Nokia CK-7W Manual

Advanced Car Kit CK-7W
User’s Guide
Installation Guide
CK-7W_ENv1_9230761.book Page 1 Friday, March 26, 2004 11:17 AM

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION, declare under our sole responsibility that the Advanced
Car Kit CK-7W is in conformity with the provisions of the following Council
Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found at:
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2004 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents
of this document in any form without the prior written permission of Nokia
is prohibited.
Nokia and Nokia Connecting People are trademarks or registered trademarks of
Nokia Corporation. Other products and company names mentioned herein may
be trademarks or tradenames of their respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of ongoing development. Nokia reserves the right to
make changes and improvements to any of the products described in this
document without prior notice.
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF
DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT
DAMAGES HOWSOEVER CAUSED.
The contents of this document are provided “as is”. Except as required by
applicable law, no warranties of any kind, either express or implied, including,
but not limited to, the implied warranties of merchantability and fitness for a
particular purpose, are made in relation to the accuracy, reliability or contents of
this document. Nokia reserves the right to revise this document or withdraw it at
any time without prior notice.
The availability of particular products and services may vary by region.
Please check with the Nokia dealer nearest to you.
EXPORT CONTROLS
This product contains commodities, technology or software exported from
the United States in accordance with the Export Administration regulations.
Diversion contrary to U.S. or Canadian law is prohibited.
FCC/INDUSTRY CANADA NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
CK-7W_ENv1_9230761.book Page 2 Friday, March 26, 2004 11:17 AM

iii
Contents
For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Your Nokia Advanced Car Kit CK-7W. . . . . . . . . . . . . . . . . . . . . . . . .2
Bluetooth wireless technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Bluetooth passcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Use of enhancements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installing the Advanced Car Kit CK-7W. . . . . . . . . . . . . . . . . . . . . 10
Function test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Using the Advanced Car Kit. . . . . . . . . . . . . . . . . . . . 14
Connecting a mobile phone using Bluetooth
wireless technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting a mobile phone over the data cable. . . . . . . . . . . . . . 15
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Remote control button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Switching the Advanced Car Kit CK-7W on/off . . . . . . . . . . . . . . 17
Operating the Advanced Car Kit CK-7W . . . . . . . . . . . . . . . . . . . . 17
Care and maintenance. . . . . . . . . . . . . . . . . . . . . . . . 20
Nokia One-Year Limited Warranty (U.S.). . . . . . . . . . 21
Nokia One-Year Limited Warranty (Canada) . . . . . . . 21
CK-7W_ENv1_9230761.book Page iii Friday, March 26, 2004 11:17 AM

iv
NOTES
CK-7W_ENv1_9230761.book Page iv Friday, March 26, 2004 11:17 AM

1
For your safety
Read these simple guidelines. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this user’s guide.
Keep all miniature SIM cards and accessories out of the reach of
small children.
ROAD SAFETY COMES FIRST
Remember that the safety of operating a motor vehicle in
traffic requires the full attention of all motorists. Only use
your Advanced Car Kit CK-7W if traffic conditions permit safe
use and check if local laws/regulations restrict the use of
mobile phones while driving.
INTERFERENCE
All wireless phones may get interference, which could
affect performance.
QUALIFIED INSTALLATION AND SERVICE
Only a qualified professional may install or repair
phone equipment.
CONNECTING TO OTHER DEVICES
When connecting to any other device using Bluetooth
wireless technology, read the relevant user’s guide for
detailed safety instructions. Do not connect incompatible
products.
FUSE REPLACEMENT
Replace a blown fuse with a fuse of the same type and size.
Never use a fuse with a higher rating!
CK-7W_ENv1_9230761.book Page 1 Friday, March 26, 2004 11:17 AM

