Nokia HF-6W - Bluetooth hands-free Car User manual

User Guide for the Nokia
Wireless Plug-in Car
Handsfree (HF-6W)
Part Number
Issue 1
HF6W_Wayne_legal_draft2.fm Page 1 Friday, January 7, 2005 10:46 AM

DECLARATIONOFCONFORMITY
We,NOKIA CORPORATION declare under our sole responsibility that the
product HF-6W is in conformity with theprovisionsofthefollowing
Council Directive: 1999/5/EC.
AcopyoftheDeclarationofConformitycanbefoundfrom
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2004 Nokia. All rights reserved.
Reproduction,transfer,distributionorstorageofpartorallofthe
contents in this document in any form without the priorwritten
permission of Nokia is prohibited.
Nokia is a registeredtrademarkofNokiaCorporation. Other product and
company names mentioned herein may betrademarks or tradenames of
theirrespectiveowners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policyof continuous development. Nokia reservesthe
righttomakechangesandimprovementstoanyof theproductsdescribed
in this document without prior notice.
HF6W_Wayne_legal_draft2.fm Page 2 Friday, January 7, 2005 10:46 AM

Under no circumstances shall Nokiabe responsible for any loss ofdata or
income or any special, incidental, consequential or indirect damages
howsoevercaused.
The contents of this document are provided "as is".Except as required by
applicablelaw,nowarrantiesofanykind, either express or implied,
including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose, aremade in relation to theaccuracy,
reliabilityorcontentsof this document. Nokia reserves the right to revise
this document or withdraw itat any time without priornotice.
Theavailabilityof particular products may vary by region. Please check
withtheNokiadealernearesttoyou.
ExportControls
Thisdevicemay contain commodities,technology orsoftwaresubject to
export laws and regulations from the US and other countries. Diversion
contraryto law is prohibited.
Partnumber/Issue 1 EN
HF6W_Wayne_legal_draft2.fm Page 3 Friday, January 7, 2005 10:46 AM

Contents
4
Contents
For your safety ............................................................. 6
1.Introduction.............................................................. 7
2.Get started................................................................ 8
Handsfree parts...................................................................................... 8
Install the handsfree in the car ....................................................... 10
Switch the handsfree on and off..................................................... 11
Connect with Bluetooth wireless technology.............................. 11
Bluetooth connection passcode................................................... 12
Pair the handsfree with a compatible phone........................... 12
Disconnect the handsfree from the phone ............................... 13
Reconnect the handsfree to the phone...................................... 14
Troubleshooting.................................................................................... 15
3.Basic use ................................................................. 16
Call functions........................................................................................ 16
Answer and end a call..................................................................... 16
Automatic answer............................................................................ 17
Reject a call........................................................................................ 17
HF6W_Wayne_legal_draft2.fm Page 4 Friday, January 7, 2005 10:46 AM

Contents
5
Mute an ongoing call...................................................................... 17
Multiple calls..................................................................................... 18
Adjust the handsfree volume........................................................... 18
Switch the call between handsfree and phone.......................... 19
Charge a compatible phone battery .............................................. 19
Use the handsfree with several paired phones........................... 20
Reset the handsfree............................................................................ 21
Care and maintenance................................................ 22
Additional safety information................................... 23
HF6W_Wayne_legal_draft2.fm Page 5 Friday, January 7, 2005 10:46 AM

For your safety
6
For your safety
Readthese simple guidelines.Notfollowing them may be
dangerousor illegal.Read the complete user guide for further
information.
ROAD SAFETY COMES FIRST
Obeyalllocallaws. Always keep your handsfreeto
operatethevehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
Allwirelessdevices may besusceptibleto interference,
whichcould affect performance.
CONNECTING TO OTHER DEVICES
Whenconnecting to any other device, readits user
guidefor detailed safety instructions. Donot connect
incompatible products.
QUALIFIED SERVICE
Onlyqualified personnel may repair this device.
HF6W_Wayne_legal_draft2.fm Page 6 Friday, January 7, 2005 10:46 AM

Introduction
7
1. Introduction
TheNokia WirelessPlug-in Car Handsfree(HF-6W) isan
easy fit handsfree product, whichisbased on Bluetooth
wirelesstechnology.
Youcan usethe handsfree to answer, endand rejecta
call,and to charge a compatible Nokia mobile phone.In
addition,you can use voice dialling, redial a number,
switch calls between the handsfree and a compatible
phone, or mute and unmute active calls.
Readthis user guide carefullybefore using thehandsfree.
Checkalso http://www.nokia.com/support or your local
NokiaWeb site for the latest version of thisguide,
additional information, downloads, and services related
to your Nokia product.
HF6W_Wayne_legal_draft2.fm Page 7 Friday, January 7, 2005 10:46 AM

