Nokia 5030 User manual

Nokia 5030 User Guide
Issue 2.1

Contents
Safety 4
Get started 6
Insert the SIM card
and battery 6
Remove the SIM
card 7
Charge the battery 7
Switch on and off 8
Your phone 10
Keys and parts 10
Main features 12
Make and answer a
call 13
Write text 14
Message 15
Contacts 16
Multi-phonebook 17
Radio 18
Turn the flashlight on
or off 20
General
information 21
Accessories 22
Battery 23
Battery and charger
information 23
Taking care of your
device 27
Recycle 28
Additional safety
information 28
Small children 28
Operating
environment 28
Medical devices 29
2Contents
© 2009 Nokia. All rights reserved.2

Vehicles 30
Potentially explosive
environments 30
Emergency calls 31
Certification
information (SAR) 32
Limited
Warranty 32
Contents 3
© 2009 Nokia. All rights reserved. 3

Safety
Read these simple guidelines. Not following them
may be dangerous or illegal. Read the complete user
guide for further information.
SWITCH ON SAFELY
Do not switch the device on when
wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your
hands free to operate the vehicle while
driving. Your first consideration while
driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect
performance.
4Safety
© 2009 Nokia. All rights reserved.4

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device
off in aircraft, near medical equipment,
fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or
repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and
batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it
dry.
Safety 5
© 2009 Nokia. All rights reserved. 5

Get started
Insert the SIM card and battery
This phone is intended for use with the BL-5C
battery.
Safe removal. Always switch the device off and
disconnect the charger before removing the battery.
1 Press the release button (1) to release the back
cover, and lift it (2). To remove the back cover,
slide it upwards (3).
2 Lift the battery, and remove it (4).
3 Insert the SIM card (5). Ensure that the gold-
coloured contact area is facing down and the
6Getstarted
© 2009 Nokia. All rights reserved.6
A

bevelled corner of the SIM card is facing the
bottom of the device.
4 Replace the battery and back cover (6, 7, 8).
Remove the SIM card
Press the release spring (1), and slide out the SIM
card (2).
Charge the battery
Your battery has been partially charged at the
factory. If the device indicates a low charge, do the
following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
Get started 7
© 2009 Nokia. All rights reserved. 7

3 When the device indicates a full charge,
disconnect the charger from the device, then
from the wall outlet.
Tip: To save energy, unplug the charger when the
battery is fully charged.
You do not need to charge the battery for a specific
length of time, and you can use the device while it
is charging. If the battery is completely discharged,
it may take several minutes before the charging
indicator appears on the display or before any calls
can be made.
Switch on and off
Press and hold the end key.
Use the phone only in its normal operating position.
8Getstarted
© 2009 Nokia. All rights reserved.8

Your device may have internal and external
antennas. Avoid touching the antenna area
unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the
communication quality and may cause a higher
power level during operation and may reduce the
battery life.
Get started 9
© 2009 Nokia. All rights reserved. 9

Your phone
Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key;
hereafter
referred to as
scroll key
5Call key
6End/Power key
7Keypad
10 Your phone
© 2009 Nokia. All rights reserved.10

8Release button
9Microphone
10 Flashlight
11 Wrist strap eyelet
12 Channel selection keys
13 FM radio key
14 Headset connector
15 Charger connector
16 Loudspeaker
Do not connect products that create an output signal
as this may cause damage to the device. Do not
connect any voltage source to the Nokia AV
Connector.
When connecting any external device or any
headset, other than those approved by Nokia for use
with this device, to the Nokia AV Connector, pay
special attention to volume levels.
Your phone 11
© 2009 Nokia. All rights reserved. 11

Main features
Select Menu and from the following:
Messages — to create, send, open, and manage
messages
Contacts — to save names and phone numbers in
the SIM card and phone memory
Call register — to access phone numbers of missed,
received, and dialled calls
Settings — to set up various features of your phone
Clock — to set the time for the alarm
Radio — to manage radio features
Reminders — to manage reminders
Games — to set up game effects, or play the games
installed in your phone
Extras — to access various applications, such as the
calculator or flashlight. Chinese lunar calendar is
also available.
SIM services — to use additional services, if
supported by your SIM card
12 Your phone
© 2009 Nokia. All rights reserved.12

