears on the display.
11
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

7.4 - SETTING SNOW ALARM
Default: not enabled
NOTE
- The sensor works only if the operating mode is set at automatic, Venetian or Open/Stop/Close,, see paragraph 4
The control unit does not have an actual snow sensor, but the alarm is generated by the combined rain sensor and
temperature sensor alarms.
ALARM: the temperature measured is lower than 2°C and the rain sensor detects water: then the control unit turns the
pergola slats to 66% of full opening and the commands are enabled only manually. Then the snow contact (terminals 7
and 8) is activated for a period from 30 minutes to 4 hours, that can be set with the VR2 trimmer “Snow Delay”
ALARM NOT PRESENT/END OF ALARM: the temperature detected is above 3°C or no rain is detected.
ALARM TEST: the control unit makes a brief opening movement followed by a brief closing movement. When the test is
completed the control unit will beep 4 times in conrmation.
PROCEDURE:
STEP 1
Keep pressing and releasing the SEL key until the
«Snow (Neve)» LED comes on.
The display shows the current setting.
STEP 2
Press and release the SET button to conrm.
The LED on the display ashes.
STEP 3
By pressing and releasing the SEL key, select the value corresponding
to the setting you want, according to the following table.
DISPLAY NO. DESCRIPTION
d Snow sensor disabled
0 Snow sensor test
y Snow sensor enabled
E Exit
STEP 4a
Press and release the
SET key and the LED
on the display will stop
ashing.
STEP 4b
Press and release the SET key and the LED on the display
will stop ashing.
To carry out the test wet the sensitive part of the rain
sensor and grasp the temperature sensor in your hands:
the control unit will make a brief opening movement
followed by a brief closing movement. When the test is
completed the control unit will beep 4 times.
NOTE: when the test is completed remember to activate/
deactivate the sensor to exit test mode.
d (disabled) 0 (test) y (enabled)
STEP 4c
Press and release the
SET key and the LED
on the display will stop
ashing.
When the sensor puts
the control unit into alarm
mode, the letter “A”
appears on the display.
12
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

7.5 - SETTING SUN SENSOR
Default: not enabled
NOTE: the input into terminals 6-7 is designed for either the wind sensor or the sun sensor. Therefore activate only the
sensor you want once it is connected.
The sensor works only:
- if the operating mode is set at automatic or Venetian, see paragraph 4
- there are no other active sensors
When the sensor detects sun for more than 10 minutes, it puts the control unit into alarm mode to create a shaded zone.
ALARM: the sensor receives direct light for a period of more than 10 minutes: then the control unit turns the slats to close
completely.
ALARM NOT PRESENT/END OF ALARM: the sensor is in the shade or a command is received
ALARM TEST: the control unit makes a brief opening movement followed by a brief closing movement. When the test is
completed the control unit will beep 4 times in conrmation.
PROCEDURE:
STEP 1
Keep pressing and releasing the SEL key until the
«Sun (Sole)» LED comes on.
The display shows the current setting.
STEP 2
Press and release the SET button to conrm.
The LED on the display ashes.
STEP 3
By pressing and releasing the SEL key, select the value corresponding
to the setting you want, according to the following table.
DISPLAY NO. DESCRIPTION
d Sun sensor disabled
0 Sun sensor test
y Sun sensor enabled
E Exit
STEP 4a
Press and release the
SET key and the LED
on the display will stop
ashing.
STEP 4b
Press and release the SET key and the LED on the display
will stop ashing.
To carry out the test illuminate the sensitive part of the
sensor or expose it to the sun: the control unit will make
a brief opening movement followed by a brief closing
movement. When the test is completed the control unit will
beep 4 times.
NOTE: when the test is completed remember to activate/
deactivate the sensor to exit test mode.
d (disabled) 0 (test) y (enabled)
STEP 4c
Press and release the
SET key and the LED
on the display will stop
ashing.
When the sensor puts
the control unit into alarm
mode, the letter “A”
appears on the display.
13
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

8 - RESETTING CONTROL UNIT
This procedure is used to set the control unit with the factory parameters.
PROCEDURE:
STEP 1
Press SET and SEL at the same time until all the red
LEDs come on.
When the reset is completed the control unit will beep
3 times in conrmation.
14
SOLE
NEVE
TEMP.
PIOGGIA
VENTO
T.MOT.
CODE
MOT.TYPE
SEL
Sens.
Rit. Neve
SET

15

V2.0
Nexta Tech
company brand of Team srl
via G.Oberdan 90, 33074
Fontanafredda (PN) - Italy
Ph. [phone]
Email: [email protected]
Web: www.nexta-tech.com