Get started
8
2. Get started
Beforeyou can start using thehandsfree, you must:
• Install the handsfree in the car.
• Pair a compatible phone with the handsfree.
■Handsfree parts
The handsfree contains the following parts:
1- Power key: Switchesthe handsfreeon and off,or
mutesthe ongoing call.
2 - Answer/end key:Answers or endsthe call.Can also
beused for voice dialling, redialling andswitching an
activecall betweenthe handsfree andthe phone.
3- Volume up key: Increases the handsfreevolume.
4 - Volume down key: Decreasesthe handsfree volume.
5 - Cable release key: Rewindsthe charger cable.
HF6W_Wayne_legal_draft2.fm Page 8 Friday, January 7, 2005 10:46 AM

Get started
9
6 - Speaker: Relaysthe caller’s voice.
7 - Microphones: Pick upyour voice.
8 - Indicator
lights: Display
thecurrent
statusof the
handsfree.Redor
greenindicates
the status of a
call,or indicates
that the
handsfreeis
beingreset. Blue
indicatesthat
theBluetooth
connectionis
active.
9 - Charger cable
HF6W_Wayne_legal_draft2.fm Page 9 Friday, January 7, 2005 10:46 AM

Get started
10
■Install the handsfree in the car
Tobe able tofunction properlythe handsfreeneeds to be
connected to the cigarette lightersocket of a car, and
there needs to be power generated by the carbattery.
Insertthe handsfree into the cigarette lighter socket of
your car. Make sure that thehandsfree is properlylocked
inplace, and does not interfere withthe normal
operationof the car.
Notealso that insome carmodelsthe cigarettelighter
socketispoweredby thecar battery evenwhenthe caris
notrunning. In those cases thecar batterymight be
discharged if the handsfree is left on, or if the handsfree
isturnedoffbutconnectedtothe cigarettelightersocket
for a long time. Contactthe vehicle manufacturer for
furtherdetailed information aboutthe vehiclein
question.
HF6W_Wayne_legal_draft2.fm Page 10 Friday, January 7, 2005 10:46 AM

Get started
11
■Switch the handsfree on and off
To switch on: press thepower key.The handsfreebeeps,
andthe greenindicator light isdisplayed briefly. When
youswitchthehandsfreeon forthefirst time,a welcome
tone is played.
To switch off: press the power key when no call is in
progress.Thehandsfree beeps, andthered indicatorlight
isdisplayed briefly.
■Connect with Bluetooth wireless
technology
Thehandsfree isspecially designed for compatible Nokia
phonesthat supportBluetooth wireless technology.You
can,however, use the handsfree withany compatible
Bluetoothdevice thatsupports the Bluetooth Handsfree
profile.
Refer to the user guideof your phone for a moredetailed
description of Bluetooth wireless technology.
HF6W_Wayne_legal_draft2.fm Page 11 Friday, January 7, 2005 10:46 AM

Get started
12
Bluetooth connection passcode
Youneed a Bluetooth passcode for pairing the handsfree
witha compatible phone using Bluetooth connectivity.
The passcode is 0000.
Pair the handsfree with a compatible
phone
Beforeyou canuse thehandsfree,you mustpair it with a
compatible phone.
1. Makesure that the compatible phoneis switched on.
2. Makesurethatthehandsfreeisinstalledproperly,and
switchit on by pressing thepower key.
3. Enter the Bluetooth menu of your phone and activate
theBluetooth feature. For more information, seethe
userguide of your phone.
4. Setthe phoneto search for Bluetooth devices as
instructedin theuser guide of the phone.
HF6W_Wayne_legal_draft2.fm Page 12 Friday, January 7, 2005 10:46 AM

Get started
13
5. Selectthe handsfree(Nokia HF-6W)from thelist.
6. Enter the Bluetooth passcode 0000 topair the
handsfreewith thephone.
Onceyou haveentered thepasscode, thephone
becomesthe default phone for thehandsfree, if the
handsfree has not been previouslypaired with
another phone. See also Use thehandsfree with
several paired phones on page 20.
Thehandsfree beepsonce and an active Bluetooth
connectionisdisplayedbyacontinuousblueindicator
light.
7. Start using the handsfree (see page 16).
Disconnect the handsfree from the phone
Todisconnect the handsfree, do oneof the following:
• Disconnectthe handsfree in the phone’sBluetooth
menu.
HF6W_Wayne_legal_draft2.fm Page 13 Friday, January 7, 2005 10:46 AM

