Njoy Astris 5K/3P2T2 User manual

User Manual
Manual de ulizare
Before using this product, carefully read all product documentaon and retain it for future reference.
Astris 3Phase
319.9.23.0

2
Content
Forward 1
Symbol Conventions 2
Safety 2
1.1 Symbols Used 3
1.2 Safety Precaution 3
Product Introduction 5
2.1 Overview 5
2.2 Model Denition 5
2.3 Product Appearance 6
Upack and Storage 8
3.1 Upack and Check 8
3.2 Storage Inverter 9
3.3 Identify Inverter 9
Installation 10
4.1 Selecting the Mounting Location 10
4.2 Mounting 14
Electrical Connection 16
5.1 Grounding 16
5.2 AC Connection 18
5.3 DC Connection 20
5.4 Communication Connection 23
Startup/Shutdown Procedure 27
6.1 Check before startup/shutdown Procedure 27
6.2 Startup Procedure 27
6.3 Shutdown Procedure 28
User Interface 29
Troubleshooting and Maintenance 33

3
English
Română
8.1 Troubleshooting 34
8.2 Maintenance 38

1
Please read this manual before using the product.
This user manual introduces the inverter in terms of its installaon,
electrical connecons, operaon, commissioning, maintenance,
and troubleshoong. Please read through the manual carefully
before installing and using the inverter, and keep the manual well
for future reference.
Forward
Preface
About This Manual
This manual describes the installaon, electrical connecon,
commissioning and maintenance, APP operaon of the inverter. Please
rst read the manual and related documents carefully before using
the product and store it in a place where installaon, operaon and
maintenance personnel can access it at any me. The illustraon in this
user manual is for reference only. This user manual is subject to change
without prior noce.
It is addressed to the following models:
SIN320050002ATCU0B - Astris 5K /3P2T2
SIN320060002ATCU0B - Astris 6K /3P2T2
SIN320080002ATCU0B - Astris 8K /3P2T2
SIN320100002ATCU0B - Astris 10K /3P2T2
SIN320100003ATCU0B - Astris 10K /3P2T3
SIN320120003ATCU0B - Astris 12K /3P2T3
SIN320150003ATCU0B - Astris 15K /3P2T3
SIN320150004ATCU0B - Astris 15K /3P2T4
SIN320170004ATCU0B - Astris 17K /3P2T4
SIN320200004ATCU0B - Astris 20K /3P2T4
SIN320220004ATCU0B - Astris 22K /3P2T4
SIN320250004ATCU0B - Astris 25K /3P2T4

2
English
Română
Symbol Convenons
The following safety instrucons and general informaon are used within
this user manual.
Symbol Description
DANGER Indicates an imminently hazardous situaon which, if not
correctly followed, will result in serious injury or death.
WARNING Indicates a potenally hazardous situaon which, if not
correctly followed, could result in serious injury or death.
CAUTION Indicates a potenally hazardous situaon which, if not
correctly followed, could result in moderate or minor injury.
NOTICE Indicates a potenally hazardous situaon which, if not correctly
followed, could result in equipment failure, or property damage.
NOTE
Calls aenon to important informaon, best pracces and
ps: supplement addional safety instrucons for your beer
use of the PV inverter to reduce the waste of your resource.
Safety
1
Before using the inverter, please read all instrucons and cauonary
markings on the unit and manual. Put the instrucons where you can
take them easily. The inverter of us strictly conforms to related safety
rules in design and test. Local safety regulaons shall be followed during
installaon, operaon and maintenance. Incorrect operaon work may
cause injury or death and damage to the inverter and other operator or a
third party. To avoid injury and damage to the inverter and other opera-
tor,please follow the safety precauons.
Target Group
Inverters must be installed by professional electrical engineers who
have obtained relevant qualicaons.