2
Introduction
•YOUR NOKIA ADVANCED CAR KIT CK-7W
Advanced Car Kit CK-7W equipment installation in the console.
The Nokia Advanced Car Kit CK-7W was developed for installation in
motor vehicles to enable handsfree operation of mobile phones and use
of individual phone features.
A special emphasis was placed on quick and easy installation. A mobile
phone can be connected to the Advanced Car Kit in one of two ways:
using an optional phone holder with a cable or over a Bluetooth
wireless connection.
In some countries, use of the Advanced Car Kit may be restricted by law.
Please observe the applicable rules and regulations.
CK-7W_ENv1_9230761.book Page 2 Friday, March 26, 2004 11:17 AM

3
•BLUETOOTH WIRELESS TECHNOLOGY
Bluetooth wireless technology is an international standard for short-
range wireless communication. It allows you to establish a wireless
connection within a range of 32.8 feet between your Advanced Car Kit
and a compatible device.
The Advanced Car Kit is intended for use with any mobile phone that
supports the Bluetooth Handsfree Profile (Bluetooth specification 1.1).
The wireless connection between the compatible devices established
using Bluetooth technology is free of charge for the user. In some
countries, there may be restrictions on using Bluetooth devices.
Check with your local authorities.
•BLUETOOTH PASSCODE
The first time you wish to establish a wireless connection to a compatible
device using Bluetooth technology, you will need to input a passcode to
pair the devices.
The passcode is a four-digit numeric code that corresponds to the last
four digits in the serial number supplied with your Advanced Car Kit.
You will find the serial number on the type label attached to the
handsfree unit and on the sticker that comes with this user’s guide.
CK-7W_ENv1_9230761.book Page 3 Friday, March 26, 2004 11:17 AM

4
1 Getting started
•OVERVIEW
The Advanced Car Kit CK-7W includes the components shown above.
1Handsfree unit HF-5 with mounting plate MK-2
2Remote control button CU-7
3Loudspeaker HFS-12
4Microphone HFM-8
5Cable set PCU-4
6Data cable CA-27
CK-7W_ENv1_9230761.book Page 4 Friday, March 26, 2004 11:17 AM

Getting started
5
•USE OF ENHANCEMENTS
Depending on the setup, a variety of optional enhancements are
available to extend your Advanced Car Kit. Before any installation work
is started, ask for professional advice on the enhancements that would
best suit your needs. Use only approved enhancements. Ensure that only
compatible products are connected to your Advanced Car Kit.
Phone holder
A phone holder may be purchased with your car kit or separately as an
enhancement.
You will need a phone holder designed for a compatible mobile phone if
the mobile phone is to be connected directly to the handsfree unit using
the data cable.
Antenna coupler
An antenna coupler may be purchased with your car kit or separately as
an enhancement.
An antenna coupler is required to connect an external antenna. A range
of antenna couplers are commercially available for the mobile phones
and phone holders on the market. An antenna coupler improves in-
vehicle reception of the mobile phone.
GSM antenna
A compatible GSM antenna enables optimized wireless connections.
You may purchase a GSM antenna from an authorized Nokia dealer.
If you have installed an external antenna, remember that in order to
comply with RF exposure requirements for mobile transmitting devices,
a minimum distance of 7.8 inches must be maintained between the
antenna and all persons.
CK-7W_ENv1_9230761.book Page 5 Friday, March 26, 2004 11:17 AM

