Nokia BT FUSION 6136 User manual

Nokia 6136 User Guide
Orange Variant
6136.ENv1_Orange_4july06.fm Page 1 Tuesday, July 4, 2006 12:39 PM

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product RM-199 is
in conformity with the provisions of the following Council Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/
declaration_of_conformity/.
The crossed-out wheeled bin means that within the European Union the product
must be taken to separate collection at the product end-of-life. This applies to your
device but also to any enhancements marked with this symbol. Do not dispose of
these products as unsorted municipal waste. For more information, see product
Eco-Declaration or country specific information at www.nokia.com.
Copyright © 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2006. Tegic Communications, Inc. All rights reserved.
Nokia, Nokia Connecting People, Pop-Port, PC Suite, and the Nokia Original Enhancements
logos are trademarks or registered trademarks of Nokia Corporation. Other company or
product names mentioned herein may be trademarks or tradenames of their respective
owners.
Nokia tune is a sound mark of Nokia Corporation.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use. Additional information
including that relating to promotional, internal and commercial uses may be obtained from
MPEG LA, LLC. See <http://www.mpegla.com>.
The information contained in this user guide was written for the Nokia 6136 product. Nokia
operates a policy of continuous development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
6136.ENv1_Orange_4july06.fm Page 2 Tuesday, July 4, 2006 12:39 PM

Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
9250633/Issue 1
6136.ENv1_Orange_4july06.fm Page 3 Tuesday, July 4, 2006 12:39 PM

4
Contents
For your safety.......................... 6
1. General information............. 9
Access codes............................................ 9
Nokia support and contact
information........................................... 10
Accessibility solutions ....................... 10
Copyright protection.......................... 10
Configuration settings service ........ 10
Download content and
applications .......................................... 11
2. Get started ......................... 12
SIM card and battery installation .. 12
Charge the battery.............................. 13
Memory card installation ................. 14
Turn the phone on and off ............... 15
Open the fold ....................................... 16
Normal operating position ............... 16
Wrist strap ............................................ 17
3. Your phone......................... 18
Keys and parts...................................... 18
Your Homescreen................................ 19
Icons ....................................................... 20
Keypad lock (keyguard) ..................... 21
4. Call functions..................... 22
Make a call ........................................... 22
Speed dialling....................................... 22
Enhanced voice dialling .................... 22
Answer or reject a call....................... 23
Options during a call.......................... 23
5. Phone menus...................... 25
Menu views........................................... 25
Access a menu function.................... 25
6. Log...................................... 26
Positioning information .................... 26
7. Contacts.............................. 27
Search for a contact .......................... 27
Save names and phone numbers.... 27
Save numbers, items, or an image. 27
Copy a contact..................................... 28
Edit contact details ............................ 28
Delete contacts or details................. 28
Business cards...................................... 29
My presence ......................................... 29
Subscribed names............................... 30
Settings.................................................. 31
Groups.................................................... 31
Speed dialling....................................... 31
Service and my numbers................... 31
8. Settings............................... 33
WLAN/Wi-Fi ......................................... 33
Profiles ................................................... 37
Themes ................................................... 37
Tones....................................................... 37
Display.................................................... 38
Time and date ...................................... 39
My shortcuts ........................................ 40
Connectivity ......................................... 41
Call .......................................................... 45
Phone...................................................... 45
Enhancements ..................................... 46
Configuration....................................... 47
Security.................................................. 48
Restore factory settings.................... 49
Phone software updates ................... 49
9. Organiser ............................ 51
Alarm clock........................................... 51
Calendar ................................................ 51
To-do list ............................................... 52
Notes ...................................................... 53
Countdown timer................................ 53
Stopwatch............................................. 54
6136.ENv1_Orange_4july06.fm Page 4 Tuesday, July 4, 2006 12:39 PM