3
1.2 Safety Precauon
1.1 Symbols Used
• Installaon and maintenance of inverters must be performed by
qualied personnel, in accordance with local electrical standards,
wiring regulaons and requirements of local power authories.
• To avoid electric shock, DC input and AC output of the inverter must
be terminated at least 10 minutes before performing any installaon
or maintenance.
Symbol Description
Danger of high voltage and electric shock!
Only qualied personnel may perform work on the inverter.
Danger of high voltage. Residual voltage in the inverter need
5 mins to discharge, wait 5 mins before operaon.
Danger of hot surface
Fire danger
Environmental Protecon Use Period
Refer to the operang instrucons
Product should not be disposed as household waste
Grounding terminal
5 mins

4
English
Română
• The temperature of some parts of the inverter may exceed 60°
• during operaon,do not touch the inverter during operaon to
avoid being burnt.
• Ensure children are kept away from inverters.
• Don’t open the front cover of the inverter. Apart from performing
work at the wiring terminal, touching or changing components
without authorizaon may cause injury to people, damage to
inverters and annulment of the warranty ropriate measures to avoid
electric shock.
• Ensure the output voltage of the proposed PV array is lower than
the maximum rated input voltage of the inverter; otherwise the
inverter may be damaged and the warranty annulled.
• When exposed to sunlight, the PV array generates dangerous high
DC voltage. Please operate according to our instrucons,or it will
result in danger to life.
• Don’t insert or pull the terminals when the inverter is running.

5
The three-phase grid-ed PV inverter converts the DC generated by PV
panels into three-phase alternang currentand is delivered to the grid.
This series inverter is an important part of PV system and it is suitable
for household use, commercial use, shery use, agricultural use and other
scenarios.
This series inverter is suitable for TN-S, TN-C, TN-C-S and TT grid system.
Refer to the following gures:
Model number descripons (using Astris 10K/3P2T2 as an example):
2.1 Overview
Product Introducon
2
PV strings Inverter AC Distribution Unit Grid
(Only take fan cooling as an example in appearance)
TN -S
L1
L2
L3
N
PE
PE
Transforme r
TN -C
L1
L2
L3
PE N
PE
TN -C-S
L1
L2
L3
N
PE
PE
TT
L1
L2
L3
N
PE
PE
Transformer Transformer Transforme r
Inverter
2.2 Model Denion
InverterInverterInverter

6
English
Română
The following is only for reference, specic please in kind prevail
2.3 Product Appearance
208.5mm 414.27mm
398mm
460mm
190.5mm
480.5mm
(Only take natural cooling as an example in appearance)
23
1
Natural cooling series
Fan cooling series
4
Output Power (10KW)
3 Phase (3P)
10KTL-D3/G2
Grid-tied;second genneratio
10K/3P2T2

7
Descripon Descripon
1 DC Switch
2 LED Indicators
3 LCD Screen (Oponal)
4 External ground terminal
Descripon Descripon
5 PV terminal
6 RS485 communicaon port
7 WiFi/GPRS/LAN model communicaon port
(Oponal)
8 AC output port
9 External fan (It is only suitable for Fan cooling
series)
9
Natural cooling series Fan cooling series 1 Fan cooling series 2
5 6 7 8

8
English
Română
Number Descripon
AThe Inverter 1
BBracket 1
C AC shield (4× M4 security screws) 1
DPV connectors 2 or 4
EFile package 1
FExpansion screws groups 3
GM6 Security screw 2
H6-Pin terminal 1
IWiFi/GPRS module (Oponal) 1 (Oponal)
j Remove tool for PV connector 1 (Oponal)
Upack and Storage
3
3.1 Upack and Check
Complete test and strict inspecon shall be done before the inverter is
sent out. When receiving the inverter, check that the packing materials
are intact. Aer unpacking, examine the PV inverter and its ngs for
damage and check that the deliverables are complete.

