Nilfisk-Advance MC 2C Series User manual

128337037 EN
P
MC 2C
Instruction manual

2 Original Instructions
Contents
1 Introduction.................................................................................................. 3
1.1 Symbols used to mark instruction.......................................................................3
2 Safety precautions and working techniques................................................3
3 Description................................................................................................... 9
3.1 Application ..........................................................................................................9
3.2 Operation elements and model survey ...............................................................9
4 Before you start using your pressure washer........................................ 10
4.1 Mounting of holders for spray lance..................................................................10
4.2 Mounting of hose hook (only models without hose reel)...................................10
4.3 Mounting of hose reel handle (only models with hose reel)..............................10
4.4 Mounting of quick coupling ...............................................................................11
4.5 Mounting of high pressure hose .......................................................................11
5 Operating your pressure washer ............................................................. 11
5.1 Connection of high pressure hose ....................................................................11
5.2 Mounting of spray lance....................................................................................12
5.3 Water connection..............................................................................................12
5.4 Telescopic handle .............................................................................................12
5.5 Start and stop of the machine (when connected to a water supply).................13
5.6 Start the machine (when connected to open containers (suction mode)).........13
5.7 Pressure regulation...........................................................................................13
5.8 Operation with detergents.................................................................................14
5.9 Regulation of pressure / water volume (only models with button for
regulation of pressure and water volume) ........................................................14
6 Fields of application and working methods............................................ 15
6.1 General .............................................................................................................15
7 After using your pressure washer ........................................................... 16
7.1 Storing the washer............................................................................................16
7.2 Winding up of electric cable and high pressure hose .......................................16
7.3 Storage of accessories .....................................................................................16
8 Maintenance............................................................................................... 17
8.1Cleaningofwaterinletlter ..............................................................................17
8.2 Cleaning of nozzle ............................................................................................17
8.3 Cleaning of machine vents ...............................................................................17
8.4 Greasing of couplings .......................................................................................17
9 Trouble-shooting ....................................................................................... 18
10 Further information ................................................................................... 19
10.1 Service and Maintenance ...............................................................................19
11 Main Technical Data .................................................................................. 19
12 EC/EU Declaration of Conformity ............................................................ 20
13 UK Declaration of Conformity .................................................................. 21

3
Original Instructions
1 Introduction
1.1 Symbols used to mark instruction
All pictograms attached to the high pressure washer and its components are shown and ex-
plained in this manual.
Safety instructions marked with this symbol must be observed to prevent personal injury or
serious damage to property.
Caution where there is a risk of damaging the machine or its individual components.
This symbol indicates tips and instructions to simplify work and to ensure a safe operation of
the high pressure washer.
2 Safety precautions and working techniques
Before starting up your machine for the rst time, this instruction manual must be read through
carefully. Save the instructions for later use.
WARNING!
• Inhalation of aerosols can be hazardous to health.
Where applicable use a device in order to avoid or re-
duce aerosols production, e.g., a shield covering the
nozzle. For protection against aerosols use a respira-
tory mask of class FFP 2 or higher.
• The high water pressure generated by the machine
and the power connection are particular sources of
danger.
• Machines shall not be used by children or untrained
personnel. Children should be supervised to ensure
that they do not play with the machine.
• Do not use the machine within range of persons un-
less they wear protective clothing.
• Before starting up your machine please check it care-
fully for any defects. If you nd any, do not start up
your machine, contact your Nilsk distributor. The in-
sulation of the electric cable should be faultless and
without any cracks. If the electric cable is damaged,
an authorized Nilsk di stributor should replace it.
• Always unplug the power plug before cleaning or
maintenance and when replacing parts or converting
the machine to another function.


