1- English
EN
1PRODUCT DESCRIPTION
OXI is a radio receiver designed for being installed on a control unit for automating gates, garage doors and
road barriers.
– All uses other than the intended use described and use in environmental conditions other than
those described in this manual should be considered improper and forbidden!
• Other product characteristics
– The receiver is compatible with the unidirectional radio codes “O-Code”, “O-Code/A”, “FloR”, “FloR/A”,
“Smilo” and “Flo”. In particular, the “O-Code” and “O-Code/A” encoding systems allow for exploiting all the
advanced and exclusive functions of the “NiceOpera” system.
– The control unit’s receiver has 1024 memory locations to memorise transmitters: one location can alterna-
tively memorise a single transmitter (if its keys are memorised as a “single set”, with the Mode 1 procedures
– read Paragraph 3.1), or a single key (if memorised with the Mode 2 procedures – read Paragraph 3.2).
–Eachreceiverhasitsownidenticationnumber,knownasthe“Certicate”.Thisallowsforaccessingseveral
operations, such as, for example: the memorisation of new transmitters without having to access the receiver,
and the use of the O-View programmer through its “BusT4” connection to the control unit.
– This receiver can be used solely with control units equipped with “SM”-type plug connector (verify the most
suitable control units on the Nice product catalogue or on the www.niceforyou.com website).
ENGLISH
Instructions translated from Italian

EN
English - 2
– This receiver automatically recognises the characteristics of the control unit on which it is installed and self-
sets in the following way:
- If the control unit manages the “BusT4”, the receiver makes available up to 15 different commands.
- If the control unit DOES NOT manage the “BusT4”, the receiver makes available up to 4 different commands.
Important! – In both cases, the number and diversity of the available commands depend on the type and
model of the control unit adopted. The “Table of commands” of each control unit is shown in the respective
instruction manual.
2INSTALLATION AND CONNECTION
The receiver must be connected to the control unit by inserting it through the relevant slot:
01. Before inserting (or removing) the receiver, discon-
nect the power supply to the control unit.
OFF
02. Connect the antenna supplied to terminal 1 of the re-
ceiver, as shown in Fig. A. Alternatively, if the radio
signal reception must be improved through the instal-
lation of an external antenna with a coaxial cable with
50Ωimpedance(typeRG58),thecoaxialcablemust
be connected directly to terminals 1 and 2 of the re-
ceiver (Fig. B), ignoring the “antenna” terminal (if pre-
sent) on the control panel.
1
2
1
2
1
2
Fig. A Fig. B

3- English
EN
03. Insert the receiver through the relevant opening on
the control unit.
RL1L2L3
Close
Open
Stop/Set
Flash
Photo Test
Stop
GND
SbS
24 V
Aerial
04. Restore the power supply to the control unit.
ON
3MEMORISING / DELETING TRANSMITTERS IN THE RECEIVER
The rstone-waytransmitter to be memorised in the receiver alsodenestheencoding system (“O-Code” or
“O-Code/A” or “FloR” or “FloR/A” or “Smilo” or “Flo”) that each successive one-way transmitter to be memo-
rised must have.
Eachsinglecodingallowsforexploitingonlythefunctionslinkedtothatspecicencodingsystem.
To verify to which encoding system the transmitters already memorised in the receiver belong, proceed as fol-
lows (Warning! – The receiver must already be connected to the control unit):

EN
English - 4
Verification of the TYPE OF ENCODING system adopted by the transmitters already memorised
01. Disconnect the power supply to the control unit then restore the
powersupplyandcountthenumberofashesemittedbyLEDB
on the receiver:
OFF
ON
•1greenash = transmitters with Flo encoding system x 1
•2greenashes = transmitters with O-Code, O-Code/A or FloR,
FloR/A encoding system x 2
•3greenashes = transmitters with Smilo encoding system x 3
•5greenashes = no transmitter memorised x 5
To change the coding assigned to the rstone-waytransmittermemorised, it is necessary to delete from the
memory all the transmitters present, by strictly adopting Procedure 4 (Paragraph 3.5) and choosing the option,
“ALLTHERECEIVERMEMORY”.
WARNINGS for carrying out the programming procedures
• During the execution of the programming procedures, refer to Fig. 1 to identify key
Aand LEDB on the receiver. • To understand the meaning of the icons featured in the
procedure, refer to the table, “Key to the symbols used in the manual”. • The proce-
dures have a limit time; therefore, before implementing them, it is important to read and
understand all the steps to be completed.
1
2
AB
1