Get started
14
• Switchoff the handsfree.
Note that you do notneed to delete the pairing with the
handsfreeto disconnectit. When youreconnect apaired
handsfree,you are not asked for its passcode.
Reconnect the handsfree to the phone
Toreconnect the handsfree to thedefault phone or the
lastused phone, switch on the handsfree. Otherwise,
makethe connection in the phone’sBluetooth menu as
instructedin theuser guide of the phone.
Notethat switching onthe handsfree creates the
connectionautomatically only if you haveset the phone
toaccept Bluetooth connection requests withoutyour
permission.InNokiaphonesthiscanbedonebychanging
yourpaired devices settingsin theBluetooth menu.
If the handsfree does not automatically reconnect tothe
default of the last used phone, press and hold the
HF6W_Wayne_legal_draft2.fm Page 14 Friday, January 7, 2005 10:46 AM

Get started
15
answer/endkey, and the handsfree starts pagingfor the
phones.
■Troubleshooting
If you cannot connect the handsfree to the compatible
phone,proceed asfollows:
• Make sure that theBluetooth feature is activated on
thecompatible phone.
• Make sure that the handsfree is properly installed,
switched on and paired withthecompatible phone.
Check also that there is powergeneratedby the car
battery.
• Ifyou use several Bluetoothdevices, makesure you
endedthe previousBluetooth connectionfrom the
phone.
• Check that the handsfree iswithin 10 meters of the
phoneandthattherearenoobstructionsorelectronic
devicesbetween the two.
HF6W_Wayne_legal_draft2.fm Page 15 Friday, January 7, 2005 10:46 AM

Basic use
16
3. Basic use
■Call functions
Whenthe handsfreeis connected tothe phone,you can
make a call in threedifferent ways. Note that the call
functionsdepend on the phone thatyou use.
• Tomake a newcall,useyourphoneinthenormalway.
• Toredialthelastdialednumber,presstheanswer/end
key twice.
• Toactivate voice dialling,press the answer/end key
for more than one second.
Answer and end a call
Whenyou receive a call, youhear a ringing tone through
thehandsfree. Note, however,that ifthe incoming call
alertsettinginyourphoneisoff,noringingtoneisplayed
throughthe handsfree.
HF6W_Wayne_legal_draft2.fm Page 16 Friday, January 7, 2005 10:46 AM

Basic use
17
To answer a call, or toend the currentlyactive call, press
the answer/end key.
You can also answer or endthe call using the phone.
Automatic answer
If, on the phone,the Automatic answer function isset to
on,the phone automatically answers the incomingcall
after a defined timeperiod, and forwards itto the
handsfree.
Reject a call
Whenyou receivean incoming callthat youdo not want
to answer, briefly press the answer/end key twice.
Mute an ongoing call
Tomute orunmute the ongoing call, pressthe power key
briefly.
HF6W_Wayne_legal_draft2.fm Page 17 Friday, January 7, 2005 10:46 AM

Basic use
18
When the mute ison, the red indicator light is shown
continuously.
Multiple calls
You cannot handle multiple callsthrough the handsfree.
Tomake multiple calls, use thekeypad of the phone.
Theonly way toanswer awaitingcall fromthe handsfree
isto firstend the active call, and then toanswer the
secondcall.
■Adjust the handsfree volume
To adjust the handsfree volume, usethe volume keys on
the handsfree, or the keypad of your phone.
Notethat the volumelevel is saved separately for each
pairedphone in the handsfree.
The volume display is shown in thephone, and different
tonesare played when you adjust the volume.When
there is no call, atone for each volume step is played.
HF6W_Wayne_legal_draft2.fm Page 18 Friday, January 7, 2005 10:46 AM

Basic use
19
Whenthere is anongoingcall,atoneisonlyplayed when
the volume reaches its minimumor maximum level.
■Switch the call between handsfree and
phone
Toswitch the activecallfrom thehandsfreeto thephone
and vice versa, press the answer/end key for more than
onesecond.
■Charge a compatible phone battery
Youcanchargethebatteriesof compatibleNokiaphones
whileusing the handsfree. Pull outthe chargercable and
connectit tothe phone. When the battery is fully
charged,disconnect thephone from thecharger cable,
and retract the cable by pressing the cable release key.
HF6W_Wayne_legal_draft2.fm Page 19 Friday, January 7, 2005 10:46 AM

Basic use
20
■Use the handsfree with several paired
phones
The handsfree can be paired with upto 8 compatible
phonesbut connectedto only one phone ata time.
The phone that was firstpaired with the handsfree is
calledthe "default phone". The phonethat was last used
withthe handsfreeis called the "last used phone".
If the handsfree is switched onwithin 10 metres of
severalpairedphones, thehandsfree will tryto connect
tothe "default phone" within afew seconds.
Ifthe handsfree cannot connectto the "default phone"
(forexample, it is switched offor its user rejects the
connection),the handsfreetries toconnect tothe "last
usedphone" within a few seconds.
Ifthe handsfree cannot connectto either of these
phones, it remains discoverable for other phones.
HF6W_Wayne_legal_draft2.fm Page 20 Friday, January 7, 2005 10:46 AM
