Nilfisk-Advance P 150.1-10 B Operating instructions

Repair Manual
P 150.1-10 B
P 160.1-15 B X-Tra

2
2 Index
A. Saftey Issues
B. Technical data
C. Construction
D. Service /Repair
F. Diagram
E. Operation.

3
3 A
Safety Issues.
Safety precautions
• WARNING! High pressure jets can be dangerous. Never direct the water jet
at persons pets, live electrical equipment or the machine self.
• The operator and anyone in the immediate vicinity of the site of cleaning
should take action to protect themselves from being struck by debris dis-
lodged during operation. Wear goggles during operation.
• Never try to clean clothes or footwear on yourself or other persons.
• Do not let children or people who have not read the instruction manual
operate the machine.
• Never use the machine in an environment where there could be a danger of
explosion. If any doubt arises, please contact the local authorities.
• It is not allowed to clean asbestos- containing surfaces with high pressure.
• This high pressure washer must not be used

4
4 B
Technical Data.
Product segment: Consumer P 150.1 P 160.1
Specification bar 140 150
Voltage V 230 230
Frequency Hz 50 50
Power consumption A 12,6 13
Power absorbed KW 2,9 3,3
Numbers of revolutions rpm./ min. 2800 2800
Water volume, HP l / min. 6 6,9
Pump pressure bar 100 112
Nozzle pressure bar 94 106
Opening pressure bar 140 140
Retaining time min. 5 5
Oil contents ml 100 100
Oil type Bartran HV68 Bartran HV68
Max water inlet temperature C 40 60
Max water inlet pressure bar 10 10
High pressure hose length m 6m Textile 8 or 9m textile
Suction height m 1m wet 1m wet
Electric cable m 5m 5m
Insulation class F F
Tightness IPX5 IPX5

5
5 C
Construction.
Construction of cabinet parts P 150 / P 160

6
6 C
Construction.
Construction of motor pump unit P 150 / P 160

7
7 D
Service / Repair.
Dismounting / mounting of front cabinet.
Remove 4 torx Screws (TX 20 )(fig.1) and 2 screws at the bottom (fig.5)
Fig.1 Fig.2
Dismounting / mounting of front chassis and motor cover.
.Remove 5 torx screws in the chassis (fig.3) and 8 screws at the bottom (fig.4)
Fig.3 Fig.4

8
8 D
Service / Repair.
Fig.1 Fig.2
Fig.4
Fig.3
Dismounting / Mounting of S/S valve.
Remove micro switch box carefully with 2 screw driver ( fig.1) and then
the S/S valve (fig.2.) Mount the micro switch (fig.3) and press down the
micro switch arm with a screwdriver (fig 4).

9
9 D
Service / Repair.
Fig.1
Dismounting / mounting of oil seal.
Tip up the oil seal with a screwdriver and discard (fig.1).
Clean up and lubricate before mounting.
Oil level
100 ml.

10
10
Use loctite 271— torque 20 Nm
Torque 16 Nm
Torque 10 Nm
D
Service / Repair.
Fig.2Fig.1
Dismounting / mounting of suction and pressure valves.
Remove valve seat with tool and discard them (fig.1 and 2). Mount new valves
with a slight finger pressure and special tool no.1220103 (fig 3 and 4).
Clean up and lubricate before mounting.
Fig.3 Fig.4
When mounting the
cylinder head you
have to tighten the
bolts in this order see
(fig.5)
Fig.5
1
2
3
4

11
11 D
Service / Repair.
Wobble Disc marking and assembling
150 bar ”1-1” or “1-2 “
160 bar ”2-1” or ”2-2”
Fig.1
Fig.2
Fig.3
Bearing track on fig.1 and fig 2 are different.
(inner diameter are different)
Bee sure it fits to the. wobble disc.

12
12 D
Service / Repair.
Dismounting / Mounting of Easy start valve.
Remove the easy seat with a small hook (fig.1) then remove the
o-ring underneath the seat ,with a small screwdriver .
Mounting : place the ball on the end of the spring (fig.2), be sure
the the ball are in the right position when mounting plug.
Regarding the mark on the seat,
See section ”Operation guide”
2.5 Handle release
Fig.1 Fig.2
Fig.1

13
13 D
Service / Repair.
Torque.

14
14 E
Operation guide.
In this situation the position of the parts are following:
The none return valve( A) is closed by the spring (B) as there is no pressure
on either of the sides. The easy start ball valve (C) is pressed against the up-
per seat by the easy start spring (D) The s/s spring pressed the s/s piston,
and the Activation arm (E) is taken to the front position the micro switch (F) at
the “switch on” position, the motor (G) will start. The handle (H) is released,
No water flow from the nozzle.
Water flow: None

15
15 E
Operation guide.
1. The none return valve (A) is closed by the spring (B) as the pressure on the front
side is still not high enough to open it.
2. The easy start ball valve (C) moves a little from the upper seat as the easy start
spring (D) is pressed a little.
3. The s/s spring pressed the s/s piston, and the Activation arm (E) is taken to the
front position, the micro switch (F) at the “switch on” position, the motor (G) is running.
4. the handle (H) is released, and no water flow from the nozzle.
Water flows:
1. From the water inlet to the pump.
2. From the pump through the ball valve to the water inlet.

16
16 E
Operation guide.
During building-up of pressure, the position of the parts are following:
1. The none return valve (A) open a little because of the high pressure from pump.2.
The easy start ball valve (C) moves to the lower seat as the easy start spring (D)
impressed more.
3. The s/s spring pressed the s/s piston, and the Activation arm (E) is taken to the front
position, the micro switch (F) at the “switch on” position, the motor (G) is running. 4.
The handle (H) is released, and no water flow from the nozzle
Water flows:
1.From the water inlet to the pump
2. (Decreases during the process). From the pump through the ball valve to the water
inlet
3. From the pump through the none-return valve to the high pressure hose.

17
17 E
Operation guide.
1. The none return valve (A) is fully open because of full working pressure and flow.
2. The easy start ball valve (C) is pressed against the lower seat by the pressure
from the pump.
3. The s/s spring is pressed a little , but the Activation arm (E) is still on the front po-
sition, The micro switch (F) at “switch on” position. The motor (G) is running.
4. The handle (H) is activated, and water flow from the nozzle.
Water flows:
1. From the water inlet to the pump.
2. From the pump through the none-return valve to the high pressure hose.

18
18 E
Operation guide.
1. The none return valve (A) is closed by the pressure in the hose system.
2. The s/s spring is pressed at max position, the Activation arm (E) moves
back , presses the Micro switch (F) at “switch off” position (means that the
motor (G) is stopped).
3. The pressure in pump drop over a leak in the easy start valve, The easy
start spring presses the ball valve (C) up against the upper seat, pressure in
the cylinder head close to the inlet pressure.
4. the handle (H) is released, and no water flow from the nozzle
Water flows:
None
2.5 Handle release

19
19 E
Operation guide.

20
20 E
Operation guide.