5
10.Messaging ......................... 55
Text messages....................................... 55
Write and send..................................... 57
Read and reply...................................... 57
SIM messages ....................................... 58
Multimedia messages......................... 58
Nokia Xpress audio messaging ........ 62
Instant messaging ............................... 63
E-mail application............................... 67
Voice messages .................................... 70
Info messages....................................... 70
Service commands .............................. 70
Delete messages .................................. 70
Message settings ................................. 71
11.Web ................................... 74
Technology background..................... 74
Service provider ................................... 74
Access service....................................... 74
Browse .................................................... 75
Security settings .................................. 77
Bookmarks ............................................. 77
Download settings .............................. 78
Service inbox......................................... 78
Cache memory...................................... 78
Browser security .................................. 79
12.Media ................................ 82
Camera ................................................... 82
Media player ......................................... 83
Music player.......................................... 83
Radio ....................................................... 85
Recorder................................................. 86
Equalizer ................................................ 87
Stereo widening................................... 87
13.Gallery................................ 88
Format memory card .......................... 88
14.Applications ...................... 89
Games..................................................... 89
Collection............................................... 89
15.Operator menu.................. 91
16.SIM services....................... 92
17.PC connectivity ................. 93
USB data storage................................. 93
Nokia PC Suite...................................... 93
EGPRS, GPRS, HSCSD, and CSD....... 93
Data communication applications . 93
18.Battery information.......... 94
Charging and discharging................. 94
Nokia battery authentication
guidelines............................................... 95
Care and maintenance ........... 97
Additional safety
information............................. 98
Index..................................... 102
6136.ENv1_Orange_4july06.fm Page 5 Tuesday, July 4, 2006 12:39 PM

For your safety
6
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless phones may get interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any regulations or rules. Switch the phone off near medical
equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in
aircraft.
SWITCH OFF WHEN REFUELING
Do not use the phone at a refueling point. Do not use near fuel or
chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the phone where blasting is in
progress.
USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Do not touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.
6136.ENv1_Orange_4july06.fm Page 6 Tuesday, July 4, 2006 12:39 PM

For your safety
7
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACKUP COPIES
Remember to make back-up copies or keep a written record of all
important information.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press the end key as
many times as needed to clear the display and return to the start
screen. Enter the emergency number, then press the call key. Give
your location. Do not end the call until given permission to do so.
■About your device
The wireless device described in this guide is approved for use on the EGSM 850,
900, 1800, and 1900 networks. Contact Orange for more information about
networks.
When using the features in this device, obey all laws and respect privacy and
legitimate rights of others.
When taking and using images or video clips, obey all laws and respect local
customs as well as privacy and legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the phone must be switched on. Do not switch the device on when
wireless phone use may cause interference or danger.
■Network services
To use the phone you must have service from a wireless service provider. Many of
the features in this device depend on features in the wireless network to
function. These network services may not be available on all networks or you may
have to make specific arrangements with Orange before you can utilise network
services. Orange may need to give you additional instructions for their use and
explain what charges will apply. There may be limitations that affect how you
can use network services. For instance, some networks may not support all
language-dependent characters and services.
Orange may have requested that certain features be disabled or not activated in
your device. If so, they will not appear on your device menu. Your device may also
6136.ENv1_Orange_4july06.fm Page 7 Tuesday, July 4, 2006 12:39 PM

For your safety
8
have been specially configured. This configuration may include changes in menu
names, menu order, and icons. Contact Orange for more information
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as multimedia messaging service
(MMS), browsing, e-mail application, instant messaging, remote synchronisation,
and content downloading using the browser or MMS, require network support for
these technologies.
■Shared memory
The following features in this device may share memory: the Gallery, contacts,
text messages, multimedia messages, e-mail, calendar, to-do notes, and JavaTM
games and applications. Use of one or more of these features may reduce the
memory available for the remaining features sharing memory. For example,
saving many Javaapplications may use all of the available memory. Your device
may display a message that the memory is full when you try to use a shared
memory feature. In this case, delete some of the information or entries stored in
the shared memory features before continuing. Some of the features, such as text
messages, may have a certain amount of memory specially allotted to them in
addition to the memory shared with other features.
6136.ENv1_Orange_4july06.fm Page 8 Tuesday, July 4, 2006 12:39 PM

