Nilfisk-Advance MX 307 H Operating instructions

11-600203072REVA
MX 307 H
EXTRACTOR
220 - 240V
CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTION MANUAL
INFORMATION
&
OPERATING
INSTRUCTIONS
20122007

11-600203072REVA
IMPORTANT SAFETY INSTRUCTIONS
This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops,
and offices other than normal residential housekeeping purposes.
When using any electrical appliance, basic precautions should always be followed, including the following:
NOTE: Read all instructions before using this machine.
WARNING!
To reduce the risk of fire, electric shock, or injury:
•Do not leave the machine unattended when it is plugged-in. Unplug the unit from the power outlet when
not in use.
•Unplug the machine from the power outlet before cleaning or servicing.
•To avoid electric shock, do not expose to rain or snow. Store, and use, indoors.
•Wear hearing protection if desired. The measured sound level of the MX 307 H is 79dB(A).
•Do not allow to be used as a toy. Close attention is necessary when used near children.
•Use only as described in this manual. Use only the manufacturer’s recommended attachments.
•Inspect the power cord regularly for damage, such as cracking, ageing, or damaged insulation. Replace
the power cord with the same type as original if any damage is found. Do not use with damaged cord or
plug.
•Do not use the power recepticles on the machine for any use other than to operate the machine.
•If the machine is not working as it should, has been dropped, damaged, left outdoors or flooded with
water, return it to a service center.
•Do not pull the machine by the cord, do not use the cord as a handle, close a door on the cord, or pull
the cord around sharp edges or corners. Do not run the machine over the cord. Keep the cord away
from heated surfaces. To unplug, grasp the plug, not the cord.
•Do not handle the plug, the cord, or the machine with wet hands.
•Extension cords must be 12/3 and no longer than 50 feet. Replace the cord or unplug immediately if the
ground prong becomes damaged.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair,
and anything that may reduce air flow.
•Keep loose clothing, hair, fingers, and all parts of body away from openings and moving parts.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes, or any
health endangering dusts. Do not use to pick up flammable or combustible liquids such as gasoline or
use in areas where they may be present.
•Turn off all controls before unplugging.
•Use extra care when cleaning on stairs.
•Liquid ejected at the spray nozzle could be dangerous as a result of its temperature, pressure,or
chemical content.

11-600203072REVA
INSPECTION:
Carefully unpack and inspect your MX 307 H for shipping damage. Each machine is tested and
inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You
should notify the carrier immediately if you notice damage to the box or to the machine or parts.
CLEANING SOLUTIONS:
We recommend liquid cleaning chemicals. Powder chemicals may be used, but unless mixed very
thoroughly they could cause a build-up in the pump, lines, heat exchanger and/or quick disconnects.
Any problem caused by a chemical build-up is not covered by warranty. Use a neutral cleaner with a
pH between 6 and 9 to avoid premature wear of the pump, seals, and/or other components.
Damage caused by the use of strong chemicals is not covered by the warranty.
MAINTENANCE:
For optimum performance flush the machine with clear water at the end of each working day. Once
a month, minimum, run a flushing compound through the machine to break up any mineral or
chemical build-up that may have formed. The vacuum motors and the pump do not require any
scheduled maintenance; however, the vacuum motors may require replacement brushes after 1000 -
1500 hours. Clean the body with an all purpose detergent, and protect it with an automobile interior
polish. Lubricate the wheels, castors, and quick disconnects with an all purpose silicone spray.
Serial Number: __________________
Model: MX 307 H
Purchase Date:_____________
Write the name and phone number of your
distributor:
_____________________________________
_____________________________________
RECORD AND KEEP THE FOLLOWING INFORMATION
(anddon’tforgettoregisteryourwarranty)

11-600203072REVA
NILFISK LABEL
MACHINE DESCRIPTIONS
Operator Handle (1) - Operator holds this to move the machine from one location to another.
Solution Tank Lid (2) - Fill Solution Tank here with warm water and chemicals.
Switch Plate (3) - This is where the switches are located that operate the pump, vacuum and heater.
Recovery Tank Lid (4) - The Recovery Tank can be flushed out by running clean water into this opening
withtheDrainGate(7) open. ThevacuumfloatShut-OFFcanalsobeaccessedthroughthisopeningfor
maintenance.
Vacuum Inlet (5) - This is where the vacuum hose attaches to the machine.
Latch (6) -Open the latches to access the base compartment, which contains the motors and heater.
Drain Gate (7) -Open this gate to drain the recovered solution out of the machine. Be sure to keep this
gateclean.
Castor (8) -Thecastorswivelsforeasy maneuvering in tight spots.
Wheel (9) -Large,non-markingwheelsforeaseof transport.
Power Cord(10) -One, 25 foot cord. Do not use if the cord is damaged.
BECOME FAMILAR WITH YOUR NEW EXTRACTOR
1
2
3
4
5
6
7
10
9
8