9
Inverter body label. The following is only for reference, specic please in
kind prevail!
If the inverter is not used immediately, please keep the inverter in a
specic environment according to the
following requirements.
• Do not unpack the inverter and put desiccant in the original box if
the PV inverter is unpacked.
• Store temperature range: -25°C~+60°C; Relave humidity range:
0~100%.
• Don’t posion the inverter leaning forward, excessively leaning
backward, lng laterally, or upside down.
• Ensure that qualied personnel inspect and test the inverter before
use if it has been stored for a long me
t
Contact your dealer immediately if there is any issue found during
operation.
NOTICE
3.2 Storage Inverter
3.3 Idenfy Inverter
Number Descripon
1 Product name and model
2 Product technical parameters
3 SN Barcode
4 Approve and Safety idencaon
Model Name:
Part Number:
1234567891011
Serial Number
5min
SN: nJoy 1234 ABCD
20
1
2
3
4

10
English
Română
Installaon
4
Aer checking the outer packing, move the PV inverter to the designated
installaon posion horizontally.
a. The storage inverter protecon class is IP65 and can be mounted
indoors or outdoors.
b. To ensure opmum operaon and long service life, the ambient
temperature must be below 50°C.
c. Do not install the inverter in a rest area since it will cause noise during
operaon.
d. The inverter carrier must be re-proof. Do not mount the inverter on
ammable building materials.
e. Ensure that the wall meets the requirements of the inverter installaon
f. Product label and warning symbols shall be clear to read aer installaon
g. The installaon height should be reasonable and make sure it is easy to
operate and view the display.
h. Please avoid direct sunlight, rain exposure, snow lay up.
4.1 Selecng the Mounng Locaon
4.1.1 Installaon Environment Requirements
Ensure there is no electronical connections around ports of the PV
inverter before installation.
DANGER
1. Please place the inverter horizontally on the foam or other soft
pads and ensure that the ports are free of load-bearing pressure to
avoid inverter damages or scratches.
2. The inverter is heavy, be careful to prevent the inverter from
slipping and hurting the operator when moving the inverter.
CAUTION

11
4.1.2 Mounng Requirements
Mount the inverter vercally or lted backward by max 15°. In order to
facilitate the heat dissipaon of the inverter
t
The wrong installation mode causes the inverter to be damaged or
unable to work properly.
NOTICE

12
English
Română
4.1.3 Installaon Space Requirements
To ensure the operaon of the inverter normally and easily, there are
requirements on available spaces of theinverter, e.g. to keep enough
clearance. Refer to the following gures.

13
Installaon perspecve schemac

14
English
Română
Step 1. Install the mounng bracket
4.2 Mounng
1.The walls must be leproof and non-ammable
materials,othewise there is a re risk.
2.Before drilling holes ,check whether there are electric power
pipes buried in the walls to avoid risks.
DANGER
1 ) Use a horizontally ruler to mark the posion of the 3 holes on the wall.
Refer to Step 1. And drill 3 holes, 10mm in diameter and 60 mm in deep.
Refer to Step 1 and Step 2.
2) Knock the expansion screw kit into the hole together with a hammer.
Refer to Step 3.
Note: Do not remove the nut unit.
3) Aer ghtening 2-3 buckles, the expansion bolts are ght and not
loose, and then unscrew the bolts, spring washer, gasket. Refer to Step 3.
4) Install the bracket on the wall,the bracket screw is pointed at the
expansion tube on the wall, then install the gasket and ghten screw.
Refer to Step 4.

15
Step 2. Install the inverter.
Install the inverter on the bracket accurately and ghten the screws at
both sides, as shown in Step 5 and Step 6.
To prevent damage of the inverter, please hang the inverter on the
bracket and conrm the reverse,do not loosen the handle until the
inverter is xed
CAUTION

16
English
Română
System Connecon
According to the EN50178 requirement, the right side of the device has
a protecve grounding connecon. Be sure to connect the protecon
ground cable to this port when installing the inverter. The user can
perform the ground connecon according to the on-site condion
Electrical Connecon
5
5.1 Grounding

17
If the positive pole or negative pole of the PV array is required to be
grounded, then the inverter output (to AC grid) must be isolated by
transformer in accordance with IEC63109-1,-2 standards.
CAUTION
According to regulations,the secondary protection grounding can’t
replace the PE terminal connection of the AC cable. Ensure that
both are grounded reliably. Otherwise,fatal injury can occur due to
the high voltage.
WARNING