General information
9
1. General information
Congratulations on your purchase of this Nokia mobile phone. Some of its other
features include a calendar, a clock, an alarm clock, a radio, a music player, and a
built-in camera.
■Access codes
Security code
The security code (5 to 10 digits) helps to protect your phone against
unauthorised use. The preset code is 12345. To change the code, and to set the
phone to request the code, see ”Security,” p. 48.
If you enter an incorrect security code five times in succession, the phone ignores
further entries of the code. Wait for five minutes, and enter the code again.
PIN codes
The personal identification number (PIN) code and the universal personal
identification number (UPIN) code (four to eight digits) help to protect your SIM
card against unauthorised use. See ”Security,” p. 48. The PIN code is usually
supplied with the SIM card. To set the phone to request the PIN code, see
”Security,” p. 48.
The PIN2 code (four to eight digits) may be supplied with the SIM card and is
required for some functions.
The module PIN is required to access the information in the security module. See
”Security module,” p. 79. The module PIN is supplied with the SIM card if the SIM
card has a security module in it.
The signing PIN is required for the digital signature. See ”Digital signature,” p. 80.
The signing PIN is supplied with the SIM card if the SIM card has a security
module in it.
PUK codes
The personal unblocking key (PUK) code and the universal personal unblocking
key (UPUK) code (eight digits) is required to change a blocked PIN code and UPIN
code, respectively. The PUK2 code is required to change a blocked PIN2 code.
6136.ENv1_Orange_4july06.fm Page 9 Tuesday, July 4, 2006 12:39 PM

General information
10
If the codes are not supplied with the SIM card, contact Orange for the codes.
Call restrictions password
The call restrictions password (four digits) is required when using Call
restrictions. See ”Security,” p. 48. You can obtain the password from Orange.
If you enter an incorrect call restrictions password three times in succession, the
password is blocked. Contact Orange for assistance.
■Nokia support and contact information
Check www.nokia.com/support for the latest version of this guide, additional
information, downloads, and services related to your Nokia product.
On the Web site, you can get information on the use of Nokia products and
services. If you need to contact customer service, check the list of local Nokia
Care contact centres at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia Care services location at
www.nokia.com/repair.
■Accessibility solutions
Nokia is committed to making mobile phones easy to use for all individuals,
including those with disabilities. For more information, visit the web site at
www.nokiaaccessibility.com.
■Copyright protection
Copyright protections may prevent some images, ringing tones, and other
content from being copied, modified, transferred, or forwarded.
■Configuration settings service
To use some of the network services, such as mobile Internet services, MMS, or
remote Internet server synchronisation, your phone needs the correct
configuration settings. You may be able to receive the settings directly as a
configuration message. After receiving the settings, you need to save them on
your phone. Orange may provide a PIN that is needed to save the settings. For
more information on availability of the settings, contact Orange.
When you have received a configuration message, Configuration sett. received
is displayed.
6136.ENv1_Orange_4july06.fm Page 10 Tuesday, July 4, 2006 12:39 PM

General information
11
To save the settings, select Show >Save. If the phone requests Enter settings'
PIN:, enter the PIN code for the settings, and select OK. To receive the PIN code,
contact Orange. If no settings are saved yet, these settings are saved and set as
default configuration settings. Otherwise, the phone asks, Activate saved
configuration settings?
To discard the received settings, select Show > Discard.
To edit the settings, see ”Configuration,” p. 47.
■Download content and applications
You may be able to download content, such as themes, tones, and video clips, to
the phone (network service). Select the download function (for example, in the
Gallery menu). To access the download function, see the respective menu
descriptions.
You may also be able to download updates of phone software (network service).
See ”Phone software updates,” p. 49.
For availability of different services, pricing, and tariffs, contact Orange.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
6136.ENv1_Orange_4july06.fm Page 11 Tuesday, July 4, 2006 12:39 PM