6
2 Installation
•SAFETY INFORMATION
The basic safety guidelines set out below are to be observed when
installing the Advanced Car Kit CK-7W.
Warning:
•Only qualified personnel should service the Advanced Car Kit CK-7W
or install it in a vehicle using the approved original Nokia parts
supplied in the sales package. Faulty installation or service may be
dangerous and may invalidate any warranty which may apply to the
unit. End users should remember that the Advanced Car Kit CK-7W
comprises complex technical equipment that requires professional
installation using special tools and expert know-how.
•Note that the instructions contained in this installation guide are
general guidelines which apply for the installation of the Advanced
Car Kit CK-7W in an automobile. However, due to the wide variety
of car types and models available on the market, this guide cannot
consider the individual technical requirements relevant for any
particular vehicle. Contact the vehicle manufacturer for further
detailed information about the vehicle in question.
•Make sure that the car ignition is off and disconnect the car battery
before beginning with the installation work and ensure that it
cannot be reconnected inadvertently.
•Remember that modern automotive systems include on-board
computers where key vehicle parameters are stored. Improper
disconnection of the car battery may cause loss of data, necessitating
extensive effort for re-initialisation of the system. If you have any
concerns, contact your car dealer before any installation work is done.
•Do not wire Advanced Car Kit CK-7W equipment to the high-voltage
lines of the ignition system.
•All equipment must be mounted so that it does not interfere with
the operation of the vehicle.
CK-7W_ENv1_9230761.book Page 6 Friday, March 26, 2004 11:17 AM

Installation
7
•Your service technician may be able to provide you with information
on alternatives for mounting the equipment suitably in your vehicle
without requiring boreholes.
•The mount for the phone holder is to be fixed to the dashboard or
to any other location in the cockpit area where the display is clearly
visible for the user but does not impair control or operation of the
vehicle. The keypad should be within easy reach of the user.
•Make sure not to impact the steering or braking systems or other
key systems essential for proper operation of the car when installing
Advanced Car Kit CK-7W equipment. Check to make sure that
deployment of the airbag is not blocked or impaired in any way.
•Do not smoke when working on the car. Make sure that there is no
source of fire or flame nearby.
•Take care not to cause damage to electrical cables, fuel or brake
lines or safety equipment during installation work.
•RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles (e.g. electronic fuel injection
systems, electronic anti-skid braking systems, electronic speed
control systems, airbag systems). Should you note a fault or change
in the operation of such a system, contact your car dealer.
•Ensure that cables are placed so that they will not be subjected
to mechanical wear and tear (e.g. not laid under car seats or over
sharp edges).
CK-7W_ENv1_9230761.book Page 7 Friday, March 26, 2004 11:17 AM

8
•CONFIGURATION
In principle, the Advanced Car Kit CK-7W offers two different basic
configurations for installation:
Connecting a mobile phone using
Bluetooth wireless technology
To be able to establish a connection from a compatible mobile phone to
the handsfree unit, both devices first have to be paired.
A compatible mobile phone supporting Bluetooth wireless technology is
required for this setup.
CK-7W_ENv1_9230761.book Page 8 Friday, March 26, 2004 11:17 AM

Installation
9
Connecting a mobile phone using
the data cable and a phone holder
When connected via the data cable, the compatible mobile phone is
ready for operation with the Advanced Car Kit when placed into the
phone holder.
Depending on your mobile phone and your vehicle equipment,
enhancements such as a phone holder, antenna coupler or external
antenna may be required.
CK-7W_ENv1_9230761.book Page 9 Friday, March 26, 2004 11:17 AM

10
•INSTALLING THE ADVANCED CAR KIT CK-7W
See "Introduction" on page 2 for an example of a suitable installation of
the Advanced Car Kit equipment.
Handsfree unit
When installing the handsfree unit, ensure that the cables for the
microphone and loudspeaker will reach the places you intend to
mount these components.
Take care not to mount the handsfree unit inside a closed metal housing
or in a place in the car where it would be shielded from radio waves, as
this may impair the use of the Bluetooth feature.
To mount the unit, first attach the mounting plate supplied with the
Advanced Car Kit and then secure the handsfree unit using the screw
that goes through the unit. Finally, insert the cover imprinted with the
Nokia logo into the recess and press it into place.
Remote control button
The remote control button should be located so that it is within easy
reach of the user. However, ensure that it is placed so that the cable for
connection to the handsfree unit can be mounted. A suitable mounting
position for the remote control button may be on the console between
the front seats.
CK-7W_ENv1_9230761.book Page 10 Friday, March 26, 2004 11:17 AM

