Nokia 2710 User manual

Nokia 2710 User Guide
Issue 1.2

Contents
Safety 4
Support 5
Get started 5
Insert SIM card and battery 5
Insert a microSD card 5
Remove the microSD card 6
Charge the battery 6
GSM antenna 7
Headset 8
Connect a USB data cable 8
Magnets and magnetic fields 9
Keys and parts 9
Access codes 10
Switch on or off 10
Home screen 11
Keypad lock 11
Use your device without a SIM card 12
Applications running in background 12
Calls 12
Make and answer a call 12
Loudspeaker 12
Dialing shortcuts 12
Write text 13
Text modes 13
Traditional text input 13
Predictive text input 13
Navigate the menus 14
Messaging 14
Text and multimedia messages 14
Flash messages 15
Nokia Xpress audio messages 15
Voice messages 16
Message settings 16
Contacts 16
Call log 17
Settings 17
Profiles 17
Tones 17
Display 18
Date and time 18
Shortcuts 18
Synchronization and backup 18
Connectivity 19
Call and phone 20
Accessories 20
Configuration 20
Restore factory settings 21
Operator menu 21
Gallery 21
Applications 21
Alarm clock 21
Calendar and to-do list 22
Extras 22
Camera and video 23
FM radio 23
Voice recorder 24
Media player 24
Maps 25
About Maps 25
Introduction 26
Navigate to your destination 27
movitalk 30
About the movitalk service 30
movitalk settings 30
Add a contact 31
Make a movitalk call 31
Answer a movitalk call 31
Switch from a movitalk call to a cellular
call 32
Send a callback request 32
View the call log 32
Web or Internet 32
2Contents

Connect to a web service 32
SIM services 33
Green tips 33
Save energy 33
Recycle 33
Learn more 33
Product and safety information 33
Index 42
Contents 3

Safety
We invite you to read the instructions on this guide before using the device.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
4Safety

Support
When you want to learn more about how to use your product or you are unsure how
your device should function, go to www.nokia.com/support, or using a cellular phone,
www.nokia.mobi/support.
If this does not resolve your issue, do one of the following:
•Reboot your device. Switch off the device, and remove the battery. After about a
minute, replace the battery, and switch on the device.
•Restore the original factory settings.
•Update your device software.
If your issue remains unsolved, contact Nokia for repair options. Go to www.nokia.com/
repair, or in Latin America, www.nokia-latinoamerica.com/centrosdeservicio. Before
sending your device for repair, always back up the data in your device.
Get started
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect the charger before removing
the battery.
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1 Slide the back cover downwards, and remove it (1).
2 Remove the battery (2).
3 Insert the SIM card. Ensure the contact surface area is facing down and the beveled
corner of the SIM card is facing the bottom of the device (3, 4, 5).
4 Replace the battery and the back cover (6, 7).
Insert a microSD card
Use only compatible microSD cards approved by Nokia for use with this device. Nokia
uses approved industry standards for memory cards, but some brands may not be fully
compatible with this device. Incompatible cards may damage the card and the device
and corrupt data stored on the card.
Support 5

Your phone supports microSD cards with a capacity of up to 16 GB.
A compatible memory card may be supplied with the device, and may already be
inserted in the device. If not, do the following:
1 Open the cover of the memory card slot.
2 Insert the card into the memory card slot with the contact surface facing up, and
press until it locks into place.
3 Close the cover of the memory card slot.
Remove the microSD card
Important: Do not remove the memory card during an operation when the card is
being accessed. Doing so may damage the memory card and the device, and corrupt
data stored on the card.
You can remove or replace the memory card during phone operation without switching
the device off, but you need to ensure that no application is currently accessing the
memory card.
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
6Getstarted

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the
device while it charges. If the battery is completely without charge, it may take several
minutes before the charging indicator appears on the display or before any calls can be
made.
GSM antenna
Your device may have internal and external antennas. Avoid touching the antenna area
unnecessarily while the antenna is transmitting or receiving. Contact with antennas
affects the communication quality and may cause a higher power level during operation
and may reduce the battery life.
The figure shows the GSM antenna area marked in grey.
Get started 7

Headset
Warning:
When you use the headset, your ability to hear outside sounds may be affected. Do not
use the headset where it can endanger your safety.
When connecting any external device or any headset, other than those approved by
Nokia for use with this device,to the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as this may cause damage to the
device. Do not connect any voltage source to the Nokia AV Connector.
Connect a USB data cable
Connect a compatible USB data cable to the USB connector. You may need to purchase
a USB data cable separately.
To modify the USB settings, select Menu > Settings > Connectivity > USB data
cable and the desired mode.
8Getstarted

Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key (scroll key)
5Call key
6Keypad
7Maps key
8End/Power key
9Microphone
10 Camera lens
11 Loudspeaker
12 Wrist strap hole
13 Headset connector/Nokia AV Connector (0.14 in)
14 Charger connector
15 movitalk key (Push to talk key)
Get started 9

16 Micro USB cable connector
17 Memory card slot
Functions of the movitalk key
•To open your movitalk contacts list, press the movitalk key.
•To view a history of your movitalk calls, press and hold the movitalk key.
•To make a movitalk call, select a movitalk contact, and press and hold the movitalk
key.
Access codes
The security code helps to protect your device against unauthorized use. The preset
code is 12345. You can create and change the code, and set the device to request the
code. Keep the code secret and in a safe place separate from your device. If you forget
the code and your device is locked, your device will require service. Additional charges
may apply, and all the personal data in your device may be deleted. For more
information, contact a Nokia Care point or your device dealer.
The PIN code supplied with the SIM card protects the card against unauthorised use.
The PIN2 code supplied with some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in succession, you are asked for the
PUK or PUK2 code. If you do not have them, contact your service provider.
The module PIN is required to access the information in the security module of your SIM
card. The signing PIN may be required for the digital signature. The restriction password
is required when using the call restriction service.
To set how your device uses the access codes and security settings, select Menu >
Settings > Security.
Switch on or off
Press and hold the power key.
10 Get started
