Nokia 105 Dual SIM User manual

User Guide
Nokia 105 Dual SIM
Issue 1.0 EN

For your safety
Read these simple guidelines. Not following them may be dangerous or against local laws and
regulations.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference
or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Microsoft Mobile for use with
this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Exercise caution when holding your device near your ear while the loudspeaker is in use.
© 2015 Microsoft Mobile. All rights reserved. 2

Get started
Get started with the basics, and have your phone up and running in no time.
Keys and parts
Explore the keys and parts of your new phone.
1 Earpiece
2 Selection keys
3 End/Power key
4 Microphone
5 Call key
6 Scroll key
7 Antenna area
8 Loudspeaker
9 Headset connector (3.5 mm)
10 Flashlight
11 Charger connector
Avoid touching the antenna area while the
antenna is in use. Contact with antennas affects the communication quality and may reduce battery
life due to higher power level during operation.
Do not connect to products that create an output signal, as this may damage the device. Do not
connect any voltage source to the audio connector. If you connect an external device or headset,
other than those approved for use with this device, to the audio connector, pay special attention to
volume levels.
Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place
credit cards or other magnetic storage media near the device, because info stored on them may be
erased.
Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may
be sold separately.
Note: You can set the phone to ask for a security code. The pre-set code is 12345, but you can
change it to protect your privacy and personal data. Note, however, that when you change the
code, you need to remember the new code, as Microsoft Mobile is not able to open or bypass
it.
Insert the SIM cards and battery
Learn how to insert the battery and SIM cards.
Important: This device is designed to be used with a standard SIM card (see figure) only. Use of
incompatible SIM cards may damage the card or the device, and may corrupt data stored on the
card. Please consult your mobile operator for the use of a SIM card that has a mini-UICC cutout.
© 2015 Microsoft Mobile. All rights reserved. 3

Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
1. Press the back cover with your thumb, carefully lift the bottom edge of the back cover with your
fingers, and remove the cover.
2. If the battery is in the phone, lift it out.
3. Slide the SIM in with the contact area face down.
SIM 1
4. To insert a second SIM, slide the SIM in with the contact area face down.
Both SIM cards are available at the same time when the device is not being used, but while one SIM
card is active, for example, making a call, the other may be unavailable.
© 2015 Microsoft Mobile. All rights reserved. 4

5. Line up the battery contacts, and put the battery in.
6. Replace the back cover.
Remove the SIM cards
Open the back cover, remove the battery, press the release spring, and slide the SIM cards out.
Switch your phone on
Press and hold the power key.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge it before you
can use your phone.
1. Plug the charger into a wall outlet.
2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the
wall outlet.
If the battery is completely discharged, it may take several minutes before the charging indicator is
displayed.
Lock or unlock the keys
To avoid accidentally pressing the keys, use keypad lock.
1. Quickly press .
2. Select Lock.
Unlock the keypad
Press , and select Unlock.
© 2015 Microsoft Mobile. All rights reserved. 5

Basics
Learn how to get the most out of your new phone.
Set which SIM card to use
If you have 2 SIM cards in your phone, you can select which one you want to use.
1. Select Menu > Settings > Dual SIM settings.
2. To choose which SIM to use for calls, select Default SIM for calls and the SIM.
3. To choose which SIM to use for messages, select Default SIM for msgs and the SIM.
Explore your phone
Explore the views and features of your phone.
See the apps and features of your phone
Select Menu.
Menu
Go to an app or feature
Press the scroll key up, down, left, or right.
Open an app or select a feature
Select Select.
© 2015 Microsoft Mobile. All rights reserved. 6

Select
Go back to the previous view
Select Back.
Back
Go back to the home screen
Press the end key.
Switch the flashlight on
On the home screen, quickly scroll up twice.
© 2015 Microsoft Mobile. All rights reserved. 7

Menu
To switch the flashlight off, scroll up once.
Do not shine the light in anyone’s eyes.
Change the volume
Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the
volume to your liking.
Scroll up or down to change the volume during a call or when listening to the radio.
Change the wallpaper
You can change the background of your home screen to your liking.
1. Select Menu > Settings > Display settings > Wallpaper.
2. Select a wallpaper.
Set the ringtone
Set a ringtone for your phone. You can set a different ringtone for each SIM card.
1. Select Menu > Settings > Tone settings.
2. Select Ringing tone. If needed, select a SIM card.
3. Pick a ringtone, and select OK.
Listen to the radio
Enjoy your favourite FM radio stations on the go.
© 2015 Microsoft Mobile. All rights reserved. 8

1. Connect a compatible headset (it acts as an antenna), and select Menu > Radio.
2. To go to a new channel, scroll left or right.
3. To close the radio, select Stop.
Write text
Writing with the keypad is easy and fun.
Press a key repeatedly until the letter is shown.
Type in a space
Press 0.
Type in a special character or punctuation mark
Press *.
Switch between character cases
Press # repeatedly.
Type in a number
Press and hold a number key.
Use predictive text
To speed up your writing, your phone can guess what you are starting to write. Predictive text is based
on a built-in dictionary. This feature is not available for all languages.
1. Select Opt. > Dictionary and the language.
2. Start writing a word. When the word you want is shown, press 0.
Change a word
Press * repeatedly until the word you want is shown.
Add a new word to the dictionary
If the word you want isn't in the dictionary, write the word, press * repeatedly to skip all unwanted
words, select Spell, and write the word.
Switch between predictive and traditional text
Press # repeatedly.
Switch predictive text off
Select Opt. > Dictionary > Dictionary off.
© 2015 Microsoft Mobile. All rights reserved. 9

People & messaging
Contact your friends and family using your phone.
Make a call
Learn how to make a call with your new phone.
1. Type in the phone number.
To type in the + character, used for international calls, press * twice.
2. Press . If asked, select which SIM to use.
3. To end the call, press .
Answer a call
Press .
Save a name and phone number
Save and organise your friends' phone numbers. Or why not spice up your contacts list by assigning
different tones for your contacts?
1. Select Menu > Contacts > Add contact.
2. Select where to save the contact.
3. Write the name, and type in the number.
Tip: To save a phone number in the dialler, type in the number, and select Opt. > Save.
Send and receive messages
Keep in touch with your friends and family through text messages.
1. Select Menu > Messages.
2. Select Create message, and write your message.
Tip: To insert special characters, such as a smiley or symbol, select Opt. > Insert options.
3. Select Opt. > Send. If asked, select which SIM to use. Type in a phone number, or select Search
and a recipient from your contacts list.
Tip: You can also press to send the message.
You can send text messages that are longer than the character limit for a single message. Longer
messages are sent as two or more messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language options, take more space, and limit the
number of characters that can be sent in a single message.
Read a message
On the lock screen, select Read.
Tip: To read the message later, select Menu > Messages > Inbox.
© 2015 Microsoft Mobile. All rights reserved. 10