4Original instructions
• Observe the national safety regulations issued, for
example, by the employers liability insurance associa-
tion, social security institutions, occupational safety
and health authorities or other organizations.
Accessories and spare parts
• To ensure the machine safety only use original spare
parts from Nilsk or approved by Nilsk.
• High pressure hoses, ttings and couplings are impor-
tant for the safety of the machine. Only use hoses, t-
tings and couplings recommended by Nilsk.
Physical, sensory or mental conditions
• This machine is not intended for use by persons
(including children) with reduced physical, senso-
ry or mental capabilities or lack of experience and
knowledge. If the machine is used by people with re-
duced physical, sensory or mental capabilities or lack
of experience and knowledge they shall have been
given supervision or instruction concerning use of the
machine in a safe way and understand the hazards
involved.
Applications
This machine has been developed for domestic use
such as:
• Car, motorbike, boat, caravan, trailer, patio/drive/ag-
stones, woodwork, brickwork, barbecue, garden furni-
ture, lawn mower.
Any other use is considered as improper use. Nilsk
accepts no liability for any damage resulting from such
use. The risk for such use is borne solely by the user.
Proper use also includes proper operation, servicing
and repairs as specied in this instruction.
Clothing and equipment
Always take action to protect yourself when operating
the machine.
• Wear shoes with non-slip soles.


5
Original Instructions
• Wear goggles, ear protection and protective clothes
during operation.
Transporting the high pressure washer
• When transporting the machine in or on a vehicle, it
must be secured, e.g. with straps, so that it cannot
slip or tip over.
• Nilsk recommends that the machine is positioned
horizontally on the backside, when transported in or
on a vehicle.
Detergents
• This machine has been designed for use with clean-
ing agents supplied or recommended by Nilsk. The
use of other cleaning agents or chemicals may ad-
versely a󰀨ect the function of the machine.
Before starting the work
Inspecting the machine
• Do not use the machine if a supply cord or important
parts of the machine are damaged, e.g., safety de-
vice, high pressure hose, and spray handle and spray
attachments.
• The trigger of the spray handle must move easily and
automatically return to its starting position when re-
leased.
• Always keep high pressure hose and spray attach-
ment in good condition (clean, moving easily) and cor-
rectly assembled.
Electrical connection
WARNING!
Minimize the risk for electrical shock:
• Voltage and frequency of the machine (see rating
plate) must match the voltage of and frequency of the
mains supply.
• Only connect the machine to electrical installa-
tion made by a certied electrician and com ply with
IEC 60364-1.



6Original instructions
• It is recommended that the electrical supply to the ma-
chine should include a residual current device that will
interrupt the supply if the leakage current to earth ex-
ceeds 30 mA for 30 ms.
• Use motor start/delayed fuses with characteristic C or
D according to IEC/EN 60898-1 / IEC 947-2 or corre-
sponding standards outside IEC.
• Inadequate extension cables can be dangerous. If an
extension cable is used, it shall be suitable for outdoor
use, and the connection has to be kept dry and o󰀨 the
ground.
• Nilsk recommends use of an extension cable drum
when cable extension is needed which keeps the
socket at least 60 mm above the ground.
• If the electric cable is damaged, it must be replaced
by an authorized Nilsk distributor or similar qualied
person in order to avoid a hazard.
• Connecting the high pressure washer to a supply
system, the max allowed impedance is = 0,4023 Ω
(Zmax). Consult with the supply authority that the
equipment is connected only to a supply of that im-
pedance or less.
Water connection
• This high pressure washer is only allowed to be con-
nected with the drinking water mains, when an appro-
priate backow preventer has been installed, Type BA
according to EN 60335-2-79.
• The backow preventer can be ordered under number
106411177.
• As soon as drinking water has own through the back-
ow preventer, it is no longer regarded as drinking wa-
ter.
• Operation by suction (e.g. a rainwater vessel) is car-
ried out without a backow preventer – see “Connec-
ting to a pressureless water supply”. The machine
can be connected to water mains with a max. inlet-
pressure of 1 MPa/10 bars and max. 60°C.