Installation
11
To mount the remote control button, use the hook and loop tape
provided. First detach the two parts of the pads from each other. Attach
the pad with the loops first: peel off the protective sheet from the
adhesive side (A) and attach the pad to the desired location in your car
(B). Make sure that the surface where you intend to attach the pad is
dry and free from dirt and dust.
Attach the pad with the hooks next: peel off the protective sheet from
the adhesive side (C) and attach the pad to the underside of the remote
control button.
Press the remote control button (D) firmly onto the loop pad mounted
in the car.
Loudspeaker
To ensure good acoustic quality, mount the loudspeaker so that it is
pointed in the user’s direction. We recommend that you mount the
loudspeaker a minimum distance of 3.28 feet away from the
microphone to avoid feedback.
The Advanced Car Kit also supports connection to a compatible car radio
system. If yo wish to use the car radio installed in your vehicle with the
Advanced Car Kit for audio output, ask your service technician for
professional advice.
Connect the loudspeaker or a compatible car radio system to the
"SPEAKER" output.
Microphone
Careful selection of the mounting location of the microphone can
increase the quality of voice transmission.
Mount the microphone approx. 11.8 inches from the user’s head, and
position it so that it points towards the user’s mouth. Experience has
shown that the best locations are near the rearview mirror or the sun
visor. We recommend that you keep the microphone a minimum distance
of 3.28 feet away from the Advanced Car Kit phone loudspeaker to
avoid feedback.
CK-7W_ENv1_9230761.book Page 11 Friday, March 26, 2004 11:17 AM

12
Take care to mount the microphone so that it is not exposed to air
streams from the vents. Do not lay the microphone cable in the heating,
ventilation or AC system. Use the double-sided adhesive tape supplied
to fix the microphone, as this will prevent noise from the car body being
transmitted into the interior.
Insert the plug into the "MIC" socket in the handsfree unit and turn it
clockwise to lock it firmly.
Note: Use of any other microphone than the microphone
supplied with the Advanced Car Kit (HFM-8) may impact
the transmission quality.
Cable set
The wires making up the cable harness are to be connected as per the
wiring diagram.
•Connect the black wire to the vehicle ground (GND).
•Connect the yellow wire to the MUTE connection of the car radio.
If your car radio does not have a mute connection, this line may
remain unconnected. In this case, your car radio will not be muted
automatically during a call.
An additional relay can be used to enable the car radio to be muted.
When a call is accepted, the Advanced Car Kit switches the yellow
line (MUTE) to ground, muting the car radio. When the call is ended,
the yellow line is separated from ground and the car radio is unmuted.
CK-7W_ENv1_9230761.book Page 12 Friday, March 26, 2004 11:17 AM

Installation
13
•Connect the blue wire to the IGNS line of the car using the
1A fuse supplied.
Some vehicles do not come with an IGNS connection. This line is not
necessary for operation of the Advanced Car Kit; the blue wire can
be left unconnected. However, in this case, the Advanced Car Kit
does not switch off automatically when the ignition is turned off.
To prevent accidental draining of the car battery, the Advanced Car
Kit automatically switches off after two minutes unless a mobile
phone is connected over Bluetooth wireless technology or the
data cable.
•Connect the red wire to the positive terminal of the 12V car battery
using the 2A fuse supplied.
The four-pin plug of the cable set is plugged into the "DC" port of
the handsfree unit.
Data cable
The data cable connects the handsfree unit with a compatible mobile
phone, i.e. via the phone holder.
Plug one end of the cable into the "PHONE" socket in the handsfree unit
and the other into the phone holder.
If the Advanced Car Kit is to be used only with Bluetooth wireless
technology, the data cable does not need to be connected.
•FUNCTION TEST
After your Advanced Car Kit has been installed, it needs to be checked
to ensure that it is working properly. When testing the operation of the
equipment, also check that it has been mounted so that it in no way
impairs the driver during operation of the vehicle.
CK-7W_ENv1_9230761.book Page 13 Friday, March 26, 2004 11:17 AM