5- English
EN
KEY TO THE SYMBOLS USED IN THE MANUAL
Symbol Description
(onthereceiver)LED“B”STEADYLIT
(onthereceiver)LED“B”LONGFLASH
(onthereceiver)LED“B”QUICKFLASH
(onthereceiver)LED“B”OFF
OFF
ON
Disconnect power supply / Restore power supply
5 s
Wait ...
>5 sec <Perform the operation within 5 seconds ...
1
2
Hold down key “A” of the receiver

EN
English - 6
1
2
Press and release key “A” of the receiver
1
2
Release key “A” of the receiver
Press and release the desired transmitter key
Hold down the desired transmitter key
Release the desired transmitter key
Read the control unit’s instruction manual
... Observe when LED“B”emitssignals

7- English
EN
The system can be programmed in Mode 1 or in Mode 2: see Paragraphs 3.1 and 3.2.
3.1 - Memorisation in “Mode 1”
While Procedure 1 is being carried out, the receiver memorises all the keys present on the transmitter, auto-
matically assigning output 1 of the receiver to the 1st key, output 2 to the 2nd key, and so forth. Once the pro-
cedure terminates, the memorisation will occupy a single memory location and the command associated with
eachkeywilldependonthe“Listofcommands”presentontheautomation’scontrolunit.
PROCEDURE 1 - Mode 1 memorisation
01. On the receiver:holddownkeyAandwaitforthegreenLEDB
to light up. Subsequently, release key A.
1
2
1
2
02. On the transmitter being memorised:
• (within 10 seconds) on the transmitter: hold down any key and
releaseitonceLEDB(onthereceiver)emitsthe1st of 3 green
flashes (=memorisation completed correctly). (*1)
(*1) Note - If there are other transmitters to be memorised, repeat step 02 within the next 10 seconds
after the first 10. The procedure will terminate automatically once this time elapses.
3.2 - Memorisation in “Mode 2”
While Procedure 2 is being carried out, the receiver memorises a single key among those present on the trans-
mitter, associating it with the receiver output chosen by the installer. To memorise further keys, repeat the pro-
cedure from the beginning for each key to be memorised. Once the procedure terminates, the memorisation
will occupy a single memory location and the command associated with the memorised key will be that chosen
bytheinstallerfromthe“Listofcommands”oftheautomation’scontrolunit.Note - A key can be associated

EN
English - 8
with only one output, while the same output can be associated with multiple keys.
PROCEDURE 2 - Mode 2 memorisation (and extended Mode 2)
01. In the control unit manual: choose the command to be memo-
rised and remember its “identification number”.
02. On the receiver: press and release key A for a number of times
matching the number that identifies the command chosen at
step 01:LEDBwillflashthesamenumberoftimes.
1
2
x No. ....
=...
03. On the transmitter with the key to be memorised:
• (within 10 seconds) on the transmitter: hold down the key to be
memorisedandreleaseitonceLEDB(onthereceiver)emitsthe
1st of 3 green flashes (=memorisation completed correctly). (*2)
(*2) Note - If there are other keys to be memorised (belonging to other transmitters) with the same com-
mand, repeat step 03 within the next 10 seconds for each further key to be memorised (the procedure
terminates once this time elapses).
3.3 - Memorising a new transmitter “near the receiver”
This procedure allows for memorising a new transmitter by means of a second functioning transmitter, already
memorised in the same control unit. This enables the new transmitter to receive the same settings as the
transmitter already memorised. The procedure does not entail any direct action on key A of the receiver, only
the presence of the transmitter within the receiver’s reception range.
• The memorisation “near the receiver” can be prevented by blocking the receiver’s function through Procedure
6 (Paragraph 3.7). Alternatively, the receiver can also be blocked with the O-Box programmer.