7
Original Instructions
Safety devices
Locking device on spray handle:
• The spray handle features a locking device. When the
pawl is activated, the spray handle cannot be ope-
rated.
Thermal sensor:
• A thermal sensor protects the motor against overload-
ing. The machine will restart after a few minutes when
the thermal sensor has cooled.
Pressure safety device:
• An integrated hydraulic safety valve protects the
system from excessive pressure.
During work
WARNING!
• It is not allowed to clean asbestos-containing surfaces
with high pressure.
• Risk of explosion – Do not spray ammable liquids.
• Never draw in uids containing solvents (e.g., gaso-
line, heating oil, paint thinner or acetone) These sub-
stances damage the materials used in the machine.
Their spray is highly combustible, explosive and poi-
sonous.
• Never direct the water jet at yourself, other persons,
not even to clean clothing or footwear – risk of injury.
• Never direct the water jet at pets or other animals.
• Never direct the water jet at live electrical equipment
or the machine itself – danger of short-circuiting.
• Hold the spray lance rmly with both hands. The
spray lance is a󰀨ected by a thrust of up to 27.4 N and
a sudden torque when activating the trigger of the
spray handle during operation.
• Never start up a frozen machine. Frost damages are
not covered by the guarantee!
• Always ensure rm and safe footing.
• The machine shall be operated in an upright position.
• If the machine is left or not used for 5 minutes, it must
be switched o󰀨 on the start/stop switch “O” (1).

8Original instructions
  Afternishingthework
WARNING!
• Always switch o󰀨 the machine and unplug the power
plug from the socket after work and when leaving the
machine unattended.
• Disconnect water inlet hose between machine and
water supply.
• Always empty pump, hose and accessories of water
after use of the machine and prior to storing.
Maintenance and repairs
WARNING!
• Always disconnect the electrical plug from the socket
prior to maintenance, cleaning and repair.
• Any repair should always be made in Nilsk autho-
rized workshop with original Nilsk spare parts.
• Do not attempt any maintenance not described in the
instructions.
• If the machine refuses to start, stops, pulsates, pres-
sure uctuates, motor busses, fuse blows or no wa-
ter comes out, check the trouble shooting diagram
in these instructions. In case other problems occur,
please contact your local Nilsk distributor.
Correct disposal of this product:
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or hu-
man health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of mate-
rial resources. To return your used device, please use
the return and collection systems or contact the retailer
where the product was purchased. They can take this
product for environmental safe recycling.

9Original Instructions
3 Description
This high-pressure washer has
been developed for semiprofes-
sional routine cleaning:
– Professional craftsman jobs,
cleaning of vehicles, boat,
caravan and minor cleaning
jobs within building and con-
struction
Section 6 describes the use of
the high-pressure washer for
various cleaning jobs.
Only use the high-pressure
washer for purposes described
in this manual.
The safety precautions must be
observed to prevent damage
to the machine, the surface to
be cleaned or severe personal
injuries.
3.1 Application
3.2 Operation elements and
model survey
See illustration at the end of
this manual.
1 Start/stop switch
2 Water inlet (with lter)
3 High pressure connection
(only machines without
hose reel)
4 High pressure hose
5 Electric cable
6 Button for regulation of
pressure and water volume
(not standard)
7 Ergo 2000 spray handle
with lock (7a)
8 Flexopower Plus spray
lance (standard models)
9 4-in-1 spray lance (T and
XT models)
10 Detachable detergent con-
tainer
11 Nozzle cleaning tool
12 Hose reel
13 Hose hook (only machines
without hose reel)
14 Model tag
15 Button for telescopic handle
16 Telescopic handle
17 Turnable cable hook
Specications: See model tag
(14) of machine.
We reserve the right to alter the
specications.

10 Original Instructions
4 Before you start using your pressure
washer
4.1 Mounting of holders for
spray lance
Mount the holders for spray
lance on the machine.
4.2 Mounting of hose hook
(only models without
hose reel)
Mount the hose hook (13) on
the handle (2 screws).
Note: The hose hook can be
mounted on the front as well as
on the back. Front position is to
be used if the product is used
together with a special wall
hook for wall storage.
4.3 Mounting of hose reel
handle (only models
with hose reel)
1. Click the hose reel handle
on to the trolley handle (no
screws).