14
3 Using the Advanced Car Kit
A compatible mobile phone can be connected to the Advanced Car Kit
CK-7W in one of two ways: over a Bluetooth wireless connection or
using a compatible phone holder with a cable.
•CONNECTING A MOBILE PHONE USING
BLUETOOTH WIRELESS TECHNOLOGY
The first time you establish a wireless link from your Advanced Car Kit
using Bluetooth technology, you will have to pair the handsfree unit
with the compatible mobile phone that you are using. This only needs to
be done once: after this the devices will automatically recognize each
other and establish the link.
Note: If you wish to establish a connection using Bluetooth
wireless technology, make sure that there is no mobile phone
inserted in the phone holder.
Pairing using a Bluetooth passcode
1Make sure that the mobile phone is switched on and the battery
is charged.
2Switch on the Advanced Car Kit. For further information, see
"Switching the Advanced Car Kit CK-7W on/off" on page 17.
3Open the Bluetooth menu in the mobile phone and activate the
Bluetooth function.
4Make the required settings on the mobile phone to activate a search
for Bluetooth devices within range. For further information on the
settings required on your mobile phone, see the relevant user’s guide.
5Select Advanced Car Kit from the list of Bluetooth devices found.
6When prompted, key in the Bluetooth passcode. You will find this
code on the sticker attached to the front of this user’s guide.
The Bluetooth passcode is a four-digit numeric code that corresponds
to the last four digits in the serial number supplied with your
Advanced Car Kit. You will find the serial number on the sticker
attached to the handsfree unit.
CK-7W_ENv1_9230761.book Page 14 Friday, March 26, 2004 11:17 AM

Using the Advanced Car Kit
15
7The mobile phone has now been paired with the Advanced Car Kit
and is ready for operation.
Note: The Advanced Car Kit can only establish a Bluetooth
wireless connection to one compatible mobile phone at a time.
Therefore, you may need to end any existing Bluetooth wireless
connection before connecting to a different mobile phone.
Automatic pairing with a compatible mobile phone
1Make the appropriate settings in the mobile phone so that it will
pair with your Advanced Car Kit without requiring separate
acceptance or authorization. Your car kit can be paired with up to
8 compatible mobile phones. The settings for each of the mobile
phones will be stored in the car kit memory for future use. For further
information on the settings required on your mobile phone, see the
relevant user guide.
2Switch on the Advanced Car Kit.
3The Advanced Car Kit now starts an automatic 30-second search for
up to seven different mobile phone settings that have been paired
and stored in its memory. The Advanced Car Kit, by default, pairs
with the mobile phone that it paired with last. The active Bluetooth
search is indicated by the flashing light on the remote control button.
•CONNECTING A MOBILE PHONE OVER THE
DATA CABLE
If you are using this form of connection, the mobile phone is ready for
use with the Advanced Car Kit when placed into the phone holder; you
do not need to pair the devices.
If a mobile phone is inserted into a phone holder connected to the
Advanced Car Kit via the data cable, this phone is the active device and
you will not be able to establish a connection to any device via Bluetooth
wireless technology. Inserting a mobile phone that is currently involved
in an active Bluetooth wireless connection into a phone holder connected
to the Advanced Car Kit CK-7W will cause the Bluetooth wireless
connection to be terminated automatically.
CK-7W_ENv1_9230761.book Page 15 Friday, March 26, 2004 11:17 AM

16
4 Operation
The Advanced Car Kit CK-7W can be controlled with the remote control
button or operated using the keypad of a compatible mobile phone.
•REMOTE CONTROL BUTTON
1 The button can be used as follows:
•Press
•Press and hold (approx. 1 second)
•Press twice briefly
•Press and hold for a long time (longer than 10 seconds)
2 The ring can be used as follows:
•Turn to the left
•Turn to the right
3 The indicator light has three states:
•On
•Flashing
•Off
CK-7W_ENv1_9230761.book Page 16 Friday, March 26, 2004 11:17 AM