11-600203072REVA
CAUTION! If water or foam comes out of the
vacuum exhaust, turn the machine off immediately
OPERATION
1Inspect the machine, hoses, and cleaning tools for cleanliness and completeness.
2Fill the Solution Tank with warm water. Using warm water may be a benefit in cleaning
effectiveness, but do not use hot water (above 54°C / 130°F+) in the tank. Add liquid cleaning
solution with a pH value of between 6 and 9. High pH detergents and/or acid rinses will
accelerate the wear of the seals and will void the warranty.
3Plug in the power cords. Turn the Heat switch on.
4Attach the spray hose to the solution quick disconnect on the front of the machine and attach
the vacuum hose to the hose barb on the recovery tank. Attach the other ends of the hoses to
the cleaningtool.
5Allow the heat exchanger two minutes to reach operating temperature.
6Turn the pump on. Turn the vacuum on. NOTE: the pump has a built in pressure switch; the
pump runs only while you are spraying.
7Begin cleaning using the correct hoses and tool.
8Use defoamer in the recovery tank any time foaming occurs.
9Monitor the water level in the solution tank. Do not let the pump run dry.
10 When the solution tank gets low, turn off the pump, fill the solution tank, empty and clean the
recovery tank.
11 When finished with the job, remove any unused solution from the solution tank, and run a few
gallons of clean water through the system to rinse out any detergent.
BALL FLOAT VACUUM SHUT-OFF
Prior to using the machine, always check that the float filter is clean and the ball can travel freely.
When the recovery tank is full, the ball float will rise and will shut off the vacuum flow to prevent any
more water from entering the tank. Turn off the vacuum, and empty the recovery tank.
NOTE: if foam is present or if the ball float is prevented from rising, the float will not be able to stop
the air flow, and the tank may over fill.
CAUTION!
To avoid vacuum motor damage, always make sure the float filter is clean and the ball can travel
freely prior to using the machine. And always use a defoamer when foaming occurs.

11-600203072REVA
12
45
6
8
8
10
11
12
13
15
16
16
20 18
14
19
24
20 December 2007
21
25
26
7
23
Nilfisk Label
MX 307 H
27

11-600203072REVA
MX 307H EXTRACTOR
PART LIST
220 - 240V
1 1 600730701 Lid kit, vac tank and holding tank
2 1 600730703 Heat system replacement kit, 1600W
4 1 600730704 Switch kit
5 1 600730705 Filter kit
6 1 600730706 Holding tank kit
7 1 600730707 Pump kit
8 1 600730708 Vacuum motor kit
9 1 600730709 Vacuum hose kit, internal hoses
10 1 600730710 Ball float & manifold kit
11 1 600730711 Vacuum tank
12 1 600730712 Vacuum inlet kit
13 1 600730713 Drain Gate kit
14 1 600730714 Latch kit
15 1 600730715 Louver kit
16 2 600730716 Castor kit
17 1 600730717 Wheel kit
18 1 600730718 Base
19 1 600730722 Power cord kit, UK plug
600730719 Power cord kit, EU plug
20 1 600730720 Gasket
21 1 600730721 Heat repair kit
23 1 600730723 Label Kit
24 1 600730724 Fuse kit
25 1 600730725 Switch plate
26 1 600730726 QD kit
27 1 600730727 RFI filter
ITEM QTY PART No. DESCRIPTION

11-600203072REVA
TROUBLESHOOTING
CHECK THIS
Solution tank is empty.
Cloggedspraytip.
Pumpnot running.
Valveontoolnot operating.
Solution path is plugged. Pump should only run while spraying.
Solution tank may be empty, or nearly empty.
No power to pump. Test the switch. Test the pump motor.
Partiallypluggedsolutionpath(hose, heater, tool).
Worn pressure switch in pump. Adjust pressure sensor in pump head.
Debrismaybepluggingthe cleaning tool or vacuum hose.
Drain gate is not completely closed, or seals are damaged.
Internalvacuumhose is cracked.
Recovery tank lid is not closed, is cracked, or gasket is damaged.
Debrisimpeding air movement onvacmotor impellors.
No power to motor. Test the switch. Test the vacuum motor.
Trying to spray too long. Try spraying for 10 - 12 seconds per cycle
Heatexchangerneeds to be flushed
Wrong tool being used. Too much water passing through
Longerhose, or larger diameter hose,thanstandard
Heat switch is off
No power in the wall outlet — check to see if breaker has tripped
Check to see if the fuse has blown.
No power to heat switch — check power cord for ‘opens’
No power out of heat switch. Check power at Bi-metalic switch
Follow troubleshooting steps to isolate the problem. Call your distributor.
IF PROBLEM OCCURS
NOSPRAY
PUMP
DOESN’T
RUN
PUMP
PULSATES
LOW
SUCTION
NOSUCTION
LOW
HEAT
NO
HEAT
Ifyou are unable to diagnosethe problem, contact the companyfrom whom you purchasedyour MX 307H
SPECIFICATIONS:
Rotomolded Body:
Vacuum:
Heat Exchanger:
VAC Shutoff:
Pump:
Suction:
Weight:
Dimensions:
Lifetime Warranty
3-stage
1600 W
Ball float
7 Bar / 100 psi, demand
28 KPA
34.3 Kg
79 X45 X 86 cm
ALWAYS UNPLUG THE MACHINE
BEFORE DISCONNECTING OR
CONNECTING ANY WIRES OR
COMPONENTS.

11-600203072REVA
MX 307 H
EXTRACTOR
220- 240V
NOTES:
MAINTENANCE SCHEDULE
CLEANALLFILTERS X
FLUSH OUT with DESCALER
X
DAILY
WEEKLY
MONTHLY
OTHER
CHECK POWER CORD
REPLACE VAC MOTOR BRUSHES
YEARLY
X
Around1500hours