9- English
EN
PROCEDURE 3 - Memorising a new transmitter “near the receiver”
01. On the NEW transmitter: hold down the key to be memorised;
wait at least 7 seconds then release it. x 7 sec
1
3
2
4
1
2
1
NEW
02. On the transmitter ALREADY MEMORISED: press and re-
lease 3 times the memorised key to be copied. 1
3
2
4
1
2
1
OLD
03. On the NEW transmitter: press and release once the same key
pressed at step 01. 1
3
2
4
1
2
1
NEW
If there are other transmitters to be memorised, repeat the procedure from the beginning for each new
transmitter.
3.4 - Memorising a new transmitter using the “enabling code” of an old transmitter already memo-
rised in the receiver - only for transmitters with “O-Code” and “O-Code/A” encoding system
The memory of transmitters with “O-Code” and “O-Code/A” encoding contains an “enabling code” (secret)
which can be used to enable a new transmitter to be memorised in the receiver. To perform this enabling
procedure, read the transmitter’s instruction manual and get an old transmitter already memorised in the same
receiver in which the new transmitter is to be memorised. Warning! - The enabling code can only be transferred
between two transmitters that have the same radio coding.
Subsequently,whenthenewenabledtransmitterwillbeused,itwillsendtothereceiver(intherst20transmis-
sions)thecommand,itsownidenticationcodeandthe“enablingcode”received.Atthispoint,thereceiver
willrecognisetheenablingcodeoftheoldtransmitterandautomaticallymemorisetheidenticationcodeof
the new transmitter.
• The undesired memorisation of transmitters through the “enabling code” can be prevented by blocking the

EN
English - 10
receiver’s function through Procedure 6 (Paragraph 3.7). Alternatively, the receiver can be blocked also with the
O-Box programmer, by intervening on the receiver or on the transmitters already memorised.
3.5 - Deleting the receiver’s memory (fully or partially)
PROCEDURE 4 - FULL or PARTIAL deletion of the receiver’s memory
01. On the receiver: hold down key A and observe the status of the
greenLEDB:after6 seconds it will light up then switch off. After
a few seconds it will start flashing; then immediately choose the
type of desired deletion:
1
2
> to delete ALL the transmitters: release key A exactly at the
3rd flash
1
2
> to delete ALL THE RECEIVER’S MEMORY: release key A
exactly at the 5th flash
1
2
This function can be performed also using the O-Box / O-View programmers.
3.6 - Deleting a SINGLE transmitter or a SINGLE key from the receiver memory
PROCEDURE 5 - Deleting a SINGLE transmitter or a SINGLE key from the receiver memory
01. On the receiver: hold down key A, observe the green
LEDBlightupandmovetostep02whenitswitchesoff.
1
2

11 - English
EN
02. On the transmitter to be deleted:
• (on the transmitter) hold down the key (*4) to be de-
letedandreleaseitafterLEDB(onthereceiver)has
emitted the 1st of 5 quick green flashes (= deletion
completed correctly).
(*4) Note - If the transmitter is memorised in “Mode 1”, any key can be pressed. If the transmitter is memo-
rised in “Mode 2”, the entire procedure must be repeated for each memorised key that must be deleted.
This operation can also be performed through the O-Box / O-View programmers.
3.7 - Locking (or release) of memorisations carried out with the “near the control unit” procedure
and/or through the “enabling code”
This function prevents the memorisation of new transmitters in the receiver, when using the “near the receiver”
procedure (Paragraph 3.3) or the “enabling code” procedure (Paragraph 3.4). The default setting is ON for both
procedures. To perform the following procedure it is necessary to have a transmitter already memorised in the
receiver.
PROCEDURE 6 - Locking (or release) of memorisations carried out with the “near the control
unit” procedure and/or through the “enabling code”
01. Disconnect the power supply and wait 5 seconds.
OFF
5 s

EN
English - 12
02. Hold down key A of the receiver and simultaneously restore the
powersupply:LEDBrst emits the signals relative to the memo-
rised transmitters (Chapter 3) then emits a few short orange
ashes:release key A exactly at the end of the 2ndorangeash.
+
ON
1
2
1
2
...
03. Within 5 seconds: repeatedly press and release key A of the
receivertochooseoneofthefollowingfunctions,identiableby
thestatusofLEDB:
- No lock active=LEDOFF
- Lockingofthememorisation“nearthecontrolunit”=REDLED
- Lockingofthememorisationwiththe“enablingcode”=GREENLED
- Lockingofbothmemorisations (“near the control unit” and with
“enablingcode”)=ORANGELED
1
2
...
>5 sec <
04. Within 5 seconds: on a transmitter already memorised in the
receiver, press and release a key (memorised) to save the function
that has just been chosen >5 sec <
This function can be performed also using the O-Box / O-View programmers.