Get started
12
2. Get started
■SIM card and battery installation
Keep all SIM cards out of the reach of small children. For availability and
information on using SIM card services, contact Orange. Before installing the
SIM card and removing the battery, always switch the device off, and disconnect
the charger.
The SIM card and its contacts can easily be damaged by scratches or bending, so
be careful when handling, inserting, or removing the card.
Always switch off the power, and disconnect the charger and any other device
before removing the cover. Avoid touching electronic components while
changing the cover. Always store and use the device with the cover attached.
To install the SIM card, do the following:
1. Press firmly and slide the top of the back cover
to release it; then continue sliding the back
cover to remove and lift it from the phone.
2. After you have removed the back cover, insert
your finger under the battery, and lift it as
shown.
3. Place a fingernail in the middle of the metal
SIM card holder. Then, unlatch and swing the
SIM card holder open.
4. Insert the SIM card into the holder as shown,
beveled corner first, with the gold-coloured
contacts on the SIM card face up (away from
the phone).
2
3
45
6136.ENv1_Orange_4july06.fm Page 12 Tuesday, July 4, 2006 12:39 PM

Get started
13
5. Swing the SIM card holder closed. The gold-coloured contacts on the SIM
card meet the gold-coloured contacts on the inside of the phone. Gently
press the SIM card holder into the phone until it clicks into place.
6. Replace the battery by positioning it (with the
label side facing up) so the gold-coloured
contacts match up with those on the phone.
Slide the battery in until it snaps into place.
7. Slide the back cover until it locks into place.
■Charge the battery
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
This device is intended for use with the BL-4C battery. Always use original Nokia
batteries. See ”Nokia battery authentication guidelines,”p. 95.
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from the AC-4 charger.
For availability of approved enhancements, please check with your dealer.
1. Connect the charger to a standard
wall outlet.
2. Insert the charger plug into the
round jack in the bottom of the
phone. If the battery is completely
discharged, it may take a few
minutes before the charging
indicator appears on the display or
before any calls can be made.
6
7
6136.ENv1_Orange_4july06.fm Page 13 Tuesday, July 4, 2006 12:39 PM

Get started
14
3. Disconnect the charger from the phone when the battery is fully charged.
You can use the phone while the charger is connected. The charging time
depends on the charger and the battery used. For example, charging a BL-4C
battery with the AC-4 charger takes approximately 1 hour and 10 minutes while
the phone is in the standby mode.
■Memory card installation
Use only compatible microSD cards with this device.
Other memory cards do not fit in the memory card slot
and are not compatible with this device. Using an
incompatible memory card may damage the memory card
as well as the device, and data stored on the incompatible
card may be corrupted.
Use only microSD cards approved by Nokia for use with this device. Nokia utilises
the approved industry standards for memory cards but not all other brands may
function correctly or be fully compatible with this device.
You can use a memory card to extend the memory of the Gallery. See ”Gallery,”
p. 88. You can insert or change the memory card without turning the phone off.
Important: Do not remove the memory card in the middle of an
operation when the card is being accessed. Removing the card in the
middle of an operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
To insert the memory card, use a fingernail as a lever, place it in the recessed area
of the memory card holder and swing the holder open (1). Place the memory card
in the card holder (2). Make sure that the memory card is properly inserted and
6136.ENv1_Orange_4july06.fm Page 14 Tuesday, July 4, 2006 12:39 PM

Get started
15
that the gold-coloured contacts on the card are facing upwards. Close the
memory card holder (3).
You can use the memory card to save your multimedia files, such as video clips,
sound files, and images, in the Gallery.
To remove the memory card, use a fingernail as a lever, place it in the recessed
area of the memory card holder and swing the holder open. Push with a fingernail
to loosen the memory card from the holder; then, pull the card out. Close the
memory card holder.
To format the memory card, see ”Format memory card,” p. 88.
■Turn the phone on and off
Press and hold the end key until the
phone turns on or off. If the phone asks
for a PIN, enter the code, and select OK.
Plug and play service
When you turn on your phone for the first time, and the phone is in the
Homescreen mode, you may be asked to get the configuration settings from your
service provider (network service). Confirm or decline the query. See Connect to
service provider support in ”Configuration,” p. 47 and ”Configuration settings
service,” p. 10.
6136.ENv1_Orange_4july06.fm Page 15 Tuesday, July 4, 2006 12:39 PM

