NIMO IronMaid User manual

IronMaid
427001159
EN Ironing board cabinet User manual
Keep this manual so
that it is always to
hand for future use

Doc. No: 427001159 Rev. 01
Article and serial number
Dear NIMO customer,
Congratulations on making an excellent choice of product, and welcome to the NIMO
family, a global family with its roots in Sweden.
We at NIMO thank you for your trust and hope that you will enjoy using
your new ironing board cabinet.
A good ironing cabinet should be well designed, give good ironing results, have a low
environmental impact, be user-friendly, save time and energy, have a long service
life and be reliable. NIMO oers you all these features.
When you buy a NIMO product you can be sure that the inside is just as
good as the outside and that the ethics and morals that go into building this
product are just as high as the quality and function you are getting. That's what
Swedish quality is all about.
Before using the product for the rst time, please read the user instructions and the
advice on caring for the product. This will help you get the best possible results from
your product and all its functions.
If you have any questions, do not hesitate to call us or to contact us through
our website.
Best wishes from Sweden and the NIMO team.
Manufacturer:NIMO-VERKEN AB
Box 124 S-548 22 HOVA
Tel +46 (0)506 / 488 00
Fax +46 (0)506 / 488 10
[email protected]om
www.nimoverken.com

3
CONTENTS
SCRAPPING
When the ironing cabinet has reached
the end of its useful life and is going to
be scrapped it must be immediately made
unusable. Contact your local authority
for information about where your ironing
board cabinet should be scrapped and
recycled correctly.
The cabinet is manufactured and labelled
for recycling.
IMPORTANT SAFETY INFORMATION 4
INSTALLATION 5
UNPACKING 5
ELECTRICAL CONNECTION 5
SUSPENSION 5
OPERATION 7
IRONING 7
SERVICING 8
CARE 8
CLEANING 8
REPLACEMENT PART 8
TROUBLESHOOTING 8
TECHNICAL DATA 9

4
This advice on safe operation has been compiled to enable you to
avoid incorrect use and unnecessary risks of accidents and should
be read before the ironing board cabinet is installed and used.
pThe ironing board cabinet can be used by children over the age
of 8 and persons (including children) with physical, sensory
or mental disabilities or who lack experience or knowledge,
provided they have received guidance or information on how
to use the ironing board cabinet in a safe way and understand
the risks that may arise.
pDo not allow children to play in, on or with the ironing board
cabinet. Keep an eye on children when they are in the imme-
diate vicinity of the cabinet.
pIf the power cord is damaged, it must be immediately replaced,
and this must be done only by the manufacturer, the manu-
facturer's service agent or similarly qualied persons in order
to avoid danger.
pCleaning and maintenance must not be performed by children
without supervision.
p Remember to switch o󰀨 the iron if the board is folded up.
p
Do not store any ammable objects in the ironing board cabinet.
pDo not sit on the ironing board and do not use it as a surface
for temporary storage.
pThe ironing board cabinet must be installed or kept indoors.
pFollow NIMO instructions in repair and replacement of parts.
p
Adapt the ironing temperature and follow the manufacturer's instruc-
tions closely for ironing. Take care not to iron at too high a heat.
pKeep the area around the power socket clear of dust and dirt.
IMPORTANT SAFETY INFORMATION

5
240
130
75
1076
701
1852
1076
INSTALLATION
UNPACKING
Remove all packaging material; do not use
sharp tools that may damage the ironing
board cabinet.
After unpacking, check that the ironing board
cabinet is intact. Damage, defects and any
missing parts must be reported to the dealer
immediately.
A complete delivery should include:
pComplete cabinet with mounted ironing
board.
pFittings for securing the cabinet against
wall item 7.
p2 screws and two plugs for xing suspen-
sion ttings (items 2,3)
p3 screws, 3 plugs, 3 washers and 3 caps
for screw heads for fixing of cabinet
through back (items 1,4,5,6).
pUser Manual
Item numbering - see next page.
ELECTRICAL CONNECTION
Voltage: 240 V
Fuse: 10 A.
SUSPENSION
NB: Important safety information
pTo ensure safe mounting, the cabinet
must be firmly anchored in a wall.
pFor wall mounting, the screws must be
anchored in battens.
pFor mounting on a concrete wall the
plugs supplied must be used.
pFor mounting on a stud wall, the
screws must be anchored in ‘noggins’.
pIf you are unsure, contact a qualified
tradesperson for advice.
Check to make sure that the product has
not been damaged in transit. Any damage
incurred in transit must be reported to the
dealer within 7 days.
Check that all transport securing devices
have been removed before connecting the
ironing board cabinet.
Packaging materials such as plastic
and Styrofoam must be kept out of the
reach of children.
Noggins

6
7
1
23
456
1
4
5
6
Air intake
INSTALLATION
Noggins

7
CAUTION:
Read the safety instructions on page 4 before using the ironing board cabinet.
IRONING
Most settings and adjustments of the Iron-
Maid can be carried out with one hand.
Adjustment is illustrated.
Fold the board up/down
Fold the ironing board down by gripping at
the bottom edge and pull the board out of
the cabinet.
To fold it in again, release the safety catch
with the lever below the board, lift at the
rear edge and place the ironing board in the
cabinet.
Adjust in height and sideways
The height of the ironing board is adjusted
by turning the adjusting screw. The setting
is retained when the ironing board is folded
back into the cabinet.
The ironing board can be adjusted steplessly
sideways through 90 degrees in both direc-
tions if you wish.
Storage of iron
There is a shelf on the cabinet wall behind
the ironing board for storage of the iron. For
convenience during ironing there is also a tra-
ditional holder below the ironing board itself.
Power socket/timer
There is a power socket with timer and indica-
tor on the cabinet wall The timer can be set
to max 30 minutes at a time. The indicator
lights up if the power is on.
Shelves/hanger
On the inside of the door there is a hanger for
clothes hangers and wire shelves for storage.
There are slots for the shelves in the cabinet
door so that they can be adjusted in height.
Hanger for
clothes hangers
Shelves
Adjusting screw
for height
adjustment
Lever for release of
safety catch
OPERATION
Power socket Timer

8
Always appoint qualied professionals for
servicing. The power cord must be replaced
only by the manufacturer, service agent or
similar.
New covers for the ironing board can be
purchased from Nimoverken.
CARE
CLEANING
pClean the ironing board cabinet with a mild
soap solution on a damp cloth.
pClean the ironing board with a damp cloth.
SERVICING
Do not use high-pressure cleaning.
TROUBLESHOOTING
Fault Cause Action
The iron does not emit any heat The timer is at zero
The iron does not work
No power in the socket
Turn on the timer
Repair or replace the iron
Contact supplier for further
instructions
REPLACEMENT PART
If the power cord for any reason is damaged,
it must be replaced. A genuine spare part can
be obtained from the dealer who supplied
the cabinet.
NB: A power cord must only be fitted by
a qualified electrician.

9
1915
995
835
1313
1076 701
75
1320
730
370
R604
R344
90°
90°
300
998
1320
871
235
TECHNICAL DATA