13 - English
EN
4OTHER FUNCTIONS
4.1 - Locking (or releasing) the management of the “Priority” function in the receiver
The“identicationcode”ofatransmitterwith“O-Code”and“O-Code/A”encodingsystemisaccompanied
by a number (from 0to 3)thatallowsfordening(inthereceiver)itspriority level with respect to any other
transmitters with the same code. The “priority” is aimed at replacing and disabling the use of a lost or stolen
transmitter,withouthavingtogotothecustomer’ssystem.Useofthepriorityfunctionrequiresknowledgeof
the lost transmitter code and allows for keeping the same code and functions of the previous transmitter. The
lost transmitter can therefore be deactivated by simply updating the priority level of the new transmitter to the
next highest value.Whenthetransmitterisusedforthersttime,thereceiverwillmemorisethenew priority
level received and ignore any command sent by the lost or stolen transmitter, should it be used. The priority
can be changed through the O-Box programmer.
By default the receiver has the “Priority” function enabled, so the installer can exploit its potential applications.
Nonetheless, the O-Box programmer can be used to lock (or release) the receiver in managing this function.
4.2 - Enabling (or disabling) reception of the transmitter codes, modified with respect to the default code
The codes of transmitters with“FloR”,“FloR/A”,“O-Code”and“O-Code/A”encodingsystemcanbemodied
as desired using the O-Box or O-View programmer. By enabling or disabling this function, the receiver can
acceptorrefusethecommandofatransmitterwithmodiedidenticationcode(thedefaultsettingisON).
4.3 - Disabling (or enabling) the “variable part” (rolling code) of the code received
The receiver is programmed by default to only receive “rolling code”-type codes. The O-Box programmer,
however, can be used to programme the receiver so that it ignores the variable part (rolling code) of the code
received and considers it asa“xed”-typecode.

EN
English - 14
4.4 - “Transmitter keys release” function” (only with O-Code and O-Code/A encoding)
During normal use of the transmitter, when a pressed key is released the automation’s manoeuvre continues
for a short pre-set time. If the manoeuvre must be interrupted exactly when the key is released (for example,
to perform a minor adjustment), this function must be enabled in the receiver through the O-Box programmer.
This function is disabled by default.
4.5 - Enabling (or disabling) the receivers to send/receive radio commands through the BUST4 net-
work that connects two or more automations
If one of the automations in systems containing multiple automations connected through the “BusT4” must be
commanded from a distance exceeding the radio range of the transmitter-receiver system, this function can
be enabled in the receivers involved to increase their reception range. In this way, the receiver that received the
commandviaradiocanretransmititthroughtheBusT4cabletothedestinationreceiver(inwhichtheidentica-
tion code of the transmitter that sent the command is memorised), so that the latter can execute the command.
This function is disabled by default. To enable (or disable) the repetition and/or reception of the code via BusT4,
programme the relevant receivers appropriately through the O-View and O-Box programmers.
4.6 - Blocking access (through password) to the receiver programming
This function activates in the receiver (with the O-Box / O-View programmer) a password consisting of maximum
10 characters, chosen by the installer. The function allows for protecting all the settings already effected in the
receiver; moreover, it also prevents any subsequent settings through key A of the receiver (Fig. 1) or through
the O-Box and O-View programmers, if the password is not known.

15 - English
EN
5TECHNICAL SPECIFICATIONS
OXI
Product type Receiver
Decoding “O-Code” / “O-Code/A” / “FloR” / “FloR/A” / “Flo” / “Smilo”
Input impedance 50Ω
Reception frequency 433.92 MHz
Outputs 4 (on “SM” plug-type connector)
Sensitivity –108dBm
Absorption 50 mA (maximum)
Dimensions (mm) W49.5;H41.9;D18
Weight (g) 22
Operating temperature –20 °C ... +55 °C
•Notesontheproducttechnicalspecications
– The reception capacity of the receivers and the transmitter range are strongly affected by other devices (e.g.
alarms, headphones, etc.) operating on the same frequency in your area. Nice cannot provide any guarantee
with regard to the actual range of its devices under such conditions.
–Alltechnicalspecicationsstatedhereinrefertoanambienttemperatureof20°C(±5°C).
–Nicereservestherighttoapplymodicationstotheproductatanytimewhendeemednecessary,without
altering the intended use and functions of the product itself.