Get started
16
■Open the fold
When you open the fold of the
phone, it opens up to approximately
155 degrees. Do not try to force the
fold open more.
■Normal operating
position
Use the phone only in its normal operating
position.
6136.ENv1_Orange_4july06.fm Page 16 Tuesday, July 4, 2006 12:39 PM

Get started
17
Your device has an internal antenna.
Note: As with any other radio transmitting device, do not touch the
antenna unnecessarily when the device is switched on. Contact with
the antenna affects call quality and may cause the device to operate at
a higher power level than otherwise needed. Avoiding contact with the
antenna area when operating the device optimises the antenna
performance and the battery life.
■Wrist strap
Remove the back cover from the phone
and thread the wrist strap as shown in
the picture.
6136.ENv1_Orange_4july06.fm Page 17 Tuesday, July 4, 2006 12:39 PM

Your phone
18
3. Your phone
■Keys and parts
• Earpiece (1)
• Main display (2)
• Call key (3)
• Left, middle, and right selection keys (4)
• Four-way navigation key (5)
• End key ends calls (short key press) and turns
phone on and off (long key press) (6)
• Keypad (7)
• Camera lens (8)
• Mini display (9)
• Loudspeaker (10)
• Camera release key (11)
• Memory card holder (12)
• Pop-Port connectorTM (13)
• Charger connector (14)
• Infrared (IR) port (15)
6136.ENv1_Orange_4july06.fm Page 18 Tuesday, July 4, 2006 12:39 PM

Your phone
19
• Volume is activated by volume down/up key (short key press), and voice
dialling is activated by volume down key (long key press) (16)
■Your Homescreen
When you turn on your phone, the first screen
that appears is the start screen, which indicates
your phone is in the Homescreen. When your
phone is in the Homescreen, the selection keys
access specific functions, and the indicators
appear on the start screen. Indicators show the
status of the phone.
• Network signal strength (1)
• Battery strength indicator (2)
• Clock (3) — if the time is set to appear on the
display. See ”Time and date,” in ”Settings,” p.
39.
• The Orange name or logo (4)
• Calendar (5) — the date is displayed if it is set to appear on the display See
”Time and date,” p. 39.
• The left selection key (7) is Go to or a shortcut to another function. See ”Left
selection key,” p. 40.
• The middle selection key (8) mode is Menu.
• The right selection key (9) may be Names to access the list of contacts in the
Contacts menu, an Orange specific name to access an Orange Web site, or a
shortcut to a function that you selected. See ”Right selection key,” p. 40.
Homescreen shortcuts
To access the list of dialled numbers, press the call key once. See ”Make a call,” p.
22.
To call Orange Answer Phone, press and hold 1.
To connect to Orange World, press and hold 0.
To set shortcut functions for the navigation key, see Navigation key in ”My
shortcuts,” p. 40.
6136.ENv1_Orange_4july06.fm Page 19 Tuesday, July 4, 2006 12:39 PM

Your phone
20
To make a call by pressing a number key with an assigned phone number, see
”Speed dialling,” p. 22.
To toggle between the Normal profile to the Silent profile, press and hold #.
Power saving screen saver
To save power, a digital clock screen saver overwrites the display when no
function of the phone has been used for a certain period of time. See ”Power
saver,” in ”Main display,” p. 38 or ”Power saver,” in ”Mini display,” p. 39 for
information on activating the power screen saver.
■Icons
Icons are graphical representations of a specific item or situation. The following
list describes each icon.
You have unread messages in the Inbox folder.
You have unsent, cancelled, or failed messages in the Outbox folder.
The phone registered a missed call.
You have received one or several instant messages, and you are
connected to the instant messaging service.
The keypad is locked.
The alarm clock is set to On.
The phone does not ring for an incoming call or text message.
The countdown timer is running.
The stopwatch is running in the background.
/The phone is registered to the GPRS or EGPRS network.
/A GPRS or EGPRS connection is established.
/The GPRS or EGPRS connection is suspended (on hold), for example, if
there is an incoming or outgoing call during an EGPRS or GPRS dial-up
connection.
When the infrared connection is activated, the indicator is shown
continuously.