Make and answer a call
Make a call
Enter the phone number, including the country code
and area code, if necessary, and press the call key.
Answer a call
Press the call key.
End or reject a call
Press the end key.
Use the loudspeaker or earpiece
During a call, select Loudsp. or Hands..
Adjust the volume
During a call, scroll left or right to adjust the volume
of the earpiece or headset.
Warning:
Continuous exposure to high volume may damage
your hearing. Listen to music at a moderate level,
and do not hold the device near your ear when the
loudspeaker is in use.
Your phone 13
© 2009 Nokia. All rights reserved. 13

Write text
Use traditional text input
Press a key repeatedly until the desired letter is
displayed.
Activate predictive text input
Select Options > Dictionary and the desired
language.
Deactivate predictive text input
Select Options > Dictionary > Dictionary off.
When using predictive text input, press each key
once for a single letter. If the desired word is
displayed, press 0, and start writing the next word.
If ? is displayed after the word, the word is not in
the dictionary.
Change a word
Press *repeatedly until the desired word is
displayed.
14 Your phone
© 2009 Nokia. All rights reserved.14

Add a word
Select Spell, enter the word using traditional text
input, and select OK.
Add a space
Press 0.
Change text input method
Press #repeatedly, and check the indicator at the
top of the display.
Add a number
Press and hold the desired number key.
Add a special character
Press *when using traditional text input; press and
hold *when using predictive text input.
Undo clearing of a message
Select Options > Undo clear.
Message
The message services can only be used if they are
supported by your service provider.
Your phone 15
© 2009 Nokia. All rights reserved. 15

Your device supports text messages beyond the limit
for a single message. Longer messages are sent as
two or more messages. Your service provider may
charge accordingly. Characters with accents, other
marks, or some language options take more space,
and limit the number of characters that can be sent
in a single message.
Write and send a message
1 Select Menu > Messages > Create message.
2 Write the message. The message length
indicator shows how many characters you can
enter in the message.
3 Select Options > Send, enter the recipient's
phone number or select it from the contacts list,
and select OK.
Delete messages
Select Menu > Messages > Delete messages > All
read or the desired folder.
Contacts
You can save names and phone numbers in the
phone and SIM card memory. The contacts list can
16 Your phone
© 2009 Nokia. All rights reserved.16

contain up to 500 contacts, stored in the phone
memory.
Search for a contact
Scroll down in the standby mode, enter the first
characters or letters of the name, and scroll to the
desired contact.
Save contacts to the contacts list
Select Menu > Contacts > Add contact.
Copy contacts between the phone and SIM card
memory
Select Menu > Contacts > Copy.
Multi-phonebook
Your phone supports up to five separate
phonebooks for multiple users. When the multi-
phonebook is activated, only the contacts in the
active phonebook are visible.
Your phone 17
© 2009 Nokia. All rights reserved. 17

A contact can belong to one or several phonebooks.
The contacts in Shared contacts are accessible from
all phonebooks.
Select Menu > Contacts > Settings > Multi-
Phonebook and the appropriate options.
Activate the multi-phonebook
Select Phonebook style > Multi-Phonebook.
Activate a phonebook
Select Current phonebook and the desired
phonebook or Shared contacts.
Assign a contact to one or more phonebooks
Select Manage contacts and the desired contact.
Rename a phonebook
Select Rename phonebooks and the desired
phonebook.
Radio
To open the radio, select Menu > Radio, or press
the FM radio key.
18 Your phone
© 2009 Nokia. All rights reserved.18

Select from the following:
Switch off — Close the radio.
Save channel — Save an active channel.
Auto tuning — Tune radio channels automatically.
To start automatic tuning, scroll up or down.
Manual tuning — Tune radio channels manually.
To change the frequency, scroll up or down.
Set frequency — Enter a desired frequency.
Delete channel — Delete a saved channel.
Rename — Rename a saved channel.
Clock radio — Manage clock radio features.
Loudspeaker or Headset — Listen to the radio
using the loudspeaker or a headset.
To adjust the volume of the radio, scroll left or right.
You may need a compatible headset for better
reception of radio signals.
Your phone 19
© 2009 Nokia. All rights reserved. 19

Warning:
Continuous exposure to high volume may damage
your hearing. Listen to music at a moderate level,
and do not hold the device near your ear when the
loudspeaker is in use.
Turn the flashlight on or off
Select Menu > Extras > Flashlight.
20 Your phone
© 2009 Nokia. All rights reserved.20