EN
English - 16
6PRODUCT DISPOSAL
This product constitutes an integral part of the automation and, therefore, must be disposed of together with it. Similarly
to the installation phase, once the product reaches the end of its useful life, the disassembly and scrapping operations must be per-
formed by qualified personnel. This product is made of various types of materials, some of which can be recycled while others must be
scrapped. Seek information on the recycling and disposal systems envisaged by local regulations in your area for this product category.
WARNING! - Some parts of the product may contain polluting or hazardous substances which, if released into
the environment, constitute serious environmental and health risks.
As indicated by the adjacent symbol, the product may not be disposed of together with domestic waste. Sort the
materials for disposal, according to the methods envisaged by current legislation in your area, or return the product
to the retailer when purchasing an equivalent product.
WARNING! - Local regulations may envisage the application of heavy fines in the event of improper
disposal of this product.
Compliance with the FCC rules (Part 15) and with RSS-210 rules
This device complies with Industry Canada’s licence-exempt RSS-210s, and with Part 15 of the FCC rules of
theUnitedStatesofAmerica.Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcause
interference; (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Any changes or modifications made to this device, without the express permission of the manufacturer, may
void the user’s authority to operate this device.
SIMPLIFIED EU DECLARATION OF CONFORMITY
HerebyNiceS.p.A.declaresthattheradioequipmenttypeOXIisincompliancewithDirective2014/53/EU.
ThefulltextoftheEUdeclarationofconformityisavailableatthefollowinginternetaddress:
https://www.niceforyou.com/en/support

17 - English
EN
Signals emitted by LED B of the receiver
Longashes>GREEN
On start-up:
1 Z= Current encoding system: “Flo”
2 Z= Current encoding system: “O-Code” / “O-Code/A” / “FloR” / “FloR/A”
3 Z= Current encoding system: “Smilo”
5 Z= No remote control memorised
During operation:
1 Z= Indicates that the code received is not stored in the memory
3 Z= Saving code in memory
5 Z= Memory deleted
6 Z= During programming, indicates that the code is not authorised for memorisation
8Z= During programming, indicates that the memory is full
Shortashes>GREEN
1 Z= “Certicate”notvalidformemorisation
2 Z= During programming, indicates that the code cannot be memorised because it transmits the “cer-
ticate”
4 Z= Output in “Mode 2” not managed on control unit

EN
English - 18
5 Z= During the deletion procedure, indicates that the code has been deleted
5 Z= “Certicate”withlowerprioritythantheadmissiblelevel
6 Z= Code synchronisation failure
Longashes>RED
1 Z= Non-original code block
2 Z= Code with lower priority than the authorised level
Shortashes>RED
1 Z= “In vicinity” programming block
1 Z= “Certicate”memorisationblock
2 Z= Memory block (PIN entry)
Shortashes>ORANGE
2 Z= Indicates activation of block programming (on start-up)

1- Italiano
IT
1DESCRIZIONE DEL PRODOTTO
OXI è un ricevitore radio destinato ad essere installato su una centrale di comando per le automazioni di cancelli,
portoni da garage e alzabarriere stradali.
– Qualsiasi altro uso diverso da quello descritto e in condizioni ambientali diverse da quelle ripor-
tate in questo manuale è da considerarsi improprio e vietato!
• Altre caratteristiche del prodotto
– Il ricevitore è compatibileconlecodicheradiomonodirezionali“O-Code”, “O-Code/A”, “FloR”, “FloR/A” ,
“Smilo”e“Flo”.Inparticolare,lecodiche“O-Code”e“O-Code/A” permettono di sfruttare tutte le funzioni
avanzate ed esclusive del Sistema “NiceOpera”.
– Il ricevitore della centrale possiede 1024 locazioni di memoria per la memorizzazione dei trasmettitori: una
locazione può memorizzare alternativamente un singolo trasmettitore (se i suoi tasti vengono memorizzati
come “un insieme unico”, con le procedure in Modo 1 - leggere il paragrafo 3.1), oppure un singolo tasto (se
questo viene memorizzato con le procedure in Modo 2 - leggere il paragrafo 3.2).
–Ogniricevitorepossiedeunproprionumerocheloidentica,chiamato“Certicato”.Questopermettedi
accedere a molte operazioni come, ad esempio: la memorizzazione di nuovi trasmettitori senza la necessità
di accedere al ricevitore, l’uso del programmatore O-View tramite il suo collegamento “BusT4” alla centrale.
–Questoricevitorepuòessereusatosoltantoconlecentralidicomandodotatediconnettoreadinnestoditipo
“SM”(vericaresulcatalogodeiprodottiNiceonelsitowww.niceforyou.comqualisonolecentraliidonee).
ITALIANO
Istruzioni originali
